特别注意: 请再次确认接线是否正确
和牢固。请勿将电池盒红黑线接反，
否则可能导致电路板烧坏！
接线柱使用方法：
(a) 请先拧松螺丝。
(b) 插入连接线。
C1
9 10
8
请检查轮子是否插紧。请将线放于电池盒下方。
11
13
12
14
(仅支持iOS平台)
STEP 1: 扫描二维码，下载软件GoBLE。
Link 灯亮，表示蓝牙连接成功
* 如出现蓝牙连接失败或者连接后无法操控的情况，
请先断开设备电源，重启APP，重新建立蓝牙连接。
目前暂不支持多台设备同时操控。
STEP 2: 请进入手机的设置界面，启动蓝牙功能。
STEP 3: 打开APP, 将手机靠近风火轮, 进行蓝牙自动连接。 STEP 4: 通过摇杆和按键，操控风火轮运动方向。
蓝牙图标呈绿色，表示蓝牙设备已连接
* 如出现电源指示灯不亮的情况，请检查电池盒接线是否正确和
牢固。或者电池极性是否装反。
* 如出现风火轮操控方向与运动方向不一致的情况，请检查电机C2
的红黑两线是否接反。
请按正确极性安装电池，同时电源指示灯点亮。请
勿将不同类型或者新旧电池混用。
D
C3
B7
D2
D1
A4
C1
B4
A5
B5
B4
D3
B6
D3
B6
(c) 再拧紧螺丝。
8
Warning! Please check and confirm
the wires connection of battery box
in right position and tightly connected.
Incorrect way of installation would
cause the circuit board boiled.
Instruction of binding post:
(a) Loose the screw.
(b) Insert the wire.
(c) Tighten the screw.
Please set the wire under the battery box.
STEP 1: Scan QR code, download the APP— GoBLE
STEP 3: Open the APP, put the phone close to Flamewheel Robot,
process automatic Bluetooth connection.
STEP 4: Use rocker and buttons to control
the direction of the Flamewheel Robot motion.
* If the direction of Flamewheel Robot motion does not accord
with direction of control, please check and confirm the red and
black wires connection of the motor C2 in the right polarity.
STEP 2: Please enter the phone settings interface,
turn on the Bluetooth function.
Only supports iOS platform
The Bluetooth icon in green means
that the Bluetooth device is online.
The Link LED lighten means
the Bluetooth connection succeeded.
* If Bluetooth connection fails
or robot is uncontrollable after connection.
Power off the robot，restart the app
and reconnect the Bluetooth.
Currently it does not support multiple devices
to control at the same time.
Please install batteries in the correct polarity.
The power LED will light when power is on.
Please do not mix different types or old
and new batteries.
* If the Power LED does not light, please check
and confirm the wires connection of battery box
in right position and tightly connected, or the
batteries are in the wrong polarity.
Please check that the wheels seated.
