Contents
• User Safety
• Battery Safety
• Setup (Load Batteries)
• Operation
• Warranty
• Error Codes
• Specifications
Retain all sections of this manual for future
reference.
User Safety
WARNING: Carefully read the Safety
Instructions and Product Manual
before using this product. The person
responsible for the product must ensure
that all users understand and adhere
to these instructions.
WARNING: The following label
information is placed on your laser tool
to inform you of the laser class for your
convenience and safety.
USA CANADA/LAG EU/GEMUSA
The DWHT77100 tools emit a visible laser
beam, as shown in Figure A 1 . The laser beam
emitted is Laser Class 2 per IEC 60825-1.
WARNING: While the laser tool is in
operation, be careful not to expose
your eyes to the emitting laser beam
(red light source). Exposure to a laser
beam for an extended time period may
be hazardous to your eyes. Do not look
into the beam with optical aids.
WARNING: To reduce the risk of
injury, user must read the Product User
manual, Laser Safety manual, and
Battery Safety information.
CAUTION:Use of controls or
adjustments or performance of
procedures other than those specified
herein may result in hazardous
radiation exposure.
Battery Safety
WARNING: Batteries can explode or
leak and cause serious injury or fire. To
reduce the risk:
• ALWAYS follow all instructions and
warnings on the battery label and package.
• DO NOT short any battery terminals.
• DO NOT charge alkaline batteries.
• DO NOT mix old and new batteries. Replace
all of them at the same time with new
batteries of the same brand and type.
• DO NOT mix battery chemistries.
• DO NOT dispose of batteries in fire.
• ALWAYS keep batteries out of reach of
children.
• ALWAYS remove batteries if the device will
not be used for several months.
• NOTE: Ensure that the recommended
batteries are used.
NOTE: Ensure the batteries are inserted in the
correct manner, with the correct polarity.
Setup (Load Batteries)
1. Locate the battery compartment latch on
the back of the tool (Figure D 2 ).
2. Using your finger, pull the latch up to
unlock and remove the battery door
(Figure E 1 and 2 ).
3. Insert two AAA batteries, making sure to
position the - and + ends of each battery
as noted inside the battery compartment
(Figure E 3 ).
4. Slide the pins at the bottom of the battery
door into the notches in the battery
compartment (Figure E 4 ).
5
E

5. Push the battery door down until it snaps
in place (Figure E 5 ).
When the tool is ON, the battery level appears
in the display window (Figure C 1 ).
SETUP LDM
Turn On Tool
Click On (Figure A 3 ) to turn on the tool.
Changing the
Reference Location
The tool will measure the distance from the
bottom (Figure F 1 ) or top (Figure F 2 ) of the
tool to the wall or object.
1. Press and hold the gear button (Figure
A 4 ) for 3 seconds. The measurement
reference location icon (Figure C 5 ) will
flash on the display window.
2. Press the gear button again to change the
reference location.
3. Press the On button (Figure A 3 ) to
confirm the reference location.
Changing the Unit of Measure
Once the current measurement is taken (the
device is not in Continuous Measure mode),
you can change the unit of measure from
decimal ft (6.21 ft) to fractional ft (6'02"9/16),
fractional ft to meters (1.894 m), meters to
inches (74 9/16 in), or inches to decimal ft.
• To change the measurement unit, hold
the gear button (Figure A 4 ) for three
seconds to enter the units menu. Press
the on button to confirm your reference
location. Once confirmed, the current
unit of measurement will be displayed,
press the gear to change units and the on
button to confirm
OPERATION
Measuring Distance to a Wall
or Object
1. Point the laser (Figure A 1 ) toward the
wall or object whose distance you need to
measure (Figure F).
2. Press On button (Figure A 3 ) to measure
the distance from the tool to the wall or
object. Refer to Setup LDM to change
the reference location and / or unit of
measurement.
3. At the bottom of the display window
(Figure A 2 ), view the current
measurement (Figure C 3 ), which will
keep changing as you move the tool.
To record the measurement click On. To record
another measurement, click On again. Then
repeat steps 1-3.
Measuring Area
You can measure the area of a wall, floor, or
object.
1. Press the gear button (Figure A 4 ) once
to show the area icon (Figure B 1 ) on the
display window (Figure A 2 ).
Measure the length.
1. Position the tool at one end of the target
and point the laser dot across the length.
(Figure G 1 shows where to position the
tool if measuring from the top of the tool.)
2. Press On to display the length
measurement on the first line of the
display window.
Measure the width.
1. Point the top of the tool at one side of the
target (wall, floor, or object).
2. Position the tool at one end of the target
and point the laser dot across the width.
(Figure G 2 shows where to position the
tool if you are measuring from the top of
the tool.)
6
E

