Di-soric ID-05 User manual

ID-05
High Performance Imager
User’s Manual
ID-05 User’s Manual

ii ID-05 High Performance Imager User’s Manual
Copyright and Disclaimer

ID-05 High Performance Imager User’s Manual iii
Introduction
Copyright ©2010
ISO 9001 Certified
Issued by TüV USA
All rights reserved. The information contained herein is proprietary and is provided solely for the purpose
of allowing customers to operate and/or service di-soric manufactured equipment and is not to be
released, reproduced, or used for any other purpose without written permission of di-soric.
Throughout this manual, trademarked names might be used. Rather than place a trademark (™) symbol
at every occurrence of a trademarked name, we state herein that we are using the names only in an editorial
fashion, and to the benefit of the trademark owner, with no intention of infringement.
Disclaimer
The information and specifications described in this manual are subject to change without notice.
Latest Manual Version
For the latest version of this manual, see the Download Center on our web site at:
www.di-soric.com.
Technical Support
For technical support, e-mail: [email protected].
Warranty and Terms of Sale
For Standard Warranty information contact:
di-soric GmbH & Co. KG
Steinbeisstraße 6
DE-73660 Urbach
Fon: +49 (0) 71 81 / 98 79 - 0
Fax: [phone] / 98 79 - 179
[email protected]
www.di-soric.com

iv ID-05 High Performance Imager User’s Manual
Table of Contents
Table of Contents
Chapter 1 Quick Start
Step 1 Check Hardware .......................................................................... 1-2
Step 2 Connect the System..................................................................... 1-3
Step 3 Position Imager and Symbol ........................................................ 1-4
Step 4 Install di-soric ID........................................................................... 1-5
Step 5 Select Model ................................................................................ 1-6
Step 6 Select Protocol and Connect........................................................ 1-7
Step 7 Locate the Symbol in the Field of View ........................................1-9
Step 8 Calibrate..................................................................................... 1-11
Step 9 Test Read Rate .......................................................................... 1-12
Step 10 Configure the Imager in di-soric ID .......................................... 1-13
Step 11 Save Configuration in di-soric ID.............................................. 1-14
Chapter 2 Using di-soric ID
EZ Mode .................................................................................................. 2-2
Application Mode ..................................................................................... 2-3
Menu Toolbar .......................................................................................... 2-4
Autoconnect.......................................................................................... 2-12
View...................................................................................................... 2-14
Navigating in di-soric ID........................................................................ 2-15
Send/Receive Options.......................................................................... 2-16
Using EZ Trax........................................................................................ 2-18
Chapter 3 Communications
Communications by di-soric ID................................................................ 3-2
Communications Serial Commands ........................................................ 3-3
Host Port Connections............................................................................. 3-4
Host Port Protocol ................................................................................... 3-5
ACK/NAK Options ................................................................................... 3-7
Polling Mode Options .............................................................................. 3-8
RS-422 Status ......................................................................................... 3-9
Auxiliary Port Connections .................................................................... 3-10
Auxiliary Port System Data Status......................................................... 3-18
Daisy Chain Autoconfigure .................................................................... 3-19
Response Timeout ................................................................................ 3-20
LRC Status ............................................................................................ 3-21
Protocol Configuration Examples .......................................................... 3-22
USB HID Interface ................................................................................. 3-23
ASCII Character Entry Modifier ............................................................. 3-32
Preamble ............................................................................................... 3-33
Postamble.............................................................................................. 3-34
Chapter 4 Calibration
Calibration Serial Commands.................................................................. 4-2

ID-05 High Performance Imager User’s Manual v
Introduction
Calibration Overview................................................................................4-2
Calibration Options ..................................................................................4-3
Calibration by di-soric ID........................................................................4-11
Initiating Calibration ...............................................................................4-13
Additional Notes about Calibration ........................................................4-19
Chapter 5 Read Cycle
Read Cycle by di-soric ID ........................................................................5-2
Read Cycle Serial Commands.................................................................5-3
Read Cycle Setup....................................................................................5-4
Multisymbol..............................................................................................5-5
Trigger Mode and Filter Duration.............................................................5-6
External Trigger Polarity ........................................................................5-11
Serial Trigger .........................................................................................5-12
Start Trigger Character (Non-Delimited)................................................5-13
Stop Trigger Character (Non-Delimited) ................................................5-14
End of Read Cycle.................................................................................5-15
Capture Mode ........................................................................................5-17
Capture Timing ......................................................................................5-21
Image Processing Timeout ....................................................................5-23
Image Storage .......................................................................................5-24
Minimum Good Reads ...........................................................................5-26
Setting Up the Imager for EZ Trax.........................................................5-28
Chapter 6 Symbologies
Symbologies by di-soric ID ......................................................................6-2
Symbologies Serial Commands...............................................................6-3
Data Matrix ..............................................................................................6-4
Aztec Code ..............................................................................................6-6
QR Code..................................................................................................6-7
Micro QR Code ........................................................................................6-8
Code 39 ...................................................................................................6-9
Code 128/EAN 128................................................................................6-12
BC412....................................................................................................6-15
Interleaved 2 of 5 ...................................................................................6-16
Code 93 .................................................................................................6-19
Codabar .................................................................................................6-20
UPC/EAN...............................................................................................6-23
Pharmacode ..........................................................................................6-27
Postal Symbologies ...............................................................................6-29
GS1 DataBar (RSS)...............................................................................6-34
PDF417..................................................................................................6-36
MicroPDF417.........................................................................................6-37
Composite..............................................................................................6-38
Narrow Margins/Symbology Identifier....................................................6-39
Background Color ..................................................................................6-41

vi ID-05 High Performance Imager User’s Manual
Table of Contents
Chapter 7 I/O Parameters
I/O Parameters by di-soric ID .................................................................. 7-2
I/O Parameters Serial Commands........................................................... 7-3
Symbol Data Output ................................................................................ 7-4
No Read Message................................................................................... 7-7
Read Duration Output.............................................................................. 7-8
Output Indicators ..................................................................................... 7-9
Beeper................................................................................................... 7-13
LED Configuration ................................................................................. 7-14
Serial Verification................................................................................... 7-15
EZ Button............................................................................................... 7-17
EZ Button Modes................................................................................... 7-19
Configurable Output 1 ........................................................................... 7-21
Trend Analysis Output 1 ........................................................................ 7-24
ISO/IEC 16022 Symbol Quality Output 1 .............................................. 7-27
Diagnostic Output 1 ............................................................................... 7-30
Configurable Output 2 ........................................................................... 7-31
Trend Analysis Output 2 ........................................................................ 7-31
ISO/IEC 16022 Symbol Quality Output 2 .............................................. 7-31
Diagnostic Output 2 ............................................................................... 7-31
Configurable Output 3 ........................................................................... 7-32
Trend Analysis Output 3 ........................................................................ 7-32
ISO/IEC 16022 Symbol Quality Output 3 .............................................. 7-32
Diagnostic Output 3 ............................................................................... 7-32
Power-On/Reset Counts........................................................................ 7-33
Time Since Reset .................................................................................. 7-34
Service Message ................................................................................... 7-35
Frame Information ................................................................................. 7-36
Image Output......................................................................................... 7-37
Database Identifier Output..................................................................... 7-40
Quality Output........................................................................................ 7-41
Configuring EZ Trax Output................................................................... 7-42
Chapter 8 Symbol Quality
Symbol Quality Serial Commands........................................................... 8-2
Overview of Symbol Quality .................................................................... 8-3
Symbol Quality by di-soric ID .................................................................. 8-4
Symbol Quality Separator/Data Matrix Output Mode .............................. 8-8
ISO/IEC 16022 Symbol Quality Output ................................................. 8-10
ISO/IEC 16022 Symbol Quality Output by di-soric ID ........................... 8-12
di-soric Symbol Quality Output .............................................................. 8-13
di-soric Symbol Quality Output by di-soric ID ........................................ 8-16
Chapter 9 Matchcode
Matchcode by di-soric ID ......................................................................... 9-2
Matchcode Serial Commands ................................................................. 9-3

ID-05 High Performance Imager User’s Manual vii
Introduction
Overview of Matchcode ...........................................................................9-4
Matchcode Type ......................................................................................9-5
Match Replace.......................................................................................9-10
Mismatch Replace .................................................................................9-11
New Master Pin .....................................................................................9-12
Chapter 10 Camera and IP Setup
Camera and IP Setup by di-soric ID ......................................................10-2
Camera and IP Setup Serial Commands...............................................10-3
Video......................................................................................................10-4
Evaluation ..............................................................................................10-5
Calibration..............................................................................................10-8
Window of Interest .................................................................................10-9
Configuration Database .......................................................................10-13
Dynamic Setup ....................................................................................10-14
X-Mode™.............................................................................................10-15
Pixel Sub-Sampling .............................................................................10-16
Camera Settings ..................................................................................10-18
Camera Settings (3 Megapixel) ...........................................................10-19
Focal Distance .....................................................................................10-20
Focal Distance (3 Megapixel) ..............................................................10-21
Focal Distance Table (Read-Only) ......................................................10-22
Focal Distance Table (Read-Only) (3 Megapixel)................................10-23
Increment Focus Position ....................................................................10-24
Decrement Focus Position...................................................................10-24
Increment Focus Position (3 Megapixel) .............................................10-25
Decrement Focus Position (3 Megapixel)............................................10-25
Illumination Brightness.........................................................................10-26
Color Filter ...........................................................................................10-27
Skew Correction ..................................................................................10-28
Morphological Pre-Processing.............................................................10-31
Morphological Operation and Operator Size .......................................10-32
Chapter 11 Configuration Database
Configuration Database Serial Commands ...........................................11-2
Number of Active Indexes......................................................................11-3
Configuration Database Status..............................................................11-4
Database Mode ...................................................................................11-10
Save Current Settings to Configuration Database...............................11-15
Load Current Settings from Configuration Database...........................11-16
Request Selected Index Settings.........................................................11-17
Request All Configuration Database Settings......................................11-18
Chapter 12 Terminal
Terminal Window ...................................................................................12-2
Find........................................................................................................12-3
Send ......................................................................................................12-4

viii ID-05 High Performance Imager User’s Manual
About the ID-05 High Performance Imager
Macros................................................................................................... 12-5
Terminal Window Menus ....................................................................... 12-6
Chapter 13 Utilities
Serial Utility Commands ........................................................................ 13-2
Read Rate ............................................................................................. 13-4
Counters ................................................................................................ 13-5
Device Control ....................................................................................... 13-7
Differences from Default........................................................................ 13-8
Master Database ................................................................................... 13-9
Firmware.............................................................................................. 13-15
Default/Reset/Save.............................................................................. 13-18
Imager Status Requests ...................................................................... 13-20
Learn Operations................................................................................. 13-22
Other Operational Serial Commands .................................................. 13-23
Chapter 14 Output Format
Output Format Serial Commands.......................................................... 14-2
Output Format Status ............................................................................ 14-3
Format Assign ....................................................................................... 14-4
Format Extract ....................................................................................... 14-5
Format Insert ......................................................................................... 14-7
Output Filter Configuration .................................................................... 14-9
Ordered Output Filter........................................................................... 14-13
Appendices
Appendix A General Specifications .........................................................A-2
Appendix B Electrical Specifications .......................................................A-6
Appendix C Serial Configuration Commands ........................................A-10
Appendix D Communications Protocol ..................................................A-16
Appendix E ASCII Table........................................................................A-25
Appendix F Interface Standards ............................................................A-26
Appendix G Operational Tips ................................................................A-27
Appendix H Using an External Trigger ..................................................A-28
Appendix I USB-to-Serial Virtual COM Port Driver................................A-29
Appendix J ID-05 Image Output ............................................................A-32
Appendix K Glossary of Terms..............................................................A-35
Index

ID-05 High Performance Imager User’s Manual ix
Introduction
About the ID-05 High Performance Imager
The key features of the ID-05 High Performance Imager are:
• Powerful X-Mode™algorithm for Direct Part Mark decoding
• High Density (SXGA), High Speed (WVGA)
• Software-adjustable focus
• USB, RS-232, and RS-422/485 connectivity
• Support for both linear and 2D symbologies
• High-output LED illumination
• EZ Button for setup and testing
• A blue target pattern that identifies the center point of the field of view
• A green flash (visible from all angles) to signal a successful read
• Compact size for easy integration into a wide variety of applications
ID-05 Communications
There are three ways to configure and test the ID-05:
• di-soric Windows-based di-soric ID (Setup Program), which offers point-and-click
ease of use and visual responses to user adjustments.
• Serial commands, such as <K100,1>, that can be sent from di-soric ID’s Terminal or
another terminal program.
• The EZ Button at the back of the imager.

xID-05 High Performance Imager User’s Manual
Statement of Agency Compliance
Warning and Caution Summary
• Viewing the ID-05’s LED output with optical instruments such as magnifiers, eye loupes,
or microscopes within a distance of 100 mm could cause serious eye injury.
• Maximum LED output: .564 mW.
• Wavelength: 470 nm; 525 nm; 617 nm.
• Location of the ID-05’s LED aperture window:
CAUTION: Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
IMPORTANT: The ID-05 is intended for connection to a UL-listed direct plug-in power unit
marked Class II and rated 5 VDC at 3.5 Watts, or greater if using electrical accessories.
European models must use a similarly rated Class I or Class II power supply that is certified
to comply with standard for safety EN 60950.
WARNING
LED LIGHT
DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 1 LED PRODUCT
LED Output: .564 mW. Wavelength: 470 nm; 525 nm; 617 nm.
IEC 60825-1:1993+A1:1997+A2:2001
LED Aperture Window

ID-05 High Performance Imager User’s Manual xi
Introduction
Statement of Agency Compliance
The ID-05 has been tested for compliance with FCC (Federal Communications Commis-
sion) regulations and has been found to conform to all applicable FCC Rules and Regula-
tions.
To comply with FCC RF exposure compliance requirements, this device must not be co-located
or operate in conjunction with any other antenna or transmitter.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
The ID-05 has been tested for compliance with CE (Conformité Européenne) standards and
guidelines, and has been found to conform to applicable CE standards, specifically the
EMC requirements EN 55024:1998+A1:2001+A2:2003, ESD EN 61000-4-2, Radiated RF
Immunity EN 61000-4-3, ENV 50204, EFT EN 61000-4-4, Conducted RF Immunity EN
61000-4-6, EN 55022:1998+A1:2000+A2:2003 for Class A products, Class B Radiated
Emissions, and Class B Conducted Emissions.
The ID-05 has been tested by an independent electromagnetic compatibility laboratory in
accordance with the applicable specifications and instructions.

xii ID-05 High Performance Imager User’s Manual
Statement of RoHS Compliance
Statement of RoHS Compliance
All di-soric ID readers are RoHS-Compliant.
These products meet all the requirements of the European Parliament and the Council of the
European Union for RoHS compliance. In accordance with the latest requirements, our
RoHS-compliant products and packaging do not contain intentionally added Deca-BDE,
Perfluorooctanes (PFOS) or Perfluorooctanoic Acid (PFOA) compounds above the
maximum trace levels. To view the documents stating these requirements, please visit:
http://eur-lex.europa.eu/LexUriServ/LexUriServ.do?uri=CELEX:32002L0095:EN:HTML
and
http://eur-lex.europa.eu/LexUriServ/LexUriServ.do?uri=OJ:L:2006:372:0032:0034:EN:PDF
Please contact your sales manager for a complete list of di-soric’s RoHS-Compliant
products.
This declaration is based upon information obtained from sources which di-soric believes to be reliable, and from
random sample testing; however, the information is provided without any representation of warranty, expressed or
implied, regarding accuracy or correctness. di-soric does not specifically run any analysis on our raw materials or
end product to measure for these substances.
The information provided in this certification notice is correct to the best of di-soric’s knowledge at the date of
publication. This notice is not to be considered a warranty or quality specification. Users are responsible for
determining the applicability of any RoHS legislation or regulations based on their individual use of the product.

ID-05 High Performance Imager User’s Manual 1-1
1 Quick Start
Contents
This chapter is designed to get your ID-05 up and running quickly, using the EZ button or
di-soric ID (Setup Program). Following these steps will allow you to get a sense of
the imager’s capabilities and to test sample symbols.
Detailed setup information for installing the imager into your actual application can be
found in the subsequent chapters.
Step 1 Check Hardware................................................................................................................1-2
Step 2 Connect the System ..........................................................................................................1-3
Step 3 Position Imager and Symbol..............................................................................................1-4
Step 4 Install di-soric ID................................................................................................................1-5
Step 5 Select Model......................................................................................................................1-6
Step 6 Select Protocol and Connect.............................................................................................1-7
Step 7 Locate the Symbol in the Field of View .............................................................................1-9
Step 8 Calibrate ......................................................................................................................... 1-11
Step 9 Test Read Rate .............................................................................................................. 1-12
Step 10 Configure the Imager in di-soric ID............................................................................... 1-13
Step 11 Save Configuration in di-soric ID.................................................................................. 1-14

1-2 ID-05 High Performance Imager User’s Manual
Check Hardware
Step 1 — Check Hardware
Item Description Part Number
1ID-05 Reader ID-05-IMX-X-X
2Power Converter 24V-5V VSID-A-24/5V-S
3Interface Box VSID-IB-S
4Power Supply (90-264 VAC, 24VDC, USA/Euro plug) VSID-PS-IB
5Object Detector contact di-soric
6Communication Cable VSID-K-25S/9K-2
Scanner
Network
Host
Hardware Required
Caution: Be sure that all cables are connected BEFORE applying power to the
system. Always power down BEFORE disconnecting any cables.
1
3
2
45
6

ID-05 High Performance Imager User’s Manual 1-3
Quick Start
Step 2 — Connect the System
Connecting by RS-232/RS-422/RS-485
• Connect the imager (1) to the Interface (2) and (3).
• Connect the host cable (6) to the host and to the host port on the Interface Box(3).
• Connect the object detector (5) to the Interface Box (3).
• Connect the power supply (4) to the Interface Box (3).
• Apply power to the imager.
Important: If you are using a USB model, you must connect the device to the host computer
before powering-on. Otherwise the unit will not be recognized as a USB device.
Scanner
Network
Host
Hardware Configuration
Caution: Be sure that all cables are connected BEFORE applying power
to the system. Always power down BEFORE disconnecting any cables.
1
3
2
45
6

1-4 ID-05 High Performance Imager User’s Manual
Position Imager and Symbol
Step 3 — Position Imager and Symbol
• Position the imager at a focal distance between 2 and 6 inches from the symbol.
• Tip the imager relative to the symbol to avoid the glare of direct (specular) reflection. The
case parting line should be perpendicular to the plane of the symbol by either pitching the
symbol or the imager as shown.
• Position the imager in a place with as little ambient light as possible.
• Symbols can be rotated (tilted) at any angle; however, for best results symbols should
be aligned with the FOV (field of view).
• In the case of linear symbols, aligning the bars in the direction of their movement (“ladder”
orientation) will minimize the chances of blurring, and will produce better reads.
Important: Avoid excessive skew or pitch. Maximum skew is ±30°; maximum pitch is
±30°. The illustration below shows skew axis, pitch axis, and tilt axis.
Note: For accuracy of testing and performance, di-soric recommends using a mounting
arm adapter kit. Contact your di-soric sales manager for details about mounting arm
adapter kits and other accessories.
Imager and Symbol Orientation

ID-05 High Performance Imager User’s Manual 1-5
Quick Start
Step 4 — Install di-soric ID
di-soric ID Software can be found on the di-soric Tools USB-Stick that is packaged with the
ID-05.
1. Follow the prompts to install di-soric ID from the USB-Stick.
2. Click on the di-soric ID icon to run the program.
Note: di-soric ID can also be installed from the Download Center
at www.di-soric.com.
Minimum System Requirements
• 166 MHz Pentium processor (Pentium II processor recommended)
• Windows 7, Vista, XP, or 2000 operating system
• Internet Explorer 5.0 or higher
• 64 MB minimum RAM (128+ MB RAM recommended)
• 80 MB hard drive space
• 800 x 600 minimum 256 color display (1024 x 768 32-bit color recommended)

1-6 ID-05 High Performance Imager User’s Manual
Select Model
Step 5 — Select Model
When you start di-soric ID, the following menu will appear:
1. Click the button showing the ID-05.
2. Click OK.
Note: You can also double-click the ID-05 button to make your selection.
3. Click Yes when this dialog appears:
Note: If you need to select another model later, click the Switch Model button near
the top of the screen or use Model > New Model in the menu toolbar.

ID-05 High Performance Imager User’s Manual 1-7
Quick Start
Step 6 — Select Protocol and Connect
• Choose the connection protocol you are using and click Connect.
• Once you select your communications mode, follow the simple prompts to
establish your connection.

1-8 ID-05 High Performance Imager User’s Manual
Select Protocol and Connect (cont.)
Step 6 — Select Protocol and Connect (cont.)
When you are connected, you will see the green connection indicator in the status bar at
the bottom right of your screen.
• If your RS-232 connection attempt fails, click the Autoconnect button, select a different
communications port, and try again.
Note: If your RS-232 host settings cannot be changed to match the imager’s settings,
check the Force Connect box in the RS-232 dialog and click the Connect.
USB:
RS-232:
