Dewenwils HOSL08A User manual

Please pay attention to the warning signs
Read the instructions with caution before operating
and keep it properly
V20704
SKU: HOSL08A

Important safety information to reduce risk of fire injury.
1. Do not install within 10 feet (3 m) of a pool, spa or fountain.
2. There are no serviceable parts inside the power supply unit. DO NOT
DISASSEMBLE.
3. Do not repair or tamper with cord or plug.
4. Do not submerge transformer in water.
5. Do not mount the transformer onto combustible material.
6. Do not connect two or more transformers in parallel.
7. Do not use the transformer with a dimmer switch.
8. Plug the power supply unit directly into a GFCI wet location outlet.
9. For use with low voltage outdoor landscape lighting system only.
10. The maximum output of this transformer is 600 watts. The two zone of
this transformer have total of 600w, 300w per zone.Do not overload the
transformer. Be sure that the total cumulative wattage of all 12 volt fixtures
connected to the transformer is equal to or less than 600 watts. Each Zone
does not exceed 300w.
SAFETY INSTRUCTIONS:
The 600 Watt transformer has 600 watt circuits which will power up to 600
watts of light.Maximum 300w per zone. To make sure the maximum number
of fixtures can be safely connected to this transformer, add up the individual
wattage of all the fixtures. The total wattage of your fixtures must not exceed
output capacity of the 600 Watt transformer. Each Zone does not exceed
300w.
Being careful when splitting it.
NOT to expose the copper cable.
Remove the landscape cable
insulation 1/2 inch from both
cables and twist ends.
CALCULATION LIGHTING CAPACITY
1. Preparing the Cable
INSTALLATION
CAUTION: This landscape light system must be installed in accordance with
all local codes and ordinances. If you are experiencing problems, contact a
qualified electrician.

Lay the transformer on a flat, stable surface and use screwdriver to connect
the stripped ends of the cable under the terminal clamping plate.
Tips: Wire under each terminal pressure plate and tighten screw securely.
Make sure wire insulation clears pressure plate.
As the following image shows, there are 3 group wiring ports(COM/12V/
14V for each group), you can choose any group of them to connect your cable.
For each group, there are 2 terminal output ends- 12V/14V, select the
appropriate terminal according to your lamp voltage.
2. Connecting the cable to the Transformer
Lay your fixtures (not included) to your desired location. Be sure they do not
exceed the 600-watt rating of the transformer.Each Zone does not exceed
300w. Coil the rest of the cable after the last fixture. Transformer Cable
Fixtures.
3. Placing Your Fixtures and Routing the cable
Note: Gently pull on the landscape
cable to verify if the connection is strong.
300VA Max
COM 12V 13V 14V 15V
300VA Max
COM 12V 13V 14V 15V
Total bulb’s watt age doesn’t
exceed max wattage
Tighten screws s ecurely
Connected Ground
RESET SWITCH-Press to reset
transformer if light go out

Use the cable connectors to attach your fixtures with the cable. Plug the
transformer in the GFCI outlet and enter the ON mode. Then the lamps will
light up.
4.Attaching Your Fixtures
Use the screw to mount the transformer directly on a wall. 12 inch to 48 inch
(0.3 m to 1.2 m) high from the ground would be suggested.12in. to 48in.
(0.3m to 1.2m)
5.Mounting the Transformer

The transformer does not work, there is no output voltage, and the load
lamps will not light.
Figure 1: OFF MODE
The transformer will maintain the output throughout the day, and the load
lamps will always be on.
Note: If the "." on the display goes off after a few seconds, it means that the
wiring of the lamp is abnormal or the wire is broken. You need to cut off the
power supply of the transformer to eliminate the abnormal
situation, then restart the power supply.
Figure 2: ON MODE
In this mode, it will take 0 ~30s for the transformer to detect the external
environment firstly. If it is night, the currently selected output port of the
transformer will start output later, then the load lamps will light on
automatically and off at dawn. If it is during the day, the currently selected
output port of thetransformer will have no output and the load lamps will
not light.
Note: If the light emitted by the load lamps shines on the sensor at night, it
may cause the transformer to continuously switch on/off, and the load lamps
flash continuously, with a flash interval of 30s.
Figure 3: AUTO MODE
When the "F" lights, the outlet is overloaded or short circuit.To solve it, pull
out the plug and check the circuit. Connect the power again after
troubleshooting, the transformer will reset automatically.
Figure 6: FAILURE MODE
In this mode, it will also take 30s for the transformer to detect the external
environment firstly. If it is night, the transformer will start output 30s later
and the load lamps will light. Then they will turn off automatically when the
the countdown is over. If it is during the day, the transformer will have no
output and the load lamps will not light. Note: When the system starts to
count down, if the surrounding light shines on the sensor for more than 30s,
the countdown will end, the transformer will stop output, and the load lamps
will go out.
Figure 4 & Figure 5: COUNTDOWN MODE

1. When the transformer is working, the dot in the lower right corner of the
display lights up. If the dot is not light up, it means that the transformer
has no output voltage.
2. The transformer has a power-off memory function. After the transformer
has been working in the current mode for 24 hours, the transformer will
remember the current working mode. When the transformer powers on
again, the transformer will enter the working mode before the power failure.
3. The transformer has two outputs with a total output power of 600VA.
Each zone has a maximum output power of 300w.
TIPS:
Step 1: Unplug the transformer from the power outlet.
Step 2: Check if the transformer is overloaded or not.
Step 3: Check if there is a short circuit at the transformer terminals.
Step 4: Check whether the connection between the lamp and the buried
wire is short-circuited.
Step 5: Press the circuit breaker button switch.
Step 6: After troubleshooting, replug the transformer, it will automatically reset.
TROUBLE SHOOTING
T1 The display shows "F"
Step 1: Unplug the transformer from the power outlet.
Step 2: Check if the transformer terminals are properly connected.
Step 3: Check whether the connection between the lamp and the buried
wire is correct.
Step 4: After troubleshooting, replug the transformer, it will automatically reset.
T2. In ON mode, the load lamp is off, the display shows "0"
Step 1: Unplug the transformer from the power outlet.
Step 2: Check if the transformer terminals are properly connected.
Step 3: Check whether the connection between the lamp and the buried
wire is correct.
Step 4: After troubleshooting, replug the transformer into the power outlet.
T3. In AUTO mode or COUNTDOWN mode, the load lamp does not
light, the display shows "A" or "N" (N is the selected timing time).

Step 5: Press the up/down button to enter AUTO mode or COUNTDOWN
mode, cover the sensor for more than 30s, the load lamp will light
up. CABLE SELECTION CHART

-1 x Low-Voltage Transformer
-2 x Screws
-2 x Wall Anchors
-1 x Instruction Manual
PACKING LIST
- Model: DA-600-12W4-1
- Input Voltage: 120VAC, 60Hz
- Output: 12VAC/14 VAC
- Max Power Rating: 600W, Each zone has a maximum output power
of 300w.
- Photo Sensor Cable Length: 6 ft
SPECIFICATIONS
One Year Limited Warranty
Supported by our professional R&D team and QC team, we provide One
Year Warranty for materials and workmanship from the purchase date.
Please note that the warranty does not cover damage caused by personal
misuse or improper installation.
Please attatch your Order ID and Name so that our dedicated customer
service team can help you better.
