Delta Amplon MX Series User manual

www.deltapowersolutions.com
Delta UPS - Amplon Family
User Manual
The power behind competitiveness
MX Series, Single Phase
1.1/ 2/ 3 kVA

II
Amplon MX Series
Save This Manual
This manual contains important instructions and warnings that you should
follow during the installation, operation, storage and maintenance of this
product. Failure to heed these instructions and warnings will void the warranty.
Copyright © 2019 by Delta Electronics Inc. All Rights Reserved. All rights of this
User Manual (“Manual”), including but not limited to the contents, information,
and figures are solely owned and reserved by Delta Electronics Inc. (“Delta”).
The Manual can only be applied to the operation or the use of this product. Any
disposition, duplication, dissemination, reproduction, modification, translation,
extraction, or usage of this Manual in whole or in part is prohibited without the prior
written permission of Delta. Given that Delta will continuously improve and develop
the product, changes may be made to the information in this Manual at any time
without obligation to notify any person of such revision or changes. Delta will make
all possible efforts to secure the accuracy and the integrity of this Manual. Delta
disclaims any kinds or forms of warranty, guarantee, or undertaking, either expressly
or implicitly, including but not limited to the completeness, faultlessness, accuracy,
non-infringement, merchantability or tness for a particular purpose of the Manual.

Table of Contents
III
Table of Contents
Chapter 1 : Important Safety Warnings------------------------------- 1
1.1 Transportation ---------------------------------------------------- 1
1.2 Preparation-------------------------------------------------------- 1
1.3 Installation--------------------------------------------------------- 1
1.4 Operation ---------------------------------------------------------- 2
1.5 Maintenance, Service and Faults --------------------------- 2
1.6 Packing List ------------------------------------------------------- 4
Chapter 2 : Installation and Setup ------------------------------------- 6
2.1 Rear Panel View------------------------------------------------- 6
2.2 Operating principle ---------------------------------------------- 8
2.3 Install The UPS -------------------------------------------------- 8
2.4 Setup the UPS --------------------------------------------------10
2.5 Battery Replacement ------------------------------------------13
2.6 Battery Kit Assembly (option)--------------------------------15
Chapter 3 : Operation -----------------------------------------------------17
3.1 Button Operation -----------------------------------------------17
3.2 LCD Panel--------------------------------------------------------18
3.3 Audible Alarm----------------------------------------------------20
3.4 LCD Display Wordings Index--------------------------------20
3.5 UPS Setting------------------------------------------------------22
3.6 Operating Mode Description---------------------------------27
3.7 Faults Reference Code ---------------------------------------29
3.8 Warning Indicator-----------------------------------------------29
Chapter 4 : Troubleshooting --------------------------------------------31
Chapter 5 : Storage and Maintenance -------------------------------33
Chapter 6 : Technical Specications ---------------------------------34
Chapter 7 : Warranty-------------------------------------------------------36

1
Amplon MX Series
Chapter 1 : Important Safety Warnings
Please comply with all warnings and operating instructions in this manual strictly.
Save this manual properly and read carefully the following instructions before
installing the unit. Do not operate this unit before reading through all safety
information and operating instructions carefully
1.1 Transportation
z
zPlease transport the UPS system only in the original package to protect against
shock and impact.
1.2 Preparation
z
zCondensation may occur if the UPS system is moved directly from cold to warm
environment. The UPS system must be absolutely dry before being installed.
Please allow at least two hours for the UPS system to acclimate the environ-
ment.
z
zDo not install the UPS system near water or in moist environments.
z
zDo not install the UPS system where it would be exposed to direct sunlight or
near heater.
z
zDo not block ventilation holes in the UPS housing.
1.3 Installation
z
zDo not connect appliances or devices which would overload the UPS system (e.g.
laser printers) to the UPS output sockets.
z
zPlace cables in such a way that no one can step on or trip over them.
z
zDo not connect domestic appliances such as hair dryers to the UPS output sockets.
z
zThe UPS can be operated by any individuals with no previous experience.
z
zConnect the UPS system only to an earthed shockproof outlet which must be
easily accessible and close to the UPS system.
z
zPlease use only VDE-tested, CE-marked mains cable (e.g. the mains cable of
your computer) to connect the UPS system to the building wiring outlet (shock-
proof outlet).

