Denon Professional DN-300C MKII User manual

DN-300C MKII
User Guide English ( 2 – 14 )
Guía del usuario Español ( 15 – 27 )
Guide d’utilisation Français ( 28 – 39 )
Guida per l’uso Italiano ( 40 – 52 )
Benutzerhandbuch Deutsch ( 53 – 65 )
A
ppendix English ( 66 – 67 )

2
User Guide (English)
Introduction
Box Contents Support
DN-300C MKII
Power Cable
Remote Control
RCA Cable
User Guide
Safety & Warranty Manual
For the latest information about this product
(documentation, technical specifications, system
requirements, compatibility information, etc.) and
product registration, visit denonpro.com.
Safety Instructions
Please also see the included Safety & Warranty Manual for more information.
Before turning the power
on:
Make sure all connections are secure and correct and that there are no
problems with the connection cables.
Power is supplied to some of the circuitry even when the unit is powered off.
When the unit will not be used for long periods of time, disconnect the power
cable from the power outlet.
Proper ventilation: If the unit is left in a room which is not properly ventilated or is full of smoke
from cigarettes, dust, etc. for long periods of time, the surface of the optical
pickup may get dirty, causing incorrect operation.
A
bout condensation: If there is a major difference in temperature between the inside of the unit and
the surroundings, condensation may form inside the unit, causing the unit not
to operate properly. If this happens, let the unit sit for an hour or two while
powered off, and wait until there is little difference in temperature before using
the unit.
Cautions on using mobile
phones:
Using a mobile phone near this unit may cause noise. If this occurs, move the
mobile phone away from this unit when it is in use.
Moving the unit: Before moving the unit, turn off its power and disconnect the power cable from
the power outlet. Next, disconnect its connection cables from other devices
before moving it.
A
bout care: Wipe the cabinet and control panel clean with a soft cloth.
Follow the instructions when using a chemical cleaner.
Do not use benzene, paint thinner, insecticide, or other organic solvents to
clean the unit. These materials can cause material changes and discoloration.
Rackmount warnings:
(required rack specifications
for mounting the unit in a
rack)
EIA standard 19-inch (48.3cm) rack
1U-size installation compatible rack
Rack that has a guide rail or shelf board that can support this device
Rack installation: This product will work normally when the player unit
is mounted within 10° off the vertical plane at the
front panel. If the unit is tilted excessively, the disc
may not load or unload properly. (See image.)
Unit
Maximum
10°

3
Features
Front Panel
1. Power Button: Press this button to turn the unit on or off. Make sure the AC In is properly connected to a power outlet. Do
not turn the unit off during media playback—doing so could damage your media.
2. Aux In: Connect an optional device to this input using a 1/8” (3.5mm) TRS cable. See Operation >Playing Audio from an
External Device for more information.
3. USB Port: Connect a mass-storage-class USB device to this port.
4. CD Slot: Insert a CD into this slot. See Operation >Playing Audio CDs for more information.
5. Source: Press this to enter Media Selection screen. See Operation >Selecting Media Playback Mode for more information.
6. Repeat Button: In CD or USB Mode, press this button to switch between Repeat Playback modes: Repeat One , Repeat
All , Repeat FLD (folder), and Repeat Off. See Operation >Playing Audio CDs for more information.
Power-On Play Button: Press and hold this button to turn Power-On Play on or off. See Operation >Additional Functions
>Power-On Play for more information.
7. Random Button: In CD or USB Mode, press this button to cycle through Random FLD/Random Play Mode , Single Play
Mode S, and Normal Play Mode.
8. Text Button: In CD or USB Mode, press this button to switch the display between the file name and other text information.
Lock Button : Press and hold this button to turn Panel Lock on and off. See Operation >Additional Functions >Panel
Lock for more information.
9. Time Button: In CD or USB Mode, press this button to switch the Time Mode in the display. See Operation >Playing Audio
CDs for more information. Folder Button: Press and hold this button to select a folder.
10. Eject Button: Press this to eject the CD in the CD slot. To force-eject a CD, power off the unit, then press and hold the eject
button while powering the unit back on. To exit force-eject mode, turn the unit off.
11. Display: This screen indicates the unit’s current operation. See Display for more information.
12. Remote Sensor: Point the remote control at this sensor when operating it. See Remote Control >Operating Range for
more information.
Note: If the remote sensor is exposed to direct sunlight, strong artificial light (like from an interverter-type fluorescent lamp),
or infrared light, the unit or remote control may not function properly.
13. Search Buttons: In CD or USB Mode, press and hold one of these buttons to rewind/fast-forward. The track will rewind/fast-
forward at 5times the normal playback speed.
14. Stop Button: Press this button to stop playback. To view current firmware version, hold the stop button while powering on
the unit.
15. Play/Pause Button: Press this button to start, resume, or pause playback.
16. Number Buttons (0–9):In CD Mode, Press one of these buttons to directly select a track to play. If the track number is two
digits, press the buttons in succession (e.g., 1then 2for Track 12). See Operation >Playing Audio CDs for more
information.
17. Jog Dial: Turn this dial to browse the options shown in the display. Press this dial to confirm a selection. In CD and USB
mode this is used to browse and select tracks.
18. Tempo Control: In CD or USB Mode, turn the knob to adjust the tempo of the audio playback in a range from -15% to
+15%. Press the knob to turn Tempo Lock on and prevent changes to the tempo setting. Press the knob again to turn off
Tempo Lock.
12
3
568
10 11 16
12 13 14 15
17
479
18

