Denver TFD-2005 User manual

TFD-2005
20.1”LCD TV DVD Combo
USER’S MANUAL

1.Product Features---------------------------------4
2.Accessories----------------------------------------4
3.Front View------------------------------------------5
4.Rear View-------------------------------------------6
5.Remote Control------------------------------------7
6.Quick start-------------------------------------------9
7.OSD menu-----------------------------------------10
8.DVD operation-------------------------------------15
9.User Help Guide-----------------------------------23
10.Technical Specification-------------------------24

TFD-2005
20.1
TFD-2005

10
/DVD
TFD-2005

TFD-2005

6. Quick start
TV
1. Connect the TV set to the power, and connect the TV signal input with the RF jack.
2. Press the POWER button on the TV set to turn on the TV set.
3. Press the TV/AV button on the TV set or remote control, the source menu
will display on the screen as the right picture, use the CH+/- button to
select the source shown, press button to confirm.
4. Press the MENU button on the TV set or the SYS MENU button on the
remote control, the screen will display the OSD menu, press the CH+/-
button to select the third menu-Channel(see the following picture), press
the button to enter the menu, press CH+/- button to select the item
"Auto Tune", press button, it will start searching channels from the lowest
frequency. When it finds a station it will automatically store it in the first location and move
to the next. When Auto Tune is complete, the TV will display the first station found. In most
cases the stored stations will be in the random order, therefore you should use the
"Channel Swap" function to exchange them into the order you need.
Note: when the Auto Tune starts, you can press SYS MENU button to stop it or it will not stop
until all the searching is finished.
DVD
1. Press the TV/AV button to display the source menu, use the CH+/- button to select the source
DVD, press button to confirm.
2. Insert the disc into the DVD player with the label side face away. Then the disc will play
automatically.
PC
1. Connect the TV set to the PC with the VGA and PC audio jacks.
2. Press the TV/AV button to display the source menu, use the CH+/- button to select the source
PC, press button to confirm. Then the TV set will display the signal from PC.
TV
AV
S-VIDEO
DVD
SCART
PC
Channel
Move Select Exit
Auto Tune
Manual Tune
Fine Tune
Skip
Sound.SYS
Channel Swap
Off
D/K

FULL

Sound Mode: select the sound mode----User, Normal, Movie, News.
You can also use the SOUND button on the remote control to select.
Volume: adjust the volume of the sound.
You can also use the VOL+/- button on the remote control or TV set to adjust the volume.
Bass: adjust the bass of the sound.
Treble: adjust the treble of the sound.
Balance: adjust the balance of the sound.
Sound
Move Select Exit
Sound Mode
Volume
Bass
Treble
Balance
New
7.2 Sound menu

Channel
Move Select Exit
Channel1
Channel2
Swap
3
4
Channel Swap: press the button to enter the swap menu as the following picture.
Use the CH+/- button to select "Channel1" or "Channel2", use the / buttons to select the
two channels you want to swap, when you confirm, select "Swap", and press button to swap.
Function
Move Select Exit
Language
Blue Back
TXT Language
Color Temp.
DNR
Reset
Timer
English
on
EAST
User
Normal
7.4 Function menu
Language: select the OSD's display language.
Blue Back: turn on/off the blue back function(the function can only be used in the mode of TV).
TXT Language: select the area of the Teletext language.
Color Temp.: Adjust the color temperature. You can select Cool, Warm, Normal, or you can select
User that you can adjust the red, green and blue color temperature.
DNR:press the key to choose "Normal" or "Strong" to reduce picture interfere.
Reset: when you press the button on the item, it will reset all the settings.

