Desoutter 2051475314 User manual

www.desouttertools.com
WARNING
WARNING
To reduce the risk of injury, before using or servicing tool, read and understand
the following information as well as separately provided safety instructions (Item
number: 354343).
24
AVERTISSEMENT
Avant toute utilisation ou intervention sur l’outil, veillez à ce que les informations
suivantes ainsi que les instructions fournies dans le guide de sécurité (Code
article : 354343) aient été lues, comprises et respectées.
26
ADVERTENCIA
Antes de utilizar la herramienta o intervenir sobre ella, asegúrense de que la
información que gura a continuación, así como las instrucciones que aparecen
en la guía de seguridad (Código artículo: 354343) han sido leídas, entendidas y
respetadas.
28
WARNUNG
Werkzeuge erst benutzen, wenn die nachstehenden Hinweise und die Regeln des
Sicherheitsleitfaden (Artikel-Nr. 354343) gelesen und verstanden wurden.
30
AVVISO
Prima di qualsiasi utilizzazione o intervento sull’attrezzo, vericate che le
informazioni che seguono e le istruzioni contenute nella guida di sicurezza
(Codice articolo: 354343) siano state lette, comprese e rispettate.
32
AVISO
Antes de utilizar ou intervir na ferramenta, leia atentamente e respeite as
informações seguintes assim como as instruções fornecidas no manual de
segurança
(Código artigo: 354343).
34
VARNING
Läs noga igenom dessa säkerhetsinstruktioner liksom anvisningarna i
säkerhetsguiden (Artikelkod: 354343) innan du börjar använda verktyget.
36
ADVARSEL
Før enhver bruk eller reparasjon av verktøyet skal de følgende instruksjonene og
forskriftene i sikkerhetsheftet (artikkelnummer: 354343) leses nøye.
37
30° Compact 2051475314 ... 2051475404
90° Compact 2051475434 ... 2051475524
360° Compact 2051475454 ... 2051475644
45° Compact 2051475654 ... 2051475824
90° Standard 2051475834 ... 2051476004
360° Standard 2051476014 ... 2051476184
Part number 2050504723
Issue no 16
Series D
Date 07/2015
Page 1 / 68
DR300-AH angle head drills

2050504723
Issue no: 16
Series: D
07/20152 / 68
VARELSE
Læs omhyggeligt, forstå og overhold disse instruktioner samt
sikkerhedsforskrifterne (Varenummer: 354343), inden værktøjet tages i brug eller
repareres.
38
WAARSCHUWING
Voor gebruik of demontage van het gereedschap altijd eerst zekerstellen dat de
navolgende informatie evenals de geleverde veiligheidsinstructies
(Code artikel: 354343) gelezen, begrepen en in acht genomen zijn.
40
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
Πριν από οποιαδήποτε χρήση ή επέμβαση στο εργαλείο, διαβάστε προσεκτικά,
κατανοήστε και τηρήστε τις παρακάτω πληροφορίες, καθώς και τις οδηγίες που
περιλαμβάνονται στο εγχειρίδιο ασφαλείας (Κωδικός προϊόντος: 354343).
42
警告
为降低被伤害的风险，在使用或维修工具之前，请阅读并理解以下信息及单独提供
的安全说 明 （项目号：354343）
44
VIGYÁZAT
A szerszám használata vagy bármilyen más beavatkozás előtt a felhasználónak
el kell olvasnia, meg kell értenie és a használat vagy beavatkozás során be kell
tartania a következő, valamint a biztonsági útmutatóban (cikkszám: 354343)
szereplő utasításokat.
46
BRĪDINĀJUMS
Lai mazinātu bīstamību, pirms apkopes instrumenta lietošanas jāizlasa un jāizprot
turpmākā informācija, kā arī atsevišķi dotie drošības tehnikas noteikumi (preces
numurs: 354343).
48
OSTRZEŻENIE
Przed podjęciem użytkowania przyrządu czy jakichkolwiek działań z
nim związanych – należy upewnić się, że instrukcje dostarczone razem
z podręcznikiem d/s bezpieczeństwa (Kod urządzenia: 354343) zostały
przeczytane, zrozumiane i będą przestrzegane.
50
VAROVÁNÍ
Aby nedošlo ke zranění, seznamte se před použitím či údržbou nástroje s
následujícími informacemi a zvlášt’dodávanými bezpečnostními pokyny
(kat.č. 354343).
52
UPOZORNENIE
Aby sa znížilo riziko poranenia, prečítajte si nasledujúce informácie, ako aj
osobitne priložené bezpečnostné opatrenia (položka číslo 354343) a snažte sa im
porozumiet’.
54
OPOZORILO
Zaradi morebitnih poškodb, pred uporabo ali servisiranjem orodja, preberite in
upoštevajte naslednje informacije, kakor tudi posebej priložena varnostna navodila
(postavka št.: 354343).
56
ĮSPĖJIMAS
Siekiant sumažinti sužeidimo pavojų, prieš naudodami arba taisydami įrankį
perskaitykite ir įsidėmėkite toliau išdėstytą informaciją, o taip pat ir atskirai
pateiktas saugos instrukcijas (dalies numeris: 354343).
58
ПРЕДУПРЕЖДЕНИЕ
До использования или вмешательства на инструменте необходимо
прочитать, усвоить и соблюдать нижеследующую информацию, а также
указания, приведенные в пособии по технике безопасности (Артикул товара :
354343).
60
ПЕРЕД НАЧАЛОМ ЭСКПЛУАТАЦИИ ДАННОГО ИНСТРУМЕНТА СЛЕДУЕТ
ВНИМАТЕЛЬНО ИЗУЧИТЬ ПРАВИЛА ТЕХНИКИ БЕЗОПАСНОСТИ ПРИ РАБОТЕ С
ПНЕВМАТИЧЕСКИМ СВЕРЛИЛЬНЫМ И РЕЗЬБОНАРЕЗНЫМ ИНСТРУМЕНТОМ,
ЧАСТЬ № 354343.
62

