DFI CS332-C246/Q370 User manual

CS332-C246/Q370
MicroATX Industrial Motherboard
User’s Manual
A-568-M-2006
Preliminary
Version
Preliminary
Version

2User's Manual | CS332
Copyright
This publication contains information that is protected by copyright. No part of it may be repro-
duced in any form or by any means or used to make any transformation/adaptation without the
prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions or
changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2019. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

3User's Manual | CS332
Table of Contents
Chapter 1 - Introduction................................................................................................................6
Specifications ......................................................................................................................... 6
CS332-C246 ..................................................................................................................... 6
CS332-Q370 ..................................................................................................................... 7
Features .................................................................................................................................. 8
Chapter 2 - Hardware Installation................................................................................................8
Board Layout........................................................................................................................... 8
Standby Power LED................................................................................................................8
System Memory .....................................................................................................................9
Installing the DIMM Module ...........................................................................................9
Removing the DIMM Module........................................................................................10
CPU........................................................................................................................................11
Installing the CPU..........................................................................................................11
Installing the Fan and Heat Sink ..................................................................................13
Jumper Settings ...................................................................................................................14
Digital I/O (DIO) Power Select......................................................................................14
Digital I/O (DIO) Power Supply .....................................................................................14
COM 1 RS232 Power Select .........................................................................................15
COM 1 Serial Mode .......................................................................................................15
Clear CMOS....................................................................................................................16
Rear I/O Ports.......................................................................................................................17
Overview.........................................................................................................................17
Graphics Interfaces .......................................................................................................17
COM 1 (Serial) Port .......................................................................................................18
USB Ports .......................................................................................................................19
RJ45 LAN Port ...............................................................................................................20
PS/2 Keyboard/Mouse..................................................................................................20
Audio...............................................................................................................................21
Internal I/O Connectors .......................................................................................................21
SMBus ............................................................................................................................21
Front Panel.....................................................................................................................22
Chassis Intrusion...........................................................................................................22
Digital I/O .......................................................................................................................23
Power Connector...........................................................................................................23
Cooling Fan Connectors................................................................................................24
SATA (Serial ATA) ..........................................................................................................24
LAN LED .........................................................................................................................25
Battery ............................................................................................................................25
LPC .................................................................................................................................26
External COM port Module ...........................................................................................26
Installing the M.2 Module .............................................................................................27
S/PDIF.............................................................................................................................28
Front Audio.....................................................................................................................29
Chapter 3 - BIOS Settings...........................................................................................................30
Overview ...............................................................................................................................30
Main.......................................................................................................................................30
Advanced .............................................................................................................................30
RC ACPI Configuration..................................................................................................31
CPU Configuration.........................................................................................................31
Power & Performance ...................................................................................................32
PCH-FW Configuration ..................................................................................................32
Trusted Computing........................................................................................................35
NCT6116D Super IO Configuration ..............................................................................35
NCT6116D HW Monitor ................................................................................................36
Serial Port Console Redirection ...................................................................................37
USB Configuration .........................................................................................................38
CSM Configuration ........................................................................................................39
Network Stack Configuration........................................................................................39
Chipset ..................................................................................................................................40
Graphics Configuration .................................................................................................40
PEG Port Configuration.................................................................................................41
PCH-IO Configuration....................................................................................................42
PCI Express Configuration............................................................................................42
SATA And RST Configuration .......................................................................................43
HD Audio Configuration ................................................................................................43
Security .................................................................................................................................44
Secure Boot....................................................................................................................44
Boot .......................................................................................................................................45
Save & Exit ............................................................................................................................45
Updating the BIOS................................................................................................................46
Notice: BIOS SPI ROM..........................................................................................................46
Chapter 4 - Intel AMT Settings...................................................................................................47
Overview ...............................................................................................................................47
Enable Intel®AMT in the AMI BIOS ....................................................................................47
Entering Management Engine BIOS Extension (MEBX)....................................................48
MEBX.....................................................................................................................................49
Main Menu .....................................................................................................................49
Intel(R) ME General Settings ........................................................................................49
Intel(R) AMT Configuration...........................................................................................51
Chapter 5 - RAID..........................................................................................................................62
RAID Levels...........................................................................................................................62
Setup Procedure...................................................................................................................62
Chapter 6 - Supported Software ................................................................................................64
Auto-run Menu......................................................................................................................64
Intel Chipset Software Installation Utility...........................................................................64
Intel HD Graphics Drivers ...................................................................................................65
Realtek Audio Drivers...........................................................................................................66
Intel LAN Driver ...................................................................................................................67
Intel ME Drivers ....................................................................................................................68
Intel Serial IO Drivers ...........................................................................................................69
Intel Rapid Storage Technology .........................................................................................70
Adobe Acrobat Reader 9.3 ..................................................................................................72

4User's Manual | CS332
About this Manual
This manual can be downloaded from the website, or acquired as an electronic file included in
the optional CD/DVD. The manual is subject to change and update without notice, and may be
based on editions that do not resemble your actual products. Please visit our website or con-
tact our sales representatives for the latest editions.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product,
inability to use the product, unauthorized replacement or alteration of components and
product specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper in-
stallation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in
or out of warranty. It must be returned to the purchase point, factory or authorized ser-
vice agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial damages to
the product that has been modified or altered.
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you
are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, con-
tacts or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or
connectors by their ends.
Safety Measures
• To avoid damage to the system, use the correct AC input voltage range.
• To reduce the risk of electric shock, unplug the power cord before removing the sys-
tem chassis cover for installation or servicing. After installation or servicing, cover the
system chassis before plugging the power cord.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other
components. Perform the upgrade instruction procedures described at an ESD
workstation only. If such a station is not available, you can provide some ESD pro-
tection by wearing an antistatic wrist strap and attaching it to a metal part of the
system chassis. If a wrist strap is unavailable, establish and maintain contact with
the system chassis throughout any procedures requiring ESD protection.

5User's Manual | CS332
About the Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• One CS332-C246/Q370 board
• One Serial ATA cable (500mm)
• One M.2 Standoff (M2x4 Female, M2.5x4.5 Male)
• Two M.2 I-head screws (M2x4)
• One I/O shield
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Optional Items
• Serial ATA cable (500mm)
• COM cable (300mm, DB9 to 2x5 pin headers)
• USB port cable (USB 2.0 / USB3.1 Gen1)
• 4-port RS232 LPC module (EXT-RS232)
• 4-port RS485 LPC module (EXT-RS485)
• CPU heatsink with fan
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Before Using the System Board
When installing the system board in a new system, you will need at least the following internal
components.
• CPU
• Memory module
• Storage device such as hard disk drive, CD-ROM, etc.
• Power adaptor
External system peripherals may also be required for navigation and display, including at least
a keyboard, a mouse and a video display monitor.

6User's Manual | CS332
Chapter 1
INTRODUCTION
Chapter 1 - Introduction
XSpecifications
CS332-C246
SYSTEM Processor 8th Generation Intel®Core™ /Pentium®/Celeron®LGA
1151 Socket Processors:
Intel®Xeon®E-2176G (6 Cores, 12M Cache, up to 4.7 GHz); 80W
Intel®Xeon®E-2124G (4 Cores, 8M Cache, up to 4.5 GHz); 71W
Intel®Core™ i7-8700K (6 Cores, 12M Cache, up to 4.7 GHz); 95W
Intel®Core™ i7-8700 (6 Cores, 12M Cache, up to 4.6 GHz); 65W
Intel®Core™ i7-8700T (6 Cores, 12M Cache, up to 4.0 GHz); 35W
Intel®Core™ i5-8500 (6 Cores, 9M Cache, up to 4.1 GHz); 65W
Intel®Core™ i5-8500T (6 Cores, 9M Cache, up to 3.5 GHz); 35W
Intel®Core™ i3-8100 (4 Cores, 6M Cache, 3.6 GHz); 65W
Intel®Core™ i3-8100T (4 Cores, 6M Cache, to 3.1 GHz); 35W
Intel®Pentium®G5400 (2 Cores, 4M Cache, 3.7 GHz); 58W
Intel®Pentium®G5400T (2 Cores, 4M Cache, 3.1 GHz); 35W
Intel®Celeron®G4900 (2 Cores, 2M Cache, 3.1 GHz); 54W
Intel®Celeron®G4900T (2 Cores, 2M Cache, 2.9 GHz); 35W
9th Generation Intel®Core™ LGA 1151 Socket Processors:
Intel®Xeon®E-2278GEL (8 Cores, 16M Cache, up to 3.9 GHz); 35W
Intel®Xeon®E-2226GE (6 Cores, 12M Cache, up to 4.6 GHz); 80W
Intel®Core™ i7-9700TE (8 Cores, 12M Cache, up to 3.8 GHz); 35W
Intel®Core™ i5-9500E (6 Cores, 9M Cache, up to 4.2 GHz); 65W
Intel®Core™ i5-9500TE (6 Cores, 9M Cache, up to 3.6 GHz); 35W
Intel®Core™ i3-9100E (4 Cores, 6M Cache, 3.7 GHz); 65W
Intel®Core™ i3-9100TE (4 Cores, 6M Cache, to 3.2 GHz); 35W
Chipset Intel®C246 Chipset
Memory Four 288-pin DIMM up to 128GB
Dual Channel DDR4 2400/2666 MHz (ECC/non ECC support)
BIOS AMI SPI 128Mbit
GRAPHICS Controller Intel®HD Gen 9 Graphics
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/
H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x VGA, resolution up to 1920x1200 @ 60Hz
2 x DP++, resolution up to 4096x2106 @ 60Hz
Triple
Displays
VGA + DP++ + DP++
EXPANSION Interface 1 x PCIe x16 (Gen 3)
2 x PCIe x4 (Gen 3)
1 x PCI
1 x M.2 2242/2280 M key (PCIe Gen3 x 4 NVMe/Intel Optane Memory
Support)
1 x M.2 2230 E key (PCIe x1/USB2.0)
AUDIO Audio Codec Realtek ALC262-VC2
ETHERNET Controller 1 x Intel®i219LM PCIe (10/100/1000Mbps) (only Xeon, Core i7/i5 sup-
port iAMT)
1 x Intel®i211AT PCIe (10/100/1000Mbps)
2 x Intel®i211AT PCIe (10/100/1000Mbps) (opt. by request, MOQ
required)
REAR I/O Ethernet 2 x GbE (RJ-45), 4 x GbE (RJ-45) (opt. by request, MOQ required)
USB 4 x USB 3.1 Gen 1
2 x USB 2.0
Serial 1 x RS-232/422/485 (RS-232 w/ power) (DB-9)
PS/2 1 x PS/2 (mini-DIN-6)
Display 1 x VGA
2 x DP++
Audio 1 x Line-out
1 x Line-in (colay, opt. by request, MOQ required)
1 x Mic-in
INTERNAL I/O Serial 3 x RS-232
USB 2 x USB 3.1 Gen 1
4 x USB 2.0 (2.54mm pitch), 1 x USB 2.0 vertical Type A
Audio 1 x S/PDIF, 1 x Front Audio Header
SATA 5 x SATA 3.0 (up to 6Gb/s) RAID 0/1/5/10
DIO 1 x 8-bit DIO
LPC 1 x LPC (support LPC EXT-RS-232/485 module)
SMBus 1 x SMBus
WATCHDOG
TIMER
Output &
Interval
System Reset, Programmable via Software from 1 to 255 sec/min
SECURITY TPM Infineon TPM 1.2/2.0 (Available Upon Request, MOQ required)
POWER Type ATX
Connector 8-pin ATX 12V power
24-pin ATX power
RTC Battery CR2032 Coin Cell
OS SUPPORT Windows 10 IoT Enterprise 64-bit
Linux
ENVIRONMENT Temperature Operating: -5 to 65°C
Storage: -30 to 60°C with RTC Battery; -40 to 85°C without RTC Battery
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MECHANICAL Dimensions microATX form factor: 244mm (9.6") x 244mm (9.6")

7User's Manual | CS332
Chapter 1
INTRODUCTION
XSpecifications
CS332-Q370
SYSTEM Processor 8th Generation Intel®Core™ /Pentium®/Celeron®LGA 1151 Socket
Processors:
Intel®Core™ i7-8700K (6 Cores, 12M Cache, up to 4.7 GHz); 95W
Intel®Core™ i7-8700 (6 Cores, 12M Cache, up to 4.6 GHz); 65W
Intel®Core™ i7-8700T (6 Cores, 12M Cache, up to 4.0 GHz); 35W
Intel®Core™ i5-8500 (6 Cores, 9M Cache, up to 4.1 GHz); 65W
Intel®Core™ i5-8500T (6 Cores, 9M Cache, up to 3.5 GHz); 35W
Intel®Core™ i3-8100 (4 Cores, 6M Cache, 3.6 GHz); 65W