Chapter 1 Important Safety Warnings
2
z
zPlease use only VDE-tested, CE-marked power cables to connect the loads to
the UPS system.
z
zWhen installing the equipment, it should ensure that the sum of the leakage cur-
rent of the UPS and the connected devices does not exceed 3.5mA.
z
zTemperature Rating - Units are considered acceptable for use in a maximum
ambient of 40°C (104°F).
z
zFor PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the
equipment and shall be easily accessible.
z
zCaution:The unit is heavy. Lifting the unit requires a minimum of two people.
1.4 Operation
z
zDo not disconnect the mains cable on the UPS system or the building wiring
outlet (shockproof socket outlet) during operations since this would cancel the
protective earthing of the UPS system and of all connected loads.
z
zThe UPS system features its own, internal current source (batteries). The UPS
output sockets or output terminals block may be electrically live even if the UPS
system is not connected to the building wiring outlet.
z
z In order to fully disconnect the UPS system, rst press the OFF/ ENTER button
to disconnect the mains.
z
z Prevent no uids or other foreign objects from inside of the UPS system.
z
zThe REPO and USB circuits are an IEC 60950-1 safety extra low voltage (SELV)
circuit. This circuit must be separated from any hazardous voltage circuits by re-
inforced insulation.
1.5 Maintenance, Service and Faults
z
zThe UPS system operates with hazardous voltages. Repairs may be carried out
only by qualied maintenance personnel.
z
zCaution - risk of electric shock. Even after the unit is disconnected from the
mains (building wiring outlet), components inside the UPS system are still con-
nected to the battery and electrically live and dangerous. Before carrying out
any kind of service and/ or maintenance, disconnect the batteries and verify that
no current is present and no hazardous voltage exists in the terminals of high
capability capacitor such as BUS-capacitors.

3
Amplon MX Series
z
zTo avoid electrical shock, turn off the unit and unplug it form the AC power
source before servicing the battery
z
zOnly persons are adequately familiar with batteries and with the required pre-
cautionary measures may replace batteries and supervise operations. Unauthor-
ized persons must be kept well away from the batteries.
z
zCaution - risk of electric shock. The battery circuit is not isolated from the input
voltage. Hazardous voltages may occur between the battery terminals and the
ground. Before touching, please verify that no voltage is present!
z
zBatteries may cause electric shock and have a high short-circuit current. Please
take the precautionary measures specied below and any other measures nec-
essary when working with batteries:
- remove wristwatches, rings and other metal objects
- use only tools with insulated grips and handles.
z
zWhen changing batteries, install the same number and same type of batteries.
z
zDo not attempt to dispose of batteries by burning them. This could cause battery
explosion.
z
z Do not open or destroy batteries. Escaping electrolyte can cause injury to the
skin and eyes. It may be toxic.
z
zA battery can may cause a risk of electrical shock and high short-circuit current.
The following precautions should be observed when working on batteries:
a)Remove watches, rings, or other metal objects. b)Use tools with insulated
handles.c)Wear rubber gloves and boots.
d)Do not lay tools or metal parts on top of batteries.
e)Disconnect charging source prior to connecting or disconnecting battery
terminals.
f)Determine if battery is inadvertently grounded. If inadvertently grounded,
remove source from ground. Contact with any part of a grounded battery can
result in electrical shock. The likelihood of such shock can be reduced if such
grounds are removed during installation and maintenance.
z
zWhen replacing batteries, use the same type and number of batteries or battery
packs.
z
zDo not dismantle the UPS system.
z
zThis is a category C1 UPS product.

Chapter 1 Important Safety Warnings
4
1.6 Packing List
For models UPA112M2MX0B035(1.1 kVA), UPA202M2MX0B035(2kVA),
UPA302M2MX0B035(3kVA)
12
3
4
57
6
Test report
No. Item Q’ty
1UPS 1 PC
2Input cable (Schuko) 1 PC
3USB cable 1 PC
4User manual 1 PC
5Tower stand with screws 4 PCS
6Ear kit with screws 2 PCS
7Test report 1 PC

5
Amplon MX Series
For models UPA112M2MX0B0BB(1.1 kVA), UPA202M2MX0B0BB(2kVA) ,
UPA302M2MX0B0BB(3kVA)
12
3
4
57
6
Test report
No. Item Q’ty
1UPS 1 PC
2Input cable (AU) 1 PC
3USB cable 1 PC
4User manual 1 PC
5Tower stand with screws 4 PCS
6Ear kit with screws 2 PCS
7Test report 1 PC

Chapter 2 Installation and Setup
6
2.1 Rear Panel View
z
zStandard Runtime Model
MX-1.1K
MX-2K
MX-3K
65
65
65
8
7
4
311 10
8
7
4
3
1
2
1
2
11
9
9
8
7
4
3
1
11 2
Chapter 2 : Installation and Setup

7
Amplon MX Series
No. Item
1Programmable outlets: connect to non-critical loads.
2Output receptacles: connect to mission-critical loads.
3AC input
4Network/Fax/Modem surge protection
5Emergency power off function connector (REPO)
6USB communication port
7RS-232 communication port
8Mini Slot
9Input circuit breaker
10 Fuse
11 Ground screw

Chapter 2 Installation and Setup
8
2.2 Operating principle
The operating principle of the UPS is shown as below
2.3 Install The UPS
For safety consideration, the UPS is shipped out from factory without connecting
battery wires. Before install the UPS, please follow below steps to re-connect bat-
tery wires rst.
Step 1 Step 2 Step 3
Remove front panel. Disconnect battery wires. Pull out the battery box
by removing two screws
on the front panel.
EMI/ RFI
Filters
Battery
Charger Battery
DC- to- DC
Converter
Inverter
AVR
TX
Output
The UPS is composed of
mains input, EMI/RFI Filters,
Inverter, Battery charger,
DC-to-DC converter, battery,
AVR TX and UPS output

9
Amplon MX Series
Rack-mount Installation
Tower Installation
Step 1
Step 2 Step 3
CAUTION :
Do NOT use the mounting brackets to lift the unit. The mounting brackets
are only for securing the unit to the rack.

Chapter 2 Installation and Setup
10
2.4 Setup the UPS
Step 1: UPS input connection
Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using
extension cords.
z
zThe power cord is attached to the UPS. For the type of power cord, please refer
to the table below.
UPS Type of Power Cord
1.1kVA Plug 10A Schuko or AU
2kVA Plug 16A Schuko or AU
3kVA Plug 16A Schuko or AU
Step 2: UPS output connection
There two kinds of outputs: programmable outlets and general outlets. Please
connect non-critical devices to the programmable outlets and critical devices to the
general outlets. During power failure, you may extend the backup time to critical
devices by setting shorter backup time for non-critical devices.
Step 3: Communication connection
RS-232
MINI SLOT
USB port
RS-232 port
Mini slot

11
Amplon MX Series
To allow for unattended UPS shutdown/start-up and status monitoring, connect
one end of communication cable to the USB/RS-232 port and the other to the
communication port of your PC. With the monitoring software installed, you can
schedule UPS shutdown/start-up and monitor UPS status through PC.
The UPS is equipped with mini slot perfect for either mini SNMP, mini relay I/O card
and mini modbus card. When installing either mini SNMP, mini relay I/O card or mini
modbus card in the UPS, it will provide advanced communication and monitoring
options.
Step 4: Network connection
Network/Fax/Phone surge Protection port
Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back
panel of the UPS unit. Connect from “OUT” outlet to the equipment with another
modem/fax/phone line cable.
Step 5: Disable and enable REPO function
This UPS is equipped with REPO function. By default, the UPS is delivered from
factory with Pin 1 and Pin 2 closed (a metal plate is connected to Pin 1 and Pin 2)
for UPS normal operation. To activate REPO function, remove two screws on REPO
port and green connector will be removed.
NOTE :
The REPO function logic can be set up via LCD setting. Please refer to
program 7 in UPS setting for the details.
To activate REPO function,
remove these two screws.
It’s in closed status for
UPS normal operation as default.

Chapter 2 Installation and Setup
12
Step 6: Turn on the UPS
Press the ON/Mute button on the front panel for two seconds to power on the UPS.
NOTE : The battery charges fully during the first five hours of normal
operation. Do not expect full battery run capability during this initial charge
period.
Step7: Install software
For optimal computer system protection, install UPS monitoring software to fully
configure UPS shutdown. Use RS-232 or USB communication cable to connect
RS-232/USB port of UPS and RS-232/USB port of PC. Then, follow steps below to
download and install monitoring software:
1. Please visit below website to download the software :
http://www.deltapowersolutions.com/en/mcis/software-center.php
UPSentry: RS232/ USB
InfraSuite Device Master: SNMP/Modbus card
2. Follow the on-screen instructions to install the software.

13
Amplon MX Series
2.5 Battery Replacement
When the icons of and are ashing in LCD display and alarm is sounding
every 2 seconds, it’s time to replace batteries. Contact your service representative
to replace batteries.
Batteries can be replaced easily without turning the UPS off or disconnecting the
load. If you prefer to remove input power to change the batteries, press the OFF
button on the front panel for two seconds to power off the UPS and switch off utility
power where the UPS is connected.
NOTE1 : DO NOT DISCONNECT the batteries while the UPS is in Battery
mode.
NOTE2 : A small amount of arcing may occur when connecting the internal
batteries. This is normal condition and no harm for personnel. Connect the
cables quickly and rmly.
NOTE3 : This UPS is equipped with internal batteries and only service
person can replace the batteries.
NOTE4 : Upon battery disconnection, equipment is not protected from
power outages.
CAUTION!! Consider all warnings, cautions, and notes before replacing
batteries.

Chapter 2 Installation and Setup
14
Step 1 Step 2 Step 3
Remove front panel. Disconnect battery wires. Pull out the battery box
by removing two screws
on the front panel.
Step 4 Step 5 Step 6
Remove the top cover of
battery box and replace
the inside batteries.
After replacing the bat-
teries, put the battery
box back to original loca-
tion and screw it tightly.
Re-connect the battery
wires.
Step 7
Put the front panel back
to the unit.

15
Amplon MX Series
2.6 Battery Kit Assembly (option)
NOTE : Please assemble battery kit rst before installing it inside of UPS.
Please select correct battery kit procedure below to assemble it.
2-battery kit
Step 1 Step 2
Remove adhesive tapes. Connect all battery terminals by follow-
ing below chart. .
Step 3 Step 4
Put assembled battery packs on one
side of plastic shells and insert one
more defect battery on the space.
Cover the other side of plastic shell as
below chart. Then, battery kit is assem-
bly well.
4-battery kit
Step 1 Step 2
Remove adhesive tapes Connect all battery terminals by follow-
ing below chart.
Tapes
Tapes
Tapes

Chapter 2 Installation and Setup
16
Step 3 Step 4
Put assembled battery packs on one
side of plastic shells.
Cover the other side of plastic shell as
below chart. Then, battery kit is assem-
bly well.
6-battery kit
Step 1 Step 2
Remove adhesive tapes. Connect all battery terminals by follow-
ing below chart.
Step 3 Step 4
Put assembled battery packs on one
side of plastic shells.
Cover the other side of plastic shell as
below chart. Then, battery kit is assem-
bly well.
Tapes
Tapes

17
Amplon MX Series
Chapter 3 : Operation
3.1 Button Operation
Button Function
ON/ MUTE
Button
z
z Turn on the UPS: Press and hold ON/Mute button for at least 2
seconds to turn on the UPS.
z
zMute the alarm: After the UPS is turned on in battery mode,
press and hold this button for at least 3 seconds to disable or
enable the alarm system. But it’s not applied to the situations
when warnings or errors occur.
z
zUp key: Press this button to display previous selection in UPS
setting mode.
z
zSwitch to UPS self-test mode: Press and hold ON/Mute button
for 3 seconds to enter UPS self-testing while in AC mode
OFF/ ENTER
Button
z
zTurn off the UPS: Press and hold this button at least 2 seconds
to turn off the UPS
z
zConrm selection key: Press this button to conrm selection in
UPS setting mode.
SELECT
Button
z
zSwitch LCD message: Press this button to change the LCD
message for input voltage, input frequency, battery voltage,
battery capacity, ambient temperature, output voltage, output
frequency, load current and load percent.
z
zSetting mode: Press and hold this button for 3 seconds to enter
UPS setting mode when UPS is off.
z
zDown key: Press this button to display next selection in UPS
setting mode.
