Please read these instructions before operating the product.
www.DEWALT.com
DW089LR, DW089LG 3 x 360° Line Laser
DW0811LR, DW0811LG 2 x 360° Line Laser

2
Figures AB

3
C
D E

4
Figures
F
3
1
2
4
5 6
7
DW089LR/LG

5
G
I
3
4
5
1
2
2
1
2
1
5/8-11
1/4-20
6
H
J

6
Figures
ab
a
c
ab
ab
> 30 . (9m)
_
c
b
1
2
3
K

7
ab
ba
> 30 . (9m)
_
b
c
ba
c
c
a
c
1
2
3
L

8
Figures
g
h
e
f
d
c
d
c
a
b
c
g
b
a
2
h
d
> 8 . (2.5m)
_
M
1
23

9
90˚
a
a
a
f
b
c
a
f
c
bc
e
e
> 14. (4m)
_
> 14. (4m)
_
> 14. (4m)
_
b
N
1
2
3

10
EContents
• Laser Information
• User Safety
• Battery Safety
• Powering the Laser
• Operating Tips
• Turning the Laser ON
• Checking Laser Accuracy
• Using the Laser
• Troubleshooting
• Accessories
• Service and Repairs
• Warranty
• Specifications
Laser Information
The DW089LR/DW089LG 3-Beam 360° Line Laser and
the DW0811LR/DW0811LG 2-Beam 360° Line Laser
are Class 2 laser products. The lasers are self-leveling
laser tools that can be used for horizontal (level) and
vertical (plumb) alignment projects.
Each product complies with 21 CFR 1040.10 and
1040.11 except for deviations pursuant to laser notice
No. 50, dated June 24, 2007.
Conforms to UL STDS 61010-1 & 2595
Certified to CSA STD C22.2 No. 61010-1
Supplier’s Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier: DW089LR, DW089LG, DW0811LR,
DW0811LG
Responsible Party – U.S. Contact Information
DEWALT
701 East Joppa Road
Towson, Maryland 21286
www.DEWALT.com
FCC Compliance Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance
with the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio and television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
ISED Compliance Statement
This device contains license-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science, and
Economic Development Canada's license-exempt
RSS(s). Operation is subject to the following two
conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of
the device.

11
E
User Safety
Safety Guidelines
The definitions below describe the level of severity for
each signal word. Please read the manual and pay
attention to these symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
NOTICE: Indicates a practice not related to personal
injury which, if not avoided, may result in property
damage.
If you have any questions or comments about
this or any DEWALT tool,
call 1-800-4-DEWALT (1-800-433-9258)
or go to www.DEWALT.com.
WARNING:
Never modify the tool or any part of it. Damage
to the laser or personal injury could result.
WARNING:
Read and understand all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not
disassemble or modify the laser level.
There are no user serviceable parts inside.
Serious eye injury could result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments or performance of procedures
other than those specified herein may result in
hazardous radiation exposure.
The label on your laser may include the following
symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels
are on your laser.
WARNING: To reduce the risk of injury,
user must read instruction manual.
WARNING: LASER RADIATION. DO
NOT STARE INTO BEAM. Class 2 Laser
Product.
≤1.5mW @ 630-680nm
IEC 60825-1: 2014
5002595
≤1.5mW @ 510-530nm
IEC 60825-1: 2014
5002595
5002595
≤1.5mW @ 630-680nm
IEC 60825-1: 2014
5002595
≤1.5mW @ 510-530nm
IEC 60825-1: 2014
• If the equipment is used in a manner not
specified by the manufacturer, the protection
provided by the equipment may be impaired.

