Deviser DS2460Q User manual

Operation Manual
DS2460Q QAM Analysis Meter
Ver：1.02

I
Warranty
All rights reserved. Reproduction, adaptation, or
translation without prior written permission is
prohibited, except as allowed under the copyright laws.
The information contained in this document is subject
to change without notice.
Deviser Instruments Inc makes no warranty of any
kind with regard to this material, including, but not
limited to, the implied warranties of merchantability
and fitness for a particular purpose.
Deviser Instruments Inc shall not be liable for errors
contained herein or for incidental or consequential
damage in connection with the furnishing, performance,
or use of this material.
Safety Notices
Observe the following safety precautions whenever you

II
operate any Deviser Instruments equipment. Failure to
comply with these and other specific warnings and
cautions is a violation of Deviser Instruments Inc’ safety
standards of design, manufacturing, and intended use
of the measurement device.
Deviser Instruments Inc assumes no liability for the
operator’s failure to comply with these precautions.
Product Damage
Danger! Do not use this product if it shows visible
damage, fails to perform, has been stored in
unfavorable conditions, or has been subject to severe
transportation stresses. Make the product inoperative
and secure it against any unintended operation.
Contact your Deviser Instruments Inc representative for
assistance.
Explosion Hazard Danger! Do not operate the

III
instrument in the presence of flammable gases or
fumes.
Electric Shock HazardDanger! To avoid the possibility
of severe injury or death, observe the following
precautions when using any Deviser Instruments
equipment:
Do not remove the system covers, and do not perform
electrical tests if there are signs of shipping damage to
the outer enclosure.
When connecting test cables to a line, do not touch the
cable’s metal contact points, or allow the cable leads to
touch each other.
Use only the supplied power cords and connect only to
a properly grounded wall outlet. Do not use extension
cords that do not have a protective ground conductor.

IV
Symbols
The following are general definitions of safety symbols
used on equipment and in manuals.
Dangerous voltage.
Protective ground.
Frame or chassis ground.
Alternating current
Direct current
Alternating or direct current
Caution! Read the manual.
This Deviser Instruments Inc product is warranted
against defects in material and workmanship for a
period of 24 months from date of shipment. During the

V
warranty period, Deviser Instruments Inc will, at its
option, either repair or replace products which prove to
be defective.
For warranty service or repair, this product must be
returned to an authorized service center designated by
Deviser Instruments Inc. The buyer shall prepay
shipping charges to Deviser Instruments Inc or to the
service center and Deviser Instruments Inc or the
service center shall pay the shipping charges to return
the product to . However, the buyer is responsible for
all shipping charges, duties, and taxes, both ways, for
products returned to Deviser Instruments Inc or one of
it’s authorized service center that are out of the
warranty period.
Deviser Instruments Inc warrants that its software and
firmware is designated by Deviser Instruments Inc for
use with Deviser Instrument equipment, and will

VI
execute its programming instructions when properly
installed on that instrument. Deviser Instruments Inc
does not warrant that the operation of the instrument,
or software, or firmware will be uninterrupted or
error-free but strives to insure the best operating
condition as per specifications and datasheets.
LIMITATION OF WARRANTY
Unauthorized repair or update, physical damage or
improper operational voltage (at the power supply or
RF input) will void this warranty. The main lithium
battery is covered for a period of 1 year.
The foregoing warranty shall not apply to defects
resulting from improper or inadequate use or
maintenance by Buyer, Buyer-supplied software or
interfacing, unauthorized modification or misuse,
operation outside of the environmental specifications
for the product.

VII
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED.
DEVISER INSTRUMENTS INC SPECIFICALLY DISCLAIMS
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
© Tianjin Deviser Electronics Instrument Co., Ltd.
Deviser Part No.: 2460Q
All rights reserved.
Printed in CHINA. August. 2017.

