Denon AVC-X6500H User manual

.
AVC-X6500H
INTEGRATED NETWORK AV AMPLIFIER
Owner’s Manual
Contents Connections Playback Settings Tips Appendix
1
Front panel Display Rear panel Remote Index

Accessories 8
Inserting the batteries 9
Operating range of the remote control unit 9
Features 10
High quality sound 10
High performance 13
Easy operation 17
Part names and functions 18
Front panel 18
Display 22
Rear panel 24
Remote control unit 28
Connections
Speaker installation 32
Connecting speakers 40
Before connecting speakers 40
Speaker configuration and “Amp Assign” settings 44
Connecting 5.1-channel speakers 46
Connecting 7.1-channel speakers 47
Connecting 9.1-channel speakers 51
Connecting 11.1-channel speakers 59
Bi-amp connection 65
Connecting 9.1-channel speakers: Second pair of front speakers 67
Connecting multi-zone speakers 68
Connecting a TV 73
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel) 74
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel) 76
Connection 3 : TV equipped without an HDMI connector 77
Connecting a playback device 78
Connecting a set-top box (Satellite tuner/cable TV) 79
Connecting a DVD player or Blu-ray Disc player 80
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function 81
Connecting a video camcorder or game console 82
Connecting a turntable 83
Connecting a USB memory device to the USB port 84
Connecting to a home network (LAN) 85
Wired LAN 85
Wireless LAN 86
Connecting an external control device 87
REMOTE CONTROL jacks 87
TRIGGER OUT jacks 88
Connecting the power cord 89
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Playback
Basic operation 91
Turning the power on 91
Selecting the input source 91
Adjusting the volume 92
Turning off the sound temporarily (Muting) 92
Playback a DVD player/Blu-ray Disc player 92
Playing a USB memory device 93
Playing files stored on USB memory devices 94
Listening to music on a Bluetooth device 97
Playing music from Bluetooth device 98
Pairing with other Bluetooth devices 100
Reconnecting to this unit from a Bluetooth device 101
Listening to Internet Radio 102
Listening to Internet Radio 103
Playing back files stored on a PC or NAS 104
Playing back files stored on a PC or NAS 105
Getting the HEOS App 108
HEOS Account 109
Playing from streaming music services 110
Listening to the same music in multiple rooms 113
AirPlay function 117
Playing songs from your iPhone, iPod touch or iPad 118
Playing iTunes music with this unit 118
Perform iTunes playback operations with the remote control unit
of this unit 119
Play a song from your iPhone, iPod touch or iPad on multiple
synced devices (AirPlay 2) 120
Spotify Connect function 121
Playing Spotify music with this unit 121
Convenience functions 122
Adding to HEOS Favorites 123
Playing back HEOS Favorites 123
Deleting a HEOS Favorites 124
Adjusting the audibility of dialog and vocals (Dialog Enhancer) 124
Adjusting the volume of each channel to match the input source
(Channel Level Adjust) 125
Adjusting the tone (Tone) 126
Displaying your desired video during audio playback (Video
Select) 127
Adjusting the picture quality for your viewing environment (Picture
Mode) 128
Playing the same music in all zones (All Zone Stereo) 129
Contents Connections Playback Settings Tips Appendix
3
Front panel Display Rear panel Remote Index

Selecting a sound mode 130
Selecting a sound mode 131
Direct playback 132
Pure Direct playback 133
Auto surround playback 133
Description of sound mode types 134
Sound mode that can be selected for each input signal 138
HDMI Control function 142
Setting procedure 142
Smart Menu function 143
Sleep timer function 145
Using the sleep timer 146
Quick select plus function 147
Calling up the settings 148
Changing the settings 149
Panel lock function 150
Disabling all key button operations 150
Disabling all button operations except VOLUME 150
Canceling the Panel lock function 151
Remote lock function 152
Disabling the sensor function of the remote control unit 152
Enabling the remote sensor function 152
Web control function 153
Controlling the unit from a web control 153
Playback in ZONE2/ZONE3 (Another room) 155
Connecting ZONE 155
Playback in ZONE2/ZONE3 160
Settings
Menu map 162
Menu operations 166
Contents Connections Playback Settings Tips Appendix
4
Front panel Display Rear panel Remote Index

