Denver TFD-1912DVBT User manual

Operating Instructions
19" TFT LCD TV+DVBT+DVD COMBO
TERMINALS INPUT: HDMI,YPBPR ,AV,SCART,PC.
AC 110-240V 50/60Hz
TELETEXT
NTSC PLAYBACK
PAL/SECAM B/G,D/K,I
SLOT IN DVD PLAYER
••••
••••
TFD-1912DVBT

Table Of Contents
1
Table of Contents 1
2
Specifications
3
Installation
4
Important Safety Instruction
Warnings and Cautions 5-7
8
Functional Parts(TV)
11-13
Connecting External Equipment
Basic Operation
19-20
Advanced Functions
21-26
Troubleshooting Tips 29
Rear View Of TV Set 10
Operation-Remote Control 14-16
Functional Parts(DVD) 9
Remote Control Operation(DVD)
17-18
Inital Settings(DVD) 27-28

Specifications
2
Receiving System:
Colour System:
LCD Panel:
Ext.Antenna:
Ext. In/Out:
Speaker:
Audio Output:
Power Supply:
75 Ohm Coaxial Cable
8 OHM
AC 110-240V 50/60Hz
Dimension:
Net Weight:
W480XD195.8XH398(mm)
6.00KG
<3W X 2
PAL,SECAM,AUTO
B/G, D/K, I
Power consumption: 55W
Standby power consumption: <3W
Note:Design and specifications are subject to change without prior notice.
482.6mm(19 inch) diagonal
HDMI, AV, YPbPr, SCART, PC(VGA/AUDIO)IN, EARPHONE

3
Thank you verymuch for yourpurchase of thisproduct, the mostnatural Colour TelevisionReceiver.
Toenjoy your setto the fullfrom the verybeginning, read thismanual carefully andkeep it handyfor ready
reference.
INSTALLATION
Locate the receiverin the roomwhere direct lightdoes not strikethe screen.
Totaldarkness or areflection on thepicture screen cancause eyestrain. Softand indirect lightingis
recommended for comfortableviewing.
Allow enoughspace between thereceiver and thewall to permitventilation.
Avoid excessively warm locationsto prevent possibledamage to thecabinet or prematurecomponent
failure.
This TV operates on a DC supply provided by the AC-DC adaptor. The voltage is as Indicated on the label
on the backcover.Only usethe AC-DCadaptor supplied withthe TV and never applyan ACmains to theTV
directly. The AC-DC adaptor operateson andAC mains supply, the voltageis as indicatedon the labelof
the AC-DCadaptor. Connectthe DC plugof theAC-DC adaptor tothe DC 12Vsocket at theback of theTV.
Connect theAC-DC adaptor andits mains cord.Insert the mainsplug in thewall socket havinga mains
voltage of 110-240V.
Do not installthe receiver ina location nearheat sources suchas radiator,air ducts, directsunlight ,or
in a placesomewhere like closecompartment and closearea.
Do not coverthe ventilation openingswhen using theset.
CAUTION
Never tamper withany components insideyour set, orany other adjustmentcontrols not mentionedin
this manual. The LCD panelused in thisproduct is madeof glass. Therefore,it can breakWhen the product
is dropped orapplied with impact.Be careful notto be injuredby broken glasspieces in casethe LCD panel
breaks.When you cleanup dust orstick of awater drop onthe LCD panel.The power cord should bepulled
out from theplug receptacle, thenwipe the receiverwith dried softcloth .During thunderand lighting ,
unplug the powercord and antennacord to preventyour TV set from damage.All televisionreceivers are
high voltage instruments.All "insidework" on yourreceiver should beperformed only bythe TV service
personnel.
If some abnormalphenomena happens ,may be youhave some mis-opertion,pleasetake off power and
restart your TV set .
Installation