4
Display
1. Media Type: This is the currently selected media: CD, USB,
or Aux. See Operation >Selecting Media Playback Mode
for more information.
2. Playback Operation Icon: This shows various symbols to
indicate the current playback status:
Playing Rewinding
Paused Fast-Forwarding
Stopped
3. Information: This shows extra information about the media
being played.
TRK Elapsed: Time Elapsed
TRK Remain: Time Remaining
DISC Elapsed: Total Time Elapsed (for CD Mode only)
DISC Remain: Total Time Remaining (for CD Mode only)
4. Track/File Number: This is the number of the track or file.
5. Function Icons: This shows various symbols to indicate these current functions:
6. Time: In CD and USB Mode, this is how much time has elapsed or is remaining, shown as hh:mm:ss (hours,
minutes, and seconds).
See Operation >Playing Audio CDs for more information.
7. Folder View
Panel Lock (see Operation >Additional Functions >Panel Lock for more information)
Random Playback (see Operation > Playing Audio CDs or more information)
Repeat One (see Operation > Playing Audio CDs for more information)
Repeat All (see Operation > Playing Aud
i
o CDs for more information)
Power-On Play (see Operation > Additional Functions > Powe
r
-On Play for more
information)
123
56
47

5
Rear Panel
1. Outputs (unbalanced RCA):These outputs send the audio signals from a CD, USB device (mass storage class),
and device connected to the Aux In. Use RCA cables to connect these outputs to external speakers, sound
system, etc. See Setup for more information.
2. Outputs (balanced XLR):These outputs send the audio signals from a CD, USB device (mass storage class),
and device connected to the Aux In. Use XLR cables to connect these outputs to external speakers, sound
system, etc. See Setup for more information.
3. AC In: Use the included power cable to connect this input to a power outlet. See Setup for more information.
Remote Control
1. Mute: Disables the sound from the audio outputs.
2. Tempo Menu: Press to select the tempo function for adjustment.
Note: Tempo control will only function in CD and USB modes.
3. Tempo Lock: Press the knob to turn Tempo Lock on and prevent
changes to the tempo setting.
4. USB: Switch to USB Mode.
5. AUX: Switch to Aux Mode.
6. CD: Switch to CD Mode.
7. Play: Plays audio from a CD or USB flash drive.
8. Pause: Pause audio from a CD or USB flash drive.
9. Stop: Stops audio from a CD or USB flash drive.
10. Eject: Ejects or inserts a CD.
11. Search Backward: Hold to rewind through a CD or USB track.
12. Search Forward: Hold to fast forward through a CD or USB track.
13. Skip Back: Press to skip to the previous track or chapter.
14. Skip Forward: Press to skip to the next track or chapter.
15. Random: Press to cycle through Random FLD/Random Play Mode or
Single Play Mode () in CD or USB mode.
16. Display: Press and release the button to adjust the display brightness.
Press and hold the button to open the options menu. Hold the button
again to close the option menu.
17. Tempo Up: Adjust the tempo up.
18. Tempo Down: Adjust the tempo down.
19. Repeat: In CD or USB mode, switch between Repeat Playback modes:
Repeat One , Repeat All , and Repeat Off.
20. Time: In CD or USB Mode, press this button to switch the time in the display from Time Elapsed,
Time Remaining, Total Elapsed Time, or Total Time Remaining (for CD Mode only).
21. Text/Lock: In CD or USB Mode, press to switch the display between the track name and artist
name. Press and hold to turn Panel Lock on and off.
DN-300C MK
123
PAUSE
EJECT
PLAY
AUX CD
MUTE TEMPO
TEMPO
LOCK
TEMPO
STOP
USB
RANDOM
DISPLAY
TIME
REPEAT
TEXT
LOCK
DN-300C MK

6
DN-300C MK
ZONE 2
SOURCE ZONE 3 ZONE 3 SOURCE STATUS DIMMER
VIDEO
AUX 1
SETUP MIC
INTEGRATEDNETWORK AV RECEIVER
SSEERI
AVR-X4000
IN-Command
L - AUDIO - R
1 CBL/SAT 3 GAME 4 NETWORK
QUICK SELECT
2 Blu-ray
PHONES BACK
ENTER
INFO
SETUP
ZONE 2
SOURCE SELECT
MASTER VOLUME
ON/OFF
AUX 1
HDMI 7 5V/1A
ON/OFF OPTION
Setup
Important: Connect all cables securely and properly (with stereo cables: left with left, right with right), and
do not bundle them with the power cable.
1. Use XLR cables or a stereo RCA cable to connect the Outputs (balanced or unbalanced) to the
analog inputs of your external receiver, amp, powered monitors, etc.
2. After completing all the connections, use the included power cable to connect the AC In to a power
outlet.
Example:
Receiver, amp, etc. Power
Powered Monitors