2050504723
Issue no: 16
Series: D
07/2015 3 / 68
3m
Ø6mm (1/4") Pmax 6.3 barPmin 4.0 bar Ø12.5 mm (1/2")
ISO VG15
AIR CONNECTION - Fig.1
Find more information and your Desoutter contacts on:
www.desouttertools.com
Software and documentation available at:
http://resource-center.desouttertools.com
No login/password required.

2050504723
Issue no: 16
Series: D
07/20154 / 68
COMPLETE TOOL ASSEMBLY
3
4
5
6
7
7*
8
8
8
8
8
8
2
1
A
20Nm
A
20Nm
ALoctite 243

2050504723
Issue no: 16
Series: D
07/2015 5 / 68
Item Description Part number
1Kit adaptor 1/4" BSP 472633
2Kit adaptor 1/4" NPT 472623
3 Straight grip 2050552063
4 Gasket 2050504523
5 Motor 550 / 1000 / 3000 / 5500 rpm 2050500743
5 Motor 4500 rpm 2050500753
5 Motor 2000 rpm 2050491473
6 Gearbox 550 rpm 2050505493
6 Gearbox 1000 rpm 2050505483
6 Gearbox 2000 rpm 2050505443
6 Gearbox 3000 rpm 2050505453
6 Gearbox 4500 rpm 2050505473
6 Gearbox 5500 rpm 2050505463
7 Spacer yellow (T550) 2050550083
7 Spacer green (T1000) 2050550073
7 Spacer red (T2000) 2050550063
7 Spacer blue (T3000) 2050550053
7 Spacer purple (T4500) 2050550043
7 Spacer orange (T5500) 2050550033
7* Spacer (only T550 & T1000) 2050494473
8 Angle head 45°cpt (collet) 2050503993
8 Angle head 45° cpt ¼ x 28 UNF 2050504003
8 Angle head 360° std (collet) 2050504113
8 Angle head 360° std ¼ x 28 UNF 2050504123
8 Angle head 90° std (collet) 2050504053
8 Angle head 90° std ¼ x 28 UNF 2050504063
8 Angle head 90° cpt (collet) 2050495803
8 Angle head 90° cpt ¼ x 28 UNF 2050495813
8 Angle head 360° cpt (collet) 2050503953
8 Angle head 360° cpt ¼ x 28 UNF 2050503963
8 Angle head 30° cpt (collet) 2050503873
8 Angle head 30° cpt ¼ x 28 UNF 2050503883