VIII
Catalog
1 Maintenance and Safety Considerations ................ 1
1.1 Calibrating the Meter .................................... 1
1.2 About Battery, Adapter and Firmware
upgrade ......................................................... 3
2 General Introduction .............................................. 6
2.1 Channel Measurement.................................. 8
2.2 Constellation Diagram ................................... 8
2.3 BER Statistics ................................................. 9
2.4 Tilt/Level List ................................................. 9
2.5 Channel Scanning .......................................... 9
2.6 Spectrum Analysis ......................................... 9
2.7 Hum Measurement ..................................... 10
2.8 Limit Measurement ..................................... 10
2.9 Return Path.................................................. 11
2.10 Voltage Measurement ................................. 11
2.11 Multiple User Channel................................. 11
2.12 File Management......................................... 11

IX
2.13 Intelligent Power Management................... 12
3 Introduction.......................................................... 13
3.1 Appearance ................................................. 13
3.2 Keypad......................................................... 16
3.2.1 Soft keys .............................................. 17
3.2.2 Shortcut keys....................................... 17
3.2.3 Alphabet/Number Input...................... 18
3.3 Display Description ...................................... 19
4 Using the Instrument............................................ 20
4.1 Function Menu Display................................ 20
4.2 Learn User Channel Plan.............................. 22
4.3 Level Measurement..................................... 34
4.3.1 Analog channel measurement ............ 36
4.3.2 Digital channel measurement ............. 39
4.3.3 Limit Display ........................................ 41
4.4 Constellation Diagram ................................. 42
4.5 8VSB Measurement(Option) ....................... 48
4.6 BER Statistics Measurement........................ 50

X
4.6.1 Parameter Description ........................ 51
4.6.2 Soft Keys Operations ........................... 52
4.7 Tilt/Level List Measurement........................ 53
4.7.1 Tilt Mode ............................................. 55
4.7.2 Level List Mode ................................... 57
4.8 Channel Scanning ........................................ 59
4.8.1 Buttons Operation............................... 61
4.9 Mini SCAN.................................................... 63
4.10 Return Path Spectrum ................................. 65
4.11 Fast Spectrum.............................................. 67
4.12 Spectrum Scanning...................................... 69
4.13 HUM Measurement..................................... 71
4.13.1 Soft Keys Operation............................. 72
4.14 Limit Measurement ..................................... 73
4.15 C/N Measurement....................................... 76
4.16 Fiber Optical Connector Introduction.......... 79
4.17 Optical Power Meter(Option) ...................... 83
4.18 Visual Fault Location (Option) ..................... 88
4.19 TDR (Option)................................................ 89
4.20 PING Test ..................................................... 94

XI
4.21 File Management......................................... 97
4.21.1 File Directory ....................................... 98
4.21.2 Save File............................................... 99
4.21.3 Read File............................................ 101
4.21.4 Delete File ......................................... 105
5 Setup................................................................... 107
5.1 Brief Introduction ...................................... 107
5.2 Information................................................ 109
5.3 General...................................................... 110
5.3.1 Meter Shutdown Time ...................... 110
5.3.2 Language Selection............................ 111
5.3.3 Date and Time ................................... 112
5.3.4 Files Status ........................................ 113
5.3.5 System upgrade................................. 114
5.3.6 Network............................................. 116
5.4 Measurement Parameter Setup ................ 118
5.4.1 Level Unit .......................................... 118
5.4.2 TP Compensation .............................. 119
5.4.3 Limit Select ........................................ 121

XII
5.4.4 Limit Setup ........................................ 122
5.4.5 Auto Diagnosis................................... 129
5.4.6 Measure Mode(Option) .................... 130
5.4.7 Voltage and temperature .................. 132
5.5 Channel Plan.............................................. 134
5.5.1 Select User Plan................................. 134
5.5.2 Learn User Plan ................................. 137
5.5.3 Edit User Plan .................................... 139
5.5.4 Load Default ...................................... 142
6 Power Supply ...................................................... 143
6.1 Battery....................................................... 143
6.2 Charging .................................................... 144
7 Port ..................................................................... 145
8 Specification ....................................................... 147
9 Standard Accessories .......................................... 152

DS2460Q QAM Analysis Meter Operation Manual
1
1Maintenance and Safety Considerations
1.1 Calibrating the Meter
All the instruments have analog circuitry:
preamplifiers, filter, etc.-whose performance can
change over time. A regular schedule of calibrations
will keep your instrument in optimal condition to
support you design, troubleshooting, and
manufacturing work.
It is recommended to calibrate and verify the meter
at least once a year to ensure that the meter meets
the original designed performance and specifications.
To avoid damaging the default calibration data stored
in a non-violated memory, a calibration to the meter
can only be done by an authorized service center and
qualified personnel with appropriate equipment.
For detailed information on the calibration
procedures, please contact factory or authorized
distributor.
Environmental condition: Calibration or verification

DS2460Q QAM Analysis Meter Operation Manual
2
test should be performed under laboratory condition
whereby the ambient temperature or relative
humidity can be controlled.
Warm up: Allow up to at least 5 minutes warm-up
before performing calibration to the meter. After
exposure or storage in a high humidity (condensing)
environment, relative recovery period is required
essentially.

DS2460Q QAM Analysis Meter Operation Manual
3
1.2 About Battery, Adapter and Firmware
upgrade
Please charge-discharge the battery in every 3 months
to extend battery life!
Warning：Danger of explosion if the battery is
incorrectly replaced. Replace only with the same type
battery recommended. Do NOT dispose of batteries in
a fire. Do NOT place batteries in the trash. Batteries
must be recycled or disposed of properly.
CAUTION: Recharge the battery only in the meter. If
left unused, a fully charged battery will discharge
itself over time.
Never use a damaged or worn-out adapter or battery.
Charging the batteries internally, even while the
analyzer is powered off, the analyzer may keep warm.
To avoid overheating, always disconnect the analyzer
from the AC adapter before storing the analyzer into
the soft carrying case.
CAUTION: Connect the automotive adapter to the

DS2460Q QAM Analysis Meter Operation Manual
4
power output connector for IT equipment, when
charging the battery on your automotive.
CAUTION: Temperature extremes will affect the ability
of the battery to charge. Allow the battery to cool
down or warm up as necessary before use or charging.
Storing a battery in extreme hot or cold temperatures
will reduce the capacity and lifetime of a battery.
Battery storage is recommended at a temperature of
less than 25°C.
The analyzer cannot be used in the standard soft
carrying case for more than 1 hours if the ambient
temperature is higher than 35°C.
CAUTION: Use only the original AC-DC adapter or
originally supplied battery for the power source.
Whether the meter work or power off, you can charge
the battery.
1 Insert the battery in the analyzer.
2 Plug in the AC-DC adapter and switch on the
external power.
3 The charge indicator lights, indicating that the

DS2460Q QAM Analysis Meter Operation Manual
5
battery is charging. When the battery is fully charged,
the green charging indicator turns off.
The charging time for a fully depleted battery, is
approximately four hours.
If the meter is power on, the charging time is longer.
CAUTION: In updating process, there must be a
constant power supply to for at least 10 minutes. If
power fails during the updating process it can cause
damage to the instrument.
Danger: DS2460 provide option VFL (Visual Fault
Locator), VFL output signal (red light) has danger:
In any case, user forbidden directly use the VFL
output port towards himself or other person eyes.
Doing so may causethe irradiated people damageto
your eyesightand even blindness!

DS2460Q QAM Analysis Meter Operation Manual
6
2General Introduction
DS2460Q is new model with color screen and high
performance, which is developed for digital cable TV
analysis by Deviser. This model can measure and
display most indexes of Digital TV(Channel Power,
MER, BER, Constellation Diagram); Analog
TV(Single-frequency Level, Carrier Level of Full
Channels Spectrum, HUM).Also DS2460Qcan measure
Trunk Voltage, Battery Voltage, Spectrum Analysis and
channel Scanning.
DS2460Qhasmicro USB port for communicating with
PC and also the PC software – TOOLBOX which can
make files management and analysis. DS2460Q also
has one RJ-45 port which used for network function
PING.