7
Operation
Selecting the Media Playback Mode
To select what kind of media you want to play:
To cycle through the available options, press the Source button.
•CD: audio CD, CD-DA, CD-ROM, or MP3 CD with audio files (CDR) (see Playing Audio CDs)
•USB: USB device (mass storage class). (see Playing Audio Files on a USB Drive)
•Aux: device connected to Aux In.(see Playing Audio from an External Device)
Playing Audio CDs
To play audio CDs:
1. If the unit is off, press the Power button to power it on.
Important: Do not insert a CD when the power is off. Doing so may damage the unit.
2. Insert a CD into the CD slot. (Hold the edges of the CD without touching the recorded surface. Be careful not to
trap your fingers when the disc is drawn into the unit.)
3. Select CD as the media type (described in Selecting the Media Playback Mode).
The CD will start playing automatically when Power-On Play mode is active.
In CD Mode, you can perform any of the following operations:
•To start, resume, or pause playback, press the Play/Pause button.
•To stop playback, press the Stop button.
•To rewind or fast-forward through the track, press and hold one of the Search buttons. The track will
rewind/fast-forward at 5times the normal playback speed. To resume playback, release the button.
•To skip directly to a track:
1. Press one of the Number buttons (0–9) to enter the desired track number. If the track number is two digits,
press the buttons in succession (e.g., 1then 2for Track 12). Alternatively, turn the Jog Dial to select a track
and press the Jog Dial to load the track.
•To select a Repeat Playback mode, press the Repeat button. It will cycle through Repeat One (the same track
will repeat indefinitely), Repeat All (the list of all tracks will repeat indefinitely), Repeat FLD (tracks in the
selected folder will repeat indefinitely), and Repeat Off (no tracks will repeat).
•To select the Play Mode, press the Random button. It will cycle through Random FLD (all tracks in the
selected folder will play back in random order), Random All (all tracks on the CD will play back in a random
order), Single Play (the current track will play until its end and then stop), and Normal (the CD will play from the
current track to the end and then stop).
•To change the Time Mode in the display, press the Time button. It will cycle through the TRK Elapsed (E):
how much time has elapsed of the current track. TRK Remaining (R):how much time remains of the current
track. Disc Elapsed: how much time elapses of all remaining tracks. This applies only to CDs. Disc Remain:
how much time remains of all remaining tracks. This applies only to CDs.
•To eject a CD, press the Eject button when the unit is stopped or paused. Ejecting will appear in the display
while ejecting the CD. No Disc will appear when there is no disc in the CD slot.
Important: Please see Other Information >CDs to learn more about the types of CDs the DN-300C MKII supports
and for more information about CD handling and care. When powering on the unit, hold the Eject button to engage
Force Eject Mode.

8
Playing MP3 Files on a CD
To play MP3 files on a CD:
1. If the unit is off, press the Power button to power it on.
Important: Do not insert a CD when the power is off. Doing so may damage the unit.
2. Do one of the following:
•Insert a CD into the CD slot. (Hold the edges of the CD without touching the recorded surface. Be careful not
to trap your fingers when the disc is drawn into the unit.)
3. Select CD as your desired media type: (described in Selecting the Media Playback Mode).
4. Select an audio file:
•To move through audio files, turn the Jog Dial on the unit.
•To enter a folder, press and hold the Folder/Time button for 3 seconds and turn the Jog Dial to select a
folder. Press the Jog Dial to enter the folder and scroll with the dial to find a track. Press the dial again to
select a track and press the Play/Pause button to play the track.
Note: If a track is not selected after a few seconds of entering a folder, the unit will exit the folder and return
back to the previously selected track/folder.
In CD Mode, you can perform any of the following operations:
•To start, resume, or pause playback, press the Play/Pause button.
•To stop playback, press the Stop button.
•To rewind or fast-forward through the track, press and hold one of the Search buttons. The track will
rewind/fast-forward at 5times the normal playback speed. To resume playback, release the button.
•To select a Repeat Playback mode, press the Repeat button. It will cycle through Repeat One (the same track
will repeat indefinitely), Repeat All (the list of all tracks will repeat indefinitely), Repeat FLD (tracks in the
selected folder will repeat indefinitely), and Repeat Off (no tracks will repeat).
•To select the Play Mode, press the Random button. It will cycle through Random FLD (all tracks in the
selected folder will play back in random order), Random All (all tracks on the CD will play back in a random
order), Single Play (the current track will play until its end and then stop), and Normal (the CD will play from the
current track to the end and then stop).
•To change the Time Mode in the display, press the Time button. It will cycle through Elapsed (E) (how much
time has elapsed of the current track) Remaining (R) (how much time remains of the current track), and Total
Remaining (how much time remains for the total audio CD).
•To eject a CD, press the Eject button. Ejecting will appear in the display while ejecting the CD. No Disc will
appear when there is no disc in the CD slot.