4
CAUTION
Never tamper withany components insideyour set, orany other adjustmentcontrols not mentionedin
this manual. The LCD panel used in this product is made of glass. Therefore,it can break When the
product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case
the LCD panel breaks.When you clean up dust or stick of a water drop on the LCD panel. The power
cord should be pulled out from the plug receptacle, then wipe the receiver with dried soft Cloth.
During thunder and lighting ,unplug the power cord and antenna cord to prevent your TV set from
damage. All television receivers are high voltage instruments. All "inside work" on your receiver should
be performed only by the TV service personnel.
If some abnormalphenomena happens ,may be youhave some mis-opertion,pleasetake off power and
restart your TV set .
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
The lighting flash with arrow head within a triangle is intended to tell the user that
parts inside the product are a risk of electric shock to persons.
The exclamation point within a triangle is intended to tell the user that important
operating and servicing instructions are in the papers with the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safety Instruction

••••
5
Caution
Do not dropor push objects into the television cabinet slots
or openings. Neverspill any kind of liquid on the television
receiver.
Caution
Do not insertanything in theventilation holes. Ifmetal or
something flammable enters,it may resultin fire orelectric shock.
Caution
Do not placeobjects on thisunit, it maydamage the screensurface.
Caution
Do not squashpower supply cordunder the televisionreceiver.
Caution
Do not throwanything at theset. The screen glass mayexplode by
impact and causeserious injury.
Warnings And Cautions
••••
••••
••••
••••

6
Caution
Never stand on,lean on, or suddenly push the television or its
stand. You should payspecial attention to children. Serious injury
may result ifit should fall.
Caution
Do not placeyour television onan unstable cart, stand ,shelf or
table. Serious injuryto an individual,and damage tothe television,
may result ifit should fall.
Caution
When the televisionreceiver is notused for anextended period of
time, it isadvisable to disconnectthe ACpower cord fromthe AC
outlet .
Caution
Do not blockthe ventilation holesin the backcover.
Adequate ventilation isessential to preventfailure of electrical
component.
Warning
Avoid exposing the television receiverto direct sunlightand other
source of theheat. Do notstand the televisionreceiver directly on
other produces whichgive off heat .E.g.video cassetteplayers.
Audio amplifiers. Donot place nakedflame sources, suchas
lighted candle onthe television. Donot expose theLCD screen
surface to thesun, it maydamage the screensurface.
Warnings And Cautions
••••
••••
••
••
••
••
••••
••••
••••

Warnings And Cautions
7
Takecare not toconnect many appliancesto the samemains
socket as thiscould result infire or electricshock.
High voltages areused in theoperation of thistelevision receiver.
Do not removethe cabinet backfrom your set.Refer servicing to
qualified service personnel.
Toprevent fire orelectrical shock hazard,Do not exposethe
television receiver torain or moisture.
For you ownsafety, Do not touchany part ofthe set, mainlead or
aerial lead duringlighting storms.
Caution
If the televisionis to bebuilt into aCompartment or similarly
enclosed, the minimumdistances must bemaintained.
Heat build-up canreduce the servicelife of yourtelevision, and can
also be dangerous.
Warning
Warning
Warning
Warning
••••
••••
••••
••••
Mindestabstande

Functional Parts( TV )
Front View of LCD Set
Toturn the TV power ON
Put the TV set onthe correct place,then connect theDC plug ofthe AC-DCadaptor to theDC 12V socket
at the backof the TV set. Connectthe adaptor maincord to thewall outlet ,thenthe LED indicatorlamp
turns red/green andthe TV set is atStandby/work Mode.At Standby Mode,if Standby Buttonis pressed
the power indicatorwill change togreen. It takesa few secondsbefore the pictureappears.
Toturn the TV power OFF
Press the StandbyButton to makethe TV set in Standby Mode, then disconnectthe power plugfrom the
wall outlet.
NOTE:
If TV is the selected input without signal received and NO operation is performed for about 5 minutes
continuously, the TV set will enter standby mode. For any inputs other than TV, the TV set will not enter
standby mode automatically without users instruction. If you are not going to use this TV set for a long
time, switch off the set and disconnect the power plug from the wall outlet.
8
2. Remote Sensor
1. LED indicator lamp
3. Standby Button
4. ButtonSource
5. MENU Button
6. P+ Button
7. P- Button
8. V+Button
9. V- Button
10. Repeat
9 8 7 6 5 4
10
1112
13
14
15
V- V+ P- P+ MENU SOURCE
13. Play/Pause
14. Stop
15. Open/Close
12. Preview
11. Next
••••
1 3 2

