Dexcom G4 Platinum User manual

Dexcom, Inc.
6340 Sequence Drive
San Diego, CA 92121 USA
1.858.200.0200
1.877.339.2664
www.dexcom.com
LBL012590 Rev 02 MT22734
CONTINUOUS GLUCOSE
MONITORING SYSTEM
Receiver with ShareTM
USER’S GUIDE

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |1
USER’S GUIDE
DEXCOM G4®PLATINUM
(PEDIATRIC) CONTINUOUS
GLUCOSE MONITORING SYSTEM
RECEIVER WITH ShareTM
IMPORTANT CONTACTS AND NUMBERS
Dexcom®Website: www.dexcom.com
Your Transmitter ID:
Your Receiver ID:
Your Healthcare Professional:
Nearest Hospital:
© 2015 Dexcom, Inc. All rights reserved.
Covered by patents www.dexcom.com/patents
Dexcom, Dexcom G4, Dexcom G4 PLATINUM, Dexcom Share, Dexcom
STUDIO, and SEVEN are either registered trademarks or trademarks
of Dexcom, Inc. in the United States and/or other countries. All other
product or company names that may be mentioned in this publication
are tradenames, trademarks or registered trademarks of their
respective owners.

2 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
DEXCOM G4 PLATINUM (PEDIATRIC) CONTINUOUS
GLUCOSE MONITORING SYSTEM
table of contents
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CHAPTER 1: DEXCOM G4 PLATINUM (PEDIATRIC)
CONTINUOUS GLUCOSE MONITORING (CGM)
SYSTEM DESCRIPTION 11
1.1 System Contents .....................................13
1.2 Introduction .........................................14
1.3 Sensor Overview .....................................15
1.4 Transmitter Overview ..................................16
1.5 Receiver Overview....................................17
1.6 Share Overview ......................................18
CHAPTER 2: INDICATIONS FOR USE AND SAFETY
STATEMENT ................................19
2.1 INDICATIONS FOR USE ...............................21
2.2 IMPORTANT USER INFORMATION ......................21
2.3 CONTRAINDICATIONS................................22
2.4 WARNINGS .........................................22
2.5 PRECAUTIONS ......................................25
2.6 CAUTION...........................................28
CHAPTER 3: RISKS AND BENEFITS 29
3.1 Risks ..............................................31
3.2 Benets ............................................32
CHAPTER 4: CHARGING YOUR RECEIVER AND THE
RECEIVER MAIN MENU 35
4.1 Charging Your Receiver Battery..........................37
4.1.1 Charging Your Receiver Battery from an AC Power Outlet 38
4.1.2 Charging Your Receiver Battery from a Windows Compatible
Computer ......................................39
4.1.3 Knowing Your Receiver is Charged ..................40
4.2 Receiver Menu Options ................................40

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |3
CHAPTER 5: DEXCOM G4 PLATINUM (PEDIATRIC)
SYSTEM SETUP 43
5.1 Setting Up the Receiver and Pairing with Your Transmitter.....45
5.2 The Settings Menu.................................... 47
5. 2.1 Getting to the Settings Menu . . . . . . . . . . . . . . . . . . . . . . . 47
5.2.2 Setting Your Receiver Time and Date . . . . . . . . . . . . . . . . 47
5.2.3 Entering Your Transmitter ID . . . . . . . . . . . . . . . . . . . . . . . 48
5.2.4 Turning On Share On Your Receiver . . . . . . . . . . . . . . . . . 49
5.3 Checking Information About Your Dexcom G4 PLATINUM
(Pediatric) System ....................................50
5.4 Transmitter and Receiver Communication..................50
CHAPTER 6: INSERTING A SENSOR AND STARTING A
SENSOR SESSION 53
6.1 Before You Start .....................................56
6.2 Removing the Sensor from its Packaging ..................57
6.3 Choosing an Insertion Site..............................58
6.4 Placing the Sensor....................................60
6.5 Sensor Insertion......................................62
6.6 Transmitter Attachment ................................63
6.7 Starting a Sensor Session ..............................65
6.8 Sensor Startup Period .................................67
6.9 Taping the Sensor Pod ................................68
6.10 Temporary Receiver Shutdown .........................68
6.11 The Dexcom G4 PLATINUM (Pediatric) System and Water ...69
CHAPTER 7: CALIBRATING YOUR DEXCOM G4
PLATINUM (PEDIATRIC) SYSTEM 71
7.1 Calibration Overview ..................................73
7.2 How to Calibrate ..................................... 75
7.3 Startup Calibration ....................................79
7.4 12-Hour Calibration Update .............................80
7.5 Other Reasons You May Need to Calibrate................. 81
CHAPTER 8: SENSOR GLUCOSE READINGS AND
TRENDS 83
8.1 Sensor Glucose Readings ..............................86
8.2 Rate of Change Arrows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

4 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
8.3 Glucose Status Area Symbols...........................92
CHAPTER 9: ALERTS, ALARM & PROFILES .......95
9.1 Setting Your Alerts ....................................97
9.1.1 Default Alert/Alarm Settings........................ 97
9.1.2 Glucose Alerts and Alarm ........................100
9.1.2.1 High Glucose Alert ....................... 101
9.1.2.2 Low Glucose Alert........................ 101
9.1.2.3 Low Glucose Alarm....................... 102
9.1.3 Getting to the Alerts Menu ........................ 103
9.1.4 High and Low Glucose Alerts ..................... 103
9.2 Advanced Alerts..................................... 105
9.2.1 Setting a Snooze Time for Your High and Low Glucose
Alerts ........................................105
9.2.2 Rise and Fall Glucose Rate Alerts..................106
9.2.3 Setting the Out of Range Alert.....................108
9.3AlertProles........................................ 110
 9.3.1 AlertProleOptions..............................111
 9.3.2 AlertProleDetails ............................. 112
CHAPTER 10: EVENTS AND DEXCOM STUDIO™
SOFTWARE 115
10.1 Events .......................................... 117
10.1.1 Selecting an Event ........................... 117
10.1.2 Setting the Date and Time for an Event ........... 118
10.1.3 Carbohydrates ............................... 119
10.1.4 Insulin . .................................... 120
10.1.5 Exercise . .................................. 121
10.1.6 Health . .................................... 122
10.2 Dexcom STUDIO Software ........................... 123
CHAPTER 11: ENDING A SENSOR SESSION 125
11.1 Automatic Sensor Shut-Off . .......................... 127
11.2 Removing a Sensor ................................. 128
11.3 Transmitter Removal . ............................... 130
CHAPTER 12: TAKING CARE OF YOUR DEXCOM G4
PLATINUM (PEDIATRIC) SYSTEM 131
12.1 Maintenance . ..................................... 133

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |5
1
12.2 Storage . ......................................... 133
12.3 Product Disposal . ..................................134
CHAPTER 13: TROUBLESHOOTING 135
13.1 Sensor Insertion Troubleshooting ...................... 137
13.2 Calibration Troubleshooting........................... 138
13.2.1 Types Of Calibration Prompts ................... 139
13.2.2 What To Do For Calibration Prompts.............. 140
13.3 Calibration Error Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 140
13.4 System Glucose Error ............................... 141
13.5 Sensor Inaccuracies ................................ 142
13.6 Sensor Shut-Off Troubleshooting ...................... 145
13.6.1 Early Sensor Shut-Off - Sensor Failure............ 145
13.6.2 Manual Sensor Shut-Off - “Stop Sensor” .......... 146
13.7 Share Pairing Error Troubleshooting .................... 147
13.8 Battery and Charger Troubleshooting ................... 148
13.9 Receiver and Transmitter Communication Troubleshooting .. 148
13.9.1 System Recovery Check ....................... 148
13.9.2 Receiver Error Code .......................... 149
13.9.3 Low Transmitter Battery ....................... 149
13.9.4 Transmitter Failed ............................ 150
13.10 Out of Range/No Antenna ........................... 150
13.11 Alerts Are Not Working.............................. 151
CHAPTER 14: TECHNICAL INFORMATION 153
14.1 Device Performance Characteristics.................... 155
14.2 ProductSpecications............................... 178
14.3 FCC Requirements .................................190
CHAPTER 15: USER ASSISTANCE 193
CHAPTER 16: WARRANTY 197
CHAPTER 17: TRAVEL INFORMATION 205
CHAPTER 18: APPENDIX 209
Appendix I: Receiver Alerts, Alarm and Prompts............... 211
Appendix II: Index.......................................224
Appendix III: Symbols Used in Labeling......................229

