Dialight VIGILANT Series User manual

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 1of 34
VIGILANT®SERIES
Dual Red/White (L-864/865)
White Lighting System (L-865)
D1xWCTR4x9 - Controller/Power Supply
with
D1xWFH408 or D1xWFH409 –Flashhead
RTOxR280x –L-810 DC Sidelights
D2566000PEC –Photocell
FAA Type D1 or E1 Systems

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 2of 34
DO NOT let any supply cords touch
hot surfaces higher than cord ratings.
DO NOT mount near gas or electric
heaters
Equipment should be mounted in
locations and at heights where it will
not be subjected to tampering by
unauthorized personnel.
The use of accessory equipment not
recommended by the manufacturer
may cause unsafe conditions.
DO NOT use this equipment for other
than intended use.
DO take pictures: Installation Photos
Required for Warranty Coverage. (All
electrical connections, bonding,
system support and grounding)
Refer to Quick Manual for list of
required pictures and commissioning
checklist
The cable information provided are for
tower structures of less than 500 feet.
SAVE THESE INSTRUCTIONS!!
The operation and maintenance must be
carried out by authorized personnel.
Repairs and Installation must only be
carried out by a qualified electrician.
Only genuine Dialight replacement parts
must be used when unforeseen repairs
are required.
Observe the national safety rules and
regulations during installation!
Earth Grounding is required throughout
the install process. Failure to do so could
void all warranties!
No alterations should be done without
agreement from Dialight Corp.
Alterations other than written in this
manual will void all warranties.
The light source contained in this
luminaire shall only be replaced by the
manufacturer or his service agent or a
similar qualified person.
SAVE THESE INSTRUCTIONS!!
READ AND FOLLOW ALL SAFETY INSTRUCTIONS

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 3of 34
Table of Contents:
WARRANTY: ......................................................................................................................................................................4
SYSTEM DESCRIPTIONS:........................................................................................................................................................4
INTRODUCTION:..................................................................................................................................................................5
NOTICE AND WARNINGS:.....................................................................................................................................................6
DIMENSIONS FOR MOUNTING THE ENCLOSURE:........................................................................................................................7
DIMENSIONS FOR MOUNTING PHOTOCELL:..............................................................................................................................7
DIMENSIONS FOR MOUNTING THE D1XWL864/865 FLASHHEADS:............................................................................................8
ELECTRICAL SPECIFICATIONS:...............................................................................................................................................10
ENVIRONMENTAL SPECIFICATIONS:.......................................................................................................................................10
INSTALLATION TIPS AND REQUIREMENTS:..............................................................................................................................10
SYSTEM CABLE SPECIFICATIONS: ..........................................................................................................................................11
CONTROLLER/POWER SUPPLY COMPONENT LAYOUT:..............................................................................................................13
CONNECTION OF INPUT POWER:..........................................................................................................................................14
CONNECTION OF THE SIDE MARKER LIGHTS: ..........................................................................................................................15
PHOTOCELL CONNECTION:..................................................................................................................................................16
FLASHHEAD CABLE PREPARATION:........................................................................................................................................17
FLASHHEAD/CONTROLLER CABLE CONNECTIONS:....................................................................................................................18
SPARE PARTS -CONTROLLER/POWER SUPPLY: .......................................................................................................................20
SYSTEM CONFIGURATION SCREENS:......................................................................................................................................21
USER INTERFACE SCREENS: .................................................................................................................................................27
MANUAL LIGHTING INSPECTION: .........................................................................................................................................31
COMMISSIONING PHOTOGRAPHS:........................................................................................................................................34
TECHNICAL SUPPORT:........................................................................................................................................................34
SERIAL NUMBER CODING: ..................................................................................................................................................34
REVISION HISTORY:...........................................................................................................................................................34