Functional Parts(DVD)
Switch this LCD-TVSet to DVDstatus, insert thedisk to DVD slot, and the player will suck it in.
Notes:
1.Do not attachany seal orlabel to eitherside (the labeled side or the recorded side) of a disc.
2.Do not useirregularly shaped CDs(e.g., Heartshaped or octagonal)since they may result in
malfunctions.
3.Some playback operationsof DVDs andVideo CDs maybe intentionally programmed by
software manufacturers. This unit plays DVDS and Video CDs according to disc content
designed by thesoftware manufacturer, thereforesome playback featuresmay not be
available or otherfunctions
may be added.
1. DVD Slot
9
1

Rear View Of TV Set
DC IN 12V
HDMI
VGA
VIDEO
YPbPr
SCART
TUNER
NOTE:
Precautions when connecting to other equipment
When using external equipment with this TV set, please read the instruction manual of the external equipment.
Switch off all power supplies to the equipment and TV set before connection.
Always ensure that the input and output terminals are correctly connected.
The UPDATE terminals just use to update the system software.
TUNER PC-A IN SCART
VIDEO LR
YPb Pr
VGA HDMI DC-12V
UPDATE
10

TUNER PC-A IN SCART VIDEO
Y
L
Pb
R
Pr VGA HDMI DC-12V
UPDATETUNER PC-A IN SCART VIDEO
Y
L
Pb
R
Pr VGA HDMI DC-12V
UPDATE
Connecting External Equipment
Connecting a PC
When your PCis connected tothe TV with D-SUB cable and audio cable.
You can view and listen to the PC's video and audio output on the TV. Use the VASE 1440 X 900@60Hz
format to obtainthe best imagequality for yourTV.
Connecting a VCRor other device(E.G.DVD/Digital cable Box/SatelliteReceiver) with composite
video connectors.
Connect the videooutput of thedevice to thecomposite video input (yellow RCA) on the TV. Connect the
line-level audio outputof the deviceto the audio inputs( Red and White RCA) on the TV with AV cable.
BOTTOM
11
BOTTOM
Note: Cable are oftencolor-coded to connectors.Connect red tored, white towhite ,etc.

TUNER PC-A IN SCART VIDEO
Y
L
Pb
R
Pr VGA HDMI DC-12V
UPDATE
TUNER PC-A IN SCART VIDEO
Y
L
Pb
R
Pr VGA HDMI DC-12V
UPDATE
12
Connecting External Equipment
Connecting a DVDPlayer or otherdevice (E.G. VCR/Digitalcable Box/Satellite Receiver) with
Component Video Connectors .
Use a componentvideo cable toconnect the DVDplayer's YPbPr jacks to the TV's YPbPr jacks.
Use an audiocable to connectthe DVD player'sAUDIO OUTjacks to theTV's AUIDOIN jacks . Be sure
to use thesame row ofinput that youused for thevideo connection.
Note: The YPbPr jacks on yourDVD player aresometimes labeled YCbCr, or Y, B-Y and R-Y. if so,
connect the cablesto like colors.
Note: Cable are oftencolor-corded to connectors.Connect red tored, white towhite, etc.
BOTTOM
DVD PIAYER
Connecting a VCRor other device(E.G. DVD/Digital CableBox/ Satellite Receiver)withScart
connectors
Use a SCART video cable to connect the VCR SCART jacks to the TV'S SCART jacks.
Scart cable
BOTTOM

TUNER PC-A IN SCART VIDEO
Y
L
Pb
R
Pr VGA HDMI DC-12V
UPDATE
TUNER PC-A IN SCART VIDEO
Y
L
Pb
R
Pr VGA HDMI DC-12V
UPDATE
Connecting External Equipment
Connecting a DVDwith High-definition multimediaconnectors
Use HDMI cableconnect the DVDHDMI jack tothe TV's HDMI jack.
HDMI
HDMI
Y
COAXIAL
COAXIAL
U/Pb
V/Pr
VIDEO
VIDEO
S-VIDEO
S-VIDEO
LEFT
LEFT
RIGHT
DVD PIAYER
Connecting a televisionsystem and earphone
Use RF cableconnect the antenna / set top box /satellite R.F output jack to the TV's TUNER jack.
Use stereo audiocable to connect the earphone to the TV's earphone jack.
Satellite
Receiver
Toantenna or
set top
box/satellite
R.Foutput.
BOTTOM
13
BOTTOM
HDMI cable

••••
••••
•••••
•••••
•••••
•••••
Operation-Remote Control
Insert Batteries intothe Remote Control
Insert two sizeAAAbatteries by matching the and on the batteries to the diagram insidethe battery
compartment.
Precaution on batteryuse
Improper use ofbatteries can result in a leakage of chemicals and/or explosion. Be sure to follow the
instructions below.
Place batteries withtheir terminals corresponding to the (+) and (-) indications.
Different types ofbatteries have differentcharacteristics .Do notmix batteries ofdifferent types.
Do not mixold and new batteries. Mixing old and new batteries can shorten the life of new batteries
and/or cause oldbatteries to leak chemicals.
Remove batteries assoon as they are non-operable. Chemicals that leak from batteries can cause a
rash .If chemicalleakage is found, wipe with the product may have a shorter life expectancy due to storage
conditions.
If the remotecontrol is notused for an extended period of time, remove the batteries from the remote
control.
Using the RemoteControl
Use the remotecontrol by control by pointing it towards the remote sensor window of the set. Objects
between the remotecontrol and sensor window may prevent proper operation.
Cautions regarding useof remote control:
Do not exposethe remote control to shock. In addition, do not expose the remote control to liquids , and
do not placein an areawith high humidity.
Do not installor place theremote control under direct sunlight. Theheat may causedeformation of the
unit.
The remote controlmay not workproperly if theremote sensor windowof the mainunit is under direct
sunlight or stronglighting. In such a case, change the angle of the lighting or TV set, or operate the remote
control closer tothe remote sensor window.
Note:This above illustationis for reference only. The remote sensor may be in differentlocations on
different models.
14

Operation-Remote Control
BUTTON DESCRIPTIONS
1. POWER
Turn the unit on or off
2. GUIDE
Toaccess the ProgramGuide in DTVmode
3. 0-9 numberbuttons
Use these numberbutton to selectchannel or input
password
4. P.P button
Use to changethe desired picturemode
5. INFO/Display button
Toaccess the programinformation
6. SMODE
Tochange the desiredsound mode
7. AUDIO/NICAM button
Tochange stereo soundmode inATV channels.
Toselect audio languagein DTV channels
8. LIST
Todisplay the channellist in DTV/TVmode
9. Q.view(REVEAL)
Toswitch between thecurrently tuned channeland
the previously tunedchannel.
Toreveal answers thehidden information forsome
Teletextpages(e.g answers topuzzles or riddles).
Press again tohide the information
10. HOLD
Tostop the automaticpage change fromTeletext.
11. MIX
Toenter the mixmode. (For SUBTITLEor
NEWSFLASH teletext page,please use mixmode).
Please again toexit.
12. RADIO
Toswitch to RADIOprogram from DTVprogram in
DTV mode. Pressagain to return.
13. SIZE
Press repeatedly tochange the screendisplay mode
in the teletextmode.
14. INDEX
Togo to theindex page inthe teletext mode
15. TEXT
Press to enteror exit theteletext mode.
15
POWER
P. P
MENU
PROG+
PROG-
VOL+
Q.
VIEW
Q.
VIEW
VOL-
MUTE
NICAM
SOURCE
EXIT
AUDIO
SMODE
ENTER
LIST
GUIDE
INFO
MIX SIZE RADIO
HOLD
SUB.PAGE
TEXTINDEX
OK
2
1
3
8
4
5
6
7
9
10
11
13
12
14
15
16
17
18
19
20
21
22
23
24
25
26
REVEAL
28
27
30
29
31
33
32
34