12
E• Do not operate the laser in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. This tool may
create sparks which may ignite the dust or fumes.
• Store an idle laser out of reach of children and
other untrained persons. Lasers are dangerous in
the hands of untrained users.
• Tool service MUST be performed by qualified
repair personnel. Service or maintenance performed
by unqualified personnel may result in injury. To
locate your nearest DEWALT service center go to
www.DEWALT.com.
• Do not use optical tools such as a telescope or
transit to view the laser beam. Serious eye injury
could result.
• Do not place the laser in a position which may
cause anyone to intentionally or unintentionally
stare into the laser beam. Serious eye injury could
result.
• Do not position the laser near a reflective
surface which may reflect the laser beam toward
anyone’s eyes. Serious eye injury could result.
• Turn the laser off when it is not in use. Leaving
the laser on increases the risk of staring into the
laser beam.
• Do not modify the laser in any way. Modifying the
tool may result in hazardous laser radiation exposure.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury
may result.
• Do not remove or deface warning labels. If labels
are removed, the user or others may inadvertently
expose themselves to radiation.
• Position the laser securely on a level surface. If
the laser falls, damage to the laser or serious injury
could result.
Personal Safety
• Stay alert, watch what you are doing, and use
common sense when operating the laser. Do not use
the laser when you are tired or under the influence
of drugs, alcohol, or medication. A moment of
inattention while operating the laser may result in
serious personal injury.
• Use personal protective equipment. Always wear
eye protection. Depending on the work conditions,
wearing protective equipment such as a dust
mask, non-skid safety shoes, hard hat, and hearing
protection will reduce personal injury.
Tool Use and Care
• Do not use the laser if the Power/Transport Lock
switch does not turn the laser on or off. Any tool that
cannot be controlled with the switch is dangerous and
must be repaired.
• Follow instructions in the Maintenance section of
this manual. Use of unauthorized parts or failure to
follow Maintenance instructions may create a risk of
electric shock or injury.
Battery Safety
WARNING:
Batteries can explode, or leak, and can
cause injury or fire. To reduce this risk:
• Carefully follow all instructions and warnings on the
battery label and package, and the accompanying
Battery Safety manual.
• Always insert batteries correctly with regard to
polarity +and –, as marked on the battery and the
equipment.
• Do not short battery terminals.
• Do not charge disposable batteries.
• Do not mix old and new batteries. Replace all
batteries at the same time with new batteries of the
same brand and type.

13
E
• Remove dead batteries immediately and dispose of
per local codes.
• Do not dispose of batteries in fire.
• Keep batteries out of reach of children.
• Remove batteries when the device is not in use.
• Use only the charger specified for your rechargeable
battery pack.
• Disconnect the battery pack from the laser before
making any adjustments, changing accessories, or
storing the laser. Such preventative safety measures
reduce the risk of starting the laser accidentally.
• When the battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws, or other small metal objects that
can make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
• Use the laser only with specifically designated
battery packs. Use of other battery packs may create
a risk of injury and fire.
• Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from
the battery may cause irritation or burns.
• Do not use a battery pack or laser that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion, or
risk of injury.
• Do not expose a battery pack or laser to fire
or excessive temperature. Exposure to fire or
temperature above 265° F (130° C) may cause an
explosion.
• Follow all the charging instructions and do not charge
the battery pack outside of the temperature range
specified in the instructions. Charging improperly or
at temperatures outside of the specified range may
damage the battery and increase the risk of fire.
Powering the Laser
This laser can be powered by either of these battery
packs:
• A DEWALT 12V MAX* Li-ion Battery Pack
(DCB120, DCB122, DCB123, DCB125, or DCB127).
*Maximum initial battery voltage (measured without a
workload) is 12 volts. Nominal voltage is 10.8.
• A DEWALT AA Starter Pack with 4 new high-quality
name brand AA batteries. Note: The AA Starter Pack
is only recommended for use with the red laser
(DW089LR or DW0811LR).
Use of any other batteries may create a risk of fire.
Charging the Li-ion Battery
1. If the DEWALT 12V MAX* Li-ion battery pack is
attached to the laser, remove it.
• Rotate the laser so it is easier to access the
battery pack (Figure C1).
• While pressing down on the release button on the
battery pack (Figure C2), pull the battery pack
up to unlock it from the laser.
• Pull the battery pack the rest of the way up and
out of the laser (Figure C3).
2. Plug the charger cord into an electrical outlet.
3. Slide the battery pack into the charger until it snaps
in place (Figure B1). On the charger, the left
indicator light will flash to let you know the battery is
being charged.
4. After the battery is fully-charged (the indicator light
on the charger no longer flashes), press and hold
the release button on the battery pack (Figure
B2) and slide the pack out of the charger
(Figure B3).
5. Slide the battery pack down in the laser until it
snaps in place (Figure B4).

