DeWalt XR DCS355 User manual

DCS355
DCS356
Final page size: A5 (148mm x 210mm)

B
Copyright DeWALT
English (original instructions) 5
简体中文 15
繁体中文 25
한국어 33

1
4
1
3
2
10
DCS356
DCS355
6
7
9
8
11
5
8
9
9
8
XXXX XX XX
25
Fig. A
图 A
圖 A
그림 A
Fig. B
图 B
圖 B
그림 B

2
3
22
24
23
16 18
12
20
Fig. C
图 C
圖 C
그림 C
Fig. D
图 D
圖 D
그림 D
Fig. F
图 F
圖 F
그림 F
Fig. E
图 E
圖 E
그림 E
Fig. G
图 G
圖 G
그림 G

3
14
7
1
14
7
7
6
6
7
16
15
21
13
5
6
Fig. H
图 H
圖 H
그림 H
Fig. I
图 I
圖 I
그림 I
Fig. J
图 J
圖 J
그림 J
Fig. K
图 K
圖 K
그림 K
Fig. M
图 M
圖 M
그림 M
Fig. L
图 L
圖 L
그림 L
Fig. N
图 N
圖 N
그림 N

4
2
4
1
13
17
15
16
5
21
17
23
17
19
Fig. O
图 O
圖 O
그림 O
Fig. Q
图 Q
圖 Q
그림 Q
Fig. R
图 R
圖 R
그림 R
Fig. S
图 S
圖 S
그림 S
Fig. P
图 P
圖 P
그림 P

ENGLISH
5
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.General Power Tool Safety Warnings
DCS355 DCS356
Voltage VDC 18(20 Max) 18(20 Max)
Battery type Li-Ion Li-Ion
Oscillating frequency min-1 0–20000 0–20000
Oscillating angle 1.6˚ 1.6˚
Speed 1 min-1 -15000
Speed 2 min-1 -17000
Speed 3 min-1 -20000
Weight (without battery pack) kg 1.1 1.1
WARNING: To reduce the risk of injury, read the
instructionmanual.
English (original instructions)
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
CORDLESS OSCILLATING MULTITOOL
DCS355, DCS356
Batteries Chargers / Charge Times (Minutes)
Cat# VDC Ah Weight(kg) DCB104 DCB107 DCB112
DCB1102
DCB115
DCB1104
DCB117
DCB1112 DCB118 DCB132
DCB546/DCB606 18/54 (20/60 Max) 6.0/2.0 1.08 60 270 170 90 40 60 90
DCB547/DCB609 18/54 (20/60 Max) 9.0/3.0 1.46 75* 420 270 135* 60 75* 135*
DCB548/DCB612 18/54 (20/60 Max) 12.0/4.0 1.46 120 540 350 180 80 120 180
DCB180 18 (20 Max) 3.0 0.62 45 140 90 45 45 45 45
DCB181 18 (20 Max) 1.5 0.35 22 70 45 22 22 22 22
DCB182/DCB204 18 (20 Max) 4.0 0.61 60/40** 185 120 60 60/40** 60/40** 60
DCB183/DCB203 18 (20 Max) 2.0 0.40 30 90 60 30 30 30 30
DCB184/DCB205 18 (20 Max) 5.0 0.62 75/50** 240 150 75 75/50** 75/50** 75
DCB187 18 (20 Max) 3.0 0.54 45 140 90 45 45 45 45
DCB189/DCB240 18 (20 Max) 4.0 0.54 60 185 120 60 60 60 60
DCB186 18 (20 Max) 6.0 0.95 60 270 170 90 60 60 90
DCB208 18 (20 Max) 8.0 0.95 70 360 240 120 70 70 120
DCBP034 18 (20 Max) 1.7 0.32 27 82 50 27 27 27 27
DCBP520 18 (20 Max) 5.0 0.75 75/50** 240 150 75 75/50** 75/50** 75
*Date code 201811475B or later
**Date code 201536 or later

6
ENGLISH
c ) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.

7
ENGLISH
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
of injury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130 °C may causeexplosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk of fire.
6) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Additional Safety Rules for Oscillating
Multi‑Tool
WARNING: Take special care when sanding some woods
(e.g. beech, oak) and metal which may produce toxic dust.
Wear a dust mask specifically designed for protection
against toxic dust and fumes and ensure that persons
within or entering the work area are alsoprotected.
WARNING: Use this tool in a well-ventilated area when
sanding ferrous metals. Do not operate the tool near
flammable liquids, gases or dust. Sparks or hot particles
from sanding or arcing motor brushes may ignite
combustiblematerials.
Sanding Paint
WARNING: Observe the applicable regulations for
sanding paint. Pay special attention to the following:
• Whenever possible, use a vacuum extractor for dustcollection.
• Take special care when sanding paint which is possibly
lead based:
ʵ Do not let children or pregnant women enter the
workarea.
ʵ All persons entering the work area should wear a mask
specially designed for protection against lead paint dust
andfumes.
ʵ Do not eat, drink or smoke in the workarea.
• Dispose of dust particles and any other removal debrissafely.
• Hold power tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring. Contact with a "live" wire will make
exposed metal parts of the tool "live" and shock theoperator.
• Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by hand or against your body leaves it unstable and may
lead to loss ofcontrol.
Residual Risks
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
Chargers
DeWALT chargers require no adjustment and are designed to be
as easy as possible tooperate.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
Your DeWALT charger is double insulated in
accordance with IEC60335; therefore no earth wire
isrequired.
If the supply cord is damaged, it must be replaced by a
specially prepared cord available through the DeWALT
serviceorganisation.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1mm2; the maximum length
is30m.

8
ENGLISH
When using a cable reel, always unwind the cablecompletely.
Important Safety Instructions for All Battery
Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
• Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only DeWALT rechargeable batteries. Other types of
batteries may burst causing personal injury anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such as,
but not limited to, steel wool, aluminum foil or any buildup
of metallic particles should be kept away from charger
cavities. Always unplug the charger from the power supply
when there is no battery pack in the cavity. Unplug charger
before attempting to clean
• DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
• These chargers are not intended for any uses other than
charging DeWALT rechargeable batteries. Any other uses
may result in risk of fire, electric shock orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when disconnecting
charger. This will reduce risk ofdamage to electric plug
andcord.
• Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire,electric shock, orelectrocution.
• Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
• Do not operate charger with damaged cord or plug—
have them replacedimmediately.
• Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
• Do not disassemble charger; take it to an authorised
service centre when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution
orfire.
• In case of damaged power supply cord the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
• Disconnect the charger from the outlet before
attempting any cleaning. This will reduce the risk of
electric shock. Removing the battery pack will not reduce
thisrisk.
• NEVER attempt to connect two chargerstogether.
• The charger is designed to operate on standard 220-
240V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig. B)
1. Plug the charger into an appropriate outlet before inserting
battery pack.
2. Insert the battery pack 1 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly indicating that the charging
process has started.
3. The completion of charge will be indicated by the red
light remaining ON continuously. The battery pack is fully
charged and may be used at this time or left in the charger.
To remove the battery pack from the charger, push the
battery release button 2 on the battery pack.
NOTE: To ensure maximum performance and life of lithium-ion
battery packs, charge the battery pack fully before first use.
Charger Operation
Refer to the indicators below for the charge status of the
batterypack.
Charge Indicators
Charging
Fully Charged
Hot/Cold Pack Delay*
*The red light will continue to blink, but a yellow indicator light
will be illuminated during this operation. Once the battery pack
has reached an appropriate temperature, the yellow light will
turn off and the charger will resume the charging procedure.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing to light.
NOTE: This could also mean a problem with a charger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised service centre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the

9
ENGLISH
charger as battery pack may rupture causing serious
personal injury.
• Charge the battery packs only in DeWALT chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in
locations where the temperature may reach or exceed
40 ˚C (104 ˚F) (such as outside sheds or metal buildings
in summer).
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium-ion battery packs are burned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15 minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithium salts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persists, seek
medicalattention.
WARNING: Burn hazard. Battery liquid may be flammable
if exposed to spark or flame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre for recycling.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys, etc.
CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knocked over.
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come in contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well insulated from
materials that could contact them and cause a short
circuit. NOTE: Lithium-ion batteries should not be put in
checkedbaggage.
DeWALT batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
pack charging mode. This feature ensures maximum battery
pack life.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery pack warms.
The DCB118 charger is equipped with an internal fan designed
to cool the battery pack. The fan will turn on automatically when
the battery pack needs to be cooled. Never operate the charger
if the fan does not operate properly or if ventilation slots are
blocked. Do not permit foreign objects to enter the interior of
the charger.
Electronic Protection System
XR Li-Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deep discharge.
The tool will automatically turn off if the Electronic Protection
System engages. If this occurs, place the lithium-ion battery
pack on the charger until it is fully charged.
Wall Mounting
These chargers are designed to be wall mountable or to sit
upright on a table or work surface. If wall mounting, locate the
charger within reach of an electrical outlet, and away from a
corner or other obstructions which may impede air flow. Use
the back of the charger as a template for the location of the
mounting screws on the wall. Mount the charger securely using
drywall screws (purchased separately) at least 25.4mm long
with a screw head diameter of 7–9mm, screwed into wood to
an optimal depth leaving approximately 5.5mm of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in the slots.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non-metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into a liquid.
Battery Packs
Important Safety Instructions for All Battery
Packs
When ordering replacement battery packs, be sure to include
catalogue number and voltage.
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging procedures outlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust or fumes.
• Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non-compatible

10
ENGLISH
Goods Regulations, International Maritime Dangerous Goods
(IMDG) Regulations, and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road (ADR).
Lithium-ion cells and batteries have been tested to section 38.3
of the UN Recommendations on the Transport of Dangerous
Goods Manual of Tests and Criteria.
In most instances, shipping a DeWALT battery pack will be
excepted from being classified as a fully regulated Class 9
Hazardous Material. In general, only shipments containing a
lithium-ion battery with an energy rating greater than 100 Watt
Hours (Wh) will require being shipped as fully regulated Class 9.
All lithium-ion batteries have the Watt Hour rating marked on
the pack. Furthermore, due to regulation complexities, DeWALT
does not recommend air shipping lithium-ion battery packs
alone regardless of Watt Hour rating. Shipments of tools with
batteries (combo kits) can be air shipped as excepted if the Watt
Hour rating of the battery pack is no greater than 100 Whr.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentation requirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the time
the document was created. However, no warranty, expressed or
implied, is given. It is the buyer’s responsibility to ensure that its
activities comply with the applicable regulations.
Transporting the FLEXVOLTTM Battery
The DeWALT FLEXVOLTTM battery has two modes: Use and
Transport.
Use Mode: When the FLEXVOLTTM battery stands alone or is
in a DeWALT 18V (20V MAX) product, it will operate as an 18V
(20V MAX) battery. When the FLEXVOLTTM battery is in a 54V
(60V MAX)or a 108V (120V MAX) (two 54V (60V MAX) batteries)
product, it will operate as a 54V (60V MAX) battery.
Transport Mode: When the cap is attached to the FLEXVOLTTM
battery, the battery is in Transport mode. Keep the cap for
shipping.
When in Transport mode, strings
of cells are electrically
disconnected within the pack
resulting in 3 batteries with a
lower Watt hour (Wh) rating as compared to 1 battery with a
higher Watt hour rating. This increased quantity of 3 batteries
with the lower Watt hour rating can exempt the pack from
certain shipping regulations that are imposed upon the higher
Watt hour batteries.
For example, the Transport
Wh rating might indicate
3x36 Wh, meaning 3
batteries of 36 Wh each.
The Use Wh rating might
indicate 108Wh (1battery implied).
Storage Recommendations
1. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold. For optimum
Example of Use and Transport Label Marking
battery performance and life, store battery packs at room
temperature when not in use.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimal results.
NOTE: Battery packs should not be stored completely depleted
of charge. The battery pack will need to be recharged before
use.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the labels
on the charger and the battery pack may show the following
pictographs:
Read instruction manual before use.
See Technical Data for charging time.
Do not probe with conductive objects.
Do not charge damaged battery packs.
Do not expose to water.
Have defective cords replaced immediately.
Charge only between 4 ˚C and 40 ˚C.
Only for indoor use.
Discard the battery pack with due care for the
environment.
Charge DeWALT battery packs only with designated
DeWALT chargers. Charging battery packs other
than the designated DeWALT batteries with a
DeWALT charger may make them burst or lead to
other dangerous situations.
Do not incinerate the battery pack.
USE (without transport cap). Example: Wh rating
indicates 108 Wh (1 battery with 108 Wh).
TRANSPORT (with built-in transport cap). Example:
Wh rating indicates 3 x 36 Wh (3batteries of 36 Wh).
Battery Type
The DCS355, DCS356 operate on a 18 volt (20V Max) battery
pack.

11
ENGLISH
These battery packs may be used: DCB181, DCB181, DCB182,
DCB183, DCB184, DCB187, DCB189, DCB203, DCB204,
DCB205,DCBP034,DCBP520, DCB546, DCB547, DCB548,
DCB549 DCB606, DCB609, DCB612. Refer to Technical Data for
moreinformation.
Package Contents
The package contains:
1 Adaptor for all blades
1 31mm x 43mm Fastcut wood blade
1 Sanding-pad
1 31 mm x 43 mm Wood with nails blade
1 Rigid scraper blade**
1 Blade adaptor hex key
1 Dust extraction adaptor**
1 Cutting guide**
1 100mm Semicircle blade**
25 Assorted sandpaper pieces
1 9.5mm x 43mm Wood detail blade**
1 3mm Carbide grout removal blade (100mm half moon)**
1 Cutting guide hex key**
1 Instruction manual
** Accessory included only with NT models and kits containing
battery andcharger.
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Visible radiation. Do not stare into light.
Date Code Position (Fig. B)
The date code 25, which also includes the year of manufacture,
is printed into thehousing.
Example:
2022 XX XX
Year of Manufacture
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Variable speed trigger
2 LED Worklight
3 Accessory clamp lever
4 Lock on/off button
5 Accessory side mount slots
6 Cut guide block
7 Cut guide arm
8 Battery pack
9 Battery release button
10 Speed selector (DCS356)
Intended Use
This oscillating multi-tool is designed for professional detail
sanding, plunge cutting, flush cutting, removal of excess
materials and surface preparationapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This oscillating multi-tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
WARNING: Use only DeWALT battery packs andchargers.
WARNING: Risk of lacerations or burns. Do not touch
the sharp edges of accessories at any time. Do not
touch workpiece or blade immediately after operating the
tool. They can become very hot. Handle carefully. Always
allow accessories and workpiece to cool beforehandling.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack 1 is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack 1 with the rails inside the tool’s
handle (Fig. B).

12
ENGLISH
Attaching Accessories Using the Universal
Adapter (Fig.G)
CAUTION: To avoid injury, do not use any accessory
for an application where the adaptor may fail to hold
theaccessory.
CAUTION: Read and follow all manufacturers' safety
warnings for any accessories used with thistool.
CAUTION: To avoid injury, ensure adaptor and accessory
are securelytightened.
Non-DeWALT accessories can be attached using the
universaladaptor.
1. Place the washer20 on thetool.
2. Place accessory12 on towasher.
3. Tighten and secure adaptor nut18 using hex wrench16.
Attaching the Cut Guide (Fig.H–M)
The depth/cut guide allows you to precisely cut material at a
specified depth and more accurately track a marked cutline.
1. Attach the cut guide block6 by inserting the accessory
tabs13 on the guide into the accessory side mount slots5
on the main body of thetool.
NOTE: The depth/cut guide can be attached to either side
of thetool.
2. Secure the block to the main body with the supplied
screw15 and washer21. Tighten with the supplied hex
wrench16.
Depth Guide (Fig. I, J)
This feature allows you to precisely cut material at a
specifieddepth.
1. Insert the guide arm7 as shown in FigureI into the front
slot on the guide block6.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired cut depth as shown in
FigureJ.
3. Secure the guide in place by turning the depth/cut
adjustment knob14 clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
Cut Guide (Fig. K–M)
This feature allows you to more accurately track a marked
cutline.
1. Insert the guide arm7 as shown in FigureK into the slots
on the left and right sides of the guide block6.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired length as shown in FigureL.
3. Secure the guide in place by turning the depth/cut
adjustment knob14 clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
NOTE: The guide arm can also be placed in the guard assembly
vertically in order to set the height off a cut. Refer to FigureM.
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button 2 and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button 11. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level of
charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Installing/Removing Accessories (Fig.C–M,Q)
Tool-free Accessory clamp (Fig.C–E)
The DCS355, DCS356 features a quick change accessory system.
This allows for faster accessory changes without the need for
wrenches or hex keys like other oscillating toolsystems.
1. Grasp the tool and squeeze the accessory clamping lever3
as shown in FigureC.
2. Clean any residual debris from the tool shaft and the
accessoryholder.
3. Slide the accessory between the shaft22 and the accessory
holder making sure the accessory engages all eight pins on
the holder and is flush with the shaft. Ensure the accessory is
oriented as shown in FigureD.
4. Release the accessory clamplever.
NOTE: Some accessories, such as scrapers and blades can be
mounted at an angle if required as shown in FigureE.
Installing/Removing Sanding Sheets (Fig.F)
A diamond shaped platen uses a hook and loop adhesion
system to attach the sanding sheets. The platen allows you to
use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen23 as described under
Installing/RemovingAccessories.
2. Align the edges on the sanding sheet, with the edge of
the sanding platen and press the sanding sheet24 onto
theplaten.
3. Firmly press the base with the sanding sheet attached
against a flat surface and briefly switch the tool on. This
provides for good adhesion between the platen and the
sanding sheet and also helps to prevent prematurewear.
4. When the tip of the sanding sheet becomes worn, detach
the sheet from the platen, rotate andreapply.

13
ENGLISH
Speed Selector (Fig. A)
DCS356
Your tool is equipped with a speed selector 10 which allows
you to select one of the three speeds that limits the full speed.
Select the speed based on the application and control the speed
of the tool using the variable speed trigger switch 1.
LED Worklight (Fig.P)
The LED worklight2 will activate when the trigger is depressed.
It will automatically shut off following a short period of time
once the trigger isreleased.
Using the Dust Extraction Adaptor with the
Sanding Platen (Fig.R)
1. Attach the dust extraction adaptor17. Refer to Attaching
the Dust ExtractionAdaptor.
2. Attach the sanding platen23 as described under
Installing/RemovingAccessories.
3. Attach sanding sheet as described under Installing/
Removing SandingSheets.
Using the Dust Extraction Adaptor with
Plunge Cutting Accessory (Fig.S)
1. Attach the dust extraction adaptor. Refer to Attaching the
Dust ExtractionAdaptor.
2. Push dust extraction arm19 into the lower aperture of the
dust extraction adaptor17.
3. Attach plunge cutting blade as described under Installing/
RemovingAccessories.
4. Adjust the dust extraction arm19 for bestresults.
Helpful Hints
• Always ensure the workpiece is firmly held or clamped to
prevent movement. Any movement of the material may
affect the quality of the cutting or sandingfinish.
• Do not start sanding without having the sandpaper
attached to sandingplaten.
• Use coarse grit paper to sand rough surfaces, medium grit
for smooth surfaces and fine grit for the finishing surfaces. If
necessary, first make a test run on scrapmaterial.
• Excessive force will reduce the working efficiency and cause
motor overload. Replacing the accessory regularly will
maintain optimum workingefficiency.
• Do not allow the sandpaper to wear away, it will damage
the sandingpad.
• If the tool overheats, especially when used at low speed,
set the speed to maximum and run it with no load for 2–3
minutes to cool the motor. Avoid prolonged usage at very
low speeds. Always keep the bladesharp.
Attaching the Dust Extraction Adaptor
(Fig.Q)
The Dust Extraction Adaptor allows you to connect the tool to
an external dust extractor, either using the AirLock™ system
(DWV9000-XJ), or a standard 35mm dust extractorfitment.
1. Attach the dust extraction adaptor17 by inserting the
tabs13 in to the accessory side mount slots5.
NOTE: The dust extraction adaptor can be attached to either
side of thetool.
2. Insert screw15 and washer21 into the dust extraction
adaptor17 and tighten with the supplied hex wrench16.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
WARNING: Ensure switch is fully OFF before installing
thebattery.
Proper Hand Position (Fig. N)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires the tool to be held as shown in
FigureN.
Instructions for Use (Fig. A)
1. Install the batterypack.
2. To turn the tool ON, hold it as shown in FigureN and press
the variable speed trigger1.
NOTE: The further the trigger switch is depressed the faster
the tool will operate. If in doubt about the proper speed
for your operation, test the performance at low speed and
gradually increase until a comfortable speed isfound.
3. To turn the tool OFF, release the variable speed trigger1.
Lock on/off Button (Fig.O)
The tool can be locked off by fully depressing the lock on/off
button4 shown in FigureO.
For more comfort in extended use applications, the lock
on/off button4 can lock the trigger trigger1 in the
depressedposition.
NOTE: The tool will automatically shut off after operating for
five minutes with the lock-on button engaged. To restart the
tool, the user will have to release the trigger and repress lock-
onbutton.

14
ENGLISH
Oscillating multi-material blade
Oscillating rigid scraper blade
Oscillating flexible scraper blade
Oscillating carbide grout removal blade
Oscillating fastcut carbide grout removal blade
Oscillating carbide rasp
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
the tool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed of properly.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING:To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Compatible accessories
Oscillating sanding pad
Oscillating wood w/ nails blade
Wide titanium oscillating wood w/ nails blade
Oscillating hardwood blade
Oscillating fastcut wood blade
Wide oscillating fastcut wood blade
Oscillating wood detail blade
Oscillating titanium metal blade
Oscillating semicircle blade
Oscillating titanium semicircle blade
Oscillating flush cut blade
Titanium oscillating flush cut blade

15
简体中文
16
中文简体
恭喜！
感谢您选购得伟工具。凭借多年的产品开发和创新
经验，得伟已经成为专业电动工具用户最可靠的合
作伙伴之一。
技术参数
DCS355 DCS356
电压 VDC 18(20 Max) 18(20 Max)
电池类型 锂离子 锂离子
频率 min-1 0–20000 0–20000
角度 1.6˚ 1.6˚
速度 1 min-1 -15000
速度 2 min-1 -17000
速度 3 min-1 -20000
重量（不包括电池） kg 1.1 1.1
a
警告：为降低伤害风险，请阅读使用手册。
定义：安全指南
下列定义描述了各标志术语的严重程度。请仔细阅
读本手册，并注意这些标志。

危险：表示存在紧急危险情况，如果不加以避
免，将导致死亡或严重伤害。

警告：表示存在潜在的危险情况，如果不加以
避免，可能导致死亡或严重伤害。

小心：表示存在潜在危险情况，如果不加以避
免，可能导致轻度或中度伤害。
注意：表示存在不涉及人身伤害的情况，若 如
果不加以避免，可能导致财产损失。

表示存在触电风险。

表示存在火灾风险。
锂电无刷磁浮万能用途工具
DCS355,DCS356
电池 充电器/充电时间（分钟）
目录号 伏特直流 安时 重量
（千克） DCB104 DCB107 DCB112
DCB1102
DCB115
DCB1104
DCB117
DCB1112 DCB118 DCB132
DCB546/DCB606 18/54 (最大20/60) 6.0/2.0 1.05 60 270 170 90 40 60 90
DCB547/DCB609 18/54 (最大20/60) 9.0/3.0 1.46 75* 420 270 135* 60 75* 135*
DCB548/DCB612 18/54 (最大20/60) 12.0/4.0 1.44 120 540 350 180 80 120 180
DCB180 18 (最大20) 3.0 062 45 140 90 45 45 45 45
DCB181 18 (最大20) 1.5 0.35 22 70 45 22 22 22 22
DCB182/DCB204 18 最大20) 4.0 0.61 60/40** 185 120 60 60/40** 60/40** 60
DCB183/DCB203 18 (最大20) 2.0 0.40 30 90 60 30 30 30 30
DCB184/DCB205 18 (最大20) 5.0 0.62 75/50** 240 150 75 75/50** 75/50** 75
DCB187 18 最大20) 3.0 0.54 45 140 90 45 45 45 45
DCB189/DCB240 18 (最大20) 4.0 0.54 60 185 120 60 60 60 60
DCB186 18 (最大20) 6.0 0.95 60 270 170 90 60 60 90
DCB208 18 (最大20) 8.0 0.95 70 360 240 120 70 70 120
DCBP034 18 (最大20) 1.7 0.32 27 82 50 27 27 27 27
DCBP520 18 (最大20) 5.0 0.75 75/50** 240 150 75 75/50** 75/50** 75
*
日期码 201811475B 或以后
** 日期码 201536 或以后

16
简体中文
17
中文简体
e )
手不要过分伸展。时刻注意立足点和身体平
衡。这样能在意外情况下能更好地控制住电
动工具。
f ) 着装适当。不要穿宽松衣服或佩戴饰品。让你
的头发和衣服远离运动部件。宽松衣服、佩饰
或长发可能会卷入运动部件。
g ) 如果提供了与排屑、集尘设备连接用的装置，
要确保其连接完好且使用得当。使用集尘装
置可降低尘屑引起的危险。
h ) 不要因为频繁使用工具而产生的熟悉感而掉
以轻心，忽视工具的安全准则。某个粗心的动
作可能在瞬间导致严重的伤害。
4) 电动工具使用和注意事项
a )
不要勉强使用电动工具，根据用途使用合适
的电动工具。选用合适的按照额定值设计的
电动工具会使你工作更有效、更安全。
b ) 如果开关不能接通或关断电源，则不能使用
该电动工具。不能通过开关来控制的电动工
具是危险的且必须进行修理。
c ) 在进行任何调节、更换附件或贮存电动工具
之前，必须从电源上拔掉插头和／或卸下电
池包（如可拆卸）。这种防护性的安全措施降
低了电动工具意外起动的风险。
d ) 将闲置不用的电动工具贮存在儿童所及范围
之外，并且不允许不熟悉电动工具和不了解
这些说明的人操作电动工具。电动工具在未
经培训的使用者手中是危险的。
e ) 维护电动工具及其附件。检查运动部件是否
调整到位或卡住，检查零件破损情况和影响
电动工具运行的其他状况。如有损坏，应在使
用前修理好电动工具。许多事故是由维护不
良的电动工具引发的。
f ) 保持切削刀具锋利和清洁。维护良好地有锋
利切削刃的刀具不易卡住而且容易控制。
g ) 按照使用说明书，并考虑作业条件和要进行
的作业来选择电动工具、附件和工具的刀头
等。将电动工具用于那些与其用途不符的操
作可能会导致危险情况。
h ) 保持手柄和握持表面干燥、清洁，不得沾有油
脂。在意外的情况下，湿滑的手柄不能保证握
持的安全和对工具的控制。
5) 电池式工具使用和注意事项：
a )
仅使用生产者规定的充电器充电。将适用于
某种电池包的充电器用到其他电池包时可能
会发生着火危险。
b ) 仅使用配有专用电池包的电动工具。使用其
他电池包可能会产生伤害和着火危险。
c ) 当电池包不用时，将它远离其他金属物体，例
如回形针、硬币、钥匙、钉子、螺钉或其他小金
属物体，以防电池包一端与另一端连接。电池
包端部短路会引起燃烧或着火。
电动工具通用安全警告


警告！阅读随电动工具提供的所有安全警告、
说明、图示和规定。不遵照以下所列说明会导
致电击、着火和/或严重伤害。
保存所有警告和说明书以备查阅。
警告中的术语“电动工具”指市电驱动（有线）电动
工具或电池驱动（无线）电动工具。
1) 工作场地的安全
a )
保持工作场地清洁和明亮。杂乱和黑暗的场
地会引发事故。
b ) 不要在易爆环境，如有易燃液体、气体或粉尘
的环境下操作电动工具。电动工具产生的火
花会点燃粉尘或气体。
c ) 操作电动工具时，远离儿童和旁观者。注意力
不集中会使你失去对工具的控制。
2) 电气安全
a )
电动工具插头必须与插座相配。绝不能以任
何方式改装插头。需接地的电动工具不能使
用任何转换插头。未经改装的插头和相配的
插座将降低电击风险。
b ) 避免人体接触接地表面，如管道、散热片和
冰箱。如果你身体接触接地表面会增加电击
风险。
c ) 不得将电动工具暴露在雨中或潮湿环境中。
水进入电动工具将增加电击风险。
d ) 不得滥用软线。绝不能用软线搬运、拉动电
动工具或拔出其插头。使软线远离热源、油、
锐边或运动部件。受损或缠绕的软线会增加
电击风险。
e ) 当在户外使用电动工具时，使用适合户外使
用的延长线。适合户外使用的电线将降低电
击风险。
f ) 如果无法避免在潮湿环境下操作电动工具，
应使用带有剩余电流装置（ RCD ）保护的电
源。 RCD 的使用可降低电击风险。
3) 人身安全
a )
保持警觉，当操作电动工具时关注所从事的
操作并保持清醒。当你感到疲倦，或在有药
物、酒精或治疗反应时，不要操作电动工具。
在操作电动工具时瞬间的疏忽会导致严重
人身伤害。
b ) 使用个人防护装置。始终佩戴护目镜。防护
装置，诸如适当条件下使用防尘面具、防滑
安全鞋、安全帽、听力防护等装置能减少人
身伤害。
c ) 防止意外起动。在连接电源和/或电池盒、拿
起或搬运工具前确保开关处于关断位置。手
指放在开关上搬运工具或开关处于接通时通
电会导致危险。
d ) 在电动工具接通之前，拿掉所有调节钥匙或
扳手。遗留在电动工具旋转零件上的扳手或
钥匙会导致人身伤害。

17
简体中文
18
中文简体
‒ 听力损伤。
‒ 飞溅颗粒造成的人身伤害风险。
‒ 操作过程中配件加热而产生的烧伤危险。
‒ 长时间使用引起的人身伤害风险。
‒ 撕裂或灼伤风险。任何时候都请勿触碰配件的锐
边。
工具上的标记
工具上印有下列标志：
使用前请阅读使用手册。
日期码位置（图B）
包含制造年份的日期码 (25) 印在工具外壳上。
例如：
2022 XX XX
制造年份
请妥善保管好这些说明
充电器
DeWALT充电器无需做出任何调整，专为简易操作
而设计。
电气安全
电机只适用一种工作电压。请务必检查电池包的电
压是否和铭牌上的电压一致。另外，请确保充电器电
压和主电源的电压一致。
DeWALT
充电器符合 IEC60335 双重绝缘要求，
因此无需使用接地线。
如果电源线损坏，必须由
DeWALT
或授权的维修机构
负责更换。
使用延长线
除非绝对必要，否则请勿使用延长线。使用适合您的
充电器输入功率的合格延长线（见 技术参数 ）。最 小
的导线尺寸为 1 平方毫米；最大长度为 30 米。
使用电缆卷筒时，请务必拉出所有的电缆。
针对所有电池充电器的重要安全说明
请妥善保管好这些说明： 本手册包含重要的兼容电
池充电器安全和操作说明（请参阅 技术参数 ）。
•
在使用充电器之前，请先阅读所有指示以及充电
器、电池包和使用电池包的产品上的警告标记。

警告： 触电危险。切勿让任何液体进入充电
器，否则可能会导致触电。


警告：我们建议使用漏电保护额定电流为 30
毫安或以下的漏电保护装置。
d )
在滥用条件下，液体可能会从电池包中溅出，
应避免接触。如果意外碰到液体，用水冲洗。
如果液体碰到了眼睛，还要寻求医疗帮助。从
电池中溅出的液体可能会发生腐蚀或燃烧。
e ) 不要使用损坏或改装过的电池包或工具。损
坏或改装过的电池包可能呈现无法预测的结
果，导致着火、爆炸或伤害。
f ) 不要将电池包暴露于火或者高温中。电池
包暴露于火或高于 130°C 的高温中可能导致
爆炸。
6) 维修
a )
让专业维修人员使用相同的备件维修电动工
具。这将保证所维修的电动工具的安全。
b ) 决不能维修损坏的电池包。电池包仅能由生
产者或其授权的维修服务商进行维修。
万能用途工具的附加安全规定
警告：打磨某些可能会产生有毒粉尘的
木材（例如山毛榉、橡木等）和金属时，应
特别小心。应佩戴专用于防护粉尘和烟
雾的防尘面具，并确保工作场所内或进
入工作场所的人员也受到保护。
警告：打磨黑色金属要在通风良好的场
所进行。请勿在易燃液体、气体或粉尘附
近使用本工具。打磨或马达电刷的电弧
产生的火花或高热粒子可能会引燃易燃
材料。
打磨油漆
警告：请遵守适用的打磨油漆的规定。请
特别注意下列事项：
• 尽可能使用真空吸尘器来收集粉尘。
• 打磨可能含有铅的油漆时，请特别注意：
‒ 禁止让儿童或孕妇进入工作场所。
‒ 任何进入工作场所的人员都须佩戴专用
于防护含铅油漆灰尘和烟雾的面具。
‒ 禁止在工作场所内饮食或抽烟。
• 以安全的方式处理粉尘颗粒和任何其他碎
屑。
• 执行操作时，如果切割工具可能会接触隐藏的电
线，请通过绝缘手柄表面握住电动工具。如果接
触到“带电”导线，电动工具金属部件表面就会带
电并使操作人员触电。
• 请使用夹具或采取其它可行的方法，把工件可靠
地固定在稳定的平台上。手持或用身体顶住工件
都是不稳定的，可能会造成失控。
剩余风险
尽管遵守了相关的安全法规并采用了安全装备，某
些剩余风险仍然是无法避免的。这些风险包括：

18
简体中文
19
中文简体
2. 将电池包
(1)
插入到充电器中，确定电池包完全
就位。红色（充电中）指示灯将不断闪烁，表示充
电过程已经开始。
3. 红色灯持续亮起表示充电完成。此时电池包已完
全充电，您可以使用电池包或将电池包留在充电
器上。要从充电器上取下电池包，请按下电池包
上的电池释放按钮 (2) 。
注：为了确保锂离子电池的效能和使用寿命最大化，
在首次使用电池包之前必须将其完全充电。
充电器操作
关于电池包的充电状态，请参阅以下指示灯说明。
充电状态指示灯
F充电中 I
G已完全充电 J
H热/冷电池包延迟* K
*红色指示灯会继续闪烁，但黄色指示灯在本次操作
过程中会亮起。电池包达到适当温度后，黄色指示
灯会熄灭，充电器将恢复充电程序。
此兼容充电器不能为故障的电池包充电。充电器指
示灯不亮时表示电池有故障。
注：这也可能意味着充电器有故障。
如果充电器提示存在故障，请将充电器和电池包送
到授权的服务中心进行测试。
热/冷电池包延迟
当充电器检测到电池包过热或过冷时，它会自动启
动热/冷电池延迟模式，暂停充电，直到电池包达到
适当的温度。然后，充电器会自动切换到电池包充电
模式。此功能可确保电池包拥有最长的使用寿命。
冷电池包充电速度比热电池包充电速度慢。电池包在
整个充电周期的充电速度都会较慢，即使电池包升温
也不会恢复到最大速度。
DCB118 充电器配备专用于冷却电池包的内部风扇。
电池包需要冷却时，风扇会自动启动。如果风扇运转
不正常或通风槽堵塞，切勿操作充电器。请勿让异物
进入充电器内部。
电子保护系统
XR 锂离子电池工具具有电子保护系统设计，可保护
电池包免受过载、过热或过度放电之害。
如果电子保护系统处于运作状态，该工具将自动停
止操作。如果发生这种情况，请将锂离子电池包放在
充电器上，直至其完全充电。
壁挂式安装
这些充电器设计为可以安装在墙上，也可以直立在
桌面或工作台面上。如果安装在墙上，请确保充电器
的位置可以连接到电源插座，并且远离墙角或其他
可能妨碍空气流通的障碍物。将充电器背面作为在
墙上安装螺丝的位置模板。使用至少 25.4 毫米长、螺

小心： 灼伤危险。为降低人身伤害风险，请仅
使用
DeWALT
充电式电池充电。使用其它类
型的电池可能会引起爆裂，并导致人身伤害
和损害。

小心：应看管好儿童，以确保他们不将此设备
当做玩具来玩。
注意：在某些情况下，当充电器的插头插入电
源插座时，充电器内部裸露的充电接触点可
能因为外来物件而短路。请勿让能导电的异
物靠近充电器腔，这些外来物件包括但不限
于钢棉、铝箔或任何金属颗粒的堆积物。充电
器内没有电池包时，请断开充电器与电源的
连接。清洗前，务必拔掉充电器。
• 请勿试图使用本手册指定的充电器以外的其他
任何充电器为电池包充电。充电器和电池包都是
专门设计的，互相配合使用。
• 除了为
DeWALT
充电式电池充电以外，这些充电
器并非设计用于其他用途。否则，可能会导致火
灾、触电或电击。
• 请勿将充电器暴露于雨中或雪中。
• 断开充电器连接时，应拔下插头，切勿拉拽电源
线。这将降低对电插头和电线的损害风险。
• 确保电源线布置在不易踩踏、踢绊、拉扯或会受
到损害或压力的位置。
• 除非绝对必要，否则请勿使用延长线。使用不正
确的延长线可能导致火灾、触电或电击的风险。
• 请勿将任何物件放在充电器上面，或是把充电
器放在可能会堵住通风槽的柔软表面，导致充
电器的内部过热。请把充电器放置在远离任何
热源的地方。充电器通过外壳顶端和底端的槽
进行通风。
• 禁止使用电源线或插头已损坏的充电器，请立即
更换这些充电器。
• 如果充电器受到强烈重击、掉落或出现其他损坏
情况，请勿使用充电器。请将损坏的充电器送到
授权服务中心。
• 请勿自行拆卸充电器。请将需要检修或修理的充
电器送到授权服务中心。重装不正确可能导致触
电、电击或火灾风险。
• 必须立即将已损坏的电源线交由制造商、服务代
理或类似的合格人员进行更换以防止安全隐患。
• 清洁前，请先断开充电器和插座的连接，以降低
触电风险。取出电池包不会降低此风险。
• 切勿将两个充电器连接在一起。
• 充电器是为  220V-240V  的标准家用电源而设计。
请勿试图在任何其他电压下使用充电器。此规则
不适用于车载充电器。
为电池充电 (图B)
1. 插入电池包前，先将充电器的插头插到相应的电
源插座上。
