Denon Professional DN-V750 User manual

SERVICE MANUAL
NETWORK AUDIO VIDEO PLAYER
MODEL DN-V750/V755
For U.S.A., Canada
& Europe model
JAPAN
X0221V.02 DE/CDM 0412
Some illustrations using in this service manual are
slightly different from the actual set.
●
Please use this service manual with referring to the
operating instructions without fail.
●
For purposes of improvement, specifications and
design are subject to change without notice.
●
●
本文中に使用しているイラストは、説明の都合上現物
と多少異なる場合があります。
●
修理の際は、必ず取扱説明書を参照の上、作業を行っ
てください。
サービスをおこなう前に、このサービスマニュアルを
必ずお読みください。本機は、火災、感電、けがなど
に対する安全性を確保するために、さまざまな配慮を
おこなっており、また法的には「電気用品安全法」に
もとづき、所定の許可を得て製造されております。
従ってサービスをおこなう際は、これらの安全性が維
持されるよう、このサービスマニュアルに記載されて
いる注意事項を必ずお守りください。
●
本機の仕様は性能改良のため、予告なく変更すること
があります。
●
補修用性能部品の保有期間は、製造打切後8年です。
注 意
Professional business company
Ver. 2

2
DN-V750/V755
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
LASER RADIATION
Do not stare into beam or view directly with optical instruments, class 3A laser product.
(1)
(2)
500V
1M
(1)
(2)

3
DN-V750/V755
BLOCK DIAGRAM

4
DN-V750/V755
ADJUSTMENT (for DN-V750 model)
1. Connect the terminal as shown fig. 1.
2. Set the CF card (CF-96-27=adjustment 2) to CARD SLOT.
3. Turn OFF the 1 and 2 Dip switch on the back panel.
4. Turn the power switch ON.
5. VIDEO mode
(1) Press the "SELECT" button about for 2 second.
(2) Until the display appear at the upper right of a monitor.
(3) Set "VIDEO", "AUDIO", "PICTURE", "SCRIPT" to "VIDEO".
6. Display "Color bar".
(1) Press the "STOP" button, pressing the "SELECT" button.
(2) Until the display appear at the upper right of a monitor.
(3) Press the "STOP" button to 1, pressing the "SELECT" button.
(4) Press the "PLAY" button and quickly press the "PAUSE" button.
Display "Color bar" with a still picture.
7. Adjusting the output of Composite.
Adjust "980mVP-P ± 40mVP-P" by VR101.
8. Turn the power switch OFF.
Monitor
Oscilloscope
fig.1

5
DN-V750/V755
ADJUSTMENT (for DN-V755 model)
1. Connect the terminal as shown fig. 1.
2. Set to the IDE → CF conversion P.W.B.
(1) Extract the IDE cable of HDD from the main P.W.B.
(2) Extract the power cable of HDD from the HDD.
(3) Insert the IDE cable of IDE
→ CF conversion P.W.B. to the main P.W.B.
(4) The power cable of IDE → CF conversion P.W.B. connect to the power cable of HDD.
(5) Set the CF card (CF-96-27=adjustment 2) to IDE → CF conversion P.W.B.
3. Turn OFF the 1 and 2 Dip switch on the back panel.
4. Turn the power switch ON.
5. VIDEO mode
(1) Press the "SELECT" button about for 2 second.
(2) Until the display appear at the upper right of a monitor.
(3) Set "VIDEO", "AUDIO", "PICTURE", "SCRIPT" to "VIDEO".
6. Display "Color bar".
(1) Press the "STOP" button, pressing the "SELECT" button.
(2) Until the display appear at the upper right of a monitor.
(3) Press the "STOP" button to 1, pressing the "SELECT" button.
(4) Press the "PLAY" button and quickly press the "PAUSE" button.
Display "Color bar" with a still picture.
7. Adjusting the output of Composite.
Adjust "980mVP-P ± 40mVP-P" by VR101.
8. Turn the power switch OFF.
Monitor
Oscilloscope
fig.1

6
DN-V750/V755
SEMICONDUCTORS
Only major semiconductors are shown, general semiconductors etc. are omitted to list.
主な半導体を記載しています。汎用の半導体は記載を省略しています。
1. IC’s
EM8551B (IC105)