Audio 167
Subwoofer Level Adjust 167
Bass Sync 167
Surround Parameter 168
Restorer 173
Audio Delay 174
Volume 175
Audyssey®176
Graphic EQ 179
Video 181
Picture Adjust 181
HDMI Setup 183
Output Settings 188
Component Video Out 192
On Screen Display 192
4K Signal Format 193
TV Format 195
Inputs 196
Input Assign 196
Source Rename 198
Hide Sources 198
Source Level 199
Input Select 199
Speakers 200
Audyssey® Setup 200
Procedure for speaker settings (Audyssey® Setup) 202
Error messages 208
Retrieving Audyssey® Setup settings 210
Manual Setup 211
Amp Assign 211
Speaker Config. 218
Distances 223
Levels 224
Crossovers 225
Bass 226
Front Speaker 227
2ch Playback 227
Network 230
Information 230
Connection 230
Wi-Fi Setup 231
Settings 233
Network Control 235
Friendly Name 235
Diagnostics 236
Contents Connections Playback Settings Tips Appendix
5
Front panel Display Rear panel Remote Index

HEOS Account 237
You have not signed in 237
You have already signed in 237
General 238
Language 238
ECO 238
ZONE2 Setup / ZONE3 Setup 242
Zone Rename 244
Quick Select Names 244
Trigger Out 1 / Trigger Out 2 245
Front Display 245
Firmware 246
Information 249
Usage Data 250
Save & Load 251
Setup Lock 251
Reset 252
Operating external devices with the remote control unit 253
Registering preset codes 254
Operating devices 257
Initializing registered preset codes 260
Specifying the operating zone with the remote control 260
Resetting the remote control unit 260
Tips
Tips 262
Troubleshooting 264
Power does not turn on / Power is turned off 265
Operations cannot be performed through the remote control unit 266
Display on this unit shows nothing 266
No sound comes out 267
Desired sound does not come out 268
Sound is interrupted or noise occurs 271
No video is shown on the TV 272
The menu screen is not displayed on the TV 274
The color of the menu screen and operations content displayed
on the television is different from normal 274
AirPlay cannot be played back 275
USB memory devices cannot be played back 276
Bluetooth cannot be played back 277
The Internet radio cannot be played back 278
Music files on PC or NAS cannot be played back 279
Various online services cannot be played 280
The HDMI Control function does not work 280
Cannot connect to a wireless LAN network 281
When using HDMI ZONE2, the devices does not function properly 282
Update/upgrade error messages 283
Resetting factory settings 284
Resetting network settings 285
Contents Connections Playback Settings Tips Appendix
6
Front panel Display Rear panel Remote Index

Appendix
About HDMI 286
Video conversion function 289
Playing back a USB memory devices 291
Playing back a Bluetooth device 292
Playing back a file saved on a PC or NAS 293
Playing back Internet Radio 294
Personal memory plus function 294
Last function memory 294
Sound modes and channel output 295
Sound modes and surround parameters 297
Types of input signals, and corresponding sound modes 300
Explanation of terms 303
Trademark information 312
Specifications 315
Index 321
Contents Connections Playback Settings Tips Appendix
7
Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
External antennas for
Bluetooth/wireless
connectivity
Power cord Sound calibration
microphone
Sound calibration
microphone stand
Remote control unit
(RC-1219)
R6P/AA batteries
Cable labels
Notes on radio
Cautions on Using Batteries
Safety Instructions
Quick Start Guide
Contents Connections Playback Settings Tips Appendix
8
Front panel Display Rear panel Remote Index

Inserting the batteries
1Slide the rear cover off the remote control unit in the
arrow direction.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30° 30°
Approx. 7 m
Contents Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Features
High quality sound
0With discrete circuit technology, the power amplifier provides
identical quality for all 11-channels (175 Watts x 11-channels)
For optimum realism and stunning dynamic range, the power amplifier
section features discrete power devices (not integrated circuitry).
By using high current, high power discrete power devices, the amplifier
is able to easily drive high quality speakers.
0Dolby Atmos (v p. 304)
This unit is equipped with a decoder that supports Dolby Atmos audio
format. The placement or movement of sound is accurately reproduced
by the addition of overhead speakers, enabling you to experience an
incredibly natural and realistic surround sound field.
0DTS:X (v p. 307)
This unit is equipped with the DTS:X decoder technology. DTS:X brings
the home theater experience to new heights with its immersive object
based audio technology which removes the bounds of channels. The
flexibility of objects allows for sound to be scaled large or small and
moved around the room with greater accuracy than ever before leading
to a richer immersive audio experience.
0DTS Virtual:X (v p. 307)
DTS Virtual:X technology features DTS’s proprietary virtual height and
virtual surround processing to deliver an immersive sound experience
from any type of input source (stereo to 7.1.4 channel) and speaker
configuration.
zDTS Virtual:X is not for use when Height speakers are connected.
0Audyssey LFC™ (Low Frequency Containment) (v p. 178)
Audyssey LFC™ solves the problem of low frequency sounds
disturbing people in neighboring rooms or apartments. Audyssey LFC™
dynamically monitors the audio content and removes the low
frequencies that pass through walls, floors and ceilings. It then applies
psychoacoustic processing to restore the perception of low bass for
listeners in the room. The result is great sound that no longer disturbs
the neighbors.
0Discrete subwoofers and Audyssey Sub EQ HT™ (v p. 201)
The unit has two subwoofer output capability and can adjust the level
and delay for each subwoofer individually.
Audyssey Sub EQ HT™ makes the integration seamless by first
compensating for any level and delay differences between the two
subwoofers and then applying Audyssey MultEQ® XT32 to both
subwoofers together for improved deep bass response and detail.
Contents Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index