Intel®Core™ i3-8100T (4 Cores, 6M Cache, to 3.1 GHz); 35W
Intel®Pentium®G5400 (2 Cores, 4M Cache, 3.7 GHz); 58W
Intel®Pentium®G5400T (2 Cores, 4M Cache, 3.1 GHz); 35W
Intel®Celeron®G4900 (2 Cores, 2M Cache, 3.1 GHz); 54W
Intel®Celeron®G4900T (2 Cores, 2M Cache, 2.9 GHz); 35W
9th Generation Intel®Core™ LGA 1151 Socket Processors:
Intel®Core™ i7-9700TE (8 Cores, 12M Cache, up to 3.8 GHz); 35W
Intel®Core™ i5-9500E (6 Cores, 9M Cache, up to 4.2 GHz); 65W
Intel®Core™ i5-9500TE (6 Cores, 9M Cache, up to 3.6 GHz); 35W
Intel®Core™ i3-9100E (4 Cores, 6M Cache, 3.7 GHz); 65W
Intel®Core™ i3-9100TE (4 Cores, 6M Cache, to 3.2 GHz); 35W
Chipset Intel®Q370 Chipset
Memory Four 288-pin DIMM up to 128GB
Dual Channel DDR4 2400/2666 MHz (non ECC support)
BIOS AMI SPI 128Mbit
GRAPHICS Controller Intel®HD Gen 9 Graphics
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/
H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x VGA, resolution up to 1920x1200 @ 60Hz
2 x DP++, resolution up to 4096x2106 @ 60Hz
Triple
Displays
VGA + DP++ + DP++
EXPANSION Interface 1 x PCIe x16 (Gen 3)
2 x PCIe x4 (Gen 3)
1 x PCI
1 x M.2 2242/2280 M key (PCIe Gen3 x 4 NVMe/Intel Optane Memory
Support)
1 x M.2 2230 E key (PCIe x1/USB2.0)
AUDIO Audio Codec Realtek ALC262-VC2
ETHERNET Controller 1 x Intel®i219LM PCIe (10/100/1000Mbps) (only Core i7/i5 support
iAMT)
1 x Intel®i211AT PCIe (10/100/1000Mbps)
2 x Intel®i211AT PCIe (10/100/1000Mbps) (opt. by request, MOQ
required)
REAR I/O Ethernet 2 x GbE (RJ-45), 4 x GbE (RJ-45) (opt. by request, MOQ required)
USB 4 x USB 3.1 Gen 1
2 x USB 2.0
Serial 1 x RS-232/422/485 (RS-232 w/ power) (DB-9)
PS/2 1 x PS/2 (mini-DIN-6)
Display 1 x VGA
2 x DP++
Audio 1 x Line-out
1 x Line-in (colay, opt. by request, MOQ required)
1 x Mic-in
INTERNAL I/O Serial 3 x RS-232
USB 2 x USB 3.1 Gen 1
4 x USB 2.0 (2.54mm pitch) ,1 x USB 2.0 vertical Type A
Audio 1 x S/PDIF, 1 x Front Audio Header
SATA 5 x SATA 3.0 (up to 6Gb/s) RAID 0/1/5/10
DIO 1 x 8-bit DIO
LPC 1 x LPC (support LPC EXT-RS-232/485 module)
SMBus 1 x SMBus
WATCHDOG
TIMER
Output &
Interval
System Reset, Programmable via Software from 1 to 255 sec/min
SECURITY TPM Infineon TPM 1.2/2.0 (Available Upon Request, MOQ required)
POWER Type ATX
Connector 8-pin ATX 12V power
24-pin ATX power
RTC Battery CR2032 Coin Cell
OS SUPPORT Windows 10 IoT Enterprise 64-bit
Linux
ENVIRONMENT Temperature Operating: -5 to 65°C
Storage: -30 to 60°C with RTC Battery; -40 to 85°C without RTC Battery
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MECHANICAL Dimensions microATX form factor: 244mm (9.6") x 244mm (9.6")

8User's Manual | CS332
Chapter 1
INTRODUCTION
XFeatures
Watchdog Timer
The Watchdog Timer function allows your application to regularly “clear” the system at the set
time interval. If the system hangs or fails to function, it will reset at the set time interval so that
your system will continue to operate.
DDR4
The advantages of DDR4 are its higher bandwidth and its increase in performance at a lower
power than DDR3/DDR2. It is not compatible with DDR3/DDR3L/DDR2.
Graphics
The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance
and features to meet business needs. It provides excellent video and 3D graphics with out-
standing graphics responsiveness. These enhancements deliver the performance and compat-
ibility needed for today’s and tomorrow’s business applications. The system board supports 1 x
VGA and 2 x DP++ interfaces for triple display outputs.
PCI Express
PCI Express is a high bandwidth I/O infrastructure that possesses the ability to scale speeds
by forming multiple lanes. The x4 PCI Express lane supports transfer rate of 4 Gigabyte per
second (2 directions). The PCI Express architecture also supports high performance graphics
infrastructure by enhancing the capability of a PCIe x16 Gen 3 at 16GB/s bandwidth (8GB/s in
each direction).
Serial ATA
Serial ATA (SATA) is a storage interface that is compliant with SATA 1.0a specification. With
speed of up to 6Gb/s (SATA 3.0), it improves hard drive performance faster than the standard
parallel ATA whose data transfer rate is 100MB/s.
Gigabit LAN
Two Intel®Gigabit LAN controllers (Intel® I211AT and Intel® I219LM PCI Express Gigabit Ether-
net controllers) support up to 1Gbps data transmission.
Audio
The Realtek ALC262 audio codec provides high-performance of 4-channel High Definition Audio
Codecs.
Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-on the system
manually, let the system power-on automatically, or let the system automatically return to the
last state.
USB
The system board supports USB 3.1 Gen 1, which is capable of running at a maximum trans-
mission speed of up to 5 Gbit/s, or 625 MB/s, faster than USB 2.0 (480 Mbit/s, or 60 MB/s)
and USB 1.1 (12Mb/s). USB 3.1 reduces the time required for data transmission, reduces power
consumption, and is backward compatible with USB 2.0. It is a marked improvement in device
transfer speeds between your computer and a wide range of simultaneously accessible exter-
nal Plug and Play peripherals.
Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It is
supported via the onboard LAN port or via a PCI LAN card that uses the PCI PME (Power Man-
agement Event) signal. However, if your system is in the Suspend mode, you can power-on the
system only through an IRQ or DMA interrupt.
Wake-On-USB
This function allows you to use a USB keyboard or USB mouse to wake up a system from the
S3 (STR - Suspend To RAM) state.
RTC Timer
The RTC installed on the system board allows your system to automatically power-on on the
set date and time.
ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and Power Interface)
specification. ACPI has energy saving features that enables PCs to implement Power Manage-
ment and Plug-and-Play with operating systems that support OS Direct Power Management.
ACPI when enabled in the Power Management Setup will allow you to use the Suspend to RAM
function.
With the Suspend to RAM function enabled, you can power-off the system at once by pressing
the power button or selecting “Standby” when you shut down Windows® without having to go
through the sometimes tiresome process of closing files, applications and operating system.
This is because the system is capable of storing all programs and data files during the entire
operating session into RAM (Random Access Memory) when it powers-off. The operating ses-
sion will resume exactly where you left off the next time you power-on the system.

8User's Manual | CS332
Chapter 2
HARDWARE INSTALLATION
Chapter 2 - Hardware Installation
XBoard Layout
JP5
JP17 JP19
JP18
SPI Programming
Note
PCIE3
PCIE2
JP2 JP3
JP1 JP4
SYS
FAN3
USB 9/10
(USB 2.0)
USB 13
(USB 2.0)
USB 11/12
(USB 2.0)
Front Audio
USB 5/6
(USB 3.1 Gen 1)
DIO
M.2 E Key
2230
SYS
FAN 2
COM2
COM4
COM3
SATA1 SATA2
SATA0
Buzzer
SATA3 SATA4
SPI
Flash
BIOS
LAN 1/2
LED
LAN 3/4
LED
Note
Front
Panel
ATX
power
SYS FAN1
CPU FAN
Intel
C246/Q370
1
9
219 219 2
12
13
LPC
14
1
1
2
5
6
1
2
5
6
1
2
5
6
1
2
5
6
1
11
2
2
10 9
Chassis
Intrusion
1
1
2
11
DDR4_1
LGA 1511
DDR4_2
DDR4_3 DDR4_4
PCI 1
PCIe 1 (PCIe x16)
Battery
M.2 M Key
2242/2280
1 2
7 8
1 2
7
1 2
7
8
Standby
Power
LED
1 13
12 24
+12V Power
4
8
1
5
1
1
1
210
1
210
S/PDIF
1
1
11 2
19
5 6
1 2
SMBus
1
1
10
11 19
KB/MS
USB 7/8
(USB 2.0)
DP1/2
LAN3/
LAN4
Note
Mic In
Line Out
Line In
Note
LAN2
USB 3/4
(USB 3.1 Gen 1)
LAN1
USB 1/2
(USB 3.1 Gen 1)
VGA/COM1
Important:
Electrostatic discharge (ESD) can damage your board, processor,
disk drives, add-in boards, and other components. Perform instal-
lation procedures at an ESD workstation only. If such a station is
not available, you can provide some ESD protection by wearing an
antistatic wrist strap and attaching it to a metal part of the system
chassis. If a wrist strap is unavailable, establish and maintain con-
tact with the system chassis throughout any procedures requiring
ESD protection.
Note:
These optional components are only available upon request.
Important:
When the Standby Power LED lit red, it indicates that there is pow-
er on the system board. Power-off the PC then unplug the power
cord prior to installing any devices. Failure to do so will cause se-
vere damage to the motherboard and components.
XStandby Power LED
Standby Power LED

9User's Manual | CS332
Chapter 2
HARDWARE INSTALLATION
• CS332-C246: Four 288-pin ECC/Non-ECC DIMM up to 64GB
• CS332-Q370: Four 288-pin Non-ECC DIMM up to 64GB
• Dual Channel DDR4 2400/2666 MHz
XSystem Memory
Features
The system board supports the following memory interface.
Single Channel (SC)
Data will be accessed in chunks of 64 bits from the memory channels.
Dual Channel (DC)
Data will be accessed in chunks of 128 bits from the memory channels. Dual channel provides
better system performance because it doubles the data transfer rate.
Single Channel DIMMs are on the same channel. DIMMs in a channel can be identi-
cal or completely different. However, we highly recommend using
identical DIMMs. Not all slots need to be populated.
Dual Channel DIMMs of the same memory configuration are on different channels.
DDR4_1
DDR4_3
DDR4_2
DDR4_4
Before installing the memory module, please make sure that the following safety cautions are
well-attended.
1. Make sure the PC and all other peripheral devices connected to it has been powered
down.
2. Disconnect all power cords and cables.
3. Locate the DIMM socket on the system board
4. Make sure the notch on memory card is aligned to the key on the socket.
Socket Side View
Socket Top View
DDR4 DIMM
Notch
Key
Eject TabEject Tab
Step 3
Step 2
Step 1 Step 1
Step 2
Step 3
Socket Side View
Socket Top View
DDR4 SO-DIMM
Key
Eject TabEject Tab
Step 3
Step 2
Step 1
Step 1
Step 2
Step 3
Notch
Retention Notch
XSystem Memory
Installing the DIMM Module
