Devolo MicroLink dLAN ISDN Router User manual

MicroLink dLAN ISDN Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c he n 

G e r m a n y
E-Mail: [e-mail] Internet: www.devolo.de
Status: 22.11..2006
ISDN router for Internet access and data sharing in LAN and dLAN.
• ISDN modem, router, 4-port switch, firewall and HomePlug adapter in one
device
• Ideal for use in home networks or small offices in combination with other
dLAN components from devolo
• Up to four computers can be connected directly to the router and
communicate with one another at 100 Mbps
• Integrated HomePlug adapter for networking via the household power circuit
• No new cables, no drilling, no dirt! Internet from power sockets throughout
the house
• Surf the Internet together using just one ISDN line
• Maximum security from interception thanks to DES
pro
encryption over the
electricity circuit
• Comprehensive security and firewall functions
• Easy configuration with a web browser
• 3-year warranty
The MicroLink dLAN ISDN Router from devolo unites four devices into one: The integrated
switch enables the PCs to communicate with one another, the ISDN modem and router let all of
them surf the Internet simultaneously. It also bridges the gap between separate LAN networks
through the integrated HomePlug adapter. Using the power circuit, the network can extended
almost anywhere in the building. By using further dLAN products, for example in connection with
an additional switch, spatially separated workgroups can be united for shared access to the
Internet or data in the network. With the MicroLink dLAN ISDN Router, devolo presents tried-
and-trusted technology in an innovative product.

MicroLink dLAN ISDN Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c he n 

G e r m a n y
E-Mail: [e-mail] Internet: www.devolo.de
Status: 22.11..2006
Enjoy the benefits of the MicroLink dLAN ISDN Router:
• Faster in the Internet! The MicroLink dLAN ISDN Router reaches Internet speeds of
128,000 bps when both ISDN lines are bundled. That makes those tedious waits for file
downloads, web pages and online gaming a thing of the past.
• Faster online! The Installation Wizard helps you to set up and configure the Internet
connection. A list of the most popular Internet providers helps you on the way into the
Internet.
• Work together! The MicroLink dLAN ISDN Router features an integrated switch with four
100 Mb ports for connecting up to 4 PCs directly. Printer, server, scanner, intranet, music
or photos: All information and devices can be shared within the network.
• Surf together! One ISDN line is all you need for all PCs to access the Internet
simultaneously. If you need more than four network connections, further switches can be
connected to the ports.
• Access anywhere in the building with no new cables! The integrated HomePlug
adapter enables distributed networks to be established or further work places in other
rooms to be linked up via the dLAN ISDN Router. Instead of network cables, the building’s
own electrical wiring is used for data transport. The MicroLink dLAN ISDN Router is ideally
supplemented by additional wireless, USB or Ethernet devices from the dLAN range of
products.
• Be secure! With IP masquerading (NAT), an integrated stateful inspection firewall and
comprehensive security functions, the MicroLink dLAN ISDN Router protects your PCs and
network from virus and worms.
• Meet the highest quality standards! The products from devolo are subjected to a
thorough German quality assurance. In this way, devolo assures the optimal functionality
with operating systems, international versions and protocols.

MicroLink dLAN ISDN Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c he n 

G e r m a n y
E-Mail: [e-mail] Internet: www.devolo.de
Status: 22.11..2006
Example application 1:
PCs in different ro
oms of a house can be easily connected to an ISDN
connection via the 230V electrical wiring.
Example application 2: Wireless surfing without problems from thick walls.

MicroLink dLAN ISDN Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c he n 

G e r m a n y
E-Mail: [e-mail] Internet: www.devolo.de
Status: 22.11..2006
Technical details
WAN interface
ISDN standards DSS1 (Euro-ISDN), basic rate interface (point-to-point and
point-to-multipoint connections)
WAN connection Connector type: RJ11
Data transfer rates 64,000 – 128,000 bps
Ports 1 WAN
LAN interface
LAN standards Ethernet specification IEEE 802.3
Fast-Ethernet specification IEE 802.3u
 Full-duplex specification IEEE 802.3x
Protocols CSMA/CD
TCP/IP
Data transfer rates +
range Switch: 10/100 Mbps
dLAN: 14 Mbps, 200 m via electrical wiring
dLAN security DES
pro
encryption via power circuit
Ports 4 LAN with Auto MDI-X (LAN ports also work as uplink ports),
Computer interface RJ45
Technical specifications
Power supply AC adapter: 230V / 12V DC; 700 mA
Temperature 5 – 40°C (=41°F – 104°F)
Environment 10-80% humidity (non-condensing)
Design Plastic case
Weight 340 g
Dimensions 169 x 134 x 1.57 in (width x depth x height)
Approvals CE compliant in accordance with all technical requirements for all EU countries
and Switzerland:
EN 60950-1 :2001
EN 55024 :1998 +A1:2001
EN 55022: 1998 +A1 :2000 (Class A)

MicroLink dLAN ISDN Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c he n 

G e r m a n y
E-Mail: [e-mail] Internet: www.devolo.de
Status: 22.11..2006
Protocols and functions
LEDs Power
4x3 status LEDs for Ethernet connections (Link / Act) and uplink port
3 for WAN status (Connect / Link / Data)
1 status HomePlug connection (Act)
Stateful inspection
firewall for protection
from Internet attacks,
such as:
IP spoofing
Ping of Death
Land attack
Reassembly attack
SYN flooding
DoS attack
Winnuke attack
Features:
Intrusion detection system
Ping filter
Stealth mode
Routing Class C, 254 User
Protocols
PPP
TCP/IP
MLPPP
HDLC
Supports VPN pass-through (PPTP)
System requirements CD-ROM drive
For Internet access: ISDN from any telecommunications provider
Operating systems includes, but not limited to, Windows
®
98, Windows
®
Me, Windows
®
2000,
Windows
®
XP, Linux
®
, Mac
TM
OS X and all TCP/IP operating systems
Other
Firmware updates
On/off switch
Factory-defaults button
DNS configuration
Port forwarding (virtual server)
ISDN configuration

MicroLink dLAN ISDN Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c he n 

G e r m a n y
E-Mail: [e-mail] Internet: www.devolo.de
Status: 22.11..2006
Sales information
Item numbers 01743 DE, AT
EAN code 4250059617445 DE, AT
Warranty 3 years
Service & Support Hotline Tel.: [phone] (Germany only)
E-mail: [email protected]
On-site Service Tel.: [phone] (Germany only)
Sales Infoline Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Design Plastic case
Weight 1200 g
Packaging size 188 x 302 x 115 mm (height x width x depth)
Accessories
Modem – NTBA – connection: telephone cable (RJ11 – RJ45) 5m
AC adapter: 230V / 12V DC; 700 mA
Documentation: printed manual
CD-ROM: PDF manual, installation guide
