DFI SU551 User manual

1
SU551
Embedded SBC 3.5”
User’s Manual
A42300701

2
Copyright
This publication contains information that is protected by copyright. No part of it may be re-
produced in any form or by any means or used to make any transformation/adaptation without
the prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions
or changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2017. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

3
Table of Contents
Copyright .......................................................... 2
Trademarks....................................................... 2
FCC and DOC Statement on Class B...... 2
About this Manual .......................................... 4
Warranty ......................................................... 4
Static Electricity Precautions........................ 4
Safety Measures................................................4
About the Package ......................................... 5
Optional Items................................................. 5
Chapter 2 - Hardware Installation..............8
Board Layout.......................................................................................................... 8
Block Diagram....................................................................................................... 9
Mechanical Diagram............................................................................................. 9
System Memory ..................................................................................................10
Jumper Settings ...................................................................................................10
Auto Power-on Select ............................................................... 11
LVDS Backlight Voltage Select ................................................... 11
Mini PCIe Signal Select ............................................................. 12
LVDS Panel Voltage Select......................................................... 12
Rear Panel I/O Ports .........................................................................................13
12V DC-in .............................................................................. 13
Graphics Interfaces .................................................................. 14
RJ45 LAN Ports ........................................................................ 14
USB Ports................................................................................ 15
I/O Connectors...................................................................................................16
Digital I/O Connector................................................................ 16
Digital I/O Power Connector ...................................................... 16
Front Audio Connector .............................................................. 16
COM (Serial) Ports ................................................................... 17
Front Panel Connector .............................................................. 17
SATA (Serial ATA) Connector ..................................................... 18
SATA (Serial ATA) Power Connector............................................ 18
LVDS LCD Panel Connector........................................................ 19
LCD/Inverter Power Connector................................................... 19
Expansion Slot......................................................................... 20
Cooling Fan Connector .............................................................. 20
SMBus Connector .................................................................... 21
Chassis Intrusion Connector ..................................................... 21
Battery ................................................................................... 22
Chapter 3 - BIOS Setup...............................23
Overview .............................................................................................................23
Insyde BIOS Setup Utility.................................................................................24
Main ....................................................................................... 24
Advanced ............................................................................... 24
Security .................................................................................. 32
Boot ....................................................................................... 33
Exit ........................................................................................ 34
Updating the BIOS ............................................................................................. 34
Notice: BIOS SPI ROM......................................................................................35
Chapter 4 - Supported Software...............36
Chapter 5 - RAID .........................................51
Chapter 6 - Intel AMT Settings..................55
Appendix A - Troubleshooting Checklist..68

4
About this Manual
An electronic file of this manual is included in the CD. To view the user’s manual in the CD, in-
sert the CD into a CD-ROM drive. The autorun screen (Main Board Utility CD) will appear. Click
“User’s Manual” on the main menu.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product, in-
ability to use the product, unauthorized replacement or alteration of components and prod-
uct specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper instal-
lation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in or
out of warranty. It must be returned to the purchase point, factory or authorized service
agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial damages to the
product that has been modified or altered.
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you are
ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, contacts
or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or con-
nectors by their ends.
Safety Measures
To avoid damage to the system:
• Use the correct AC input voltage range.
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis cover for installation or servic-
ing. After installation or servicing, cover the system chassis before plugging the power
cord.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other com-
ponents. Perform the upgrade instruction procedures described at an ESD worksta-
tion only. If such a station is not available, you can provide some ESD protection by
wearing an antistatic wrist strap and attaching it to a metal part of the system chas-
sis. If a wrist strap is unavailable, establish and maintain contact with the system
chassis throughout any procedures requiring ESD protection.

5
About the Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• 1 SU551 board
• 1 COM port cable
• 1 Serial ATA data cable
• 1 Serial ATA power cable
• 1 Audio cable
• 1 DVD
• 1 QR (Quick Reference)
• 1 Heat sink
Optional Items
• USB port cable
• COM port cable
• Serial ATA data cable
• Serial ATA power cable
• Power adapter (60W, 12V, Level 6)
• Power adapter (120W, 12V)
• Heat spreader
• 1 Audio cable
• Front Panel cable
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance to the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Before Using the System Board
Before using the system board, prepare basic system components.
If you are installing the system board in a new system, you will need at least the following
internal components.
• Storage devices such as hard disk drive, CD-ROM, etc.
You will also need external system peripherals you intend to use which will normally include at
least a keyboard, a mouse and a video display monitor.

6
Chapter 1 - Introduction
Specifications
Chapter 1
Chapter 1 Introduction www.d.com
SYSTEM Processor 6th Generation Intel®CoreTM Processors, BGA 1356
Intel
®
Core
TM
i7-6600U Processor, Dual Core, 4M Cache, 2.6GHz (3.4GHz), 15W
Intel
®
Core
TM
i5-6300U Processor, Dual Core, 3M Cache, 2.4GHz (3.0GHz), 15W
Intel®CoreTM i3-6100U Processor, Dual Core, 3M Cache, 2.3GHz, 15W
Intel®Celeron®Processor 3955U, Dual Core, 2M Cache, 2.0GHz, 15W
Memory One 204-pin SODIMM up to 8GB Single Channel DDR3L 1600MHz
BIOS Insyde SPI 128Mbit
GRAPHICS Controller Intel® HD Graphics GT Series
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265,
VP8, VP9
HW Encode: AVC/H.264, MPEG2, JPEG, HEVC/H265, VP8, VP9
Display 1 x VGA
1 x LVDS
1 x DP++
VGA: resolution up to 2560x1600 @ 60Hz
LVDS: dual channel 48-bit, resolution up to 1920x1200 @ 60Hz
DP++: resolution up to 4096x2304 @ 60Hz
Triple
Displays
VGA +
LVDS +
DP++
EXPANSION Interface 1 x Full-size Mini PCIe (PCIe/USB/SATA, SATA by default)
1 x Half-size Mini PCIe (PCIe/USB)
1 x SIM (Optional)
AUDIO Audio Codec Realtek ALC888S-VD2-GR
ETHERNET Controller 1 x Intel® I210AT PCIe (10/100/1000Mbps)
1 x Intel® I219LM PCIe with iAMT11.0 (10/100/1000Mbps)
(only Core i7/i5 supports iAMT)
REAR I/O Ethernet 2 x GbE (RJ-45)
USB 4 x USB 3.0
Display 1 x VGA
1 x DP++
INTERNAL I/O Serial 2 x RS-232/422/485 (RS-232 w/ power) (2.0mm pitch)
2 x RS-232 (2.0mm pitch)
USB 2 x USB 2.0 (2.00mm pitch)
Display 1 x LVDS LCD Panel Connector
1 x LCD/Inverter Power
Audio 1 x Audio (Line-out/Mic-in)
SATA 2 x SATA 3.0 (up to 6Gb/s)
1 x SATA Power
DIO 1 x 8-bit DIO
SMBus 1 x SMBus
WATCHDOG TIMER Output &
Interval
System Reset, Programmable via Software from 1 to 255 Seconds
POWER Type Single 12V +/-10% DC
Connector Right Angle Connector (4-pin)
DC Jack (available upon request)
Vertical Type Connector (4-pin) (available upon request)
Consumption Typical: 6300U:12V @ 0.40A (4.80Watt)
Max.: 6300U:12V @ 2.08A (24.96Watt)
RTC Battery CR2032 Coin Cell
OS SUPPORT Microsoft Windows 7 (32/64-bit)
WES 7 (32/64-bit)
Windows 8.1 (64-bit)
Windows 10 IoT Enterprise 64-bit
Linux Debian 8 (with VESA graphic driver)
CentOS 7 (with VESA graphic driver)
Ubuntu 15.10 (Intel graphic driver available)
ENVIRONMENT Temperature Operating: 0 to 60°C
Storage: -40 to 85°C
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MECHANICAL Dimensions 3.5" SBC Form Factor 146mm (5.75") x 102mm (4.02")
Height PCB: 1.6mm Top Side: 15.5mm, Bottom Side: 4.0mm

7
Chapter 1
Chapter 1 Introduction www.d.com
Features
• Watchdog Timer
The Watchdog Timer function allows your application to regularly “clear” the system at the set
time interval. If the system hangs or fails to function, it will reset at the set time interval so
that your system will continue to operate.
• DDR3L
DDR3L SDRAM provides backward compatibility to DDR3 memory modules but can operate at
the same or at a lower power level.
• Graphics
The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance
and features to meet business needs. It provides excellent video and 3D graphics with out-
standing graphics responsiveness. These enhancements deliver the performance and compat-
ibility needed for today’s and tomorrow’s business applications. Supports 1VGA, 1 LVDS and 1
DP++ interfaces for display outputs.
• Serial ATA
Serial ATA is a storage interface that is compliant with SATA 1.0a specification. With speed of
up to 6Gb/s (SATA 3.0), it improves hard drive performance faster than the standard parallel
ATA whose data transfer rate is 100MB/s.
• Gigabit LAN
Intel®I210AT PCI Express Gigabit Ethernet controller and Intel® I219LM PCI Express Gigabit
Ethernet controller with iAMT11.0 support up to 1Gbps data transmission.
• Audio
The Realtek ALC888S-VD2-GR audio codec provides 2.1-channel High Definition audio output.
• Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-on the system
manually or let the system power-on automatically.
• USB
The system board supports the new USB 3.0. It is capable of running at a maximum transmis-
sion speed of up to 5 Gbit/s (625 MB/s) and is faster than USB 2.0 (480 Mbit/s, or 60 MB/s)
and USB 1.1 (12Mb/s). USB 3.0 reduces the time required for data transmission, reduces
power consumption, and is backward compatible with USB 2.0. It is a marked improvement
in device transfer speeds between your computer and a wide range of simultaneously
accessible external Plug and Play peripherals.
Important:
The 5V_standby power source of your power supply must support ≥720mA.
• Wake-On-USB (Optional)
This function allows you to use a USB keyboard or USB mouse to wake up a system from the
S3 (STR - Suspend To RAM) state.
• ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and Power Interface)
specification. ACPI has energy saving features that enable PCs to implement power manage-
ment and plug-and-play with operating systems that support power management features.
With ACPI, the system can further utilize the Ethernet adapter’s wake-on-LAN (WOL) capability
that enables remote wake-up if the Ethernet adapter supports such feature.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB ports, the
5V_standby power source of your power supply must support ≥1.5A. For 3 or more
USB ports, the 5V_standby power source of your power supply must support ≥2A.
• Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It is
supported via the onboard LAN port or via a PCI LAN card that uses the PCI PME (Power Man-
agement Event) signal. However, if your system is in the Suspend mode, you can power-on
the system only through an IRQ or DMA interrupt.
Important:
The 5V_standby power source of your power supply must support ≥720mA.
• RTC Timer
The RTC installed on the system board allows your system to automatically power-on on the
set date and time.

www.d.com
8
Chapter 2 Hardware Installation
Chapter 2
Chapter 2 - Hardware Installation
Board Layout
Top View Bottom View
LAN 1
LAN 2
USB 2
USB 1
USB 3.0
USB 4
USB 3
USB 3.0
Intel WGI210AT
SPI Flash BIOS
VGA Chrontel
CH7517A
1
Chassis
Intrusion
1
Clear CMOS
Data (JP1)
21
5
SMBus
1
10
9
2
Front Audio
4-pin
Right Angle
DC-in
1CPU Fan
SATA 0
SATA 3.0
1
SATA
Power
1
2
9
1
2
5
6
1
SATA 2
1
1
1
DIO
Front Panel
USB 6-7
12
10 9
1
2
5
6
LVDS Panel Power
(JP13)
2
NXP
PTN34608S
DP
COM1-2 COM3-4
1
1
2
Battery
Buzzer
2
1920
12
19
Mini PCIe
AC Power Select
(JP16)
Mini PCIe Select
(JP7)
1LVDS Backlight Power
(JP12)
1
39
40
LVDS LCD
Panel
1
LCD/Inverter
Power
DIMM 1
Mini PCIe/ mSATA
Intel
BGA 1356
Nuvoton
NCT6106
SIM card slot
(Optional)
Realtek
ALC888S
Intel WGI219LM
MP2939

www.d.com
9
Chapter 2 Hardware Installation
Chapter 2
Block Diagram
Core
i7/i5/i3
Super IO
with WDT
Digital I/O 8-bit
DDR3L 1600MHz
SODIMM
Channel A
Half-size
Mini PCIe
PCIe x1
USB 2.0
DDI
LPC Bus
PTN3460 DDI
LVDS
SMBus
SMBus
SPI
CH7517 DDI
VGA
Full-size
mSATA
SATA 3.0
USB 2.0
SIM (Opt.)
DP++
GLAN I210AT
GLAN I219LM
PCIe x1
PCIe x1
SATA 2x
RS-232/422/485 2x
RS-232 2x
H/W Monitor
PCIe x1
USB 2.0 USB 2.0 2x
HD Audio
Codec
Header
(Line-out/Mic-in)
SATA 3.0
USB 3.0
USB 2.0 USB 3.0 4x
Mechanical Diagram
0
6
11.76
40.92
66 66.41
83.01
101.72 119.22 137.66 140 146
0
18.98
25
102
0
6
140
0
22
96 (X2)
98.40 (X2)

www.d.com
10
Chapter 2 Hardware Installation
Chapter 2
Jumper Settings
Clear CMOS Data
If you encounter the following conditions, you can reconfigure the system with the default val-
ues stored in the ROM BIOS.
a) CMOS data becomes corrupted.
b) You forgot the supervisor or user password.
To load the default values stored in the ROM BIOS, please follow the steps below:
1. Power-off the system and unplug the power cord.
2. Set JP1 pins 2 and 3 to On. Wait for a few seconds and set JP1 back to its default setting,
pins 1 and 2 On.
3. Now plug the power cord and power-on the system.
2-3 On:
Clear CMOS Data
1-2 On:
Normal (default)
31 2
31 2
JP1
System Memory
Important:
Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in
boards, and other components. Perform installation procedures at an ESD workstation
only. If such a station is not available, you can provide some ESD protection by wear-
ing an antistatic wrist strap and attaching it to a metal part of the system chassis. If
a wrist strap is unavailable, establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.
Important:
When the Standby Power LED lights red, it indicates that there is power on the sys-
tem board. Power-off the PC then unplug the power cord prior to installing any de-
vices. Failure to do so will cause severe damage to the motherboard and components.
• One 204-pin SODIMM up to 8GB
• Single Channel DDR3L 1600MHz
Features
DIMM 1