2050504723
Issue no: 16
Series: D
07/20156 / 68
STRAIGHT GRIP
A
8 Nm
8 Nm
8 Nm
Loctite 480
A
64
5
3
1
2
7
8
9
10
11
12 13
15
14
Item Description Part number Qty
1Kit adaptor 1/4" BSP 472633 1
2Kit adaptor 1/4" NPT 472623 1
3 Air feed bolt DR300 2050545283 1
4 Filter 252183 1
5 Inlet O-Ring 450803 1
6 Exhaust grid 2050506083 1
7 O-Ring 27x1.5 6156582960 1
8 Sintered bronze silencer 2050505793 1
9Air deector 2050505803 1
10 Straight case valve spring 466453 1
11 Kit valve/plunger/O-Ring (includes 5, 11 and 14) 6151431640 1
12 Seat valve 472673 1
13 Needle 2.5x23.8 6157901450 1
14 Plunger 2050504563 1
15 Safety lever 2050502883 1

2050504723
Issue no: 16
Series: D
07/2015 7 / 68
MOTOR
Motor 7T (550, 1000, 3000, 5500 rpm) 2050500743
Item Description Part number Qty
1Bearing 4x13x5 216663 1
2 Pin 2.0 x 8 222423 1
3 Housing, bearing rear 2050503723 1
4 Rotor 2050490983 1
5Blade, rotor radial 2050491113 5
6 Cylinder 2050503713 1
7 Housing, bearing front 2050549363 1
8Bearing 7x22x7 282123 1
Motor 12T (4500 rpm) 2050500753
Item Description Part number Qty
1Bearing 4x13x5 216663 1
2 Pin 2.0 x 8 222423 1
3 Housing, bearing rear 2050503723 1
4 Rotor 2050497763 1
5Blade, rotor radial 2050491113 5
6 Cylinder 2050503713 1
7 Housing, bearing front 2050549363 1
8Bearing 7x22x7 282123 1
Motor 5T (2000 rpm) 2050491473
Item Description Part number Qty
1Bearing 4x13x5 216663 1
2 Pin 2.0 x 8 222423 1
3 Housing, bearing rear 2050503723 1
4 Rotor 2050490973 1
5Blade, rotor radial 2050491113 5
6 Cylinder 2050503713 1
7 Housing, bearing front 2050549363 1
8Bearing 7x22x7 282123 1
Grease Molykote G68
A
27652 ISO VG15
B
0.040
0.025
8
2
7
6
5
3
4
1
A B A

2050504723
Issue no: 16
Series: D
07/20158 / 68
GEARBOX - MODULE ASSEMBLY
Grease Molykote G68
A1
1
17
8
8
9
15
10
13
14
11
12
9
10
11
12
2
2
16
3
3
4
4
5
5
6
6
7
7
5
6
7
A
A
A

2050504723
Issue no: 16
Series: D
07/2015 9 / 68
GEARBOX - MODULE ASSEMBLY
Gearbox Gearbox (550 rpm) 2050505493 Gearbox (1000 rpm) 2050505483 Gearbox (2000 rpm) 2050505443 Gearbox (3000 rpm) 2050505453 Gearbox (4500 rpm) 2050505473 Gearbox (5500 rpm) 2050505463
Item Description Part number Qty
1 Pinion sleeve 7T to 15T 2050491103 1 1
2 O-Ring 22x1.5 455653 1 1 1 1 1 1
3 Plate back dia. 22.0x1.5 2050491093 1 1 1 1 1 1
4 Gearcase - M28 2050491013 1 1 1 1
4 Gearcase - M28 2050492963 1 1
5 Needle 2.5x15.8 6157900480 6 6 3 3 3 3
6 Needle roller 2050491133 6 6 3 3 3 3
7 Wheel planet, 19T 2050491063 3
7 Wheel planet, 17T 2050491073 3 3
7 Wheel planet, 14T 2050491083 3 3
7 Wheel planet, 16T 2050493833 3
7 Wheel planet, 15T 2050493023 3 3
8 Shield 2050505863 1 1 1 1 1 1
9 Cage, output 2000 rpm 2050505813 1
9 Cage, output 3000 rpm 2050505823 1
9 Cage, output 5500 rpm 2050505833 1
9 Cage, output 550 / 4500 rpm 2050505853 1 1
9 Cage, output 1000 rpm 2050505843 1
10 Washer plain 2050505993 1 1 1 1 1 1
11 Bearing 15x24x5 758.49 1 1 1 1 1 1
12 Ring internal 2050505423 1 1 1 1 1 1
13 Pinion sleeve 9T (without hex) 2050493813 1
14 O-Ring 4x1 6156582620 1
15 Cage: 1st Stage 1000 rpm 2050491043 1
15 Cage: 1st Stage 550 rpm 2050492973 1
16 Washer plain 20x12x0.5 392513 1 1
17 Pinion sleeve 12T 2050493003 1

2050504723
Issue no: 16
Series: D
07/201510 / 68
OUTPUT 45° COMPACT
Model Part number
DR300-T550-T5-45 2051475654
DR300-T550-S5-45 2051475664
DR300-T1000-T5-45 2051475684
DR300-T1000-S5-45 2051475694
DR300-T2000-T5-45 2051475714
DR300-T2000-S5-45 2051475724
DR300-T3000-T5-45 2051475744
DR300-T3000-S5-45 2051475754
DR300-T4500-T5-45 2051475774
DR300-T4500-S5-45 2051475784
DR300-T5500-T5-45 2051475804
DR300-T5500-S5-45 2051475814
1
2
18
3
5
7
8
9
10
11
12 64
14
15
12
13
10
Loctite 270
B
Grease Molykote BR2 Plus
C
C
B
5 Nm
10 Nm 10 Nm
17
16

2050504723
Issue no: 16
Series: D
07/2015 11 / 68
Angle head 45° Compact
Item Description Part number Qty Remarks
1Ball bearing 392053 1
2 Shaft A/H 45° STD 2050534263 1
3 Spring compression 2050497853 1
4 Spring cylindrical 2050504933 2
5 Stop pin 2050504943 2
6Body connector 45° STD 2050534253 1
7 End cap drill AH 2050504873 1
8 Ring lock 2050504903 1
9 Spring ring 6156890340 1
10 Spacer kit 2050560493 1
11 Ball bearing 2050560503 1
12 Spiral bever gear set 2050553053 1
13 Ball bearing 2050436543 2
14 Drill spindle 5mm Collet 2050560463 1
14 Nut 2050560513 1
15 Collet 4,8 mm 2552 1
16 Drill spindle 1/4"X28unf 2050560473 1
18 45 CPT A/H sub-assembly - 5mm Collet 2050505923 1
18 45 CPT A/H sub-assembly - 1/4"X28unf 2050505933 1
OUTPUT 45° COMPACT

2050504723
Issue no: 16
Series: D
07/201512 / 68
OUTPUT 360° STANDARD
Model Part number
DR300-T550-T6-360 2051476014
DR300-T550-S6-360 2051476024
DR300-T1000-T6-360 2051476044
DR300-T1000-S6-360 2051476054
DR300-T2000-T6-360 2051476074
DR300-T2000-S6-360 2051476084
DR300-T3000-T6-360 2051476104
DR300-T3000-S6-360 2051476114
DR300-T4500-T6-360 2051476134
DR300-T4500-S6-360 2051476144
DR300-T5500-T6-360 2051476164
DR300-T5500-S6-360 2051476174
1
3
6
222324 20 14
2
7
8
9
10
11
21 13
13
12
15
16
10
11
17
18
14
10Nm
10Nm
10Nm
C
C
C
C
Grease Molykote BR2 Plus
C
Loctite 270
B
4
19
5
B
10Nm
B
5 Nm
5 Nm
10Nm

2050504723
Issue no: 16
Series: D
07/2015 13 / 68
Angle head 360° Standard 2050504113 & 2050504123
Item Description Part number Qty Remarks
1Shaft A/H 2050504893 1
2Bearing 9x24x7 629 2Z 392053 1
3 End cap drill 2050504873 1
4 Stop pin 2050504943 2
5 Spring, cylindrical 2050504933 2
6 Spring, compression 2050497853 1
7Body, connector standard A/H 2050504923 1
8 Ring lock 2050504903 1
9 Ring spring ext. 6156890340 1
12 360 housing A/H 1st angle 2050502223 1
15 Spindle 360 Std 2050505893 1
16 Spacer A/H 360 Std 2050505913 1
17 Nut spindle 360 Std 2050505903 1
18 360 housing A/H 2nd angle 2050502233 1
20 Spindle Std 1/4”x 28 UNF 2050504753 1 For 2050504123 only
21 Output spindle collet 6.4mm 2050504773 1 For 2050504113 only
22 Nut spindle A/H Std 2050504783 1
23 Collet 6.4mm bore 19182 1 For 2050504113 only
24 Collet nut 2050504793 1 For 2050504113 only
Kit gear 360° Standard 2050505403
Item Description Part number Qty Remarks
10 Bearing 6x15x5 6157581340 2
11 Gear pinion - 90 Std 2050490943 2
13 Gear - 90 Std 2050490953 2
14 Bearing 8x16x5 280663 2
19 Bearing 4x9x2.5 280953 1
OUTPUT 360° STANDARD