7
DN-V750/V755
EM8551B Terminal Function
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function
1 A1 CVBS Analog Video Output CVBS O - - - - Ext video buffer(BH7862) ganerates composite
video.
2 A2 AVDD_CVBS VDD3_3CVBS - - - - - Connect to 3.3V_A(for Video DAC)
3 A3 AVSS_CVBS VSS_CVBS - - - - - Connect to GND_A(for Video DAC)
4 A4 AVDD_VDAC VDD3_3DAC - - - - - Connect to 3.3V_A(for Video DAC)
5 A5 VID_D[23] - (O) - - - - Not used
6 A6 VID_D[17] - (O) - - - - Not used
7 A7 VID_D[12] Video Output:C[4] (O) - - - - Not used
8 A8 VID_CLKOUT Video Output:Video(Pixel) clock out (O) - - - - Not used
9 A9 VID_D[6] Video Output:Y[6] (O) - - - - Not used
10 A10 VID_D[2] Video Output:Y[2] (O) - - - - Not used
11 A11 VID_HSYNC Video Output Horizontal sync (O) - - - - Not used
12 A12 PIO1[2] Programmable I/O Port 1 Bit 2 I Lev Pu H H L:Active
13 A13 BREAKPT DEBUG IF:Breakpoint I - GND L L Connect to GND_D
14 A14 DBGACK DEBUG IF:Debug Acknowledge O - - - - Not used
15 A15 DBGRQ DEBUG IF:Debug Request I - GND L L Not used
16 A16 TRST# JTAG:Test Reset I - GND L L Not used
17 A17 TMS JTAG:Test Mode Select I - GND L L Not used
18 A18 TDO JTAG:Test Data Output O - - - - Not used
19 A19 TDI JTAG:Test Data Input I - GND L L Not used
20 A20 TCK JTAG:Test Clock Input I - A24 - - Connect to 27M(A24[24])
21 A21 PWRDWN# PowerDown/PLL Enable - - 3.3V_D H H Connect to 3.3V_D(PLL Enable)
22 A22 XIN 27MHz crystal oscillator input I - - - - Connect to X'tal for system clock
23 A23 XOUT 27MHz crystal oscillator output O - - - - Connect to X'tal for system clock
24 A24 CLKOUT 27MHz internal Oscillator
output(bufferd)
O - - - - 27M clock is used for -DTACK/RDY signal
generating.
25 A25 UART_CLKIN Receive Clock for UART 0 and 1 (I) - intPd - - Not used
26 A26 PIO0[11] Programmable I/O Port 0 Bit 11 I Lev Pu H/L H/L L:Active
27 A27 PIO0[12] Programmable I/O Port 0 Bit 12 I Lev Pu H/L H/L L:Active
28 B1 Y Analog video output Y O - - - - Connect to video buffer(BH7862:YIN and PYIN)
29 B2 AVDD_Y VDD3_3Y - - - - - Connect to 3.3V_A(for Video DAC)
30 B3 AVSS_Y VSS_Y - - - - - Connect to GND_A(for Video DAC)
31 B4 AVSS_VDAC VSS_DAC - - - - - Connect to GND_A(for Video DAC)
32 B5 VID_D[16] - (O) - - - - Not used
33 B6 VID_D[18] - (O) - - - - Not used
34 B7 VID_D[13] Video Output:C[5] (O) - - - - Not used
35 B8 VID_D[9] Video Output:C[1] (O) - - - - Not used
36 B9 VID_CLKIN Video Output:Video Clock In - - - - -
37 B10 VID_D[3] Video Output:Y[3] (O) - - - - Not used
38 B11 VID_DVLD Video Output:Video active/Video valid (O) - - - - Not used
39 B12 PIO1[1] Programmable I/O Port 1 Bit 1 I Lev Pu H/L H/L L:Active
40 B13 PIO1[5] Programmable I/O Port 1 Bit 5 O - Pd L L H:Active
41 B14 PIO1[9] Programmable I/O Port 1 Bit 9 O - - H H for Ethernet(DM9000) H:Active
42 B15 PIO1[10] Programmable I/O Port 1 Bit 10 O - Pu H H for IDE/PC card L:Active
43 B16 PIO1[8] Programmable I/O Port 1 Bit 8 O - Pd L L L:Active(mute on)/H:Mute off
44 B17 PIO1[15] Programmable I/O Port 1 Bit 15 O - - - - Control signal for rtc(RTC4543)
45 B18 UART0_DTR# UART0:Data Terminal Ready (O) - - - - Not used
46 B19 UART0_DSR# UART0:Data Set Ready (I) - intPd - - Not used
47 B20 NC - - - - - Not used
48 B21 PIO0[0] Programmable I/O Port 0 Bit 0 I Lev Pu H/L H/L L:Time set mode/H:Normal mode
49 B22 PIO0[5] Programmable I/O Port 0 Bit 5 I Lev Pu H/L H/L L:Active
50 B23 PIO0[7] Programmable I/O Port 0 Bit 7 I Ed Pu H/L H/L H to L:Pc card inserted/L to H:Pc card ejected
51 B24 PIO0[9] Programmable I/O Port 0 Bit 9 I Lev Pu H/L H/L L:Active
52 B25 PIO0[14] Programmable I/O Port 0 Bit 14 I Lev Pu H/L H/L L:Active
53 B26 PIO0[15] Programmable I/O Port 0 Bit 15 I Lev Pu H/L H/L L:Active
54 B27 SM_D[0] System Memory Data Bit0 I/O - - - - Connect to system sdram(D0) and flash chip(D0)
55 C1 U Analog Video output U O - - - - Connect to video buffer(BH7862:PBIN)
56 C2 AVDD_U VDD3_3_U - - - - - Connect to 3.3V_A(for Video DAC)
57 C3 AVSS_U VSS U - - - - - Connect to GND_A(for Video DAC)
58 C4 RSET - - - - - - 200ohm terminated(single termination)
59 C5 VID_D[19] - (O) - - - - Not used
60 C6 VID_D[20] - (O) - - - - Not used
61 C7 VID_D[14] Video Output:C[6] (O) - - - - Not used
62 C8 VID_D[10] Video Output:C[2] (O) - - - - Not used
63 C9 VID_D[7] Video Output:Y[7] (O) - - - - Not used
64 C10 VID_D[4] Video Output:Y[4] (O) - - - - Not used
65 C11 VID_D[0] Video Output:Y[0] (O) - - - - Not used
66 C12 PIO1[0] Programmable I/O Port 1 Bit 0 I Lev Pu H/L H/L L:Active
67 C13 PIO1[4] Programmable I/O Port 1 Bit 4 O - Pd L L H:Active
68 C14 PIO1[7] Programmable I/O Port 1 Bit 7 O - Pd L L H:Active
69 C15 PIO1[11] Programmable I/O Port 1 Bit 11 I - - H/L H/L Connect to RTC 1Hz output

8
DN-V750/V755
70 C16 PIO1[13] Programmable I/O Port 1 Bit 13 O - Pd - - Control signal for rtc(RTC4543) L:disable/
H:enable
71 C17 UART0_TXD UART0:Transmit Data O - - - - Not used
72 C18 UART0_RXD UART0:Receive Data I - intPd - - Not used
73 C19 UART0_DCD# UART0:Data Carriar Detect (I) - intPd - - Not used
74 C20 PIO0[1] Programmable I/O Port 0 Bit 1 I Lev Pu H/L H/L L:Pioneer LD compatible mode/H:Normal mode
75 C21 PIO0[3] Programmable I/O Port 0 Bit 3 I Lev Pu H/L H/L Reserved
76 C22 PIO0[6] Programmable I/O Port 0 Bit 6 I Lev Pu H/L H/L L:Active
77 C23 PIO0[8] Programmable I/O Port 0 Bit 8 I Lev Pu H/L H/L L:Active
78 C24 PIO0[10] Programmable I/O Port 0 Bit 10 I Lev Pu H/L H/L L:Active
79 C25 PIO0[13] Programmable I/O Port 0 Bit 13 I Lev Pu H/L H/L L:Active
80 C26 SM_D[1] System Memory Data Bit1 I/O - - - - Connect to system sdram(D1) and flash chip(D1)
81 C27 SM_D[14] System Memory Data Bit14 I/O - - - - Connect to system sdram(D14) and flash
chip(D14)
82 D1 V Analog Video output V O - - - - Connect to video buffer(BH7862:CIN and PRIN)
83 D2 AVDD_V VDD3_3V - - - - - Connect to 3.3V_A(for Video DAC)
84 D3 AVSS_V VSS V - - - - - Connect to GND_A(for Video DAC)
85 D4 VREF - O - - - - Connect to GND_D through capacitor(0.1uF)
86 D5 VID_D[22] - (O) - - - - Not used
87 D6 VID_D[21] - (O) - - - - Not used
88 D7 VID_D[15] Video Output:C[7] (O) - - - - Not used
89 D8 VID_D[11] Video Output:C[3] (O) - - - - Not used
90 D9 VID_D[8] Video Output:C[0] (O) - - - - Not used
91 D10 VID_D[5] Video Output:Y[5] (O) - - - - Not used
92 D11 VID_D[1] Video Output:Y[1] (O) - - - - Not used
93 D12 VID_VSYNC Video Output:Vertical sync (O) - - - - Not used
94 D13 PIO1[3] Programmable I/O Port 1 Bit 3 O - Pd L L H:Active
95 D14 PIO1[6] Programmable I/O Port 1 Bit 6 O - Pd L L H:Active
96 D15 PIO1[12] Programmable I/O Port 1 Bit 12 O - - - - Control signal for rtc(RTC4543) L:read/H:write
97 D16 PIO1[14] Programmable I/O Port 1 Bit 14 I/O - - - - Control signal for rtc(RTC4543)
98 D17 UART0_RTS# UART0:Request to Send (O) - - - - Not used
99 D18 UART0_RIN UART0:Ring Indicator (I) - intPd - - Not used
100 D19 UART0_CTS# UART0:Clear to Send (I) - intPd - - Not used
101 D20 PIO0[2] Programmable I/O Port 0 Bit 2 I Lev Pu H/L H/L L:OSD Off/H:OSD On
102 D21 PIO0[4] Programmable I/O Port 0 Bit 4 I Lev Pu H/L H/L L:Active
103 D22 AVSS_SPLL System PLL Ground - - - - - Connect to GND_D
104 D23 AVDD_SPLL System PLL Power - - - - - Connect to 1.8V_A(for System PLL)
105 D24 AVDD_VPLL Video PLL Power - - - - - Connect to 1.8V_A(for System PLL)
106 D25 SM_D[2] System Memory Data Bit2 I/O - Pd - - Connect to system sdram(D2) and flash chip(D2)
and mode select pulldown is mounted.
107 D26 SM_D[13] System Memory Data Bit13 I/O - - - - Connect to system sdram(D13) and flash
chip(D13)
108 D27 SM_D[12] System Memory Data Bit12 I/O - Pd - - Connect to system sdram(D12) and flash
chip(D12) and mode select pulldown is mounted.
109 E1 AUD_CLKIN Serial clock input (I) - intPd - - Not used
110 E2 NC - - - - - Not used
111 E3 NC - - - - - Not used
112 E4 NC - - - - - Not used
113 E5 VSS_CORE - - - - - - Connect to GND_D
114 E6 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
115 E7 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
116 E8 VSS_CORE - - - - - - Connect to GND_D
117 E9 VDD_IO - - - - - - Connect to 3.3V_D
118 E10 VDD_IO - - - - - - Connect to 3.3V_D
119 E11 VSS_CORE - - - - - - Connect to GND_D
120 E12 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
121 E13 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
122 E14 VSS_CORE - - - - - - Connect to GND_D
123 E15 VDD_IO - - - - - - Connect to 3.3V_D
124 E16 VDD_IO - - - - - - Connect to 3.3V_D
125 E17 VSS_CORE - - - - - - Connect to GND_D
126 E18 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
127 E19 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
128 E20 VSS_CORE - - - - - - Connect to GND_D
129 E21 VDD_IO - - - - - - Connect to 3.3V_D
130 E22 VDD_IO - - - - - - Connect to 3.3V_D
131 E23 VSS_CORE - - - - - - Connect to GND_D
132 E24 AVSS_VPLL Video PLL Ground - - - - - Connect to GND_D
133 E25 SM_D[11] System Memory Data Bit11 I/O - Pd - - Connect to system sdram(D11) and flash
chip(D11) and mode select pulldown is mounted.
134 E26 SM_D[5] System Memory Data Bit5 I/O - Pd - - Connect to system sdram(D5) and flash chip(D5)
and mode select pulldown is mounted.
135 E27 SM_D[6] System Memory Data Bit6 I/O - - - - Connect to system sdram(D6) and flash chip(D6)
136 F1 AUD_SDIN Serial data input (I) - intPd - - Not used
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