Program Play
1.Compatible with DVD, SVCD, VCD, CD, HD-CD, WMA, Digital audio disc/JPEG discs.
2.The Program Playback option allows you to enter the order in which you want chapters or tracks
to play, maximum to 16.
3.Program Menu:
If PBC is on, this operation will turn PBC off while the chapters / tracks plays in programmed
order.
4.According to the highlight, use the Numeric buttons to enter the chapters / tracks in the order
you want them to play. Then press Play or use Arrow buttons to highlight the “PLAY” item and
press Enter. The chapters / tracks will play in the programmed order. You can program
maximum 16 titles / chapters / tracks.
5.According to the Direction Indicator on the menu, you can press Arrow buttons to highlight
where you want to enter.
6.During Program Playback, if program button is repressed, the program order and the contents
will be displayed on the screen, and the Program Playback will be stopped; also you can press
Stop and Play to resume normal playback.
7.Notes:
To clear the program order, use Arrow buttons to highlight the “CLEAR” item,then press Enter.
To modify the program order, use Arrow buttons to highlight the item you are changing and enter
the new chapter / track you want to program directly.
8.The program indicator in the screen, and the playing chapter / track illuminate.
Additional operation
Selecting Tracks
1.Compatible with DVD, SVCD, VCD, CD, HD-CD, WMA, Digital audio disc/JPEG discs.
2.When playing a DVD disc, press Numeric buttons on the menu or title page to select tracks;
During DVD playback, you can input desired title numbers directly.
3.During sequence playback of a SVCD or VCD disk, press the numeric buttons to select tracks.
(During Program Playback and when the PBC is on, you can only press Prev / Next button to
select)
4.As for CD, HD-CD, discs, press Numeric buttons directly to select tracks.
5.When playing WMA, Digital audio disc / JPEG discs, press Numeric buttons to select different
tracks on current track list.
Skipping Tracks
1.Compatible with DVD, SVCD, VCD, CD, HD-CD, WMA, Digital audio disc/JPEG discs.
2.To skip forward to the beginning of the next title / chapter / track on a disc, press Next on the
remote or the right side of the player.
3.To skip backward to the beginning of the preceding title / chapter / track on a
disc, press Prev on the remote or the right side of the player.

four

Using the Search Feature
1.Compatible with DVD, SVCD, VCD, CD, HD-CD discs.
2.You can use Search feature to select a title / chapter / track number or go to a specific point in
a title. First, press Search button on the remote controller to bring up the search menu and enter
the edit state; Secondly, press Arrow buttons to highlight the title / chapter / track number or the
time option; Thirdly, use Numeric buttons to enter the title / chapter / track you want to play or
the elapsed time you want to go to in that title; At last, press Enter button to start playback. For
example, entering 01:23:56 will start playback one hour, twenty-three minutes and fifty-six
seconds into the title.
3.Notes
a）This feature does not work in Program Play mode.
b）If PBC is on, it will turn off automatically when Search Playback starts.
c）When playing WMA, Digital audio disc / JPEG discs, Search Feature does not work.
Changing the Soundtrack or Language
1.Compatible with DVD SVCD, VCD, CD, HD-CD, WMA, Digital audio disc/JPEG discs.
2.Press the LANGUAGE button to display current soundtrack.
A）Press the button to switch soundtracks.
b）Press the button again on the remote to turn to next soundtrack.
3.When playing a SVCD or VCD disc, there are five soundtracks: Stereo (L/R), L/L, R/R, L/L Auto
A/D Detect, and R/R Auto A/D Detect. With each consecutive press of the button, the soundtrack
switches. If you press the button six times, soundtrack cycles back to Stereo.
4.When playing a CD, HD-CD, WMA, or Digital audio disc, there are three: Stereo (L/R), L/L,
and R/R.
5.When playing a DVD or SVCD disc, press LANGUAGE button to display current language, press
the button again to turn to next language if the disc has different languages.
Subtitles
1.Compatible with DVD, SVCD discs.
2.Press the Subtitle button on the remote once, and the subtitle info banner appears.
3.When a DVD or SVCD is recorded with subtitles, you can use the Subtitle feature to view the
subtitles on-screen. By default, subtitles are off. The info banner will display Subtitle Off.
4.To display subtitles, press the Subtitle button again. The default language with its responding
serial number will be displayed in the info banner and subtitles will be displayed in that language.
With each consecutive press of the Subtitle button, the subtitle switches. For
example, “Language Icon: [1 English DTS 6CH] or [Off]” (the availability of the subtitles are
disc-dependent). To turn subtitles off, press the Subtitle button until Subtitle Off is displayed.