6 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
GLOSSARY
Alternative Site
BG Testing
This is when you take a blood glucose value on your meter
using a blood sample from an area on your body other than
your ngertip. Do not use alternative site testing to calibrate
your receiver.
Applicator A disposable piece that comes attached to the sensor pod and
inserts the sensor under the skin. There is a needle inside the
applicator that you remove after you insert the sensor.
BG Meter Blood glucose meter. A device used to measure how much
glucose is in the blood. You can use any commercially available
meter for testing your blood glucose.
BG Value Blood glucose value. The measurement of glucose in the blood.
A blood glucose value taken with your commercially available
blood glucose meter.
Bluetooth®Bluetooth wireless technology allows devices to wirelessly
communicate with each other. In this case, communication
between the receiver and your iPhone®/iPod touch® device.
Calibration When you enter blood glucose values from a blood glucose
meter into the receiver. Calibrations are needed for your
receiver to show continuous sensor glucose readings and trend
information. (Do not use alternative site testing for calibration).
CGM Continuous Glucose Monitoring.
Commercially
Available
Product that may be sold in the United States.
Default A setting that is selected automatically, unless you choose
another option.
(continued on next page)

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |7
GLOSSARY (continued from page before)
Dexcom G4
PLATINUM
(Pediatric)
System
The sensor, transmitter, and receiver.
Dexcom
Share™System
Secondary notication system to the Dexcom G4 PLATINUM
System. For more information, please refer to the Dexcom
Share User Manual.
Glucose Data
Gaps
Different symbols show on the trend graph instead of a sensor
glucose reading to let you know that the receiver cannot
provide a reading.
Glucose
Trends
Trends let you see the pattern of your glucose levels. The trend
graph shows where your glucose levels have been during
the time shown on the screen and where your glucose levels
are now.
Hypoglycemia Low blood glucose. Same as “low.” The default low alert in
your receiver is set to 80 mg/dL. Consult your healthcare
professional to determine the appropriate hypoglycemic setting
for you.
Hyperglycemia High blood glucose. Same as “high.” The default high alert
in your receiver is set to 200 mg/dL. Consult your healthcare
professional to determine the appropriate hyperglycemic setting
for you.
HypoRepeat Optional receiver alert setting that keeps repeating the xed
low alarm every 5 seconds until your sensor glucose reading
rises above 55 mg/dL or you conrm it. This prole can be
helpful if you want extra awareness for severe lows.
mg/dL Milligrams per deciliter. The standard unit of measure for sensor
glucose readings in the United States.
(continued on next page)

8 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
GLOSSARY (continued from page before)
Obstruction Something that blocks the wireless path between the
transmitter and receiver. There are many types of things that
could come between the transmitter and receiver, and Dexcom
could not test them all. “Without obstruction” means that we
have not tested whether items blocking the transmitter or
receiver could affect the transmission range.
Proles Sound pattern and volume level settings for your alerts.
Range The distance between the receiver and transmitter. Keep the
two devices within 20 feet of each other without obstruction to
get glucose information on your receiver.
Re-Alert A re-alert happens after the rst alert is not conrmed.
Receiver The small device that collects your glucose information from the
sensor/transmitter. Your results show on the receiver screen as
a sensor glucose reading (mg/dL) and as a trend.
Rise and Fall
(Rate of
Change) Alerts
Alerts based on how fast and how much your glucose levels
rise/fall.
RF Radio-frequency transmission used to send glucose information
from the transmitter to the receiver.
Safety Lock The safety lock keeps the needle inside the applicator
before you are ready to insert the sensor. It also helps you
snap the transmitter out of the sensor pod after your sensor
session ends.
(continued on next page)

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |9
GLOSSARY (continued from page before)
Sensor The Dexcom G4 PLATINUM (Pediatric) System part that
includes an applicator and wire. The applicator inserts the wire
under your skin, and the wire measures glucose levels in your
tissue uid.
Sensor Pod The small plastic base of the sensor attached to your skin that
holds the transmitter in place.
Snoozing The option to delay your alert for a set amount of time. A
snooze time can be set for high and low glucose re-alerts.
Startup Period The 2-hour period after you tell the receiver you inserted a
new sensor. Sensor glucose readings are not provided during
this time.
System
Reading
A sensor glucose reading shown on your receiver. This reading
is in mg/dL units and is updated every 5 minutes.
Transmitter The Dexcom G4 PLATINUM (Pediatric) System part that snaps
into the sensor pod and wirelessly sends glucose information to
your receiver.
Transmitter ID A series of numbers and/or letters that you enter into your
receiver to let it communicate with the transmitter.
Transmitter
Latch
The small, disposable piece that snaps the transmitter into the
sensor pod. It is removed after the transmitter is snapped in.
Trend (Rate
of Change)
Arrows
Arrows on trend graphs that show how fast your glucose levels
are changing. There are 7 different arrows that show when your
glucose speed and direction change.

10 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
PAGE INTENTIONALLY LEFT BLANK

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |11
1
chapter one
DEXCOM G4 PLATINUM (PEDIATRIC)
CONTINUOUS GLUCOSE MONITORING
(CGM) SYSTEM DESCRIPTION

12 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
1

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |13
CHAPTER 1: DEXCOM G4®PLATINUM
(PEDIATRIC) CONTINUOUS GLUCOSE
MONITORING (CGM) SYSTEM DESCRIPTION
1.1 SYSTEM CONTENTS:
• sensor
• transmitter
• receiver
• receiver USB charging/download cable
• AC power adapter - MT21255
• receiver case
• user’s guide
• quick start guide
• training checklist
• tutorial disc
• Dexcom STUDIO™software (available for download online at
www.dexcom.com)
Sensors are sold separately. Commercially distributed blood
glucose (BG) meter required for use.
Dexcom G4 PLATINUM
Sensor
Dexcom G4 PLATINUM
(Pediatric) Receiver with Share
Dexcom G4 PLATINUM
Transmitter

14 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
1.2 INTRODUCTION
When you use the system, you will see continuous sensor glucose
readings updated every 5 minutes for up to 7 days. These readings will
help you notice trends and patterns in your glucose levels.
The system includes the Dexcom G4 PLATINUM Sensor, the Dexcom
G4 PLATINUM Transmitter, and the Dexcom G4 PLATINUM (Pediatric)
Receiver with Share. The sensor is a disposable unit that you insert
under your skin to continuously monitor your glucose levels for up to 7
days. The transmitter is a reusable device that wirelessly sends your
sensor’s glucose information to your receiver. The receiver is a hand-held
device that receives and displays your glucose information.
Please read this user’s guide closely. It describes how to use
your system.
In addition, Dexcom®has a self-guided training tutorial for the Dexcom
G4 PLATINUM (Pediatric) CGM System. Some people have found
this to be an effective method of product training. Please review the
tutorial on the disc and discuss with your healthcare professional to
decide if the Dexcom G4 PLATINUM (Pediatric) System Tutorial is a
good training option for you. The tutorial disc can only be used with
your computer and cannot be used in DVD players. The tutorial is also
found on the Dexcom website – www.dexcom.com.
1
PRECAUTION
The Dexcom G4 PLATINUM Sensor, Transmitter, and
Receiver are not compatible with the SEVEN®/SEVEN®
PLUS Transmitter and Receiver. Different generations
will not connect with each other and will not work. Also,
make sure to use the correct version of Dexcom STUDIO
with your system.

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |15
1.3 SENSOR OVERVIEW
The sensor is the piece that comes in a sterile, sealed sensor pouch.
The sensor is made up of an applicator, a sensor pod, and a sensor
wire. You remove the applicator after insertion. The sensor pod stays on
your skin for the entire sensor session, up to 7 days. The pod is made of
plasticandanadhesivepatch.Thesensorwireisthinandexible,and
inserts just under your skin. It is attached to the sensor pod, and is made
of silver and platinum metal with polymer membranes. You discard the
sensor at the end of the session.
SeeChapter14forProductSpecications.
Plunger
Applicator barrel
(contains small introducer
needle and sensor)
Transmitter latch
Safety lock
Collar
Sensor pod
Release tab Adhesive patch

16 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
1.4 TRANSMITTER OVERVIEW
The transmitter is the gray, plastic “chip” that snaps into your sensor
pod. The 9438-01 transmitter (including sensor pod) is 1.5 inches long,
0.9 inches wide and 0.5 inches thick. The 9438-05 transmitter (including
sensor pod) is 1.5 inches long, 0.9 inches wide and 0.4 inches thick.
Once snapped into the sensor pod, the transmitter wirelessly sends your
glucose information to the receiver. The transmitter and sensor are water
resistant when properly connected. Do not throw away your transmitter.
It is reusable.
The transmission range from the transmitter to the receiver is up to 20
feet without obstruction. Wireless communication does not work well
through water, so the range is much less if you are in a pool, bathtub or
water bed.
The transmitter battery will last at least 6 months. Once you see the
transmitter low battery screen, replace the transmitter as soon as
possible. Your transmitter battery may drain as quickly as one week after
this alert appears.
SeeChapter14forProductSpecications.
Transmitter
Transmitter Low Battery screen
1

Dexcom G4 PLATINUM (Pediatric) System User’s Guide |17
1.5 RECEIVER OVERVIEW
The receiver is the small hand-held device that looks like a cell phone.
It is about 4 inches long, 1.8 inches wide and 0.5 inches thick. It
shows your sensor glucose readings, trend graph, direction and rate of
change arrow.
Donotspilluidsonthereceiverordropthereceiverintouids.Keep
themicroUSBportdoorclosedtohelppreventuidanddustfrom
getting inside the receiver.
The trend graph screen on your receiver shows your sensor glucose
readings, trend graph, direction and rate of change arrow
Therearevereceiverbuttonstomoveyouthroughthescreens.The
trend graph screens show sensor glucose readings, trend graphs
and trend arrows. The receiver menu screens let you change your
receiver settings.
EXAMPLE: 3-Hour Trend Graph Screen
Status area
High glucose
alert setting
Low glucose
alert setting
Antenna
Battery
Most recent 5-minute
sensor glucose reading
Glucose
target
range
Plot of most
recent sensor
glucose readings
Current time
Trend arrow
Trend graph hours
Glucose
values

18 |Dexcom G4 PLATINUM (Pediatric) Continuous Glucose Monitoring System
Your receiver and transmitter wirelessly pair together to communicate
securely and only with each other.
You will need a commercially available blood glucose meter to use with
your system.
SeeSection14forProductSpecications.
Receiver buttons:
• Press the UP and DOWN buttons to scroll through trend graph
screens, highlight menu items, or set values.
• Press the SELECT button to turn the receiver on or select the
highlighted option.
• Press the LEFT button to go back to the last item or screen.
• Press the RIGHT button to highlight the next item.
1.6 SHARE OVERVIEW
Dexcom Share™remote monitoring system lets one person, the Sharer,
transfer Dexcom G4 PLATINUM Continuous Glucose Monitoring
information to another person, the Follower.
Learn more about Dexcom Share by reading the Dexcom Share
User Manual.
1
UP button
DOWN
button
SELECT
button
RIGHT
button
LEFT
button
SpeakerDisplay screen USB port cover
USB port