9
DN-V750/V755
137 F2 DAMCK Serial Audio Clk Out (O) - - - - Not used
138 F3 DABCK Bitclk (O) - - - - Not used
139 F4 AUD_CH1_VD
D
DAC1 VCC 3V3 - - - - - Connect to 3.3V_D
140 F5 VDD_IO - - - - - - Connect to 3.3V_D
141 F6 VSS_IO - - - - - - Connect to GND_D
142 F7 VSS_IO - - - - - - Connect to GND_D
143 F21 VSS_CORE - - - - - - Connect to GND_D
144 F22 VSS_IO - - - - - - Connect to GND_D
145 F23 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
146 F24 SM_D[4] System Memory Data Bit4 I/O - Pd - - Connect to system sdram(D4) and flash chip(D4)
and mode select pulldown is mounted.
147 F25 SM_D[8] System Memory Data Bit8 I/O - Pd - - Connect to system sdram(D8) and flash chip(D8)
and mode select pulldown is mounted.
148 F26 SM_DQM[0] System Memory SDRAM I/O mask 0 O - - - - Connect to system sdram(DQM0)
149 F27 SM_WE# System Memory SDRAM Write enable O - - - - Connect to system sdram(-WE) and FLASH(-OE).
150 G1 DAC1_ACLK_2
56
DAC1 L Channel Positive Terminal O - - - - connect to audio dac(WM8725) I2S format
151 G2 DAC1_SCOUT DAC1 L Channel Negative Terminal O - - - - connect to audio dac(WM8725) I2S format
152 G3 DAC2_SCOUT DAC2 L Channel Negative Terminal (O) - - - - Not used
153 G4 AUD_CH2_VSS DAC1 VSS - - - - - Connect to GND_D
154 G5 VDD_IO - - - - - - Connect to 3.3V_D
155 G6 VSS_IO - - - - - - Connect to GND_D
156 G22 VSS_IO - - - - - - Connect to GND_D
157 G23 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
158 G24 SM_D[9] System Memory Data Bit9 I/O - Pd - - Connect to system sdram(D9) and flash chip(D9)
and mode select pulldown is mounted.
159 G25 SM_RAS# System Memory SDRAM Row addr.
Strobe
O - - - - Connect to system sdram(-RAS).
160 G26 SM_CS# System Memory SDRAM Chip select O - - - - Connect to system sdram(-CS)
161 G27 SM_A[11] System Memory Address Bit11 O - - - - Connect to system sdram(A11) and flash
chip(A11)
162 H1 DAC1_SDOUT DAC1 R Channel Positive Terminal O - - - - connect to audio dac(WM8725) I2S format
163 H2 DAC1_SFOUT DAC1 R Channel Negative Terminal O - - - - connect to audio dac(WM8725) I2S format
164 H3 DAC2_ACLK_2
56
DAC2 L Channel Positive Terminal (O) - - - - Not used
165 H4 AUD_CH3_VD
D
DAC2 VCC 3V3 - - - - - Connect to 3.3V_D
166 H5 VSS_IO - - - - - - Connect to GND_D
167 H6 VSS_IO - - - - - - Connect to GND_D
168 H23 VSS_IO - - - - - - Connect to GND_D
169 H24 NC - - - - - Not used
170 H25 SM_D[15] System Memory Data Bit15 I/O - - - - Connect to system sdram(D15) and flash
chip(D15)
171 H26 SM_A[9] System Memory Address Bit9 O - - - - Connect to system sdram(A9) and flash chip(A9)
172 H27 SM_A[8] System Memory Address Bit8 O - - - - Connect to system sdram(A8) and flash chip(A8)
173 J1 DAC3_ACLK_2
56
DAC3 L Channel Positive Terminal (O) - - - - Not used
174 J2 DAC3_SCOUT DAC3 L Channel Negative Terminal (O) - - - - Not used
175 J3 DAC2_SDOUT DAC2 R Channel Positive Terminal (O) - - - - Not used
176 J4 AUD_CH4_VSS DAC2 VSS - - - - - Connect to GND_D
177 J5 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
178 J23 VDD_IO - - - - - - Connect to 3.3V_D
179 J24 SM_D[3] System Memory Data Bit3 I/O - Pd - - Connect to system sdram(D3) and flash chip(D3)
and mode select pulldown is mounted.
180 J25 SM_A[7] System Memory Address Bit7 O - - - - Connect to system sdram(A7) and flash chip(A7)
181 J26 SM_A[6] System Memory Address Bit6 O - - - - Connect to system sdram(A6) and flash chip(A6)
182 J27 SM_A[0] System Memory Address Bit0 O - - - - Connect to system sdram(A0) and flash chip(A0)
183 K1 DAC3_SDOUT DAC3 R Channel Positive Terminal (O) - - - - Not used
184 K2 DAC3_SFOUT DAC3 R Channel Negative Terminal (O) - - - - Not used
185 K3 DAC2_SFOUT DAC2 R Channel Negative Terminal (O) - - - - Not used
186 K4 AUD_CH5_VD
D
DAC3 VCC 3V3 - - - - - Connect to 3.3V_D
187 K5 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
188 K23 VDD_IO - - - - - - Connect to 3.3V_D
189 K24 SM_D[10] System Memory Data Bit10 I/O - Pd - - Connect to system sdram(D10) and flash
chip(D10) and mode select pulldown is mounted.
190 K25 SM_A[5] System Memory Address Bit5 O - - - - Connect to system sdram(A5) and flash chip(A5)
191 K26 SM_A[1] System Memory Address Bit1 O - - - - Connect to system sdram(A1) and flash chip(A1)
192 K27 SM_A[2] System Memory Address Bit2 O - - - - Connect to system sdram(A2) and flash chip(A2)
193 L1 MM_A[4] Mpeg Memory Address Bit 4 O - - - - Connect to MPEG SDRAM(A4)
194 L2 NC - - - - - Not used
195 L3 AUD_SPDIFOU
T
SPDIF Digital Out (O) - - - - Not used
196 L4 AUD_CH6_VSS DAC3 VSS - - - - - Connect to GND_D
197 L5 VSS_IO - - - - - - Connect to GND_D
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

