8514-280-001 REV H PAGE 20
Settings Options:
The Settings options allow for the user to make arious programming changes to change how the control
operation affects the customer. See below for detailed information on each next le el option.
1. “Decimal Point”: If the user programs the Decimal Point to “OFF”, control display will not show a decimal
point on any end price alues. The factory default is “ON”.
2. “Display Time”: If the user programs this alue to “MIN”, then minutes only will be shown for the cycle
time. If it is programmed to “MIN+SEC”, then minutes and seconds will be shown. This also allows other
programming changes, in ol ing time, to be made in either minute increments or minutes & seconds
increments, as desired.
3. “Temp Scale”: If the user programs this alue to “F”, then the temperatures will be displayed in
Fahrenheit units. If it is programmed to “C”, then the temperature will be in Celsius units.
4. “Sounds”: If the user programs the Sounds to “OFF”, the control will not sound the enunciator at the end
of a dry cycle. The factory default is “ON”.
5. “Password”: If the user programs the password to any alue other then 0000, the control will prompt the
user to enter a password (the programmed alue) before manual programming can be accessed. The
factory default is “0000” (no password).
a. Note that if the user forgets the Password, it can be reset to factory default (no password), by
performing a hard reset on the control. Please refer to the appropriate section of this manual to
understand how to perform a hard reset.
b. The indi idual digits of the Password can be set by using the “Up” or “Down” buttons to change
the number that is flashing. Once the desired number is chosen for a single digit, press the
“Enter” button to mo e to the next one. Once all four desired digits are chosen, the “Enter”
button must be held down for 3 seconds to confirm that the complete password should be set.
6. “Language”: The control uses English for the default language of the customer prompts. Alternati ely, the
user can choose Spanish, French, Malay, or Italian for the customer display prompts. Howe er, all other
prompts, such as Manual Programming, USB Programming and any Error Codes will still display in
English.
7. “Shift Hours”: This feature allows the user to shift the time used by the control from the time kept
internally by the control. The control uses a Real Time Clock (RTC) to internally track the time and date.
The RTC continues operation e en if the control loses external power. The RTC is set for Central
Standard Time and no daylight sa ings. Because the machine may be located in another time zone, the
user can choose to create an alternate time & date that tracks in parallel to the RTC. When this alternate
time is chosen, or shifted from the RTC, the alternate time will be used to, for example, track error code
occurrences and set time-of-day pricing changes.
a. The hours in “SHIFT HOURS” can be set by using the “Up” or “Down” buttons to change the
number that is flashing. Once the desired hour shift is chosen, press the “Enter” button to mo e
to the minutes. Once the hours and minute shift are both chosen, the “Enter” button must be
held down for 3 seconds to confirm that the complete shifted time is set.
8. “Time”: The control uses a Real Time Clock (RTC) to internally track the time and date. The RTC
continues operation e en if the control loses external power. The RTC is set for Central Standard Time
and no daylight sa ings. Howe er, if a problem occurs and the RTC time is not accurate, it can be reset
to the current time using this option.
a. The hours in “TIME” can be set by using the “Up” or “Down” buttons to change the number that
is flashing. Once the desired hour is chosen, press the “Enter” button to mo e to the minutes.
Once the hours and minute are both chosen, the “Enter” button must be held down for 3 seconds
to confirm that RTC is meant to be reset to the complete entry.
9. “Date”: Similar to “Time”, if a problem occurs and the RTC date is not accurate, it can be reset to the
current date using this option.
a. The day of the month in “DATE” can be set by using the “Up” or “Down” buttons to change the
number that is flashing. Once the desired day of the month is chosen, press the “Enter” button to
mo e to the month of the year. Once the desired month of the year is chosen, press the “Enter”
button to mo e to the year. Once the day, month and year are all chosen, the “Enter” button
must be held down for 3 seconds to confirm that RTC is meant to be reset to the complete entry.
10. “Out of Ser ice” – The control can be put into an Out-of-Ser ice mode ia manual programming. When
the mode is “ON”, the control will scroll “OUT OF SERVICE” on the display. The machine will not react to
any end input and will not operate when in this mode. The factory default is “OFF”.