9
Playing Audio Files on a USB Flash Drive
To play audio files on a USB flash drive:
1. If the unit is off, press the Power button to power it on.
2. Connect your USB device (mass storage class) to the USB Port.
3. Select USB as your desired media type (described in Selecting the Media Playback Mode).
4. Select an audio file:
•To move through audio files, turn the Jog Dial on the unit.
•To enter a folder, press and hold the Folder/Time button for 3 seconds and turn the Jog Dial to select a
folder. Press the Jog Dial to enter the folder and scroll with the dial to find a track. Press the dial again to
select a track and press the Play/Pause button to play the track.
Note: If a track is not selected after a few seconds of entering a folder, the unit will exit the folder and return
back to the previously selected track/folder.
In USB Mode, you can perform any of the following operations:
•To start, resume, or pause playback, press the Play/Pause button.
•To stop playback, press the Stop button.
•To rewind or fast-forward through the track, press and hold one of the Search buttons. The track will
rewind/fast-forward at 5times the normal playback speed. To resume playback, release the button.
•To change the view mode, press the Folder/Time button.
•To select another folder or audio file, follow the steps described in Step 4 above.
•To show different track information in the display, press the Text button. It will cycle through the file name and
other text information.
•To select a Repeat Playback mode, press the Repeat button. It will cycle through Repeat One (the same track
will repeat indefinitely), Repeat All (the list of all tracks will repeat indefinitely), Repeat FLD (tracks in the selected
folder will repeat indefinitely), and Repeat Off (no tracks will repeat).
•To change the Time Mode in the display, press the Time button. It will cycle through Elapsed (E) (how much
time has elapsed of the current track) and Remaining (R) (how much time remains of the current track).
•To remove a USB device, gently remove it from the USB Port when it is not playing. (Removing a USB device
while it is playing can damage it.)
Playing Audio from an External Device
To play audio on an external device (e.g., smartphone, computer, portable music player, etc.)connected to
the Aux In:
1. If the unit is off, press the Power button to power it on.
2. Connect the 1/8” (3.5 mm) stereo/headphone output of your external device to the Aux In.
3. Select Aux as the media type (described in Selecting the Media Playback Mode). If your external device is
connected, AUX Connected will appear in the display. If your external device is not connected, AUX
Disconnect will appear in the display.
4. To start playback, press the Play button on your external device.
Important: All buttons except for Power, Source, and Eject will be locked/disabled when you are in AUX Mode.

10
Additional Functions
Panel Lock
Use the Panel Lock feature to prevent accidental changes to the unit. When Panel Lock is activated, all buttons
except for the Power button and Text/Lock button are locked/disabled on the unit. (The remote control will still
function normally.)
To activate or deactivate Panel Lock, press and hold the Text/Lock button.
•When activated, P-Lock ON and will appear in the display.
•When deactivated, P-Lock OFF will appear in the display, and will disappear.
Power-On Play
Use the Power-On Play feature to set the unit to automatically start playback of the CD in the drive.
To activate or deactivate Power-On Play, press and hold the Pwr On Play button.
•When activated, P-OnPlay On will appear on the display.
•When deactivated, P-OnPlay Off will disappear on the display.

11
Other Information
CDs
When playing audio CDs, note the following:
•DN-300C MKII can play Music CDs and CD-R discs. Both are usually marked with
the Compact Disc Digital Audio logo (see image).
•Do not play discs in non-circular shapes (heart-shaped discs, octagonal discs, etc.;
see image) or discs that have been repaired with adhesive or tape. These can
damage the unit.
•DN-300C MKII can play finalized discs only. (Finalization is the process that makes
recorded CD-R discs playable on compatible players.)
•Depending on the software used to burn a CD (or other conditions), some CDs may
not play correctly.
When playing CDs with audio files, note the following:
•The writing software format must be ISO9660 Level 1.
•You can have up to 300 folders and up to 8folder levels, including the root directory.
•You can have up to 300 audio files. If the CD contains more than 300 files, some audio files may not play or
appear correctly.
•File names, folder names, and text characters can use up to 255 characters. Only uppercase letters, lowercase
letters, numbers, and symbols can be displayed. Japanese file names will not be shown. File names that begin
with a “.” will not be shown.
•Copyright-protected files might not play properly and/or may appear as Unknown File.
•Depending on the software used to burn a CD (or other conditions), some files may not play or appear correctly.
•When playing audio files on a CD, DN-300C MKII supports the following tag data:
oID3 tags: Version 1.x and 2.x
oMETA-tags: compatible with title, artist, and album names
oSample rate: 44.1 kHz
oBit rate: 32 kbps to 320 kbps
oFormat: MPEG1 Audio Layer 3
oFile extension: .mp3
Be careful not to scratch discs when removing them from their cases. Do not bend or heat discs,
and do not enlarge the hole in the center of the disc. Do not write on the labeled surface of the
disc or attach new labels to discs.
If fingerprints, dirt, or condensation are on a disc, clean it with a commercially available disc
cleaning set or a soft, dry cloth. Gently wipe it from the inside towards the outside, not in a circular
motion. Do not use record spray, antistatic agents, benzene, thinner, or other solvents.
After using discs, remove them from the unit and store them in their cases to protect them from
dust, scratches, warping, etc. Do not store discs in places exposed to long periods of direct
sunlight or places exposed to heat, dust, humidity, etc.

12
USB Devices
When playing audio files on a USB device, note the following:
•DN-300C MKII does not charge any connected USB device and does not support USB hubs or USB extension
cables.
•DN-300C MKII supports USB devices that are mass storage class or compatible with MTP.
•DN-300C MKII supports FAT16 or FAT32 file systems only.
•You can have up to 999 folders and up to 8folder levels, including the root directory.
•You can have up to 999 audio files. If the USB device contains more than 999 files, some audio files may not play
or appear correctly.
•File names, folder names, and text characters can use up to 255 characters. Only uppercase letters, lowercase
letters, numbers, and symbols can be displayed. Japanese file names will not be shown. File names that begin
with a “.” will not be shown.
•Copyright-protected files might not play properly and/or may appear as Unknown File.
When playing audio files on a USB device, DN-300C MKII supports the following tag data:
•ID3 tags: Version 1.x and 2.x
•for MP3 files:
oSample rate: 44.1 kHz
oBit rate: 32 kbps to 320 kbps
oFormat: MPEG1 Audio Layer 3
oFile extension: .mp3
Audio File Playback Order
When playing audio files stored within multiple folders, the playback order of each folder is automatically set when
the unit reads the media. The files in each folder will play in the same order in which they were added to the media.
(This order may appear differently on your computer and/or in your software than it does on the unit.)
The folder structure also determines the playback order:
oFor audio files on a CD-R, files in all folders on the first level will play, then files in all folders on the second level,
then on the third level, and so on.
oFor audio files on a USB device, files in the first folder on the first level will play, then files on the second level in
that same folder, then files on the third level in that same folder, and so on. After playing all files on all levels of
that first folder, the same process will continue for files in the second folder on the first level.

13
Troubleshooting
If you encounter a problem, do the following:
•Make sure all cables, devices, antennae, and/or media are properly and securely connected.
•Make sure you are using the unit as described in this User Guide.
•Make sure your other devices or media are working properly.
•If you believe the unit is not working properly, check the following table for your problem and solution.
Problem Solution Please see:
Power does not turn on. Make sure the unit is connected to a
power outlet.
Setup
CD cannot be inserted into
CD slot.
Make sure the unit is connected to a
power outlet and that it is powered on.
Press the Eject button to make sure a CD
is not already in the CD slot.
Setup
No Disc appears even when
a CD is inserted.
Press the Eject button to eject the CD
and insert it again.
A specific section of the CD
does not play properly.
Playback does not start even
after pressing the Play
button.
Clean the CD with a dry cloth or
commercial CD cleaner.
Insert a different CD.
Other Information >CDs
The unit does not produce
any sound, or the sound is
distorted.
Make sure all cable, device, or media
connections are secure and correct.
Make sure none of the cables are
damaged.
Make sure the settings on your amplifier,
mixer, etc. are correct.
Setup
The unit cannot play a CD-R. Make sure the CD-R has been finalized
properly.
Make sure the CD-R is of good quality.
Clean the CD with a dry cloth or
commercial CD cleaner.
Make sure the CD uses a folder structure
that the unit supports: up to 300 folders
(up to 8folder levels, including the root)
and up to 300 files.
Make sure the CD-R contains MP3 files.
The unit cannot play other files on CD-R.
Other Information >CDs
The CD will not eject. Press and hold the Eject button while
turning on the unit.

14
Problem Solution Please see:
No Device appears even
when a USB device is
inserted.
Disconnect and reconnect the USB
device to make sure it is securely
inserted.
Make sure the USB device is of a mass
storage class or compatible with MTP.
Make sure the USB device is formatted
using a FAT16 or FAT32 file system.
Do not use a USB hub or USB extention
cable.
The unit does not supply power to USB
devices. If your USB device requires a
power source, connect it to one.
Not all USB devices are guaranteed to
work; some may not be recognized.
Other Information >USB
Devices
Files on a USB device do not
appear.
Make sure the files are of a supported file
format. Files that are not supported by
this unit will not appear.
Make sure the USB device uses a folder
structure that the unit supports: up to 999
folders (up to 8folder levels, including the
root) and up to 999 files.
If your USB device is partitioned, make
sure the files are in the first partition. The
unit will not show other partitions.
Other Information >USB
Devices
Files on a USB device
cannot play.
Make sure the files are of a supported file
format. Files that are not supported by
this unit will not appear.
Make sure the files are not copyright-
protected. The unit cannot play copyright-
protected files.
Other Information >USB
Devices
File names do not appear
properly.
Make sure the files are using only
supported characters. Characters that are
not supported will be replaced with a “.”
Other Information >USB
Devices

15
Guía del usuario (Español)
Introducción
Contenido de la caja Soporte
DN-300C MKII
Cable de corriente
Control remoto
Cable RCA
Guía del usuario
Manual sobre la seguridad
y garantía
Para obtener la información más reciente acerca de
este producto (requisitos de sistema, información de
compatibilidad, etc.) y registrarlo, visite
denonpro.com.
Instrucciones de seguridad
Para más información, consulte también el Manual de seguridad y garantía incluido.
A
ntes de encender la
unidad:
A
segúrese de que todas las conexiones estén aseguradas y correctas y que no
haya problemas con los cables de conexión.
A
lgunos circuitos permanecen alimentados aun cuando la unidad está
apagada. Cuando la unidad no se utilizará durante largos períodos de tiempo,
desconecte el cable de corriente de la toma de corriente.
V
entilación apropiada: Si la unidad se deja en una sala que no está ventilada apropiadamente o está
llena de humo de cigarrillos, polvo, etc., durante largos períodos de tiempo, la
superficie óptica puede ensuciarse, causando un funcionamiento incorrecto.
A
cerca de la condensación: Si existe una gran diferencia de temperatura entre el interior de la unidad y los
alrededores, puede acumularse condensación en el interior, haciendo que la
unidad no funcione correctamente. Si esto ocurriera, deje la unidad apagada
durante una o dos horas y espere hasta que haya una menor diferencia de
temperatura antes de utilizar la unidad.
Precauciones sobre el uso
de teléfonos móviles:
Utilizar un teléfono móvil cerca de esta unidad puede ocasionar ruido. Si esto
ocurriera, aleje el teléfono móvil de la unidad cuando lo esté utilizando.
Cómo mover la unidad:
A
ntes de mover la unidad, apáguela y desconecte el cable de corriente de la
toma de corriente. A continuación, desconecte sus cables de conexión con
otros dispositivos antes de moverlo.
Cómo cuidar la unidad: Limpie el gabinete y el panel de control con un paño suave.
Siga las instrucciones cuando utilice un limpiador químico.
No utilice benceno, diluyente de pintura, insecticidas u otros solventes
orgánicos para limpiar la unidad. Estas sustancias pueden causar cambios y
decoloración en los materiales.
A
dvertencias para el
montaje en rack:
(especificaciones para rack
requeridas para montar la
unidad en un rack)
Rack EIA estándar de 19 pulg. (48,3 cm)
Rack compatible con instalación de tamaño 1U
Rack que posee un riel guía o estante capaz de acomodar este dispositivo
Instalación del rack: Este producto funcionará normalmente cuando la
unidad de reproducción se monte a menos de 10°
respecto del plano vertical del panel frontal. Si la
unidad se inclina demasiado, puede que el disco no
se inserte o expulse correctamente. (Consulte la
imagen).
Unidad
Máximo de 10°

16
Características
Panel frontal
1. Botón de encendido: Pulse este botón para encender o apagar la unidad. Asegúrese de que la entrada AC In esté
conectada firmemente a la toma de corriente. No apague la unidad mientras esté reproduciendo medios—esto podría
dañarlos.
2. Entrada auxiliar: Conecte un dispositivo opcional a esta entrada utilizando un cable TRS de 3,5 mm (1/8 pulg.).
3. Puerto USB: Conecte un dispositivo USB de almacenamiento masivo a este puerto. Consulte Funcionamiento >
Reproducción de archivos de audio para mayor información.
4. Ranura para CD: Inserte un CD en esta ranura. Consulte Funcionamiento >Reproducción de CD de audio para mayor
información.
5. Fuente: Púlselo para entrar en la pantalla de selección de medios. Consulte Funcionamiento >Selección del modo de
reproducción de medios para mayor información.
6. Botón de repetición: En modo CD o USB, pulse este botón para alternar entre los modos de repetición de reproducción:
repetir uno , repetir todos , repetir carpeta, o repetición desactivada . Consulte Funcionamiento >Reproducción
de CD de audio para mayor información.
Botón de reproducción al encender: Mantenga pulsado este botón para encender o apagar la reproducción al encender.
Consulte Funcionamiento >Funciones adicionales >Reproducción al encender para mayor información.
7. Botón Play Mode (Modo de reproducción): Estando en modo CD o USB, pulse este botón para alternar entre el Aleatorio
FLD/modo de reproducción aleatoria , el modo de reproducción individual Sy el modo de reproducción normal.
8. Botón de texto: En modo CD o USB, pulse este botón para alternar entre el nombre del archivo y la otra información en
formato de texto a mostrar en la pantalla.
Botón de bloqueo : Mantenga pulsado este botón para activar o desactivar el bloqueo del panel. Consulte
Funcionamiento >Funciones adicionales >Bloqueo del panel para mayor información.
9. Botón de tiempo: En modo CD o USB, pulse este botón para alternar el modo de tiempo en la pantalla. Consulte
Funcionamiento >Reproducción de CD de audio para mayor información. Botón Folder (Carpeta):Mantenga pulsado
este botón para seleccionar una carpeta.
10. Botón de expulsión: Púlselo para expulsar el CD de la ranura de CD. Para expulsar un CD a la fuerza, apague la unidad y
luego mantenga pulsado el botón de expulsión mientras vuelve a encender la unidad. Para salir del modo de expulsión
forzada, apague la unidad.
11. Pantalla: Esta pantalla indica el funcionamiento actual de la unidad. Para más información, consulte Pantalla.
12. Sensor remoto: Apunte el control remoto hacia este sensor al utilizarlo. Consulte Control remoto >Alcance de
funcionamiento para mayor información.
Nota: Si el sensor del control remoto se expone a luz solar directa, luz artificial intensa (como una lámpara fluorescente de tipo
invertido) o luz infrarroja, puede que la unidad o el control remoto no funcionen correctamente.
13. Botones de búsqueda: En modo CD o USB, mantenga pulsado este botón para rebobinar/avanzar rápidamente. La pista se
rebobinará/avanzará rápidamente a 5veces la velocidad de reproducción normal.
14. Botón Parar: Pulse este botón para detener la reproducción. Para ver la versión actual del firmware, mantenga pulsado el
botón Stop (Parar) mientras enciende la unidad.
15. Botón Reproducir/Pausa: Pulse este botón para iniciar, reanudar o poner en pausa la reproducción.
16. Botones numéricos (0–9):En modo CD, pulse alguno de estos botones directamente para seleccionar una pista a
reproducir Si el número de la pista es de dos dígitos, pulse los botones en sucesión (por ej., 1 y después 2 para la pista 12).
Consulte Funcionamiento >Reproducción de CD de audio para mayor información.
17. Tecla giratoria: Gire esta tecla para navegar por las opciones que se muestran en la pantalla. Pulse esta tecla giratoria para
confirmar una selección. En los modos CD y USB, éste se utiliza para explorar y seleccionar pistas.
18. Control de tempo: En modo CD o USB, gire esta perilla para ajustar el tempo de la reproducción de audio en un rango
desde -15 a +15 %. Pulse la perilla para activar el bloqueo del tempo e impedir que se ajuste el tempo. Pulse la perilla
nuevamente para desactivar el bloqueo del tempo.
12
3
568
10 11 16
12 13 14 15
17
479
18

17
Pantalla
1. Tipo de medio: Es el medio actualmente seleccionado: CD, USB, o Aux.
Consulte Funcionamiento >Selección del modo de reproducción de
medios para mayor información.
2. Ícono de operación de reproducción: Muestra diversos símbolos para indicar
el estado de reproducción actual:
Reproduciendo Rebobinando
En pausa Avanzando rápidamente
Detenido
3. Información: Muestra información adicional sobre el medio que se está reproduciendo.
TRK Elapsed: Tiempo transcurrido
TRK Remain: Tiempo restante
DISC Elapsed: Tiempo total restante (sólo para modo de CD)
DISC Remain: Tiempo total restante (sólo para modo de CD)
4. Número de pista/carpeta: El número de la pista o archivo.
5. Íconos de función: Muestran diversos símbolos que indican las funciones actuales:
Reproducción aleatoria (consulte Funcionamiento > Reproducción de CD de audio para mayor información)
Repetir uno (consulte Funcionamiento > Reproducción de CD de audio para mayor información)
Repetir todos (consulte Funcionamiento > Reproducción de CD de audio para mayor información)
Reproducción al encender (consulte Funcionamiento > Funciones adicionales > Reproducción al encender
para mayor información)
6. Time (Tiempo):En modo CD y USB, este botón muestra en la pantalla el tiempo transcurrido o restante, expresado en
el formato hh:mm:ss (horas, minutos y segundos).
Consulte Funcionamiento >Reproducción de CD de audio para mayor información.
7. Ver carpetas
Bloqueo del panel (consulte Funcionamiento >Funciones adicionales >Bloqueo del panel para mayor
información)
Panel trasero
1. Salidas (RCA desbalanceadas):Estas salidas envían las señales de audio desde un CD, dispositivo USB (de
almacenamiento masivo) y dispositivo conectado a la entrada auxiliar Aux In. Utilice cables RCA para conectar a estas
salidas altavoces externos, un sistema de sonido, etc. Consulte Instalación para mayor información.
2. Salidas (XLR balanceadas):Estas salidas envían las señales de audio desde un CD, dispositivo USB (de almacenamiento
masivo) y dispositivo conectado a la entrada auxiliar Aux In. Utilice cables XLR para conectar a estas salidas altavoces
externos, un sistema de sonido, etc. Consulte Instalación para mayor información.
3. Entrada AC In (Corriente alterna):Utilice el cable de corriente incluido para conectar esta entrada a una toma de
corriente. Consulte Instalación para mayor información.
DN-300C MK
123
123
56
47

18
Control remoto
1. Silenciar: Desactiva el sonido que sale por las salidas de audio.
2. Tempo Menu (Menú de tempo): Pulse a fin de seleccionar la función de tempo
para ajuste.
Nota: Los controle de tempo sólo funcionarán en los modos CD y USB.
3. Bloqueo del Tempo: Pulse la perilla para activar el bloqueo del tempo e impedir
que se ajuste el tempo.
4. USB: Pasa a modo USB.
5. AUX: Pasa a modo AUX.
6. CD: Pasa a modo CD.
7. Play (Reproducir): Reproduce audio desde un CD o unidad de memoria USB.
8. Pause (Pausa): Pone en pausa el audio de un CD o unidad de memoria USB.
9. Stop (Detener): Detiene el audio de un CD o dispositivo de memoria USB.
10. Eject (Expulsar): Expulsa o inserta un CD.
11. Search Backward (Búsqueda hacia atrás): Manténgalo pulsado para rebobinar
la pista de un CD o USB.
12. Search Forward (Búsqueda hacia adelante): Manténgalo pulsado para avanzar
rápidamente por la pista de un CD o USB.
13. Buscar hacia atrás: Pulse para saltar a la pista o capítulo anterior.
14. Saltar hacia adelante: Pulse uno de estos botones para saltar a la pista o
capítulo siguiente.
15. Random (Aleatorio): Pulse este botón para alternar entre el Aleatorio FLD/modo
de reproducción aleatoria o el modo de reproducción individual () en modo CD
o USB.
16. Pantalla: Pulse y suelte el botón para ajustar el brillo de la pantalla. Mantenga
pulsado este botón para abrir el menú de opciones. Mantenga pulsado el botón
nuevamente para cerrar el menú de opciones.
17. Tempo Up (Subir tempo): Ajusta el tempo hacia arriba.
18. Tempo Down (Bajar tempo): Ajusta el tempo hacia abajo.
19. Repeat (Repetición): En modo CD o USB, alterna entre los modos de repetición de reproducción: Repetir uno,
repetir todos, o repetición desactivada.
20. Time (Tiempo): En modo CD o USB, pulse este botón para alternar el tiempo que se muestra en la pantalla
entre el tiempo transcurrido, el tiempo restante, total transcurrido tiempo, o el tiempo restante total (sólo para
modo CD).
21. Text/Lock (Texto/Bloqueo): En modo CD o USB, pulse este botón para alternar entre el nombre del archivo y el
nombre de la pista en la pantalla. Mantenga pulsado este botón para activar o desactivar el bloqueo del panel.
PAUSE
EJECT
PLAY
AUX CD
MUTE TEMPO
TEMPO
LOCK
TEMPO
STOP
USB
RANDOM
DISPLAY
TIME
REPEAT
TEXT
LOCK
DN-300C MK

19
DN-300C MK
ZONE 2
SOURCE ZONE 3 ZONE 3 SOURCE STATUS DIMMER
VIDEO
AUX 1
SETUP MIC
INTEGRATEDNETWORK AV RECEIVER
SSEERI
AVR-X4000
IN-Command
L - AUDIO - R
1 CBL/SAT 3 GAME 4 NETWORK
QUICK SELECT
2 Blu-ray
PHONES BACK
ENTER
INFO
SETUP
ZONE 2
SOURCE SELECT
MASTER VOLUME
ON/OFF
AUX 1
HDMI 7 5V/1A
ON/OFF OPTION
Instalación
Importante: Conecte todos los cables firme y correctamente (los cables estéreo: izquierdo con izquierdo, derecho con
derecho) y no los agrupe junto con el cable de corriente.
1. Utilice cables XLR o un cable RCA estéreo para conectar las salidas (balanceadas o desbalanceadas) a las entradas
analógicas de su receptor externo, amplificador, monitores alimentados, etc.
2. Una vez completadas todas las conexiones, utilice el cable de corriente incluido para conectar la entrada AC In a una
toma de corriente.
Ejemplo:
Funcionamiento
Selección del modo de reproducción de medios
Cómo seleccionar el tipo de medio que desea reproducir:
Para alternar entre las opciones disponibles, pulse el Fuente.
•CD: CD de audio, CD-DA, CD-ROM, MP3 CD, o CD con archivos de audio (CDR) (consulte Reproducción de CD
de audio)
•USB: Dispositivo USB, (de almacenamiento masivo) (consulte Reproducción de archivos de audio en una unidad
de memoria USB)
•Aux: dispositivo conectado a la entrada Aux In (consulte Reproducción de audio desde un dispositivo externo)
Receptor, amplificador, etc. Corriente
Monitores alimentados

20
Reproducción de CD de audio
Como reproducir un CD de audio:
1. Si la unidad está apagada, pulse el botón Power (Encendido) para encenderla.
Importante: No inserte un CD cuando la unidad esté apagada. Esto podría dañar la unidad.
2. Inserte un CD en la ranura de CD. (Sostenga el CD por los bordes sin tocar la superficie grabada. Tenga cuidado de que sus
dedos no queden atrapados cuando el disco se inserta en la unidad).
3. Seleccione CD como el tipo de medio (descrito en Selección del modo de reproducción de medios).
El CD comenzará a reproducirse automáticamente cuando el modo de reproducción al encender esté activado.
En modo CD, puede efectuar cualquiera de las siguientes operaciones:
•Para comenzar, reanudar o poner en pausa la reproducción, pulse el botón Play/Pause (Reproducir/poner en pausa).
•Para detener la reproducción, pulse el botón Stop (Detener).
•Para rebobinar o avanzar rápidamente por la pista, mantenga pulsado alguno de los botones Search (Buscar). La pista
se rebobinará/avanzará rápidamente a 5veces la velocidad de reproducción normal. Para reanudar la reproducción, suelte el
botón.
•Para saltar directamente a una pista:
Pulse uno de los botones numéricos (0–9) para introducir el número de la pista deseada. Si el número de la pista es de dos
dígitos, pulse los botones en sucesión (por ej., 1 y después 2 para la pista 12). Como alternativa, gire la tecla giratoria para
seleccionar una pista y luego pulse dicha tecla para cargarla.
•Para seleccionar un modo de repetición de reproducción, pulse el botón Repeat. Alternará entre repetir uno (la
misma pista se repetirá indefinidamente), repetir todos (la lista de todas las pistas se repetirá indefinidamente), repetir
FLD (l as pistas en la carpeta seleccionada se repetirán de forma indefinida), y repetición desactivada (no se repetirá
ninguna pista).
•Para seleccionar el modo de reproducción, pulse el botón Random. Realizará un ciclo por Random FLD (todas las pistas
de la carpeta seleccionada se reproducirán en orden aleatorio), Random All (todas las pistas del CD se reproducirán en
orden aleatorio), Single Play (se reproducirá la pista actual hasta el final y luego se detendrá), y Normal (se reproducirá el CD
desde la pista actual hasta el final y luego se detendrá).
•Para cambiar el modo de tiempo en la pantalla, pulse el botón Time (Tiempo). Alternará entre transcurrido TRK: cuánto
tiempo ha transcurrido de la pista actual. restante TRK: cuánto tiempo queda de la pista actual). DISC Elapsed: tiempo total
restante (sólo para modo de CD). DISC Remain: tiempo total restante sólo para modo de CD.
•Para expulsar un CD, pulse el botón Eject (Expulsar) cuando la unidad esté detenida o en pausa. Aparecerá “Ejecting”
(Expulsando) en la pantalla mientras se expulsa el CD. Aparecerá “No Disc” (Sin disco) cuando no haya discos en la ranura
de CD.
Importante: Consulte Otra información >CD para aprender más sobre los tipos de CD que soporta el DN-300C MKII y para
más información sobre la manipulación y cuidado de los CD. Al encender la unidad, mantenga pulsado el botón Eject (Expulsión)
para activar el modo de expulsión forzada.