10
DN-V750/V755
198 L11 VSS_IO - - - - - - Connect to GND_D
199 L12 VSS_IO - - - - - - Connect to GND_D
200 L13 VSS_IO - - - - - - Connect to GND_D
201 L14 VSS_IO - - - - - - Connect to GND_D
202 L15 VSS_IO - - - - - - Connect to GND_D
203 L16 VSS_IO - - - - - - Connect to GND_D
204 L17 VSS_IO - - - - - - Connect to GND_D
205 L23 VSS_IO - - - - - - Connect to GND_D
206 L24 SM_D[7] System Memory Data Bit7 I/O - Pd - - Connect to system sdram(D7) and flash chip(D7)
and mode select pulldown is mounted.
207 L25 SM_DQM[3] System Memory SDRAM I/O mask 3 O - - - - Connect to system sdram(DQM3)
208 L26 SM_A[3] System Memory Address Bit3 O - - - - Connect to system sdram(A3) and flash chip(A3)
209 L27 SM_CLK System Memory SDRAM Clock 100
MHz
O - - - - Connect to system sdram(CLOCK)
210 M1 MM_A[2] Mpeg Memory Address Bit 2 O - - - - Connect to MPEG SDRAM(A2)
211 M2 MM_A[3] Mpeg Memory Address Bit 3 O - - - - Connect to MPEG SDRAM(A3)
212 M3 DALRK Serial data L/R clk (O) - - - - Not used
213 M4 DADAT Serial data output (O) - - - - Not used
214 M5 VDD_IO - - - - - - Connect to 3.3V_D
215 M11 VSS_IO - - - - - - Connect to GND_D
216 M12 VSS_IO - - - - - - Connect to GND_D
217 M13 VSS_IO - - - - - - Connect to GND_D
218 M14 VSS_IO - - - - - - Connect to GND_D
219 M15 VSS_IO - - - - - - Connect to GND_D
220 M16 VSS_IO - - - - - - Connect to GND_D
221 M17 VSS_IO - - - - - - Connect to GND_D
222 M23 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
223 M24 SM_DQM[1] System Memory SDRAM I/O mask 1 O - - - - Connect to system sdram(DQM1)
224 M25 SM_CAS# System Memory SDRAM Column
addr. Strobe
O - - - - Connect to system sdram(-CAS)
225 M26 SM_D[16] System Memory Data Bit16 I/O - - - - Connect to system sdram(D16)
226 M27 SM_D[17] System Memory Data Bit17 I/O - - - - Connect to system sdram(D17)
227 N1 MM_A[7] Mpeg Memory Address Bit 7 O - - - - Connect to MPEG SDRAM(A7)
228 N2 MM_A[6] Mpeg Memory Address Bit 6 O - - - - Connect to MPEG SDRAM(A6)
229 N3 MM_A[5] Mpeg Memory Address Bit 5 O - - - - Connect to MPEG SDRAM(A5)
230 N4 MM_A[1] Mpeg Memory Address Bit 1 O - - - - Connect to MPEG SDRAM(A1)
231 N5 VDD_IO - - - - - - Connect to 3.3V_D
232 N11 VSS_IO - - - - - - Connect to GND_D
233 N12 VSS_IO - - - - - - Connect to GND_D
234 N13 VSS_IO - - - - - - Connect to GND_D
235 N14 VSS_IO - - - - - - Connect to GND_D
236 N15 VSS_IO - - - - - - Connect to GND_D
237 N16 VSS_IO - - - - - - Connect to GND_D
238 N17 VSS_IO - - - - - - Connect to GND_D
239 N23 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
240 N24 SM_CLKE System Memory SDRAM Clock
Enable
O - - - - Connect to system sdram(CLKE)
241 N25 SM_D[18] System Memory Data Bit18 I/O - - - - Connect to system sdram(D18)
242 N26 SM_D[29] System Memory Data Bit29 I/O - - - - Connect to system sdram(D29)
243 N27 SM_D[28] System Memory Data Bit28 I/O - - - - Connect to system sdram(D28)
244 P1 MM_A[9] Mpeg Memory Address Bit 9 O - - - - Connect to MPEG SDRAM(A9)
245 P2 MM_A[0] Mpeg Memory Address Bit 0 O - - - - Connect to MPEG SDRAM(A0)
246 P3 MM_DQM[3] Mpeg Memory Input/Output mask Bit 3 O - - - - Connect to MPEG SDRAM(DQM3)
247 P4 MM_A[10] Mpeg Memory Address Bit 10 O - - - - Connect to MPEG SDRAM(A10)
248 P5 VSS_IO - - - - - - Connect to GND_D
249 P11 VSS_IO - - - - - - Connect to GND_D
250 P12 VSS_IO - - - - - - Connect to GND_D
251 P13 VSS_IO - - - - - - Connect to GND_D
252 P14 VSS_IO - - - - - - Connect to GND_D
253 P15 VSS_IO - - - - - - Connect to GND_D
254 P16 VSS_IO - - - - - - Connect to GND_D
255 P17 VSS_IO - - - - - - Connect to GND_D
256 P23 VSS_IO - - - - - - Connect to GND_D
257 P24 SM_A[10] System Memory Address Bit10 O - - - - Connect to system sdram(A10) and flash
chip(A10)
258 P25 SM_A[4] System Memory Address Bit4 O - - - - Connect to system sdram(A4) and flash chip(A4)
259 P26 SM_D[20] System Memory Data Bit20 I/O - - - - Connect to system sdram(D20)
260 P27 SM_D[21] System Memory Data Bit21 I/O - - - - Connect to system sdram(D21)
261 R1 MM_DQM[1] Mpeg Memory Input/Output mask Bit 1 O - - - - Connect to MPEG SDRAM(DQM1)
262 R2 MM_A[11] Mpeg Memory Address Bit 11 O - - - - Connect to MPEG SDRAM(BA0)
263 R3 MM_A[8] Mpeg Memory Address Bit 8 O - - - - Connect to MPEG SDRAM(A8)
264 R4 MM_DQM[0] Mpeg Memory Input/Output mask Bit 0 O - - - - Connect to MPEG SDRAM(DQM0)
265 R5 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
266 R11 VSS_IO - - - - - - Connect to GND_D
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

11
DN-V750/V755
267 R12 VSS_IO - - - - - - Connect to GND_D
268 R13 VSS_IO - - - - - - Connect to GND_D
269 R14 VSS_IO - - - - - - Connect to GND_D
270 R15 VSS_IO - - - - - - Connect to GND_D
271 R16 VSS_IO - - - - - - Connect to GND_D
272 R17 VSS_IO - - - - - - Connect to GND_D
273 R23 VDD_IO - - - - - - Connect to 3.3V_D
274 R24 SM_D[31] System Memory Data Bit31 I/O - - - - Connect to system sdram(D31)
275 R25 SM_DQM[2] System Memory SDRAM I/O mask 2 O - - - - Connect to system sdram(DQM2)
276 R26 SM_D[22] System Memory Data Bit22 I/O - - - - Connect to system sdram(D22)
277 R27 SM_D[26] System Memory Data Bit26 I/O - - - - Connect to system sdram(D26)
278 T1 MM_CS# Mpeg Memory Chip Select O - - - - Connect to MPEG SDRAM(-CS)
279 T2 MM_WE# Mpeg Memory Write Enable for
SDRAM
O - - - - Connect to MPEG SDRAM(-WE)
280 T3 MM_D[5] Mpeg Memory Data Bit 5 I/O - - - - Connect to MPEG SDRAM(D5)
281 T4 MM_RAS# Mpeg Memory Row address strobe O - - - - Connect to MPEG SDRAM(-RAS)
282 T5 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
283 T11 VSS_IO - - - - - - Connect to GND_D
284 T12 VSS_IO - - - - - - Connect to GND_D
285 T13 VSS_IO - - - - - - Connect to GND_D
286 T14 VSS_IO - - - - - - Connect to GND_D
287 T15 VSS_IO - - - - - - Connect to GND_D
288 T16 VSS_IO - - - - - - Connect to GND_D
289 T17 VSS_IO - - - - - - Connect to GND_D
290 T23 VDD_IO - - - - - - Connect to 3.3V_D
291 T24 SM_D[19] System Memory Data Bit19 I/O - - - - Connect to system sdram(D19)
292 T25 NC - - - - - Not used
293 T26 SM_D[30] System Memory Data Bit30 I/O - - - - Connect to system sdram(D30)
294 T27 SM_D[25] System Memory Data Bit25 I/O - - - - Connect to system sdram(D25)
295 U1 MM_DQM[2] Mpeg Memory Input/Output mask Bit 2 O - - - - Connect to MPEG SDRAM(DQM2)
296 U2 MM_CAS# Mpeg Memory Column address strobe O - - - - Connect to MPEG SDRAM(-CAS)
297 U3 MM_D[4] Mpeg Memory Data Bit 4 I/O - - - - Connect to MPEG SDRAM(D4)
298 U4 MM_D[12] Mpeg Memory Data Bit 12 I/O - - - - Connect to MPEG SDRAM(D12)
299 U5 VSS_IO - - - - - - Connect to GND_D
300 U11 VSS_IO - - - - - - Connect to GND_D
301 U12 VSS_IO - - - - - - Connect to GND_D
302 U13 VSS_IO - - - - - - Connect to GND_D
303 U14 VSS_IO - - - - - - Connect to GND_D
304 U15 VSS_IO - - - - - - Connect to GND_D
305 U16 VSS_IO - - - - - - Connect to GND_D
306 U17 VSS_IO - - - - - - Connect to GND_D
307 U23 VSS_IO - - - - - - Connect to GND_D
308 U24 SM_D[23] System Memory Data Bit23 I/O - - - - Connect to system sdram(D23)
309 U25 SM_D[27] System Memory Data Bit27 I/O - - - - Connect to system sdram(D27)
310 U26 SM_A[12] System Memory Address Bit12 O - - - - Connect to system sdram(BA0) and flash
chip(A12)
311 U27 SM_D[24] System Memory Data Bit24 I/O - - - - Connect to system sdram(D24)
312 V1 MM_CLK Mpeg Memory Clock 100 MHz O - - - - Connect to MPEG SDRAM(CLK)
313 V2 MM_D[7] Mpeg Memory Data Bit 7 I/O - - - - Connect to MPEG SDRAM(D7)
314 V3 MM_D[1] Mpeg Memory Data Bit 1 I/O - - - - Connect to MPEG SDRAM(D1)
315 V4 MM_D[24] Mpeg Memory Data Bit 24 I/O - - - - Connect to MPEG SDRAM(D24)
316 V5 VDD_IO - - - - - - Connect to 3.3V_D
317 V23 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
318 V24 SM_A[15] System Memory Address Bit15 O - - - - Connect to flash chip(A15)
319 V25 SM_A[13] System Memory Address Bit13 O - - - - Connect to system sdram(BA1) and flash
chip(A13)
320 V26 SM_A[16] System Memory Address Bit16 O - - - - Connect to flash chip(A16)
321 V27 SM_A[14] System Memory Address Bit14 O - - - - Connect to flash chip(A14)
322 W1 MM_D[8] Mpeg Memory Data Bit 8 I/O - - - - Connect to MPEG SDRAM(D8)
323 W2 NC - - - - - Not used
324 W3 MM_D[21] Mpeg Memory Data Bit 21 I/O - - - - Connect to MPEG SDRAM(D21)
325 W4 MM_D[27] Mpeg Memory Data Bit 27 I/O - - - - Connect to MPEG SDRAM(D27)
326 W5 VDD_IO - - - - - - Connect to 3.3V_D
327 W23 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
328 W24 FLASH_CS[1]# Flash Chip Select 1 O - - - H Connect to flash chip(-CS1) or adress decoder(A)
329 W25 SM_A[18] System Memory Address Bit18 O - - - - Connect to flash chip(A18)
330 W26 SM_A[19] System Memory Address Bit19 O - - - - Connect to flash chip(A19)
331 W27 SM_A[17] System Memory Address Bit17 O - - - - Connect to flash chip(A17)
332 Y1 MM_D[6] Mpeg Memory Data Bit 6 I/O - - - - Connect to MPEG SDRAM(D6)
333 Y2 MM_D[9] Mpeg Memory Data Bit 9 I/O - - - - Connect to MPEG SDRAM(D9)
334 Y3 MM_D[28] Mpeg Memory Data Bit 28 I/O - - - - Connect to MPEG SDRAM(D28)
335 Y4 MM_D[17] Mpeg Memory Data Bit 17 I/O - - - - Connect to MPEG SDRAM(D17)
336 Y5 VSS_IO - - - - - - Connect to GND_D
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

12
DN-V750/V755
337 Y23 VSS_IO - - - - - - Connect to GND_D
338 Y24 FLASH_CFG[0] Flash configulation(16#/32bits flash
Width)
I - GND L L Select bus width.(L fixed:16bit bus width)
339 Y25 FLASH_RYBY# Flash ready/busy (I) - Pu H H Reserved function.
340 Y26 FLASH_CS[0]# Flash Chip Select 0 O - - - L Connect to flash chip(-CS0) or adress decoder(-
G).
341 Y27 FLASH_WE# Flash Write Enable O - - - - Connect to flash chip(-WE)
342 AA1 MM_D[10] Mpeg Memory Data Bit 10 I/O - - - - Connect to MPEG SDRAM(D10)
343 AA2 MM_D[11] Mpeg Memory Data Bit 11 I/O - - - - Connect to MPEG SDRAM(D11)
344 AA3 MM_D[3] Mpeg Memory Data Bit 3 I/O - - - - Connect to MPEG SDRAM(D3)
345 AA4 VIDIN_D[10] Video Input Data Bit 10 (I) - intPd - - Not used
346 AA5 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
347 AA6 VSS_CORE - - - - - - Connect to GND_D
348 AA22 VSS_CORE - - - - - - Connect to GND_D
349 AA23 VDD_IO - - - - - - Connect to 3.3V_D
350 AA24 IDE_IOW# IDE I/O write O - - - - IDE/PC Card I/O Write
351 AA25 IDE_CS0# IDE Chip Select 0 O - - - - IDE/PC Card chip select0
352 AA26 IDE_NPCBLID IDE Cable ID I - - - - IDE/PC Card cable ID
353 AA27 FLASH_CFG[1] Flash configulation(1#/2chips select
signal)
I - Pu/Pd - - Select quantity of flash chip(L:single
chip,H:double chip)
354 AB1 MM_D[2] Mpeg Memory Data Bit 2 I/O - - - - Connect to MPEG SDRAM(D2)
355 AB2 MM_D[13] Mpeg Memory Data Bit 13 I/O - - - - Connect to MPEG SDRAM(D13)
356 AB3 MM_D[14] Mpeg Memory Data Bit 14 I/O - - - - Connect to MPEG SDRAM(D14)
357 AB4 VIDIN_D[12] Video Input Data Bit 12 (I) - intPd - - Not used
358 AB5 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
359 AB6 VSS_CORE - - - - - - Connect to GND_D
360 AB7 VSS_CORE - - - - - - Connect to GND_D
361 AB22 VSS_CORE - - - - - - Connect to GND_D
362 AB23 VDD_IO - - - - - - Connect to 3.3V_D
363 AB24 IDE_DMAREQ IDE DMA request I - Pd - - IDE/PC Card DMA request.
364 AB25 IDE_A[2] IDE Adress bit2 O - - - - IDE/PC Card address bit2
365 AB26 IDE_CS1# IDE Chip Select 1 O - - - - IDE/PC Card chip select1
366 AB27 DVD_CLKIN - I - GND L L Not used
367 AC1 MM_D[0] Mpeg Memory Data Bit 0 I/O - - - - Connect to MPEG SDRAM(D0)
368 AC2 MM_D[15] Mpeg Memory Data Bit 15 I/O - - - - Connect to MPEG SDRAM(D15)
369 AC3 MM_D[26] Mpeg Memory Data Bit 26 I/O - - - - Connect to MPEG SDRAM(D26)
370 AC4 VIDIN_D[14] Video Input Data Bit 14 (I) - intPd - - Not used
371 AC5 VSS_CORE - - - - - - Connect to GND_D
372 AC6 VDD_IO - - - - - - Connect to 3.3V_D
373 AC7 VDD_IO - - - - - - Connect to 3.3V_D
374 AC8 VSS_CORE - - - - - - Connect to GND_D
375 AC9 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
376 AC10 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
377 AC11 VSS_CORE - - - - - - Connect to GND_D
378 AC12 VDD_IO - - - - - - Connect to 3.3V_D
379 AC13 VDD_IO - - - - - - Connect to 3.3V_D
380 AC14 VSS_CORE - - - - - - Connect to GND_D
381 AC15 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
382 AC16 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
383 AC17 VSS_CORE - - - - - - Connect to GND_D
384 AC18 VDD_IO - - - - - - Connect to 3.3V_D
385 AC19 VDD_IO - - - - - - Connect to 3.3V_D
386 AC20 VSS_CORE - - - - - - Connect to GND_D
387 AC21 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
388 AC22 VDD_CORE - - - - - - Connect to 1.8V_D(for core)
389 AC23 VSS_CORE - - - - - - Connect to GND_D
390 AC24 IDE_IOR# IDE I/O read O - - - - IDE/PC Card I/O read
391 AC25 IDE_A[0] IDE Adress bit0 O - - - - IDE/PC Card address bit0
392 AC26 IDE_A[1] IDE Adress bit1 O - - - - IDE/PC Card address bit1
393 AC27 IDE_IRQ IDE Interrupt Request I - Pd - - IDE/PC Card IRQ
394 AD1 MM_D[23] Mpeg Memory Data Bit 23 I/O - - - - Connect to MPEG SDRAM(D23)
395 AD2 MM_D[22] Mpeg Memory Data Bit 22 I/O - - - - Connect to MPEG SDRAM(D22)
396 AD3 MM_D[18] Mpeg Memory Data Bit 18 I/O - - - - Connect to MPEG SDRAM(D18)
397 AD4 VIDIN_D[15] Video Input Data Bit 15 (I) - intPd - - Not used
398 AD5 VIDIN_D[8] Video Input Data Bit 8 (I) - intPd - - Not used
399 AD6 VIDIN_D[5] Video Input Data Bit 5 (I) - intPd - - Not used
400 AD7 VIDIN_D[2] Video Input Data Bit 2 (I) - intPd - - Not used
401 AD8 NC No Connection - - - - - Not used
402 AD9 NC No Connection - - - - - Not used
403 AD10 LPB_AD[15] Local Peripheral Bus Address/Data bit
15
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
404 AD11 LPB_AD[11] Local Peripheral Bus Address/Data bit
11
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

13
DN-V750/V755
405 AD12 LPB_AD[7] Local Peripheral Bus Address/Data bit
7
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
406 AD13 LPB_AD[3] Local Peripheral Bus Address/Data bit
3
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
407 AD14 LPB_AD[0] Local Peripheral Bus Address/Data bit
0
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
408 AD15 LPB_RD# Local Peripheral Bus Read Command O - - - - Connect to Ethernet(DM9000) and CX241(for
DN-V1500X)
409 AD16 DMA_REQ Local Peripheral Bus DMA Request I (Ed) intPd - - Connect to CX241(Expansion connector for DN-
V1500X)
410 AD17 LPB_PGIO[0] Local Peripheral Bus Programmable I/
O Bit 0
I/O (Lev
)
intPd - - Connect to CX241(for DN-V1500X)
411 AD18 UART1_DSR# UART1:Data Set Ready (I) - intPd - - Not used
412 AD19 UART1_RTS# UART1:Request to Send (O) - - - - Not used
413 AD20 VFD_STB VFD:Strobe Output (O) - - - - Not used
414 AD21 I2CM_SDA I2C Master:2wire bus interface data I/O - Pu - - Connect to serial EEPROM for preset
memory(DATA)
415 AD22 IDE_D[4] IDE Data bit4 I/O - - - - IDE/PC Card data bit4
416 AD23 IDE_D[13] IDE Data bit13 I/O - - - - IDE/PC Card data bit13
417 AD24 IDE_D[0] IDE Data bit0 I/O - - - - IDE/PC Card data bit0
418 AD25 IDE_D[15] IDE Data bit15 I/O - - - - IDE/PC Card data bit15
419 AD26 IDE_IORDY IDE I/O channel ready I - Pu - - IDE/PC Card ready
420 AD27 IDE_ACK# IDE DMA acknowledge O - - - - IDE/PC Card DMA acknowredge.
421 AE1 MM_D[25] Mpeg Memory Data Bit 25 I/O - - - - Connect to MPEG SDRAM(D25)
422 AE2 NC - - - - - Not used
423 AE3 MM_D[16] Mpeg Memory Data Bit 16 I/O - - - - Connect to MPEG SDRAM(D16)
424 AE4 VIDIN_D[11] Video Input Data Bit 11 (I) - intPd - - Not used
425 AE5 VIDIN_D[7] Video Input Data Bit 7 (I) - intPd - - Not used
426 AE6 VIDIN_D[4] Video Input Data Bit 4 (I) - intPd - - Not used
427 AE7 VIDIN_D[1] Video Input Data Bit 1 (I) - intPd - - Not used
428 AE8 NC No Connection - - - - - Not used
429 AE9 NC No Connection - - - - - Not used
430 AE10 LPB_AD[14] Local Peripheral Bus Address/Data bit
14
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
431 AE11 LPB_AD[10] Local Peripheral Bus Address/Data bit
10
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
432 AE12 LPB_AD[6] Local Peripheral Bus Address/Data bit
6
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
433 AE13 LPB_AD[2] Local Peripheral Bus Address/Data bit
2
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
434 AE14 DTACK/RDY# Local Peripheral Bus Transfer
Acknowredge
I (Ed) Pu H H ACK/RDY(-WAIT) signal input for local peripheral
bus.
435 AE15 LPB_WR# Local Peripheral Bus Write Command O - - - - Connect to Ethernet(DM9000) and CX241(for
DN-V1500X)
436 AE16 DMA_REQ1 No Connection (I) - intPd - - Connect to CX241(for DN-V1500X). Not
supported function.
437 AE17 LPB_PGIO[1] Local Peripheral Bus Programmable I/
O Bit 1
I/O (Lev
)
intPd - - Connect to CX241(for DN-V1500X)
438 AE18 UART1_DCD# UART1:Data Carriar Detect (I) - intPd - - Not used
439 AE19 UART1_DTR# UART1:Data Terminal Ready (O) - - - - Not used
440 AE20 VFD_DIN VFD:Data from VFD CTRL (I) - Pu - - Connect to VFD_DOUT(AG21)
441 AE21 I2CM_SCL I2C Master:2wire bus interface clock O - (Pu) - - Connect to serial EEPROM for preset
memory(CLK)
442 AE22 IDE_D[8] IDE Data bit8 I/O - - - - IDE/PC Card data bit8
443 AE23 IDE_D[11] IDE Data bit11 I/O - - - - IDE/PC Card data bit11
444 AE24 IDE_D[2] IDE Data bit2 I/O - - - - IDE/PC Card data bit2
445 AE25 IDE_D[12] IDE Data bit12 I/O - - - - IDE/PC Card data bit12
446 AE26 IDE_D[1] IDE Data bit1 I/O - - - - IDE/PC Card data bit1
447 AE27 IDE_D[14] IDE Data bit14 I/O - - - - IDE/PC Card data bit14
448 AF1 MM_D[20] Mpeg Memory Data Bit 20 I/O - - - - Connect to MPEG SDRAM(D20)
449 AF2 MM_D[29] Mpeg Memory Data Bit 29 I/O - - - - Connect to MPEG SDRAM(D29)
450 AF3 MM_D[31] Mpeg Memory Data Bit 31 I/O - - - - Connect to MPEG SDRAM(D31)
451 AF4 VIDIN_D[9] Video Input Data Bit 9 (I) - intPd - - Not used
452 AF5 VIDIN_D[6] Video Input Data Bit 6 (I) - intPd - - Not used
453 AF6 VIDIN_D[3] Video Input Data Bit 3 (I) - intPd - - Not used
454 AF7 VIDIN_D[0] Video Input Data Bit 0 (I) - intPd - - Not used
455 AF8 AS_ALE Local Peripheral Bus Address Strobe O - - - - Connect to address latch(SN74LVC573) and
CX241(for DN-V1500X)
456 AF9 NC No Connection - - - - - Not used
457 AF10 LPB_AD[13] Local Peripheral Bus Address/Data bit
13
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
458 AF11 LPB_AD[9] Local Peripheral Bus Address/Data bit
9
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
459 AF12 LPB_AD[5] Local Peripheral Bus Address/Data bit
5
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
460 AF13 LPB_AD[1] Local Peripheral Bus Address/Data bit
1
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

14
DN-V750/V755
461 AF14 NC - - - - - Not used
462 AF15 LPB_INTR Local Peripheral Bus Interrupt
Request
I (Ed) Pu - - Connect to Ethernet(DM9000) and CX241(for
DN-V1500X)
463 AF16 LPB_PGIO[3] Local Peripheral Bus Programmable I/
O Bit 3
I/O (Lev
)
intPd - - Connect to CX241(for DN-V1500X)
464 AF17 LPB_PGIO[2] Local Peripheral Bus Programmable I/
O Bit 2
I/O (Lev
)
intPd - - Connect to CX241(for DN-V1500X)
465 AF18 UART1_CTS# UART1:Clear to Send (I) - intPd - - Not used
466 AF19 UART1_RXD UART1:Receive Data (I) - intPd - - Connect to RS232C receiver(uPD4721) and
CX241(for DN-V1500X)
467 AF20 UART1_TXD UART1:Transmit Data (O) - - - - Connect to RS232C driver(uPD4721) and
CX241(for DN-V1500X)
468 AF21 VFD_CLKOUT VFD:Clock out to CTRL (O) - - - - Not used
469 AF22 I2CS_SDA I2C Slave:2wire bus interface data (I/
O)
- - - - Not used
470 AF23 I2S_WS I2S Frame (O) - - - - Not used
471 AF24 IDE_D[6] IDE Data bit6 I/O - - - - IDE/PC Card data bit6
472 AF25 IDE_D[10] IDE Data bit10 I/O - - - - IDE/PC Card data bit10
473 AF26 NC - - - - - Not used
474 AF27 IDE_D[3] IDE Data bit3 I/O - - - - IDE/PC Card data bit3
475 AG1 MM_D[19] Mpeg Memory Data Bit 19 I/O - - - - Connect to MPEG SDRAM(D19)
476 AG2 MM_D[30] Mpeg Memory Data Bit 30 I/O - - - - Connect to MPEG SDRAM(D30)
477 AG3 VIDIN_D[13] Video Input Data Bit 13 (I) - intPd - - Not used
478 AG4 VIDIN_CLK Video Input Pixel Clock In (I) - intPd - - Not used
479 AG5 VIDIN_VSYNC Video Input Vsync In I - intPd - - Connect to CX303(for DN-V1500X)
480 AG6 VIDIN_HSYNC Video Input Hsync In I - intPd - - Connect to CX303(for DN-V1500X)
481 AG7 NC No Connection - - - - - Not used
482 AG8 NC No Connection - - - - - Not used
483 AG9 NC No Connection - - - - - Not used
484 AG10 LPB_AD[12] Local Peripheral Bus Address/Data bit
12
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
485 AG11 LPB_AD[8] Local Peripheral Bus Address/Data bit
8
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
486 AG12 LPB_AD[4] Local Peripheral Bus Address/Data bit
4
I/O - - - - Connect to Ethernet(DM9000) and CX303(for
DN-V1500X)
487 AG13 LPB_HSEL# Local Peripheral Bus Device Chip
Select
O - - - - Connect to Ethernet(DM9000) and CX241(for
DN-V1500X)
488 AG14 LPB_RESET# Local Peripheral Bus Reset O - - - - Connect to CX241(for DN-V1500X)
489 AG15 NC No Connection - - - - - Not used
490 AG16 RESET# Chip reset I - Pu - - EM8550 reset
491 AG17 SCAN_MODE Scan Mode (I) - GND L L Connect to GND_D
492 AG18 RTC_CLKIN 32kHz Clock input for Real Time Clock I - GND L L RTC is not work
493 AG19 UART1_RIN UART1:Ring Indicator (I) - intPd - - Not used
494 AG20 I2S_SCK I2S Clock (O) - - - - Not used
495 AG21 VFD_DOUT VFD:Data to VFD CTRL (I/
O)
- - - - Connect to VFD_DIN(AE20)
496 AG22 I2CS_SCL I2C Slave:2wire bus interface clock (O) - - - - Not used
497 AG23 I2S_SD I2S Data (O) - - - - Not used
498 AG24 IDE_D[7] IDE Data bit7 I/O - Pd - - IDE/PC Card data bit7
499 AG25 IDE_D[9] IDE Data bit9 I/O - - - - IDE/PC Card data bit9
500 AG26 IDE_D[5] IDE Data bit5 I/O - - - - IDE/PC Card data bit5
501 AG27 NC - - - - - Not used
Pin
No. Port Name Symbol Description I/O Det Ext Res Ini Function