16. SUB.PAGE
Toenter or exitthe sub.page in the teletext mode
17. MUTE
Tomute the sound
18. SOURCE
Toselect the signalinput source
19. MENU:Toaccess the Menumain page
PROG+/PROG-:Toselect channels upward or
downward , ormove upward or downward in menu
operation.
VOL+/VOL-:Toadjust volume orselected menu item
in menu operation;To move leftor right inmenu
operation.
20. OK(ENTER)
Toconfirm or alterthe settings of the selected menu
item
21 EXIT
Toexit menu
22 SUB.T
Toselect subtitle language or turn on subtitle display
in DTV mode.
23 FAV
Todisplay a desiredfavorite channel list
24 SLEEP
Toset the timeof television toautomatically turn off
25 ASPECT
Tochoose a properscreen aspect ratio
26 color buttons
Used to controlsome operation inmenu item or
teletext mode.
27 direction buttons
Used to directionoperation for MHEG5 program
16
Operation-Remote Control
BUTTON DESCRIPTIONS
POWER
P. P
MENU
PROG+
PROG-
VOL+
Q.
VIEW
Q.
VIEW
VOL-
MUTE
NICAM
SOURCE
EXIT
AUDIO
SMODE
ENTER
LIST
GUIDE
INFO
MIX SIZE RADIO
HOLD
SUB.PAGE
TEXTINDEX
OK
2
1
3
8
4
5
6
7
9
10
11
13
12
14
15
16
17
18
19
20
21
22
23
24
25
26
REVEAL
28
27
30
29
31
33
32
34

Remote Control Operation(DVD)
DVD Mode:
2. OPEN/CLOSE Button
Press OPEN/CLOSE buttonto load discon disc
tray.
10/11. PREV/NEXT Button
Press these buttonto go tothe previous/next
chapter(DVD).
12/13. FR/FF Button
These buttons allowskipping ahead/back at5-
level speed. Press•• PLAY•• button to return to
normal playback.
14. REPEAT Button
To press thisbutton you canrepeatedly play a
title(DVD) or alltracks(CD) .
15. PLAY/PAUSE Button
Press this buttonto start playback.Press this
button again topause playback.
16. STOP Button
Press this buttonto stop DVDplayer.
26. ZOOM button
Press ZOOM duringplayback or stillplayback
to activate theZoom function.
Note:Zoom may notwork on someDVDs.
26. ANGLE button
If the disccontains scenes recordedat different
camera angles, youcan change toa different
camera angle duringplayback.
Note:The angle indicatorwill blink onthe TV
screen during scenesrecordedat different angles
as an indicationthat angle
26. TITLE button
DVD disc:
Press TITLE button,then you canuse " "
and ENTER buttonto select programs.
17
POWER
P. P
MENU
PROG+
PROG-
VOL+
Q.
VIEW
Q.
VIEW
VOL-
MUTE
NICAM
SOURCE
EXIT
AUDIO
SMODE
ENTER
LIST
GUIDE
INFO
MIX SIZE RADIO
HOLD
SUB.PAGE
TEXTINDEX
OK
2
1
3
8
4
5
6
7
9
10
11
13
12
14
15
16
17
18
19
20
21
22
23
24
25
26
REVEAL
28
27
30
29
31
33
32
34

Remote Control Operation(DVD)
DVD Mode:
33. DISPLAY Button
To display playerOSD.
34. GOTO Button
Press this buttonto go todesired position.
26. SLOW Button
Press this buttonduring playback toactivate
the slow function.
28. DVD MENUButton
If play someDVD discs, pressthis button back
to root menuscreen.
29. PROGRAM Button
Place a trackon the programlist.
30. SUBTITLE Button
To press thisbutton, you canchange the
subtitle language fromone selected tothe
initial settings toa different language,if
available.
31. AUDIO Button
To press thisbutton, you canchange the
audio language fromthe one selectedat
settings to adifferent language, ifavailable.
32. DVD SETUPButton
You can enjoypicture frame forwardby
pressing this button.
18
POWER
P. P
MENU
PROG+
PROG-
VOL+
Q.
VIEW
Q.
VIEW
VOL-
MUTE
NICAM
SOURCE
EXIT
AUDIO
SMODE
ENTER
LIST
GUIDE
INFO
MIX SIZE RADIO
HOLD
SUB.PAGE
TEXTINDEX
OK
2
1
3
8
4
5
6
7
9
10
11
13
12
14
15
16
17
18
19
20
21
22
23
24
25
26
REVEAL
28
27
30
29
31
33
32
34