3. Press On to display the width
measurement at the top of the display
window.
View the Area measurement at the bottom of
the display window (Figure E 3 ).
Measuring Volume
You can measure the volume of a room or
object.
1. Press the gear button (Figure A 4 ) three
times to show the indirect measurement
height on the display window (Figure
E 3 ).
Measure the width.
1. Point the top of the tool at one side of the
target (room or object).
2. Position the tool at one end of the target
and point the laser dot across the width.
(Figure H 1 ) shows where to position the
tool if you are measuring from the top of
the tool.)
3. Press to display the width measurement at
the top of the display window.
Measure the length.
1. Position the tool at one end of the target
and point the laser dot across the length.
(Figure H 2 ) shows where to position the
tool if you are measuring from the top of
the tool.)
2. Press On to display the length
measurement on the second line of the
display window.
Measure the height.
1. Positon the tool at one end of the target
and point the laser dot across the height.
2. Press On to display the height
measurement on the third line of the
display window.
View the Volume measurement at the bottom
of the display window (Figure C 3 ).
Measuring the Height of a Tall Object
If you need to measure the height of a tall
object (e.g., a tall building), you can calculate
the height based on the distances from the
same point to 2 or 3 points on the object.
The tool will use the Pythagorean Theorem
(A2+B2=C2) to calculate the height.
Measure a distance with two
measurements
You can use the distance to two points on a
tall object (Indirect Height) to determine its
height (Figure I1).
1. Point the tool's laser (Figure A 1 toward
a wall or object, and not toward anyone's
eyes.
2. Press On button (Figure A 3 ) to turn the
tool on and display the red laser dot.
3. Press the gear button (Figure A 4 ) three
times to show pythagoras (Figure B 1 ) on
the display window.
4. Position the tool opposite the bottom of
the building or object whose height you
need to measure (Figure I2).
5. Aim the laser at the highest point of the
building or object (Figure I2).
6. Press On button (Figure A 3 ) to measure
the distance.
7. From the same point, aim the laser
straight ahead toward the lowest point of
the building or object (Figure I3).
8. Press On button (Figure A 3 ) to measure
the distance.
9. On the bottom line of the screen, view the
height of the building or object.
Measure a distance with three
measurements
You can use the distance to three points on a
tall object to determine its height (Figure J1).
1. Point the tool's laser (Figure A 1 toward
a wall or object, and not toward anyone's
eyes.
7
E

2. Press On button (Figure A 3 ) to turn the
tool on and display the red laser dot.
3. Press the gear button (Figure A 4 ) four
times to show pythagoras on the display
window (Figure C 7 ).
4. Position the tool opposite the
approximate center of the vertical height
to be measured (Figure J2).
5. Aim the laser at the highest point of the
building or object (Figure J2).
6. Press On button (Figure A 3 ) to measure
the distance.
7. From the same point, aim the laser
straight ahead toward the center of the
building or object (Figure J3).
8. Press On button (Figure A 3 ) to measure
the distance.
9. From the same point, aim the laser at the
lowest point of the building or object
(FigureJ4).
10. Press On button (Figure A 3 ) to measure
the distance.
11. On the bottom line of the screen, view the
height of the building or object.
Adding Measurements
You can add two measurements to get a total
measurement of the two distances.
1. Press gear button (Figure A 4 ) to show
the addition icon on the display window
(Figure E 4 )
2. Press On button (Figure A 3 ) to measure
the distance from the tool to the wall or
object.
3. Press the On button to record the first
measurement on the top line.
4. Point the laser (Figure A 1 ) toward the
next wall or object.
5. Press the On button to record the second
measurement on the middle line.
6. View the total of the two measurements
at the bottom of the display window
(FigureE 3 ).
Subtracting Measurements
You can subtract one measurement from
another.
1. Press gear button (Figure A 4 ) to show
the subtraction icon on the display
window (Figure C 3 ).
2. Point the laser at the top of the tool laser
(Figure A 1 ) toward the wall or object
whose distance you need to measure.
3. Press On button (Figure A 3 ) to measure
the distance from the tool to the wall or
object.
4. Press the On button to record the first
measurement on the top line.
5. Point the laser at the top of the tool
toward the next wall or object.
6. Press the On button to record the second
measurement on the middle line.
7. View the difference of the two
measurements at the bottom of the
display window (Figure C 3 ).
NOTE: If Second measurement is larger
than first: IC 601 will be displayed
for a negative number. Please switch
measurement points so first measurement
is larger than second
Turning Off the Tool
The tool can be turned off in either of these
ways:
• Press and hold the on button
(Figure A 3 ) for several seconds (until the
display window clears).
• If you do not use the tool for 180 seconds,
it will automatically turn off.
8
E

