USER MANUAL
MANUEL BATTERY CHARGERS
BC 2425
BC 2440
BC 2460
BC 24100

1. PRECAUTIONS TO BE CONSIDERED BEFORE USING THE BATTERY CHARGER AND
SAFETY PRECAUTIONS
-Supply your protective equipment.
-Use work shoes.
-A good ventilation is required for battery charging. The battery and charger can become hot.
-Fire extinguishers and materials must always be present in the work environment to ensure
safety against fire. Combustible materials, gasoline, oil, thinner etc. materials should be kept
away from the welding place.
-Do not operate the rectifier during rainy weather (open air). Disconnect the power supply.
Failure to do so may result in electric shocks.
2. PREPARATION AND INSTALLATION OF THE BATTERY CHARGER
-Mains Connection
Charger is operated with 220 V single-phase mains voltage.
Your machine has a power input cable that is located at the back panel.
-Always connect the input cable of the machine to a grounded outlet.
-Use proper fuse or circuit breakers for the charger.
For models of BC 2425, BC 2440, BC 2460 and BC 24100, a 16 A rated C type circuit breaker
must be used at input.
3. TECHNICAL SPECIFICATIONS
-Suitable for charging lead acid batteries: WET serviceable and maintenance free.
-Short circuits protection
-Inversions of polarity protection
-Short circuits on the clamps protection
BC 2425
BC 2440
BC 2460
BC 24100
Input Voltage
1 Phase, 220 V 50 Hz.
1 Phase, 220 V 50 Hz.
1 Phase, 220 V 50 Hz.
1 Phase, 220 V 50 Hz.
Required Input Fuse
C Type 16 A
C Type 16 A
C Type 16 A
C Type 16 A
Charge Voltage Steps
6 V - 12 V - 24 V
6 V - 12 V - 24 V
6 V - 12 V - 24 V
6 V - 12 V - 24 V
Maximum Charge Current
25 A
40 A
60 A
100 A
Current Steps
3 Steps
3 Steps
3 Steps
3 Steps
Battery Type
Lead Acid
Lead Acid
Lead Acid
Lead Acid
Battery Capacity
up to 180 Ah
up to 250 Ah
up to 350 Ah
up to 600 Ah
Diemensions (w/d/h) (cm)
39 x 40 x 40
39 x 40 x 40
40 x 45 x 40
45 x 65 x 45
Weight
17.6 kgs
24 kgs
34 kg
55 kgs
4. USE OF THE CHARGER
-The combinations of series/parallel connections are shown below.

-You can charge your batteries in various groups by turning the rectifier's fine and coarse
adjustment switches to the positions indicated in the table below.
Position of Fine
Adjustment Switch
Position of Coarse
Adjustment Switch
Battery Capacity
Target
Voltage
1
6 V
6 V battery
7.2 V
1
12 V
2 pcs of 6 V battery in series or 12 V battery
15.5 V
1
24 V
2 pcs of 12 V battery in series or 24 V battery
31.0 V
-Connect positive (+) pole of the battery to the positive output of the charger and connect the
negative (-) pole accordingly.
-Lift the input and output fuses on the front panel and turn on the charger. After that, you can
observe that the signal bulb on the front panel of the rectifier is lit.
-For BC 2425,
-You will see values on the digital voltage and current display on the front panel of the
rectifier. The recommended maximum charging current for this rectifier is between 17 A and
22 A. This value is important for the life of your battery and the charger.
-Maximum battery size to charge is 180 Ah.
-If you cannot observe a value between 17 A and 22 A when you set the fine-tuning switch to
first position, you can increase the charging current by turning the fine-tuning switch.
-For BC 2440,
-You will see values on the digital voltage and current display on the front panel of the
rectifier. The recommended maximum charging current for this rectifier is between 30 A and
35 A. This value is important for the life of your battery and the charger.
-Maximum battery size to charge is 250 Ah.
-If you cannot observe a value between 30 A and 35 A when you set the fine-tuning switch to
first position, you can increase the charging current by turning the fine-tuning switch.
-For BC 2460,
-You will see values on the digital voltage and current display on the front panel of the
rectifier. The recommended maximum charging current for this rectifier is between 50 A and
55 A. This value is important for the life of your battery and the charger.
-Maximum battery size to charge is 350 Ah.
-If you cannot observe a value between 50 A and 55 A when you set the fine-tuning switch to
first position, you can increase the charging current by turning the fine-tuning switch.
-For BC 24100,
-You will see values on the digital voltage and current display on the front panel of the
rectifier. The recommended maximum charging current for this rectifier is between 85 A and
95 A. This value is important for the life of your battery and the charger.
-Maximum battery size to charge is 600 Ah.
-If you cannot observe a value between 85 A and 95 A when you set the fine-tuning switch to
first position, you can increase the charging current by turning the fine-tuning switch.
-To switch off the charger, lower the output fuse and remove the mains power connection.
-Observe charging every one hour. When the value in the digital voltmeter reaches your
target value, the batteries are charged. During this time, the charging current will be reduced
to 2 to 4 A.

5. MAINTENANCE
-The electrical connection must be disconnected before starting the machine maintenance.
-Periodic inspection and preventive maintenance guarantees the safe, proper operation and
long service life of the device.
-A complete inspection is carried out in our factory immediately after production before the
first run.
-The first service maintenance must be carried out 6 months after the start of use. Then,
according to the power and operating environment of the device, 6 or 12 month
maintenance period should be done.
-If the operating conditions of the device are difficult, maintenance should be done in shorter
periods.
6. GENERAL MAINTENANCE WORK
-All ports and cables are reviewed. Protective parts and connections are carefully controlled.
(Tightening of screws, cracks, poles)
-All moving and working mechanical components are checked to see if they are fulfilling their
functions.
-If necessary, clean the windings with a soft cloth or compressor air.
-Never use abrasives to clean the windings, which may cause arc or permanent damage.
7. BASIC FAULTS AND FIXES
Problem
Possible Cause
Action
Voltage or current do not
change when the tap
switches are turned.
Coarse or fine adjustment
breaker switch fault
Disconnect power from the
machine and call for service
The rectifier shows the
charging current but the
batteries do not charge.
Batteries are defective
Have the battery checked
Output connections are
broken
Clean the pole heads.
Clean the tongs or replace
them with a new one.
Display shows incorrect values
Disconnect power from the
machine and call for service
