RGBlink FLEX DS1 User manual

Article No: RGB-RD-UM-DS1 C001
Revision No: V1.0
FLEX DS1
USER MANUAL

FLEX DS1 User Manual
CONTENTS
CONTENTS........................................................................................................................................................ 1
Declarations..................................................................................................................................................... 2
FCC/Warranty...........................................................................................................................................2
Operators Safety Summary......................................................................................................................3
Installation Safety Summary.................................................................................................................... 3
Chapter 1 Your Product.................................................................................................................................... 1
1.1 In the Box........................................................................................................................................... 1
1.2 Product Overview.............................................................................................................................. 2
1.2.1 Rear Panel............................................................................................................................... 3
1.2.2 Dimension............................................................................................................................... 4
Chapter 2 Installing Your Product.................................................................................................................... 5
2.1 Plugging in Signals..............................................................................................................................5
2.2 Plugging in Main Power..................................................................................................................... 5
2.3 IP Settings...........................................................................................................................................6
2.4 DHCP.................................................................................................................................................. 7
Chapter 3 Using Your Product.......................................................................................................................... 9
3.1 Understanding the MENU Structure................................................................................................. 9
3.2 Using the MENU...............................................................................................................................10
3.2.1 Design................................................................................................................................... 10
3.2.2 Scheduler.............................................................................................................................. 22
3.2.3 Controller.............................................................................................................................. 24
3.2.4 Language...............................................................................................................................28
Chapter 4 Ordering Codes..............................................................................................................................29
4.1 Product.............................................................................................................................................29
4.2 Sending Card.................................................................................................................................... 29
Chapter 5 Support ........................................................................................................................................ 30
5.1 Contact Us........................................................................................................................................30
Chapter 6 Appendix........................................................................................................................................31
6.1 Specification.....................................................................................................................................31
6.2 System Upgrade............................................................................................................................... 33
6.3 Terms & Definitions......................................................................................................................... 35
6.4 Revision History............................................................................................................................... 39

FLEX DS1 User Manual
Thank you for choosing our product!
This User Manual is designed to show you how to use this video processor quickly and make use of all
the features. Please read all directions and instructions carefully before using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area may cause harmful interference, in which case the user will be
responsible for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally stipulated
terms of guarantee. On receipt, the purchaser must immediately inspect all delivered goods for
damage incurred during transport, as well as for material and manufacturing faults. RGBlink must be
informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and
software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of
justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion
within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can
demand a reduction in the purchase price or cancellation of the contract. All other claims, in particular
those relating to compensation for direct or indirect damage, and also damage attributed to the
operation of software as well as to other service provided by RGBlink, being a component of the system
or independent service, will be deemed invalid provided the damage is not proven to be attributed to
the absence of properties guaranteed in writing or due to the intent or gross negligence or part of
RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if
the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if,
after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all
guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are
system failures which are attributed to programs or special electronic circuitry provided by the purchaser,
e.g. interfaces. Normal wear as well as normal maintenance are not subject to the guarantee provided by
RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in this
manual must be complied with by the customer.

FLEX DS1 User Manual
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous
voltages. To avoid personal injury, do not remove the top cover. Do not operate the unit without the
cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts rms
between the supply conductors or between both supply conductor and ground. A protective ground
connection by way of grounding conductor in the power cord is essential for safe operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical shock,
plug the power cord into a properly wired receptacle before connecting to the product input or output
terminals. A protective-ground connection by way of the grounding conductor in the power cord is
essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is in good
condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating
characteristics. Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
Installation Safety Summary
Safety Precautions
For all processor installation procedures, please observe the following important safety and handling
rules to avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire
provided in the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.
Unpacking and Inspection
Before opening shipping box, inspect it for damage. If you find any damage, notify the shipping carrier

FLEX DS1 User Manual
immediately for all claims adjustments. As you open the box, compare its contents against the packing
slip. If you find any shortages, contact your sales representative.
Once you have removed all the components from their packaging and checked that all the listed
components are present, visually inspect the system to ensure there was no damage during shipping. If
there is damage, notify the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your product should be clean, properly lit, free from static, and
have adequate power, ventilation, and space for all components.

Chapter 1: Your Product
1
Chapter 1 Your Product
1.1 In the Box
Note:
The USB file contains Warranty/Registration Card.
AC Power Cord supplied as standard according to the destination market.
Power cable
USB cable
DVI cable
DUAL LINK to
DVI+VGA cable
Screwdriver
Anti-static bag
Certificate of
Qualification
Warranty card
&USB file

Chapter 1: Your Product
2
1.2 Product Overview
FLEX DS1 is a video processor that can be only operated on Google Chrome. It can be connected
to the PC through the LAN port at the rear panel, and completely operated on Chrome. Concise
but complete, it can be used to schedule and play programs in restaurants (menu and price) ,
outdoor advertisements and weddings.

Chapter 1: Your Product
3
1.2.1 Rear Panel
Inputs
9
HDMI
Can be connected to HDMI output port.
10
CVBS
Can be connected to video signal from high-definition player and computer.
11
VGA/Yp
Can be connected to video signals from high-definition player and computer.
12
DVI
Can be connected to video signals from high-definition player, DVD and computer.
Compatible with VGA signal.
13
DVI-LOOP
DVI LOOP OUT. Can be connected to DVI IN of another DS1.
Outputs
4
HDMI
Can be connected to a monitor.
5
DVI3
Can be connected to DVI IN at the bottom left corner at the rear panel.
6
DVI1
Can be connected to display or LED screen which has DVI or HDMI connector.
7
DVI2
Can be connected to display or LED screen which has DVI or HDMI connector.
Control Connector
8
USB-A
Used to upgrade and import plans.
LAN
RS232-RJ45 connector used to upgrade and control from the computer.
Switch & Power
2
Switch
Switch
1
IEC –Power socket
AC 85-264V; 50/60Hz; Max power: 45W; IEC-3 power socket
Optional Slot
3
Optional slot for sending card
Two optional slots for sending card are available for DS1. Refer to Sending Card.

Chapter 1: Your Product
4
1.2.2 Dimension

Chapter 2: Installing Your Product
5
Chapter 2 Installing Your Product
2.1 Plugging in Signals
(1) Connect the device to computer with a LAN cable. Control the output with computer.
(2) Connect HDMI/DVI3 OUT to HDMI/DVI IN, the signal processed by computer is the output
signal.
(3) Connect DVI1/DVI2 OUT to a display or LED screen which has DVI/HDMI connector. The
display is based on the settings on the operation interface.
DVI connection:
HDMI to DVI connection:
Note:
HDMI OUT or DVI3 OUT is connected to DVI IN of the device.
DVI1 OUT or DVI2 OUT is connected to the display or LED screen.
2.2 Plugging in Main Power
Connect the IEC cable to device and plug into the wall socket.