Three Year Limited
Warranty
DeWALT will repair, without charge, any defects
due to faulty materials or workmanship for
three years from the date of purchase. This
warranty does not cover part failure due to
normal wear or tool abuse. For further detail
of warranty coverage and warranty repair
information, visit www.DeWALT.com or call
1–800–4-DeWALT (1–800–433–9258). This
warranty does not apply to accessories or
damage caused where repairs have been
made or attempted by others. This warranty
gives you specific legal rights and you may
have other rights which vary in certain states
or provinces.
In addition to the warranty, DeWALT tools are
covered by our:
1 YEAR FREE SERVICE
DeWALT will maintain the tool and replace
worn parts caused by normal use, for free, any
time during the first year after purchase.
90 DAY MonEY BACk GuARAntEE
If you are not completely satisfied with the
performance of your DeWALT Power Tool,
Laser, or Nailer for any reason, you can return it
within 90 days from the date of purchase with
a receipt for a full refund - no questions asked.
RECONDITIONED PRODUCT: Reconditioned
product is covered under the 1Year Free
Service Warranty. The 90 Day Money Back
Guarantee and the Three Year Limited Warranty
do not apply to reconditioned product.
FREE WARNING LABEL REPLACEMENT: If your
warning labels become illegible or are missing,
call 1-800-4-DeWALT or visit your local service
center for a free replacement.
Protecting the
Environment
Separate collection. This product must
not be disposed of with normal
household waste.
Should you find one day that your DeWALT
product needs replacement, or if it is of no
further use to you, do not dispose of it with
household waste. Make this product available
for separate collection.
Separate collection of used products
and packaging allows materials to be
recycled and used again. Re-use of
recycled materials helps prevent
environmental pollution and reduces the
demand for raw materials.
Local regulations may provide for separate
collection of electrical products from the
household, at municipal waste sites or by the
retailer when you purchase a new product.
DeWALT provides a facility for the collection
and recycling of DeWALT products once they
have reached the end of their working life. To
take advantage of this service please return
your product to any authorised repair agent
who will collect them on our behalf.
You can check the location of your nearest
authorised repair agent by contacting your
local DeWALT office at the address indicated in
this manual. Alternatively, a list of authorised
DeWALT repair agents and full details of our
after-sales service and contacts are available
on the Internet at: www.2helpU.com.
9
E

Batteries
• When disposing batteries, think of the
protection of the environment.
• Check with your local authorities for
an environmentally safe way of battery
disposal.
Error Codes
If INFO appears on the display window with a Code number, perform the corresponding Corrective Action.
Code Description Corrective Action
IC101 Received signal too high Target is too reective. Use the target plate or change the target
surface.
IC201 Too much background light Reduce the background light on the target area.
IC302 Temperature out of range Allow device too warm or cool and repeat measurement
IC303 Distance not in range or
signal too low
Adjust range, if within range change target surface
IC401 Battery too low for
measurements
Recharge battery or change batteries if non-rechargeable
IC505 Hardware error Switch the device on/off several times. If error still occurs, return
device to Service Center or Distributor
IC601 Negative number Measure longer distance before shorter distance for positive result
IC604 Invalid measurement for
calculation
Remeasure distances, hypotenuse must be larger than sides of
triangle
10
E

