Dhollandia DH-VZ Operating instructions


Quick guide for use of lift model
DH-VZ
Doc date :
Doc :USE-DHVZ
n/a
Last Rev date :
2011-11-04
Created / amended by : Lok3
§1 - Introduction
• This document forms a quick guide for the use of the lift model DH-VZ. It must be read in conjunction with the general
user’s manual with regards to the safety instructions for the operator (chapter A), the periodic maintenance (chapter B),
and the legal requirements regarding period testing and certification (chapter C).
• In case of doubt, stop immediately, and ask further advice from DHOLLANDIA prior to continuing.
§2 - Electrical controls
• The DH-VZ is partially operated by hand, partially via a 2-button control in the lift’s body. The rotating movements of the lift frame IN /
OUT the vehicle body, rotation from the position at the loading floor 90° outwards, and the folding / unfolding of the platform is done
by hand. The electrical control is used to LIFT / LOWER the platform, when the lift frame is positioned in its work position outside the
vehicle.
• The electrical control unit works as follows:
Consult the user’s manual before getting
started. Follow all safety instructions.
Check if the lift can be used safely, and
that no urgent maintenance or repair is
required. DO NOT continue if any unsafe
condition exists
Switch on the electrical power to the lift
(cabin switch in the driver’s cabin, or main
battery isolator switch)
Press LIFT to check if the hydraulic system
is building up pressure, and there is no
visual oil leaks.
§3 - Putting the lift into service


2/4
Release the mechanical travel lock Release the rotation lock and manually
rotate the lift 90° or 180° until the lift is
behind the vehicle.
If the lift was stored in this position, it
should be rotated 90° Position behind the vehicle. Now unfold the platform. Beware of hand and finger traps.
If the lift was stored in this position, it
should be rotated 180°
The lift is now ready for use.


Follow the loading instructions of the user’s
manual. Observe the max. nominal capaci-
ty and the loading diagrams indicating the
SWL
Release the second rotation lock in order
to rotate the lift body. Rotate the lift 90° outwards to bring it in the position where it can start lowering
Lower the platform to the ground (or pave-
ment at the roadside)
Do not load / offload the platform before it
has reached its final parking position at the
ground
3/4
§4 - Loading and unloading

 
Use to controls to LIFT the platform to the
loading floor level of the vehicle. Release
the LIFT button when the platform has
reached its highest position
Release the rotation lock of the lift body
and manually rotate the lift body back to
the position behind the vehicle.
Lower the lift until the front of the platform
is resting on the loading floor. ... and move the load from the platform to the vehicle floor or vice versa


§5 - Stowing the lift away in its travel position
Switch off the electrical power to the lift
(cabin switch in the driver’s cabin, or main
battery isolator switch)
Engage the mechanical travel lock
Stored position alongside the van wall (e.g.
when the van is empty) - 180° rotated.
Stored position behind the doors (e.g.
when goods inside the van prevent further
rotation) - 90° rotated.
Release the rotation lock and manually
rotate the lift 90° or 180° until the lift is in
stored position.
Fold the platform back into vertical posi-
tion. Beware of hand and finger traps.
Lift the platform to its highest position.