0Denon’s unique high quality playback technology “Denon Link
HD” (v p. 311)
This unit is equipped with our exclusive “Denon Link HD” technology.
When connected to a Denon disc player that has Denon Link HD, the
sound localization becomes more precise, with increased detail and
definition. The system works by carrying the critical clock timing signals
via the dedicated Denon Link HD connection, minimizing the jitter
caused by conventional digital connections. This effect can be applied
to an audio source of any media from a Blu-ray Disc player.
This technology enables the playback of 2-channel source audio or
7.1/5.1 multi-channel source audio through a maximum 11.1-channel
speakers, achieving an even broader soundstage.
Contents Connections Playback Settings Tips Appendix
11
Front panel Display Rear panel Remote Index

0Auro-3D
This unit is equipped with an Auro-3D decoder.
With Auro-3D, Front Height (FHL + FHR), Surround Height (SHL + SHR) and Top Surround (TS/optional) are added to a conventional 5.1-channel
system to achieve a natural and realistic sound field that is three-dimensional and fully immersive.
You will be able to fully enjoy Auro-3D playback if you properly place the speakers for Auro-3D.
2 Auro-3D playback
.
FHL FHR
SHL SHR
TS
FL FR
SW
SL SR
C
2 Dolby Atmos playback
.
FHL FHR
SHL SHR
TS
FL FR
SW
SL SR
C
0Auro-3D does not support a Dolby Atmos configuration using Top Front, Top Middle or Top Rear speakers.
But it is possible to support both an Auro-3D and Dolby Atmos by adding Front Height and Rear Height speakers* to a 5.1 configuration.
zFor an optimum Auro-3D experience Surround Height speakers are strongly recommended.
Contents Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

High performance
04K 60Hz input/output supported
.
When 4K Ultra HD (High Definition) is used, an input/output speed of 60
frames per second (60p) is achieved for video signals. When connected
to 4K Ultra HD and 60p video signal input compatible TV, you can enjoy
the sense of realism only available from high-definition images, even
when viewing fast-moving video.
This unit also supports image processing for 4K 60p, 4:4:4 and 24-bit
videos. By processing the video at the original resolution, this unit lets
you enjoy flawless, high-definition picture quality.
This unit also supports HDR (High Dynamic Range) and BT.2020 wide
color gamut.
0HDCP 2.2
This unit is compatible with HDCP 2.2 copyright protection standard.
0Digital video processor upscales analog video signals (SD
resolution) to HD (720p/1080p) and 4K (v p. 190)
.
4K
Up scaling
Up to 1080p
This unit is equipped with a 4K video upscaling function that allows
analog video or SD (Standard Definition) video to be output via HDMI at
4K (3840 × 2160 pixels) resolution. This function enables the device to
be connected to a TV using a single HDMI cable, and produces high
definition images for any video source.
0Equipped with HDMI ZONE2 output (v p. 155)
The ZONE2 multi-room output includes an HDMI output that lets you
enjoy a different A/V source in that room, with another program playing
in the main room.
Contents Connections Playback Settings Tips Appendix
13
Front panel Display Rear panel Remote Index

0HDMI connections enable connection to various digital AV
devices (8 inputs, 3 outputs)
.
83
OutIn
For connection to a broad range of digital sources, this unit features 8
HDMI inputs, including 1 on the front panel that lets you quickly and
conveniently connect a camcorder, game console or other HDMI-
equipped device. There are dual HDMI outputs for the main room, and a
third HDMI output for another room.
0eARC (Enhanced Audio Return Channel) function compatibility
The eARC function is compatible with conventional ARC function-
compatible audio formats in addition to multichannel linear PCM, Dolby
TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X and other audio
formats a conventional ARC function cannot transmit.
Additionally, connecting to an eARC function-compatible television
enables enjoyment of higher-quality surround playback of the audio
content played from your television.
0The device is equipped with a AirPlay® function in addition to
network functions such as Internet radio etc. (v p. 117)
.
You can enjoy a wide variety of content, including listening to Internet
Radio, playing audio files stored on your PC.
This unit also supports Apple AirPlay which lets you stream your music
library from an iPhone®, iPad®, iPod touch® or iTunes®.
0Supports AirPlay 2® wireless audio
Sync multiple AirPlay 2 compatible devices/speakers for simultaneous
playback.
This unit supports AirPlay 2 and requires iOS 11.4 or later.
Contents Connections Playback Settings Tips Appendix
14
Front panel Display Rear panel Remote Index

0Playback of DSD and FLAC files via USB and networks
This unit supports the playback of high resolution audio formats such as
DSD (5.6 MHz) and FLAC 192 kHz files. It provides high quality
playback of high resolution files.
0Wireless connection with Bluetooth devices can be carried out
easily (v p. 97)
.
You can enjoy music simply by connecting wirelessly with your
smartphone, tablet, PC, etc.
0Multi-Room audio (v p. 129)
.
【MAIN ZONE】【ZONE2】/【ZONE3】
You can select and play back the respective inputs in MAIN ZONE,
ZONE2 and ZONE3.
In addition, when the All Zone Stereo function is used, the music being
played back in MAIN ZONE can be enjoyed in all the zones at the same
time. This is useful when you want to let the BGM propagate throughout
the whole house.
0Energy-saving design
This unit is equipped with an ECO Mode function that allows you to
enjoy music and movies while reducing the power consumption during
use, and also an auto-standby function that automatically turns off the
power supply when the unit is not in use. This helps reduce
unnecessary power use.
Contents Connections Playback Settings Tips Appendix
15
Front panel Display Rear panel Remote Index

0Compatible with the “Denon 2016 AVR Remote” Appz for
performing basic operations of the unit with an iPad, iPhone or
Android™ devices (Google, Amazon Kindle Fire)
.
Along with many new features, the graphics and user interface have
been completely overhauled. The new app gives you full control of the
AVR as well as access to its setup menu for detailed adjustments from
your phones or tablets. “Denon 2016 AVR Remote” App also gives you
quick access to the receiver's status display, option menus, Denon Blu-
ray Disc player control, and online owner's manual for your
convenience.
zDownload the appropriate “Denon 2016 AVR Remote” App for your iOS or
Android devices. This unit needs to be connected to the same LAN or Wi-Fi
(wireless LAN) network that the iPhone or iPod touch is connected to.
0HEOS provides streaming music from your favorite online music
sources
.
HEOS wireless multi-room sound system that enables you to enjoy your
favorite music anywhere and everywhere around your home. By utilizing
your existing home network and the HEOS App (available for iOS,
Android and Amazon devices), you can explore, browse, and play
music from your own music library or from many online streaming music
services.
When multiple HEOS devices are connected to the same network,
HEOS devices can be grouped to play back the same music on all
devices simultaneously, or different music can be played on each
separate HEOS device.
Contents Connections Playback Settings Tips Appendix
16
Front panel Display Rear panel Remote Index

Easy operation
0“Setup Assistant” provides easy-to-follow setup instructions
First select the language when prompted. Then simply follow the
instructions displayed on the TV screen to set up the speakers, network,
etc.
0Easy to use Graphical User Interface
This unit is equipped with a Graphical User Interface for improved
operability.
Contents Connections Playback Settings Tips Appendix
17
Front panel Display Rear panel Remote Index

Part names and functions
Front panel
.
wq re yt
u
For details, see the next page.
Contents Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

.
wq reyt
u
APower operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 91)
BPower indicator
This is lit as follows according to the power status:
0Green: Power on
0Off: Normal standby
0Red:
0When “HDMI Pass Through” is set to “On” (v p. 183)
0When “HDMI Control” is set to “On” (v p. 185)
0When “Network Control” is set to “Always On” (v p. 235)
CSOURCE SELECT knob
This selects the input source. (v p. 91)
DRemote control sensor
This receives signals from the remote control unit. (v p. 9)
EDisplay
This displays various pieces of information. (v p. 22)
FMASTER VOLUME knob
This adjusts the volume level. (v p. 92)
GDoor
When you are using buttons and/or connectors behind the door, press
the bottom of the door to open it. Be careful not to catch your fingers
when closing the door.
.
Contents Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

With the door open
.
io Q0qw r t y ue
AZONE2 ON/OFF button
This turns the power of ZONE2 (another room) on/off. (v p. 160)
BZONE2 SOURCE button
This selects the input source for ZONE2. (v p. 160)
CZONE3 ON/OFF button
This turns the power of ZONE3 (another room) on/off. (v p. 160)
DZONE3 SOURCE button
This selects the input source for ZONE3. (v p. 160)
ESTATUS button
Each press of this switches the status information that is shown on the
display.
FInformation button (INFO)
This displays the status information on the TV screen. (v p. 250)
GCursor buttons (uio p)
These select items.
HOPTION button
This displays the option menu on the TV screen.
IDIMMER button
Each press of this switches the brightness of the display. (v p. 245)
JQUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 147)
Contents Connections Playback Settings Tips Appendix
20
Front panel Display Rear panel Remote Index