Specifications
Range .2m to 30m
Measuring Accuracy* ± 3mm*
Resolution** 1mm**
Laser Class Class 2 (IEC/EN60825-1: 2014)
Laser Type ≤ 1.0mW @ 620-690nm
Backlight Automatic Switch-off After 20s
Laser After 120s
Unit Automatic Switch-off After 180s
Continuous Measuring Yes
Area/Volume Yes
Battery Life (2 x AAA) Up to 3000 Measurements
Dimension (H x D x W) 120 x 48.5 x 26mm
Weight (with Batteries) 100g
Storage Temperature Range -10° C ~ +60 C
Operating Temperature Range 0° C ~ +40° C
*Measuring Accuracy depends on the current conditions:
• Under favorable conditions (good target surface, low background illumination, and room temperature), up to 10m. The
measurement error can increase by ± 0.1mm/m for distances over 10m
• In unfavorable conditions (poor target surface, high background illumination, operating temperatures at the Upper or lower
end of the temperature range), the measurement range may be reduced and the accuracy can increase to ± 6mm for
distances under 10m. Beyond 10m the measurement error can increase by ±0.25mm/m.
**Resolution is the nest measurement you can see. In mm, that is 1mm.
11
E

12
EKR 목차
• 사용자안전사항
• 배터리안전사항
• 설정(배터리탑재)
• 사용
• 보증
• 에러코드
• 규격
향후참조를위해이설명서의모든
섹션을보관하십시오.
사용자 안전 사항
경고:이제품을사용하기전에
안전지침및제품설명서를
주의해서읽어주십시오.
제품을담당하는책임자는모든
사용자가이지침을이해하고
준수할수있도록확실하게
조치하십시오.
경고:사용자의편의와안전을
위해레이저클래스를알려주는
라벨정보가다음과같이레이저
공구에부착되어있습니다.
USA CANADA/LAG EU/GEMUSA
DWHT77100공구는그림A1에
표시된것처럼가시성레이저빔을
방출합니다.2019년5월8일에수립된
레이저고지56에기술된바와같이,
방출되는레이저빔은IEC60825-1
에따라레이저클래스2에해당되며
IEC60825-1ED.3에대한부합을
제외하고21CFR1040.10및1040.11
을준수합니다.
경고:레이저공구가작동하는
동안,방출되는레이저빔(
적색광원)에눈을노출시키지
않도록주의하십시오.레이저
빔에장시간노출되면눈이
상해를입을수있습니다.광학
보조기구로빔을들여다보지
마십시오.
경고:부상위험을줄이기위해
사용자는제품사용설명서,
레이저안전수칙설명서및
배터리안전정보를읽어야
합니다.
배터리 안전 사항
경고:배터리의폭발또는
누출로인해심각한부상이나
화재가발생할수있습니다.이런
위험을줄이는방법:
• 배터리라벨과패키지에있는
모든지침과경고사항을항상
준수하십시오.
• 배터리단자를단락하지마십시오.
• 알카라인배터리를충전하지
마십시오.
• 오래된배터리와새배터리를
혼합하지마십시오.브랜드와종류가
동일한새배터리로모든배터리를
동시에교체하십시오.
• 배터리화학물을혼합하지마십시오.
• 배터리를화염에노출시키지
마십시오.
• 절대로어린이가배터리를만지지
못하게하십시오.
• 장치를여러달동안사용하지
않을예정이라면항상배터리를
제거하십시오.
• 참고:권장배터리를사용하는지
확인하십시오.
참고:배터리가극성에맞게올바른
방식으로삽입되었는지확인하십시오.
설정(배터리 탑재)
1.공구뒷면에서배터리함래치의
위치를확인합니다(그림D2).