14
EInstalling New AA Batteries
CAUTION:
The AA Starter Pack is designed specifically
for use with DEWALT 12V compatible laser
products and cannot be used with any other
tools. Do not attempt to modify the product.
1. If the AA Starter Pack is attached to the laser,
remove it.
• Rotate the laser so it is easier to access the
Starter Pack (Figure C1).
• While pressing down on the release button on the
Starter Pack (Figure C2), pull the Starter Pack
up to unlock it from the laser).
• Pull the Starter Pack the rest of the way up and
out of the laser (Figure C3).
2. On the AA Starter Pack, lift up the latch to open the
battery compartment cover (Figure A1and
A2).
3. Insert four new, high-quality, name brand AA
batteries, making sure to position the -and +
ends of each battery as noted inside the battery
compartment (Figure A3).
4. Push the battery compartment cover down until it
snaps in place (Figure A4).
5. Slide the Starter Pack down in the laser until it
snaps in place (Figure A5).
Viewing the Battery Meter
When the laser is ON, the battery meter on the keypad
(Figure F7) indicates how much power remains.
Each of the four LEDs on the battery meter represents
25% of the power.
• The bottom LED will illuminate and flash when the
battery level is low (below 12.5%). The laser may
continue to operate for a short time while the battery
power continues to drain, but the beam(s) will quickly
dim.
• After fresh batteries are installed in the AA Starter
Pack, or the 12V MAX Li-ion battery is charged, and
the laser is turned ON again, the laser beam(s) will
return to full brightness and the battery indicator level
will indicate full capacity.
• If all 4 LEDs on the battery meter remain ON, this
indicates that the laser is not fully powered OFF.
When the laser is not in use, make sure the Power/
Transport Lock switch is placed to the LEFT to the
Locked/OFF position (Figure F2).
Operating Tips
• To extend battery life per charge, turn the laser off
when it is not in use.
• To ensure the accuracy of your work, check the
laser calibration often. Refer to Checking Laser
Accuracy.
• Before attempting to use the laser, make sure it is
positioned securely, on a smooth, flat stable surface
that is level in both directions.
• To increase beam visibility, use a Laser Target Card
(Figure D) and/or wear Laser Enhancement Glasses
(Figure E) to help find the beam.
CAUTION:
To reduce the risk of serious injury, never stare
directly into the laser beam with or without
these glasses. Refer to Accessories for
important information.
• Always mark the center of the beam created by the
laser.
• Extreme temperature changes can cause movement
or shifting of building structures, metal tripods,
equipment, etc., which can effect accuracy. Check
your accuracy often while working.
• If the laser has been dropped, check to make sure
your laser is still calibrated. Refer to Checking Laser
Accuracy.

15
E
Turning the Laser On
Place the laser on a flat level surface. Slide the Power/
Transport Lock switch F2to the right to unlock/turn
ON the laser.
Each laser line is powered on by pressing its button on
the keypad (Figure F3). Pressing the button again
turns the laser line off. The laser lines can be powered
one at a time or all at the same time.
Laser Buttons
DW089LR/LG Horizontal laser line
(Figure F4)
Side vertical laser line
(Figure F5)
Front vertical laser line
(Figure F6)
DW0811LR/LG Horizontal laser line
(Figure F4)
Side vertical laser line
(Figure F5)
When the laser is not in use, slide the Power/Transport
Lock switch to the left in the OFF/Locked position. If
the Power/Transport Lock switch is not placed in the
lock position, all 4 LEDs will continuously flash on the
Battery Meter.
Checking Laser Accuracy
The laser tools are sealed and calibrated at the factory.
It is recommended that you perform an accuracy check
prior to using the laser for the first time (in case the
laser was exposed to extreme temperatures) and then
regularly to ensure the accuracy of your work. When
performing any of the accuracy checks listed in this
manual, follow these guidelines:
• Use the largest area/distance possible, closest to the
operating distance. The greater the area/distance,
the easier to measure the accuracy of the laser.
• Place the laser on a smooth, flat, stable surface that
is level in both directions.
• Mark the center of the laser beam.
Horizontal Beam - Scan Direction
Checking the horizontal scan calibration of the laser
requires two walls 30′(9m) apart. It is important to
conduct a calibration check using a distance no shorter
than the distance of the applications for which the tool
will be used.
1. Place the laser against the end of the wall on a
smooth, flat, stable surface that is level in both
directions (Figure K1).
2. Move the Power/Transport Lock switch to the right
to turn the laser ON.
3. Press to turn on the horizontal beam.
4. At least 30′(9m) apart along the laser beam, mark
aand b.
5. Turn the laser 180º.
6. Adjust the height of the laser so the center of the
beam is aligned with a(Figure K2).
7. Directly above or below b, mark calong the laser
beam (Figure K3).
8. Measure the vertical distance between band c.
9. If your measurement is greater than the Allowable
Distance Between band cfor the
corresponding Distance Between Walls in the
following table, the laser must be serviced at an
authorized service center.
Distance
Between Walls
Allowable Distance
Between band c
30’ (9m) 1/4” (6.0mm)
40’ (12m) 5/16” (8.0mm)
50’ (15m) 13/32” (10.0mm)

16
EHorizontal Beam - Pitch Direction
Checking the horizontal pitch calibration of the
laser requires a single wall at least 30′(9m) long.
It is important to conduct a calibration check using
a distance no shorter than the distance of the
applications for which the tool will be used.
1. Place the laser against the end of the wall on a
smooth, flat, stable surface that is level in both
directions (Figure L1).
2. Move the Power/Transport Lock switch to the right
to turn the laser ON.
3. Press to turn on the horizontal beam.
4. At least 30′(9m) apart along the laser beam, mark
aand b.
5. Move the laser to the opposite end of the wall
(Figure L2).
6. Position the laser toward the first end of the same
wall and parallel to the adjacent wall.
7. Adjust the height of the laser so the center of the
beam is aligned with b.
8. Directly above or below a, mark calong the laser
beam (Figure L3).
9. Measure the distance between aand c.
10. If your measurement is greater than the Allowable
Distance Between aand cfor the correspond-
ing Distance Between Walls in the following table,
the laser must be serviced at an authorized service
center.
Distance
Between Walls
Allowable Distance
Between aand c
30’ (9m) 1/4” (6.0mm)
40’ (12m) 5/16” (8.0mm)
50’ (15m) 13/32” (10.0mm)
Vertical Beam (DW089)
Checking the vertical (plumb) calibration of the
laser can be most accurately done when there is a
substantial amount of vertical height available, ideally
30’ (9m), with one person on the floor positioning
the laser and another person near a ceiling to mark
the position of the beam. It is important to conduct a
calibration check using a distance no shorter than the
distance of the applications for which the tool will be
used.
1. Place the laser on a smooth, flat, stable surface
that is level in both directions (Figure M1).
2. Move the Power/Transport Lock switch to the right
to turn the laser ON.
3. Press and to turn on both vertical beams.
4. Mark two short lines where the beams cross
a, band also on the ceiling c, d. Always mark
the center of the beam's thickness (Figure M2).
5. Pick up and rotate the laser 180º, and position it
so the beams line up with the marked lines on the
level surface ( e, f) (Figure M3).
6. Mark two short lines where the beams cross on the
ceiling g, h.
7. Measure the distance between each set of marked
lines on the ceiling ( c, gand d, h). If the mea-
surement is greater than the values shown below,
the laser must be serviced at an authorized service
center.
Ceiling Height
Allowable Distance
Between Marks
8’ (2.5m) 1/16” (1.5mm)
10’ (3m) 3/32” (2.0mm)
14’ (4m) 1/8” (2.5mm)
20’ (6m) 5/32’ (4mm)
30’ (9m) 1/4’ (6mm)