2050504723
Issue no: 16
Series: D
07/201514 / 68
OUTPUT 90° STANDARD
1
3
6
5
4
2
7
8
9
10
11
12
10Nm
10Nm
10Nm
C
Grease Molykote BR2 Plus
C
Loctite 270
B
B
13
14
15
16
17
18
19
20
C
5 Nm
Model Part number
DR300-T550-T6-90 2051475834
DR300-T550-S6-90 2051475844
DR300-T1000-T6-90 2051475864
DR300-T1000-S6-90 2051475874
DR300-T2000-T6-90 2051475894
DR300-T2000-S6-90 2051475904
DR300-T3000-T6-90 2051475924
DR300-T3000-S6-90 2051475934
DR300-T4500-T6-90 2051475954
DR300-T4500-S6-90 2051475964
DR300-T5500-T6-90 2051475984
DR300-T5500-S6-90 2051475994

2050504723
Issue no: 16
Series: D
07/2015 15 / 68
Angle head 90° Standard 2050504053 & 2050504063
Item Description Part number Qty Remarks
1Shaft A/H 2050504893 1
2Bearing 9x24x7 392053 1
3 End cap drill 2050504873 1
4 Stop pin 2050504943 2
5 Spring, cylindrical 2050504933 2
6 Spring, compression 2050497853 1
7Body, connector standard A/H 2050504923 1
8 Ring lock 2050504903 1
9 Ring spring ext. 6156890340 1
10 Bearing 6x15x5 6157581340 1
11 Gear pinion - 90 Std 2050490943 1
12 90 Std A/H housing 2050495703 1
13 Bearing 4x9x2.5 280953 1
14 Gear - 90 Std 2050490953 1
15 Bearing 8x16x5 280663 1
16 Output spindle collet 6.4mm 2050504773 1 For 2050504053 only
17 Spindle Std 1/4” x 28 UNF 2050504753 1 For 2050504063 only
18 Nut spindle- A/H Std 2050504783 1
19 Collet 6.4mm 19182 1 For 2050504053 only
20 Collet nut 2050504793 1 For 2050504053 only
OUTPUT 90° STANDARD

2050504723
Issue no: 16
Series: D
07/201516 / 68
OUTPUT 90° COMPACT
1
3
6
5
4
2
7
8
9
10
11
10Nm
10Nm
10Nm
C
Grease Molykote BR2 Plus
C
Loctite 270
B
13
12
14
15
16
17
18
19
C
B
5 Nm
Model Part number
DR300-T1000-T5-90 2051475434
DR300-T1000-S5-90 2051475444
DR300-T2000-T5-90 2051475454
DR300-T2000-S5-90 2051475464
DR300-T3000-T5-90 2051475474
DR300-T3000-S5-90 2051475484
DR300-T4500-T5-90 2051475494
DR300-T4500-S5-90 2051475504
DR300-T5500-T5-90 2051475514
DR300-T5500-S5-90 2051475524

2050504723
Issue no: 16
Series: D
07/2015 17 / 68
Angle head 90° Compact 2050495803 & 2050495813
Item Description Part number Qty Remarks
1Shaft A/H 2050504893 1
2Bearing 9x24x7 392053 1
3 End cap drill 2050504873 1
4 Stop pin 2050504943 2
5 Spring, cylindrical 2050504933 2
6 Spring, compression 2050497853 1
7Body, connector compact A/H 2050504913 1
8 Ring lock 2050504903 1
9 Ring spring ext. 6156890340 1
12 90 Cpt A/H housing 2050494533 1
16 Spindle 1/4”x28 UNF 2050494553 1 For 2050495813 only
17 Spindle collet- 5mm 2050494563 1 For 2050495803 only
18 Collet 5mm 2552 1 For 2050495803 only
19 Nut-spindle 2050494573 1
Kit gear 90° Compact 2050505283
Item Description Part number Qty Remarks
10 Bearing 6x13x3.5 2050491513 1
11 Gear pinion - 90 Cpt 2050490533 1
13 Bearing 4x9x2.5 280953 1
14 Gear - 90 Cpt 2050490543 1
15 Bearing 7x14x3.5 758.15 1
OUTPUT 90° COMPACT

2050504723
Issue no: 16
Series: D
07/201518 / 68
OUTPUT 360° COMPACT
Model Part number
DR300-T1000-T5-360 2051475554
DR300-T1000-S5-360 2051475564
DR300-T2000-T5-360 2051475574
DR300-T2000-S5-360 2051475584
DR300-T3000-T5-360 2051475594
DR300-T3000-S5-36 2051475604
DR300-T4500-T5-360 2051475614
DR300-T4500-S5-360 2051475624
DR300-T5500-T5-360 2051475634
DR300-T5500-S5-360 2051475644
1
3
6
22 21 14
2
7
8
9
10
11
12
23 20 13
13
14
15
16
10
11
17
18
10Nm
10Nm
10Nm
C
C
Grease Molykote BR2 Plus
C
Loctite 270
B
4
19
5
10Nm
C
C
B
5 Nm
B
5 Nm
10Nm

2050504723
Issue no: 16
Series: D
07/2015 19 / 68
Angle head 360° Compact 2050503953 & 2050503963
Item Description Part number Qty Remarks
1Shaft A/H 2050504893 1
2Bearing 9x24x7 392053 1
3 End cap drill 2050504873 1
4 Stop pin 2050504943 2
5 Spring, cylindrical 2050504933 2
6 Spring, compression 2050497853 1
7Body, connector compact A/H 2050504913 1
8 Ring lock 2050504903 1
9 Ring spring ext. 6156890340 1
12 360 Cpt A/H housing 1st angle 2050495723 1
15 Spindle, 360 Cpt 2050505563 1
16 Spacer A/H 360 Cpt 2050505583 1
17 Nut, spindle - 360 Cpt 2050505573 1
18 360 Cpt A/H housing 2nd angle 2050495733 1
20 Spindle 1/4”x28UNF 2050494553 1 For 2050503963 only
21 Spindle collet- 5mm 2050494563 1 For 2050503953 only
22 Collet 4.8mm 2552 1 For 2050503953 only
23 Nut-spindle 2050494573 1
Kit gear 360 Compact 2050505293
Item Description Part number Qty Remarks
10 Bearing 6x13x3.5 2050491513 2
11 Gear pinion - 90 Cpt 2050490533 2
13 Gear - 90 Cpt 2050490543 2
14 Bearing 7x14x3.5 758.15 2
19 Bearing 4x9x2.5 280953 1
OUTPUT 360° COMPACT

2050504723
Issue no: 16
Series: D
07/201520 / 68
Angle head 30° Compact 2050503873 & 2050503883
Item Description Part number Qty Remarks
1Shaft A/H 350W 2050504893 1
2Bearing 9x24x7 392053 1
3 End cap drill 2050504873 1
4 Stop pin 2050504943 2
5 Spring, cylindrical 2050504933 2
6 Spring, compression 2050497853 1
7Body, connector compact A/H 2050504913 1
8 Ring lock 2050504903 1
9 Ring spring ext. 615890340 1
12 30 Cpt angle head body 2050501943 1
15 Spindle 1/4”x28UNF 2050505013 1 For 2050503883 only
16 Spindle collet- 5mm 2050505023 1 For 2050503873 only
17 Collet 4.8mm 2552 1 For 2050503873 only
18 Nut-spindle 2050494573 1
OUTPUT 30° COMPACT
1
3
6
18
15
2
7
8
9
10
11
12
10Nm
10Nm
10Nm
C
Grease Molykote BR2 Plus
C
Loctite 270
B
4
13
16
17
14
5
B
5 Nm
Models Part number
DR300-T550-T5-30 2051475294
DR300-T550-S5-30 2051475304
DR300-T1000-T5-30 2051475314
DR300-T1000-S5-30 2051475324
DR300-T2000-T5-30 2051475334
DR300-T2000-S5-30 2051475344
DR300-T3000-T5-30 2051475354
DR300-T3000-S5-30 2051475364
DR300-T4500-T5-30 2051475374
DR300-T4500-S5-30 2051475384
DR300-T5500-T5-30 2051475394
DR300-T5500-S5-30 2051475404