13
EKR
2.손가락으로래치를위로당겨잠금을
풀고배터리도어를제거합니다(그림
E1및2).
3.배터리함의안쪽에표시된각
배터리의-및+극위치를
확인하면서두개의AAA배터리를
삽입합니다(그림E3).
4.배터리도어하단에있는핀을
배터리함의홈에밀어넣습니다(그림
E4).
5.배터리도어가제자리에끼워질
때까지배터리도어를아래로
누릅니다(그림E5).
공구전원을켜면배터리레벨이
디스플레이창에표시됩니다(그림E1).
LDM 설정
공구 켜기
On(그림A3)을클릭하여공구를
켭니다.
기준위치변경하기
이공구는공구의하단(그림F1)또는
상단(그림F2)에서벽또는물체까지의
거리를측정합니다.
1.기어버튼(그림A4)을3초동안
길게누릅니다.측정기준위치
아이콘(그림C5)이디스플레이
창에서깜박입니다.
2.기어버튼을다시눌러서기준
위치를변경합니다.
3.On버튼(그림A3)을눌러서기준
위치를확인합니다.
측정 단위 변경하기
현재의측정이완료되면(장치가연속
측정모드에있지않은경우),측정
단위를소수점ft(6.21ft)에서분수
ft(6'02"9/16)로,분수ft에서미터(1.894
m)로,미터에서인치(749/16in)로,
또는인치에서소수점ft로변경할수
있습니다.
• 측정단위를변경하려면기어버튼(
그림A4)을3초동안길게눌러서
단위메뉴로들어갑니다.On버튼을
눌러서기준위치를확인합니다.
기준위치가확인되면,현재의측정
단위가표시됩니다.기어를눌러서
단위를변경하고On버튼을눌러서
확인합니다.
사용
벽또는물체까지의거리측정하기
1.거리를측정해야하는벽또는
물체를향해레이저(그림A1)를
겨냥합니다(그림F).
2.On버튼(그림A3)을눌러
공구에서벽또는물체까지의거리를
측정합니다.기준위치및/또는측정
단위를변경하려면LDM설정을
참조합니다.
3.디스플레이창(그림A2)의하단에
현재측정(그림C3)이표시되며,
사용자가공구를움직일때마다계속
변경됩니다.
측정을기록하려면On을클릭합니다.
다른측정을기록하려면On을다시
클릭합니다.그다음,1-3단계를
반복합니다.
면적 측정
벽,바닥또는물체의면적을측정할수
있습니다.
1.기어버튼(그림A4)을한번
눌러서면적아이콘(그림B1)
을디스플레이창(그림A2)에
표시합니다.
길이를 측정합니다.
1.공구를대상의한쪽끝에배치하고
길이를가로지르도록레이저도트를
겨냥합니다.(그림G2는공구의
상단에서측정하는경우어디에
공구를배치하는지나타냅니다.)

14
EKR
• MAKE DIST BUTTON ON BUTTON
2.On을누르면디스플레이창의첫
번째라인에길이측정이표시됩니다.
너비를 측정합니다.
1.대상(벽,바닥또는물체)의한쪽에
공구의상단을겨냥합니다.
2.공구를대상의한쪽끝에배치하고
너비를가로지르도록레이저
도트를겨냥합니다.(그림G1는
사용자가공구의상단에서측정하는
경우어디에공구를배치하는지
나타냅니다.)
3.On을누르면디스플레이창의
상단에너비측정이표시됩니다.
디스플레이창의하단에서면적측정을
확인합니다(그림E3).
부피 측정
공간또는물체의면적을측정할수
있습니다.
1.기어버튼(그림A4)을두번
눌러서부피아이콘을디스플레이창
(그림E3)에표시합니다.
너비를 측정합니다.
1.대상(공간또는물체)의한쪽에
공구의상단을겨냥합니다.
2.공구를대상의한쪽끝에배치하고
너비를가로지르도록레이저
도트를겨냥합니다.(그림H1는
사용자가공구의상단에서측정하는
경우어디에공구를배치하는지
나타냅니다.)
3.On을누르면디스플레이창의
상단에너비측정이표시됩니다.
길이를 측정합니다.
1.공구를대상의한쪽끝에배치하고
길이를가로지르도록레이저
도트를겨냥합니다.(그림H2는
사용자가공구의상단에서측정하는
경우어디에공구를배치하는지
나타냅니다.)
2.On을누르면디스플레이창의두
번째라인에길이측정이표시됩니다.
높이를 측정합니다.
1.공구를대상의한쪽끝에배치하고
높이를가로지르도록레이저
도트를겨냥합니다.(그림H3는
사용자가공구의하단에서측정하는
경우어디에공구를배치하는지
나타냅니다).
2.On을누르면디스플레이창의세
번째라인에높이측정이표시됩니다.
디스플레이창의하단에서부피측정을
확인합니다(그림C3).
큰 물체의 높이 측정
큰물체(예:큰빌딩)의높이를측정해야
하는경우,동일한지점에서물체의
2또는3지점까지의거리를토대로
높이를계산할수있습니다.이공구는
피타고라스정리(A2+B2=C2)를사용하여
높이를계산합니다.
2 지점까지의 거리
큰물체에있는두지점까지의거리를
사용하여(이중간접높이),높이를파악할
수있습니다(그림I1).
1.공구의레이저(그림A1)를벽또는
물체에겨냥합니다.다른사람의
눈에는겨냥하지마십시오.
2.On버튼(그림A3)을눌러공구를
켜고적색레이저도트를표시합니다.
3.기어버튼(그림A4)을세번
눌러서디스플레이창에피타고라스(
그림B1)를표시합니다.
4.높이를측정해야하는빌딩또는
물체의하단맞은편에공구를
배치합니다(그림I2).
5.빌딩또는물체의가장높은지점에
레이저를겨냥합니다(그림I2).
6.On버튼(그림A3)을눌러서
거리를측정합니다.