17
E
90º Accuracy Between Vertical Beams
(DW089)
Checking 90º accuracy requires an open floor area at
least 33’ x 18’ (10m x 5m). Refer to Figure Nfor the
position of the laser at each step and for the location of
the marks made at each step. Always mark the center
of the beam's thickness.
1. Place the laser on a smooth, flat, stable surface
that is level in both directions.
2. Move the Power/Transport Lock switch to the right
to turn the laser ON.
3. Press to turn on the side vertical beam.
4. Mark the center of the beam at three locations
(a, b, c) on the floor along the side laser line.
Mark bshould be at the midpoint of the laser line
(Figure N1).
5. Pick up and move the laser to b.
6. Press to turn on the front vertical beam too
(Figure N2).
7. Position the front vertical beam so it crosses
precisely at b, with the side beam aligned with c
(Figure N2).
8. Mark a location ealong the front vertical beam at
least 14’ (4m) away from the unit (Figure N2).
9. Rotate the laser 90º so the side vertical beam now
passes through band e(Figure N3).
10. Directly above or below a, mark falong the front
vertical beam.
11. Measure the distance between aand f. If the
measurement is greater than the values shown
below, the laser must be serviced at an authorized
service center.
Distance from
ato b
Allowable Distance
Between aand f
14’ (4m) 5/32” (3.5mm)
17’ (5m) 3/16” (4.5mm)
20’ (6m) 7/32” (5.5mm)
23’ (7m) 1/4” (6mm)
Using the Laser
Leveling the Laser
As long as the laser is properly calibrated, the laser is
self-leveling. Each laser is calibrated at the factory to
find level as long as it is positioned on a flat surface
within average ± 4° of level. No manual adjustments
are required.
If the laser has been tilted so much that it cannot
self-level (> 4°), the laser beam will flash. There are
two flashing sequences associated with the out of level
condition.
• Between 4° and 10° the beams flash with a constant
blink cycle
• At angles greater than 10° the beams flash with a
three blink cycle.
When the beams flash THE LASER IS NOT LEVEL
(OR PLUMB) AND SHOULD NOT BE USED FOR
DETERMINING OR MARKING LEVEL OR PLUMB.
Try repositioning the laser on a more level surface.

18
EUsing the Pivot Bracket
The laser has a magnetic pivot bracket (Figure G1)
permanently attached to the unit.
WARNING:
Position the laser and/or wall mount on
a stable surface. Serious personal injury or
damage to the laser may result if the laser
falls.
• The bracket has magnets (Figure H2) which allow
the unit to be mounted to most upright surfaces
made of steel or iron. Common examples of suitable
surfaces include steel framing studs, steel door
frames, and structural steel beams.
• The bracket has a keyhole slot (Figure G2or
H1) so it can be hung from a nail or screw on any
kind of surface.
Maintenance
• To maintain the accuracy of your work, check the
laser often to make sure it is properly calibrated.
See Field Calibration Check.
• Calibration checks and other maintenance repairs
may be performed by DEWALT service centers.
• When not in use, store the laser in the kit box
provided. Do not store your laser at temperatures
below -5˚F (-20˚C ) or above 140˚F (60˚C).
• Do not store your laser in the kit box if the laser is
wet. The laser should be dried first with a soft dry
cloth prior to storage.
Cleaning
Exterior plastic parts may be cleaned with a damp cloth.
Although these parts are solvent resistant, NEVER use
solvents. Use a soft, dry cloth to remove moisture from
the tool before storage.
Troubleshooting
The Laser Does Not Turn On
• Make sure AA batteries (when used) are installed
correctly according to +and –on the inside of the
battery door.
• Make sure the batteries or rechargeable pack are
in proper working condition. If in doubt, try installing
new batteries.
• Make sure that the battery contacts are clean and
free of rust or corrosion. Be sure to keep the laser
level dry and use only new, high-quality, name brand
batteries to reduce the chance of battery leakage.
• If the laser unit is heated above 120˚F (50˚C), the
unit will not turn on. If the laser has been stored in
extremely hot temperatures, allow it to cool. The
laser level will not be damaged by pressing the on/
off button before cooling to its proper operating
temperature.
The Laser Beams Flash
The lasers are designed to self-level up to an average
of 4° in all directions If the laser is tilted so much that
the internal mechanism cannot level itself, the laser
beams will flash indicating that the tilt range has been
exceeded. THE FLASHING BEAMS CREATED BY THE
LASER ARE NOT LEVEL OR PLUMB AND SHOULD
NOT BE USED FOR DETERMINING OR MARKING
LEVEL OR PLUMB. Try repositioning the laser on a
more level surface.
The Laser Beams Will Not Stop Moving
The laser is a precision instrument. Therefore, if it is
not positioned on a stable (and motionless) surface,
the laser will continue to try to find level. If the beam
will not stop moving, try placing the laser on a more
stable surface. Also, try to make sure that the surface is
relatively flat, so that the laser is stable.