15
DN-V750/V755
DM9000EP (IC308)
11
DM9000
75
74
73
72 71
70
69
68
67
66
65
64
63 62
61
60
59 58
57
56
55
54 53 52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
76
TXD1
1 2
3
4
5 6 7 8 9
10 12 13 14 15 16
17 18
19
20
21
22
23
24 25
BGRES
DGND
NC
LINK_O
WAKEUP
PW_RST#
DGND
SD12
IOR#
77
78
79
80
81
82
83
84
85
SD15
SD14
SD13
SD8
SD11
SD10
SD9
SA4
DVDD
IO16
CMD
SA8
SA5
SA6
SA7
SA9
DGND
INT
IOW#
AEN
IOWAIT
DVDD
SD0 SD1 SD2 SD3 SD4 SD5 SD6 SD7
RST
DGND
TEST1 TEST2 TEST3 TEST4
DVDD
X2_25M X1_25M
DGND
SD
AGND
AVDD
AVDD
RX+
RX-
AGND
AGND
TXO+
TXO-
AVDD
DVDD
LINK_I
RXD0
RXD1
RXD2
RXD3
DGND
CRS
COL
RX_DV
RX_ER
RX_CLK
TEST5
TX_CLK
TXD0
TXD2 TXD3 TX_EN DVDD MDIO MDC DGND CLK20MO SPEED# DUP# LINKACT# DGND EEDI EEDO EECK EECS GPIO0 GPIO1 GPIO2 GPIO3 DVDD DVDD NC NC

16
DN-V750/V755
DM9000EP Terminal Function
Pin No. Pin Name Type Description
MII Interface
37 LINK_I I External MII device link status.
41,40,39,
38
RXD[3:0] I External MII Receive Data
43 CRS I External MII Carrier Sense
44 COL I External MII Collision Detect
45 RX_DV I External MII Receive Data Valid
46 RX_ER I External MII Receive Error
47 RX_CLK I External MII Receive Clock
49 TX_CLK I External MII Transmit Clock
53,52,51,
50
TXD[3:0] I/O External MII Transmit Data
TXD[2:0] also used as the strap pins of IO base address when the DM9000 is
operated in ISA mode.
The IO base = (strap pin value of TXD[2:0]) * 10H + 300H
54 TX_EN O External MII Transmit Enable
56 MDIO I/O MII Serial Management Data
57 MDC I/O MII Serial Management Data Clock
This pin is also used as the strap pin of the polarity of the INT pin.
When the MDC pin is pull-high, the INT pin low active; otherwise the INT pin is
high active.
Processor interface
1 IOR# I Processor Read command.
This pin is low active at default, its polarity can be modified by EEPROM setting.
See the EEPROM content description for detail.
2 IOW# I Processor Write command.
This pin is low active at default, its polarity can be modified by EEPROM setting.
See the EEPROM content description for detail.
3 AEN I Address enable used for ISA mode or
chip select for general processor mode.
In general processor mode, the polarity of this pin can be modified by EEPROM
setting. See the EEPROM content description for detail.
4 IOWAIT O Processor command ready
When a command is issued before last command completed, the IOWAIT will be
pulled to low to indicate the current command is waited.
14 RST I Hardware reset command, high active to reset the DM9000.
6,7,8,9,10,
11,12,13,
89,88,87,
86,85,84,
83,82
SD0~15 I/O Processor data bus bit 0~15

17
DN-V750/V755
93,94,95,
96,97,98
SA4~9 I address bus 4~9 for ISA mode
92 CMD I Command type:
When high, the access of this command cycle is DATA port.
When low, the access of this command cycle is ADDRESS port.
91 IO16 O word command indication
When the access of internal memory is word or dword width, this pin will
be asserted.
This pin is low active at default, its polarity can be modified by EEPROM
setting. See the EEPROM content description for detail.
100 INT O interrupt request
This pin is high active at default, its polarity can be modified by EEPROM
setting or strap pin MDC. See the EEPROM content description for detail.
56,53,52,
51,50,49,
47,46,45,
44,43,41,
40,39,38
37
SD16~31 (in
double word
mode)
I/O Processor data bus bit 16~31
These pins are used as data bus bits 16~31 when the DM9000 is set to
double word mode (the straps pin EEDO is pull-high and WAKEUP is not
pull-high).
57 IO32 (in double
word mode)
O Double word command indication
This pins is used as the Double word command indication when the
DM9000 is set to double data word mode and when the access of internal
memory is double word width, this pin will be asserted.
This pin is low active at default, its polarity can be modified by EEPROM
setting. See the EEPROM content description for detail.
EEPROM Interface
64 EEDI I Data from EEPROM
65 EEDO I/O Data to EEPROM
This pin is also as a strap pin. Combine with strap pin WOL, it can set the
data width of the internal memory access.
The decoder table is the following, where the logic 1 means the strap pin
is pull-high.
WAKEUP EEDO data width
0 0 word
0 1 doubleword
1 0 byte
1 1 reserved
66 EECK O Clock to EEPROM
67 EECS I/O Chip Select to EEPROM
This pin is also used as a strap pin to define the LED modes.
When it is pull-high, the LED mode is the mode 1;
Otherwise it is mode 0.
Clock Interface
21 X2_25M O Crystal 25MHz Out
22 X1_25M I Crystal 25MHz In

18
DN-V750/V755
59 CLK20MO O 20Mhz clock output
It is used as the clock signal for the external MII device’s clock is 20Mhz.
LED Interface
60 SPEED100# O Speed LED
It is low output to indicate that the internal PHY is operated in 100M
speed, or it is floating for the 10M mode of the internal PHY.
61 DUP# O Full-duplex LED
In LED mode 1, It is low output to indicate that the internal PHY is
operated in full-duplex mode, or it is floating for the half-duplex mode of
the internal PHY.
In LED mode 0, It is low output to indicate that the internal PHY is
operated in 10M mode, or it is floating for the 100M mode of the internal
PHY.
62 LINK&ACT# O Link LED
In LED mode 1, it is the combined LED of link and carrier sense signal of
the internal PHY.
In LED mode 0, it is the LED of the carrier sense signal of the internal
PHY only.
10/100 PHY/Fiber
24 SD I Fiber-optic signal detect
PECL signal which indicates whether or not the fiber-optic receives pair is
receiving valid levels.
25 AGND Bandgap ground.
26 BGRES I/O Bandgap pin.
27 AVDD Bandgap and guard ring power
28 AVDD RX power
29 RX+ I TP RX input
30 RX- I TP RX input
31 AGND RX ground
32 AGND TX ground
33 TXO+ O TP TX output
34 TXO- O TP TX output
35 AVDD TX power
Miscellaneous
16,17,18,
19
TEST1~TEST4 I Operation Mode
Test1,2,3,4=(1,1,0,0) : the processor interface is ISA compatible.
Test1,2,3,4=(1,1,0,1) : the processor interface is for general processor .
48 TEST5 I It must be ground.
68,69,70,
71
GPIO0~3 I/O General I/O ports
Registers GPCR and GPR can program these pins.
The GPIO0 is output mode with output data high at default to power down
internal PHY and other external MII device.
GPIO1~3 default are input ports.

19
DN-V750/V755
64M SDRAM (IC102)
78 LINK_O O Cable link status output. Active High.
This pin is also used as a strap pin to define the MII interface is reversed
MII interface (pull-high) or normal MII interface (not pull-high).
79 WAKEUP O Issue a wake-up signal when wake-up event happens.
80 PW_RST# I Hardware Reset
Active low signal to initiate the DM9000.
74,75,77 NC Not connect
Power
5,20,36,
55,72,90,
73
DVDD Digital VCC
15,23,42,
58,63,81,
99,76
DGND Digital GND

20
DN-V750/V755
64M SDRAM Terminal Function