15
EKR
7.동일한지점에서빌딩또는물체의
수직아래가장낮은지점에똑바로
레이저를겨냥합니다(그림I3).
8.On버튼(그림A3)을눌러서
거리를측정합니다.
9.화면의하단라인에서빌딩또는
물체의높이를확인합니다.
3 지점까지의 거리
큰물체에있는세지점까지의거리를
사용하여,높이를파악할수있습니다(
그림J1).
1.공구의레이저(그림A1)를벽또는
물체에겨냥합니다.다른사람의
눈에는겨냥하지마십시오.
2.On버튼(그림A3)을눌러공구를
켜고적색레이저도트를표시합니다.
3.기어버튼(그림A4)을네번
눌러서디스플레이창(그림C7)에
피타고라스를표시합니다.
4.측정하려는수직높이의대략중간
지점맞은편에공구를배치합니다(
그림J2).
5.빌딩또는물체의가장높은지점에
레이저를겨냥합니다(그림J2).
6.On버튼(그림A3)을눌러서
거리를측정합니다.
7.동일한지점에서빌딩또는물체의
수직아래중앙지점에레이저를
겨냥합니다(그림J3).
8.On버튼(그림A3)을눌러서
거리를측정합니다.
9.동일한지점에서빌딩또는물체의
가장낮은지점에레이저를
겨냥합니다(그림J4).
10.On버튼(그림A3)을눌러서
거리를측정합니다.
11.화면의하단라인에서빌딩또는
물체의높이를확인합니다.
측정 더하기
두측정을더하여두거리의총측정값을
얻을수있습니다.
1.기어버튼(그림A4)을눌러서
더하기아이콘을디스플레이창(그림
E4)에표시합니다
2.On버튼(그림A3)을눌러
공구에서벽또는물체까지의거리를
측정합니다.
3.On버튼을눌러상단라인에첫번째
측정을기록합니다.
4.그다음벽또는물체에레이저(그림
A1)를겨냥합니다.
5.On버튼을눌러중간라인에두번째
측정을기록합니다.
6.디스플레이창의하단에서두
측정값의합을확인합니다(그림E
3).
측정 빼기
한측정에서다른측정을뺄수있습니다.
1.기어버튼(그림A4)을눌러서빼기
아이콘을디스플레이창(그림C3)
에표시합니다.
2.거리를측정해야하는벽또는
물체를향해공구레이저상단의
레이저(그림A1)를겨냥합니다.
3.On버튼(그림A3)을눌러
공구에서벽또는물체까지의거리를
측정합니다.
4.On버튼을눌러상단라인에첫번째
측정을기록합니다.
5.그다음벽또는물체에공구상단의
레이저를겨냥합니다.
6.On버튼을눌러중간라인에두번째
측정을기록합니다.
7.디스플레이창의하단에서두
측정값의차이를확인합니다(그림
C3).참고:두번째측정값이
첫번째보다큰경우:음수결과에
대해IC601이표시됩니다.첫번째
측정값이두번째보다크도록측정
지점을전환하십시오.
공구 전원 끄기
다음방법중하나로공구전원을끌수
있습니다:

16
EKR • On버튼(그림A3)을몇초동안
길게누릅니다(디스플레이창이
지워질때까지).
• 공구를180초동안사용하지않으면,
공구가자동으로꺼집니다.
3년 한정 보증
DeWALT는구입일로부터3년동안
재료또는제작불량으로인해
발생한결함을무료로수리해줍니다.
정상적인마멸또는공구남용으로
인한고장은이보장범위에들어가지
않습니다.보증범위및보증수리
정보에대해자세한내용이필요하면,
www.DeWALT.co.kr을방문하거나
DeWALT(대포번호1577-0933)
대표번호로
연락하십시오.
배터리,충전기외액세서리는구입일
로부터1년간품질을보증하며보증기간
내에제품의제조상하자로발생한
결함에
대해서는무상으로수리해드립니다.
환경보호
분리수거,본제품을일반가정용
쓰레기통에처리하면안됩니다.DeWALT
제품을교체해야하거나더이상
쓸모가없어졌다고판단될때에는본
제품을가정용쓰레기와함께처리하지
마십시오.이제품은분리수거하십시오.
사용하던제품과포장을분리수거하면
자원을재활용및재사용할수있습니다.
재활용자원을이용하면환경오염이
방지되고고철자원에대한수요를줄일
수있습니다.
지역에따라가정용가전제품을분리
수거하는규정이마련되어있거나새로운
제품을구입할때판매점에서폐기방법을
알려줄수있습니다.

17
EKR
규격
범위 7.9인치~100피트(0.2m~30m)
측정정확도* 10미터기준±1/8인치(±3mm)*
해상도** 1/16인치(1mm)**
레이저클래스 클래스2(IEC/EN60825-1:2014)
레이저유형 ≤1.0mW@620-690nm
백라이트자동꺼짐 20초후
레이저 120초후
장치자동꺼짐 180초후
연속측정 예
면적/부피 예
배터리수명(2xAAA) 최대3000회측정
치수(HxDxW) 4.72x1.91x1.02인치(120x48.5
x26mm)
무게(배터리포함) 3.21oz(100g)
보관온도범위 14°F~140°F(-10°C~
+60C)
작동온도범위 32°F~104°F(0°C~+40°
C)
*측정정확도는현재조건에따라다름:
양호한조건(좋은대상면,약한배경조명및상온)하에서최대
30’(10m).거리가30’(10m)를넘는경우측정오차가±0.1mm/m
만큼늘어날수있습니다.
안좋은조건(부실한대상면,강한배경조명,온도범위의상한또는
하한에가까운작동온도)에서측정범위가줄어들수있고30’(10m)
미만의거리에대해정확도가±6mm까지늘어날수있습니다.
30’(10m)를초과하면측정오차가±0.25mm/m만큼늘어날수
있습니다.
**해상도는볼수있는최상의측정치입니다.인치의경우,1/16"입니다.
mm의경우,1mm입니다.

18
EKR 에러코드
INFO(정보)가코드번호와함께디스플레이창에표시되면,해당되는
수정조치를수행하십시오.
코드 설명 수정조치
IC101 수신신호가너무
높음
대상의반사효과가너무강합니다.
표적판을사용하거나대상면을
변경하십시오.
IC201 배경빛이너무
많음
대상영역에서배경빛을줄이십시오.
IC302 온도범위이탈 장치를데우거나식힌후측정을
반복하십시오.
IC303 거리가범위를
벗어나거나
신호가너무낮음
범위를조정하고,범위내에있으면
대상면을변경하십시오.
IC401 배터리레벨이
낮아서측정불가
배터리를충전하거나,비충전식이면
배터리를교체하십시오.
IC505 하드웨어에러 장치를여러번껐다켜보십시오.
여전히에러가발생하면,장치를서비스
센터또는대리점으로반송하십시오.
IC601 음수 더먼거리를측정한후짧은거리를
측정하면양수결과가나옵니다.
IC604 계산에맞지않는
측정
거리를다시측정하십시오.삼각형의
빗변이다른두변보다커야합니다.
제품명:건전지-건전지(알칼리망간전지)
기본모델명:AAA-E92-LR03
신고번호:B052R1216-21001
종류:LR03
정격/안전기준상의모델구분:1.5V
극성:제품표면에표기
제조자명:EnergizerHouseholdProducts(Shanghai)Co.,Ltd.
수입자명:블랙앤드데커아시아퍼시픽피티이리미티드
사용권장기간:건전지에표시

19
EKR
사용권장기간:건전지에표시
제조국:중국
주소및전화번호:서울강남구역삼로218재승빌딩1층1577-0933
사용상주의사항:
1)누액,파열의우려가있으므로(+),(-)를바르게넣을것
2)충전,분해,단락,가열하지말것
3)다른전지와혼용하여사용하지말것

Notes:
