DeWalt XR Li-Ion DCL050-XE User manual

DCL050-XE
18V LED HAND-HELD WORKLIGHT
INSTRUCTION MANUAL

1
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal
word. Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury which, if
not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR ANY DEWALT TOOL,
CALL US AT: 1800 338 002 (Aust) or 0800 339 258 (NZ).
Technical Data
DCL050-XE
Voltage V 18
Weight kg 0.68
SAFETY INSTRUCTIONS FOR POWER TOOLS
When using power tools, always observe the safety regulations applicable in your
country to reduce the risk of fire, electric shock and personal injury. Read the following
safety instructions before attempting to operate this product. Keep these instructions in
a safe place.
WARNING: To reduce the risk of injury, read the instruction manual.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious
injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool. This worklight is a power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or

2
under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories,
or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits, etc. in accordance with
these instructions, taking into account the working conditions and the work
to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects like
paper clips, coins, keys, nails, screws, or other small metal objects that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
Electrical Safety
The electric motor has been designed for one voltage range only. Always check that
the power supply corresponds to the voltage on the rating plate. 220–240 V AC
means your tool will operate on alternating current. Operation at a voltage outside this
range can cause loss of power and can result in overheating. All DEWALT tools are

3
factory tested; if this tool does not operate, check the power supply. Your DEWALT
tool is double insulated, therefore no earth wire is required.
• Young children and the infirm. This appliance is not intended for use by young
children or infirm persons without supervision.
– This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
– Children should be supervised to ensure that they do not play with the appliance.
•Replacement of the supply cord. If the supply cord or plug is damaged, it must
be replaced by the manufacturer or an authorised DEWALT Service Centre in
order to avoid a hazard.
Extension Cords
CAUTION: Use only extension cords that are approved by the country’s Electrical
Authority. Before using extension cords, inspect them for loose or exposed wires,
damaged insulation and defective fittings. Replace the cord if necessary.
Specific Safety Rules for Worklights
WARNING: Fire hazard. Do not operate worklight near flammable liquids or in
gaseous or explosive atmospheres. Internal sparks may ignite fumes causing personal
injury.
• Do not expose light to wet or damp areas. Do not expose light to rain or snow.
• Do not wash light with water or allow water to get inside light. Do not submerge
light in water at any time.
WARNING: Do not place the worklight in a position which may cause anyone to
intentionally or unintentionally stare into the light. Serious eye injury could result.
CAUTION: When not in use, place light on its side on a stable surface where it
will not cause a tripping or falling hazard. Some products with large battery packs
will stand upright on the battery pack but may be easily knocked over.
• The label on your worklight may include the following symbols. The symbols and
their definitions are as follows:
V......................volts A.........................amperes
Hz ....................hertz W........................watts
min ..................minutes or AC ............alternating current
or DC.....direct current or AC/DC......alternating or
...................Class I Construction ...........................direct current
(grounded) no .......................no load speed
...................Class II Construction n .........................rated speed
(double insulated) .......................earthing terminal
…/min .............per minute .......................safety alert symbol
BPM.................beats per minute IPM .....................impacts per minute
RPM.................revolutions per minute SPM....................strokes per minute
sfpm ................surface feet per minute
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE
Important Safety Instructions for All Battery Packs
When ordering replacement battery packs, be sure to include the catalog number and
voltage. Consult the chart at the end of this manual for compatibility of chargers and
battery packs.
The battery pack is not fully charged out of the carton. Before using the battery pack
and charger, read the safety instructions below and then follow charging procedures
outlined.
READ ALL INSTRUCTIONS
• Do not charge or use the battery pack in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Inserting or removing the
battery pack from the charger may ignite the dust or fumes.
• Never force the battery pack into the charger. Do not modify the battery pack
in any way to fit into a non-compatible charger as battery pack may rupture
causing serious personal injury. Consult the chart at the end of this manual for
compatibility of batteries and chargers.
• Charge the battery packs only in designated DEWALT chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in locations where the
temperature may reach or exceed 40 °C (105 °F) (such as outside sheds
or metal buildings in summer). For best life store battery packs in a cool, dry
location.

4
Important Safety Instructions for All Battery Chargers
SAVE THESE INSTRUCTIONS: This manual contains important safety and operating
instructions for battery chargers.
• Before using the charger, read all instructions and cautionary markings on the
charger, battery pack and product using the battery pack.
WARNING: Shock hazard. Do not allow any liquid to get inside the charger. Electric
shock may result.
CAUTION: Burn hazard. To reduce the risk of injury, charge only DEWALT
rechargeable battery packs. Other types of batteries may overheat and burst resulting
in personal injury and property damage.
NOTICE: Under certain conditions, with the charger plugged into the power supply, the
charger can be shorted by foreign material. Foreign materials of a conductive nature,
such as, but not limited to, grinding dust, metal chips, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from the charger cavities. Always
unplug the charger from the power supply when there is no battery pack in the cavity.
Unplug the charger before attempting to clean.
•DO NOT attempt to charge the battery pack with any chargers other than the
ones in this manual. The charger and battery pack are specifically designed to
work together.
• These chargers are not intended for any uses other than charging DEWALT
rechargeable batteries. Any other uses may result in risk of fire, electric shock
or electrocution.
• Do not expose the charger to rain or snow.
• Pull by the plug rather than the cord when disconnecting the charger. This will
reduce the risk of damage to the electric plug and cord.
• Make sure that the cord is located so that it will not be stepped on, tripped
over or otherwise subjected to damage or stress.
• Do not use an extension cord unless it is absolutely necessary. Use
of improper extension cord could result in risk of fire, electric shock or
electrocution.
• When operating a charger outdoors, always provide a dry location and use an
extension cord suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
NOTE: Do not store the battery packs in a tool with the trigger switch locked
on. Never tape the trigger switch in the ON position.
WARNING: Fire hazard. Never attempt to open the battery pack for any reason. If
the battery pack case is cracked or damaged, do not insert into the charger. Do not
crush, drop or damage the battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or damaged in any way (e.g.,
pierced with a nail, hit with a hammer, stepped on). Damaged battery packs should be
returned to the service center for recycling.
WARNING: Fire hazard. Do not store or carry the battery pack so that metal
objects can contact exposed battery terminals. For example, do not place the battery
pack in aprons, pockets, tool boxes, product kit boxes, drawers, etc., with loose
nails, screws, keys, etc. Transporting batteries can possibly cause fires if the battery
terminals inadvertently come in contact with conductive materials such as keys,
coins, hand tools and the like. The US Department of Transportation Hazardous
Material Regulations (HMR) actually prohibit transporting batteries in commerce or on
airplanes (e.g., packed in suitcases and carry-on luggage) UNLESS they are properly
protected from short circuits. So when transporting individual battery packs, make
sure that the battery terminals are protected and well insulated from materials that
could contact them and cause a short circuit.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION (Li-Ion)
• Do not incinerate the battery pack even if it is severely damaged or is
completely worn out. The battery pack can explode in a fire. Toxic fumes and
materials are created when lithium ion battery packs are burned.
• If battery contents come into contact with the skin, immediately wash area
with mild soap and water. If battery liquid gets into the eye, rinse water over the
open eye for 15 minutes or until irritation ceases. If medical attention is needed,
the battery electrolyte is composed of a mixture of liquid organic carbonates and
lithium salts.
• Contents of opened battery cells may cause respiratory irritation. Provide fresh
air. If symptoms persist, seek medical attention.
WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or
flame.

5
• Do not place any object on top of the charger or place the charger on a soft
surface that might block the ventilation slots and result in excessive internal
heat. Place the charger in a position away from any heat source. The charger is
ventilated through slots in the top and the bottom of the housing.
• Do not operate the charger with a damaged cord or plug.
• Do not operate the charger if it has received a sharp blow, been dropped or
otherwise damaged in any way. Take it to an authorized service center.
• Do not disassemble the charger; take it to an authorized service center when
service or repair is required. Incorrect reassembly may result in a risk of electric
shock, electrocution or fire.
• Disconnect the charger from the outlet before attempting any cleaning. This
will reduce the risk of electric shock. Removing the battery pack will not reduce
this risk.
• NEVER attempt to connect 2 chargers together.
• The charger is designed to operate on standard 230 V household electrical
power. Do not attempt to use it on any other voltage. This does not apply to the
vehicular charger.
Chargers
Your tool uses a DEWALT charger. Be sure to read all safety instructions before using
your charger. Consult the chart at the end of this manual for compatibility of chargers
and battery packs.
Charging Procedure (Fig. 1) FIG. 1 D
1. Plug the charger into an appropriate outlet before
inserting the battery pack.
2. Insert the battery pack (D) into the charger, as
shown in Figure 1, making sure the pack is fully
seated in charger. The red (charging) light will blink
continuously, indicating that the charging process
has started.
3. The completion of charge will be indicated by the
red light remaining ON continuously. The pack is
fully charged and may be used at this time or left in
the charger.
Indicator Light Operation
PACK CHARGING
PACK CHARGED
x
HOT/COLD DELAY
PROBLEM PACK OR CHARGER
PROBLEM POWERLINE
Charge Indicators
This charger is designed to detect certain problems that can arise. Problems are indicated
by the red light flashing at a fast rate. If this occurs, re-insert the battery pack into the
charger. If the problem persists, try a different battery pack to determine if the charger
is working properly. If the new pack charges correctly, then the original pack is defective
and should be returned to a service center or other collection site for recycling. If the new
battery pack elicits the same trouble indication as the original, have the charger and the
battery pack tested at an authorized service center.
HOT/COLD DELAY
This charger has a hot/cold delay feature: when the charger detects a battery that is
hot, it automatically starts a delay, suspending charging until the battery has cooled.
After the battery has cooled, the charger automatically switches to the pack charging
mode. This feature ensures maximum battery life. The red light flashes long, then
short while in the hot/cold delay mode.
LEAVING THE BATTERY PACK IN THE CHARGER
The charger and battery pack can be left connected with the charge indicator showing
Pack Charged.
WEAK BATTERY PACKS: Weak batteries will continue to function but should not be
expected to perform as much work.
FAULTY BATTERY PACKS: This charger will not charge a faulty battery pack. The
charger will indicate faulty battery pack by refusing to light or by displaying problem pack
or charger.

6
NOTE: This could also mean a problem with a charger.
PROBLEM POWERLINE
Some chargers have a problem powerline indicator. When the charger is used with
some portable power sources such as generators or sources that convert DC to AC, the
charger may temporarily suspend operation, flashing the red light with two fast blinks
followed by a pause. This indicates the power source is out of limits.
Important Charging Notes
1. Longest life and best performance can be obtained if the battery pack is charged
when the air temperature is between 18 ° – 24 °C (65 °F and 75 °F). DO NOT
charge the battery pack in an air temperature below +4 °C (+40 °F), or above
+40 °C (+105 °F). This is important and will prevent serious damage to the
battery pack.
2. The charger and battery pack may become warm to the touch while charging.
This is a normal condition, and does not indicate a problem. To facilitate the
cooling of the battery pack after use, avoid placing the charger or battery pack in
a warm environment such as in a metal shed or an uninsulated trailer.
3. A cold battery pack will charge at about half the rate of a warm battery pack. The
battery pack will charge at that slower rate throughout the entire charging cycle
and will not return to maximum charge rate even if the battery pack warms.
4. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp or other appliance;
b. Check to see if receptacle is connected to a light switch which turns power off
when you turn out the lights;
c. Move the charger and battery pack to a location where the surrounding air
temperature is approximately 18 ° – 24 °C (65 °F and 75 °F);
d. If charging problems persist, take the tool, battery pack and charger to your
local service center.
5. The battery pack should be recharged when it fails to produce sufficient power
on jobs which were easily done previously. DO NOT CONTINUE to use under
these conditions. Follow the charging procedure. You may also charge a partially
used pack whenever you desire with no adverse effect on the battery pack.
6. Foreign materials of a conductive nature such as, but not limited to, grinding dust,
metal chips, steel wool, aluminum foil, or any buildup of metallic particles should
be kept away from charger cavities. Always unplug the charger from the power
supply when there is no battery pack in the cavity. Unplug the charger before
attempting to clean.
7. Do not freeze or immerse the charger in water or any other liquid.
WARNING: Shock hazard. Don’t allow any liquid to get inside the charger. Electric
shock may result.
WARNING: Burn hazard. Do not submerge the battery pack in any liquid or allow
any liquid to enter the battery pack. Never attempt to open the battery pack for any
reason. If the plastic housing of the battery pack breaks or cracks, return to a service
center for recycling.
Storage Recommendations
1. The best storage place is one that is cool and dry, away from direct sunlight and
excess heat or cold.
2. For long storage, it is recommended to store a fully charged battery pack in a
cool dry place out of the charger for optimal results.
NOTE: Battery packs should not be stored completely depleted of charge. The battery
pack will need to be recharged before use.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE
COMPONENTS (Fig. 2)
WARNING: Never modify the power tool or any part of it. Damage or personal
injury could result.
A. Switch E. Battery release button
B. Hang hook F. Lense cover assembly
C. Pivoting head G. Belt hook screw
D. Battery pack H. Belt hook (optional accessory)
INTENDED USE
This LED worklight is designed for professional to provide additional lighting to aid in
professional applications.
DO NOT use under wet conditions or in presence of flammable liquids or gases.
This LED worklight is a professional power tool. DO NOT let children come into
contact with the tool. Supervision is required when inexperienced operators use this
tool.

7
G
H
B
C
E
A
D
F
FIG. 2
OPERATION
WARNING: To reduce the risk of serious personal injury, turn the worklight off
and disconnect the battery pack before making any adjustments or removing/
installing attachments or accessories. An accidental start-up can cause injury.
Installing and Removing the Battery Pack (Fig. 3)
WARNING: To reduce the risk of injury, never depress the battery release button
without removing the battery pack. Depressing the battery release button without
removing the battery pack can result in the battery pack falling out unexpectedly.
NOTE: For best results, make sure your battery pack is fully charged. The worklight
will shut off without warning when the battery is fully discharged.
FIG. 3
E
To install the battery pack (D) into the tool handle, align the battery pack with the
rails inside the tool’s handle and slide it into the handle until the battery pack is firmly
seated in the tool and ensure that it does not disengage.
To remove the battery pack from the tool, press the release button (E) and firmly pull
the battery pack out of the tool handle. Insert it into the charger as described in the
charger section of this manual.
FUEL GAUGE BATTERY PACKS (FIG. 4)
I
FIG. 4
Some DEWALT battery packs include a
fuel gauge which consists of three green
LED lights that indicate the level of charge
remaining in the battery pack.
To actuate the fuel gauge, press and hold
the fuel gauge button (I). A combination of
the three green LED lights will illuminate
designating the level of charge left. When
the level of charge in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.

8
HANG HOOK (FIG. 5)
The telescopic hang hook (b) extends out of the pivoting head (c). The hang hook
locks into place when fully collapsed or when fully extended, as shown in Figure 4.
The hook rotates 360 degrees.
BELT HOOK (OPTIONAL ACCESSORY) (FIG. 2)
WARNING: To reduce the risk of serious personal injury, ensure the screw
holding the belt hook is secure.
IMPORTANT: When attaching or replacing the belt hook (H), use only the screw (G)
that is provided. Be sure to securely tighten screw.
The belt hook (H) can be be attached to either side of the worklight using only the
screw (G) provided, to accommodate left- or right-handed users. If the hook is not
desired at all, it can be removed from the worklight.
To move belt hook, remove the screw (G) that holds the belt hook in place, then
reassemble on the opposite side. Be sure to securely tighten screw.
MAINTENANCE
WARNING: To reduce the risk of serious personal injury, turn the worklight off
and disconnect the battery pack before making any adjustments or removing/
installing attachments or accessories. An accidental start-up can cause injury.
Cleaning
WARNING: Never use solvents or other harsh chemicals for cleaning the
non-metallic parts of the tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with water and mild soap. Never let
any liquid get inside the tool; never immerse any part of the tool into a liquid.
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect the charger from the AC outlet before
cleaning. Dirt and grease may be removed from the exterior of the charger using a
cloth or soft non-metallic brush. Do not use water or any cleaning solutions.
Repairs
This charger and battery pack are not serviceable. Servicing at an authorized service
centre is required to avoid damage to static sensitive internal components.
To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment
NOTE: The fuel gauge is only an indication of the charge left on the battery pack.
It does not indicate tool functionality and is subject to variation based on product
components, temperature and end-user application.
For more information regarding fuel gauge battery packs, please contact Stanley Black
& Decker, 82 Taryn Drive, Epping, VIC 3076 Australia or call 1800 338 002 or (NZ)
0800 339 258.
Switch (Fig. 2)
The worklight has a high beam and low beam setting. Press the switch (A) once for high
beam, twice for low beam, and a third time to turn the worklight off.
Pivoting Head (Fig. 2)
The pivoting head rotates in nine positions ranging from 0°–144°.
Carrying and Suspending the Worklight (Fig. 2, 5)
CAUTION: When the worklight hangs by the belt hook or hang hook, do not shake
the worklight or the object from which it hangs. Do not hang the worklight from any
electrical wires or anything that is not secure. Personal injury or property damage
may occur.
CAUTION: Only use the belt hook or the hang hook for hanging the LED worklight.
The belt hook and hang hook are not intended to support additional weight. Do not
attach or hang anything additional to the worklight or risk of breakage may occur.
CAUTION: Do not use the belt hook or hang hook to reach with or to support your
weight in any situation.
B
FIG. 5