19
E
The Battery Meter LEDs Flash
When all 4 LEDs continuously flash on the Battery
Meter this indicates that the unit has not been fully
powered off using the Power/Transport Lock switch
(Figure F2). The Power/Transport Lock switch
should always be placed in the LOCKED/OFF position
when the laser is not in use.
Accessories
The laser is equipped with both 1/4 - 20 and 5/8 - 11
female threads (I) on the bottom of the unit (Figure I).
This thread is to accommodate current or future DEWalt
accessories. Only use DEWalt accessories specified
for use with this product. Follow the directions included
with the accessory.
WARNING:
Since accessories, other than those offered
by DEWalt, have not been tested with this
product, use of such accessories with this
tool could be hazardous. To reduce the risk of
injury, only DEWalt recommended accessories
should be used with this product.
If you need any assistance in locating any accessory,
please contact your nearest DEWALT service center or
go to www.DEWALT.com.
Target Card
Some laser kits include a Laser Target Card (Figure D)
to aid in locating and marking the laser beam. The
target card enhances the visibility of the laser beam as
the beam crosses over the card. The card is marked
with standard and metric scales. The laser beam
passes through the red plastic and reflects off of the
reflective tape on the reverse side. The magnet at the
top of the card is designed to hold the target card to
ceiling track or steel studs to determine plumb and level
positions. For best performance when using the Target
Card, the DEWALT logo should be facing you.
Laser Enhancement Glasses
Some laser kits include Laser Enhancement Glasses
(Figure E). These glasses improve the visibility of
the laser beam under bright light conditions or over
long distances when the laser is used for interior
applications. These glasses are not required to operate
the laser.
CAUTION:
These glasses are not ANSI approved
safety glasses and should not be used while
operating other tools. These glasses do not
keep the laser beam from entering your eyes.
CAUTION:
To reduce the risk of serious injury, never stare
directly into the laser beam with or without
these glasses.
Ceiling Mount
The laser ceiling mount (Figure J1), if included, offers
more mounting options for the laser. The ceiling mount
has a clamp (Figure J2) at one end which can be fixed
to a wall angle for acoustic ceiling installation (Figure
J3). At each end of the ceiling mount is a screw hole
(Figure J4and J5), allowing the ceiling mount to
be attached to any surface with a nail or screw.
Once the ceiling mount is secured, its steel plate
provides a surface to which the magnetic pivot bracket
(Figure J6) can be attached. The position of the
laser can then be fine-tuned by sliding the magnetic
pivot bracket up or down on the wall mount.

20
EService and Repairs
NOTE: Disassembling the laser level(s) will void all
warranties on the product.
To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustment should be performed by
authorized service centers. Service or maintenance
performed by unqualified personnel may result in a risk
of injury. To locate your nearest DEWalt service center
call 1-800-4-DEWALT (1-800-433-9258) or go to www.
DEWALT.com.
Warranty
Go to www.DEWALT.com for the latest warranty
information.