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 4of 34
Warranty:
Please visit www.dialight.com/resources/warranties for the latest warranty policy.
System Descriptions:
The below devices are covered in this manual.
D1RWCTR409
Gen5 Dual Red/White Controller/Power Supply
120/277AC 50/60Hz Input Voltage
+48VDC L-810 Sidelights (RTO1R1800x)
L-864/865 or L-865 flash head, 4 conductor cable required
D1RWCTR449
Gen5 Dual Red/White Controller/Power Supply
±48VDC Input Voltage
+48VDC L-810 Sidelights (RTO1R1800x)
L-864/865 or L-865 flash head, 4 conductor cable required
D1CWCTR409
Gen5 Dual Red/White w/Infrared (IR) Controller/Power Supply
120/277VAC Input Voltage
±48VDC L-810 Sidelights w/IR (RTOCR2800x)
L-864/865 or L-865 flash head w/IR, 4 conductor cable required
D1CWCTR449
Gen5 Dual Red/White w/Infrared (IR) Controller/Power Supply
±48VDC Input Voltage
+48VDC L-810 Sidelights w/IR (RTOCR2800x)
L-864/865 or L-865 flash head w/IR, 4 conductor cable required
D1RWFH409
Gen5 Dual Red/White w/4 conductor Flash Head
- Configured in controller as Dual Red/White or White Only
D1CWFH409
Gen5 Dual Red/White w/Infrared (IR) & 4 conductor Flash Head
- Configured in controller as Dual Red/White or White Only
RTO1R1800x
+48VDC L-810 LED Sidelight, Single or Double
RTOCR2800x
+48VDC L-810 LED Sidelight w/IR, Single or Double
D2566000PEC
Medium Intensity Photocell
System not listed, please contact Dialight technical support at 844-436-5422.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 5of 34
Introduction:
This manual is for installing the FAA Type E (L-864/865, Dual Red/White) or FAA Type D
(L-865, White only) lighting systems. Please see the separate user manual for FAA Type A
(L-864, Red Only) systems.
Covered in this manual is the following information.
Warranty Policy
System Descriptions
Notice and Warnings
Dimensions of Controller/Power Supply Enclosure
Dimensions of Photocell
Dimensions of D1xW Flashhead
Electrical & Environmental Specifications
Installation Tips and Requirements
System Cable Specifications
Controller Component Layout
AC Power, Sidelight, Photocell & Flashhead Connections
Spare Parts for Controller/Power Supply
Navigating the LCD Display
oConfiguration Screens
oMain Menu Screens
oManual Lighting inspection test
Commissioning Photographs
Technical Support
Serial Number Coding
Not included in this manual:
Refer to the quick start manual for the below information
RS485 Communication Connections for multiple systems
Controller Status LED’s
Dry contact connections
Resetting system & external GPS option
Display Events and Alarm Descriptions
Alarm list and possible causes
INEM installation and setup

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 6of 34
Notice and Warnings:
This manual contains important information regarding the proper installation, operation,
and maintenance of this product. Before using the product, read and understand all
instructions, cautions, notes and warnings, as well as all of the labels affixed to the
product. Failure to do so could result in personal injury or damage to equipment and/or
void the product warranty.
FAILURE TO LEAVE THE ENCLOSURES FREE FROM DEBRIS UPON COMPLETION OF INSTALLATION MAY
CAUSE SHORT CIRCUITS
FAILURE TO TIGHTEN DOWN CLAMP WASHERS WILL MAKE INTERNAL COMPONENTS VULNERABLE TO
SURGE OR LIGHTNING DAMAGE
FAILURE TO PROPERLY BOND THE EARTH GROUND WIRE TO THE JUNCTION BOX WILL RESULT IN
EVENTUAL LIGHTNING DAMAGE OF THIS SYSTEM.TO AVOID WARRANTY NULLIFICATION,FOLLOW
THE DIRECTIONS IN THEIR ENTIRETY.
CAUTION:ONLY APPROVED DIALIGHT PHOTOCELLS CAN BE USED WITH THIS SYSTEM
FAILURE TO PROPERLY BOND THE FLASHHEADS AND CONTROLLER ENCLOSURE TO THE TOWER
STRUCTURE WILL RESULT IN EVENTUAL LIGHTNING DAMAGE OF THIS SYSTEM.THE SYSTEM’S
WARRANTY SHALL BE VOID IF ALL FLASHHEADS AND CONTROLLER ENCLOSURE ARE NOT
PROPERLY BONDED TO THE TOWER STRUCTURE.TO AVOID WARRANTY NULLIFICATION,FOLLOW
THE DIRECTIONS IN THEIR ENTIRETY.
CAUTION:NEVER LOOK AT THE FLASH HEAD WHILE THE SYSTEM IS ENERGIZED.THE FLASH HEAD
COULD START FLASHING CAUSING TEMPORARY BLINDNESS WHICH WOULD BE DANGEROUS AT HIGH
ELEVATIONS.
FAILURE TO SET UP THE SYSTEM CORRECTLY DURING STARTUP MAY RESULT IN THE TOWER HAVING
TO BE CLIMBED AGAIN TO PERFORM TROUBLESHOOTING.
USE PROPER METHODS OF LIFTING AND CARRYING TO PROTECT AGAINST INJURY.
FOLLOW THE RECOMMENDATIONS BELOW TO ENSURE ENCLOSURES ARE HANDLED IN
A SAFE MANNER:
BASED ON FACILITY SAFETY REQUIREMENTS DETERMINE IF THE ENCLOSURE
REQUIRES TEAM LIFTING
BEND AT THE KNEES AND MAKE SURE YOUR BACK IS STRAIGHT BEFORE LIFTING
LIFT WITH YOUR LEGS AND NOT YOUR BACK
KEEP THE ENCLOSURE CLOSE TO YOUR BODY WHILE CARRYING
KEEP YOUR BACK STRAIGHT WHEN LOWERING

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 7of 34
Dimensions for Mounting the Enclosure:
NOTE: Both the Controller and Power Supply use the same enclosure.
Recommended mounting hardware diameter is 3/8” (10.3mm)
Weight of the complete enclosure is 49.5 lb (22.45kg).
Six (6) ¾-inch NPT entrance holes provided on bottom side of enclosure
Dimensions for Mounting Photocell:
Four (4) ꝋ0.22” (5.6mm) thru holes provided for mounting

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 8of 34
Dimensions for Mounting the D1xW L864/865 Flashheads:
D1xWFH409 Flashhead
Weight 21 lbs.(9.5kg)
D1RWFH408 Flashhead

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 9of 34
Recommended Locations for Cable Entry:
The enclosures are supplied with six factory-drilled holes. Remove any red dust caps and
all entrance holes must be properly sealed with watertight connectors or plugs to ensure
proper moisture protection. Typical port entrances for cables/seal-tight are shown below.
Input voltage location has red dust cap from factory, this must be removed and replaced
with watertight connector or plug.
To maintain water ingress protection all additional holes should located at the bottom side
of the enclosure.
NOTE: Dimensions are suited for ¾-inch NPT cord grips or seal tight.
NOTE: Additional Grounding can be added at either the mounting feet or inserted to the
ground terminal block (GL) located in the enclosure. Grounding cables not supplied.
Multiple grounding points provided in the enclosure for protective and functional
Earth/Ground connections.
Dry Contact Monitoring
Marker Lights,
L810
Flash Head
Photocell
Earth Ground
Input Voltage

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 10 of 34
Electrical Specifications:
D1xWCTR409 Controller/Power Supply –90 Watts, 120/277 VAC 50/60Hz
D1xWCTR449 Controller/Power Supply –75 Watts, ±48VDC
D1xWFH4xx Flashhead –36 Watts
RTO1R18001 48VDC L-810 –1.5 Watts
RTOCR28001 48VDC L-810 w/IR –5.2 Watts
Environmental Specifications:
Operating Temperature Range: -40°F to +130°F (-40°C to +55°C)
Humidity: 95% relative humidity
Wind: up to 150 mph (240kmph)
Protection: IP66, Suitable for outdoor use
Pollution degree: P1
Equipment intended to be installed at an altitude of 2000m or less
Installation Tips and Requirements:
The D1xWCTR4x9 Controller/Power Supply is housed in a NEMA4X rated outdoor
enclosure and can be installed either outside or in a shelter. If installed outside, the
installer must consider water ingress and proper earth grounding to reduce the risk of
premature failures.
For AC or DC Input, it is recommended that the electrician or installer calculate the wire
requirements based on the system being installed. It is recommended that installation
does not utilize less than 14AWG 600V cable with at least a 90ºC temperature rating. See
electrical parameters for further information.
It is recommended that the lighting system be on its own breaker adequately rated for the
system’s power consumption. The breaker MUST be rated for at least 20% higher than the
systems total current draw.
Proper grounding techniques must be utilized based on local, state and federal
guidelines and customer specifications. The system has built in Lightning and RF
immunity at each section, but for it to be effective proper ground connection
techniques must be used.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 11 of 34
System Cable Specifications:
NOTE: Cables for AC/DC Input and remote monitoring are not supplied.
Specification for Input cable:
Requires three conductors for AC or DC Input.
Typical AC color code is Black, White and Green.
Typical DC color code is Red, Black and Green.
Earth Ground is required in the controllers.
A minimum of 14AWG is to be used.
Bonding ground wire when required is to be 6AWG.
Individual wires can be used in lieu of a cable but must be routed through conduit or
seal tight.
Specification for RS485 Cable:
Requires three conductors of 18AWG, drain wire plus a braid for grounding.
Typical color code is Grey, Yellow, and Blue.
NOTE: Only required for systems that have more than one (1) Controller/Power
Supply.
Specification for Photocell Cable:
Requires three conductors of 18AWG.
Typical colors are Red, Black and Green.
Maximum distance is 500 feet (152 meters).
Specification for 48Vdc L810 Side Marker Cable:
Requires three conductors of 18AWG.
Typical color code is Red, Black and Green.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 12 of 34
Specification for the Flashhead cable
The Vigilant® flashhead requires a 4-conductor cable with a minimum of 14 AWG
with foil and braid shielding.
Typical colors are Red, Red with black stripe, White and White with black stripe.
Cable needs to be an un-cut (no splices) run from flashhead to controller/power
supply surge protection devices.
NOTE: Stripes are always for the negative connection on DC systems.
All cables that extend up the structure must be
adequately secured to the structure with the
use of ¾” filament tape and 2” black all
weather tape at a maximum of 5 foot
intervals. Route cables inside the structure
leg when possible. Maximum #14-AWG
cable length is 680 feet (207 meters).
#12-4C should be used on taller structures.
Failure to meet any of the above cable
requirements could void all factory
warranties. If in doubt please contact your sales
representative or Dialight.com.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 13 of 34
Controller/Power Supply Component Layout:
NOTE: Interior Door with LCD Display and Sidelight Module not shown.
I D
Description
I D
Description
W1
WHITE LED DRIVER #1
I/L
INTERLOCK SWITCH
W2
WHITE LED DRIVER # 2
AC/DC
POWER SUPPLY CONVERTER
TB2
SIDELIGHT/RS485/PHOTOCELL
M/F
MICRO/FILTER ASSY
GL
EARTH GROUND LUG
CAP
CAPACITOR BOARD
TB1
INPUT VOLTAGE (AC or DC)
LPB
LIGHTNING PROTECTION BOARD
F/S
FILTER/SURGE BOARD
R
RED LED DRIVER
ALM
DRY CONTACT ALARM MODULE
RS485
RS485 CONNECTOR BOARD
LCD
LCD MODULE (door mounted)
SLM
SIDELIGHT MODULE (door mounted)
(W1)
(W2)
(CAP)
(LPB)
(M/F)
(R)
(TB2)
(TB1)
(F/S)
(I/L)
(GL)
(AC/DC)
(RS485)
(ALM)

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 14 of 34
Connection of Input Power:
Input cable or wire NOT supplied with the system. Input power connected at terminals
labeled TB1 (see below).
The AC connection requires three conductors. Live, Neutral and Earth Ground.
Input Voltage is 120/277 VAC 50/60Hz (100-305 VAC range).
The DC connection requires three conductors. Positive, Negative and Ground.
Input Voltage is ±48VDC (40-60 VDC range).
Individual wires can be used but must be fed through seal tight or conduit.
Earth ground connection is required to provide safety and proper operation of the
system.
WARNING: Floating Neutrals are not permissible within the wiring of the system and
the installer must verify the connections. This will “Void” all warranties and cause
system failure during turn on.
WARNING: No more than 305VAC measured from Live to Earth Ground or Live to
Neutral on TB1, or 60VDC from Positive to Negative or Positive to Ground. This must
be measured before powering up the system.
NOTE: The load and voltage loss of the cable must be quantified before selecting the
cable size requirements. See electrical specifications for details.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 15 of 34
Connection of the Side Marker Lights:
The DC connection requires three conductors. Positive, Negative and Ground.
Voltage to the L-810 sidelights is +48VDC and cable/wire connections on TB2 (Return &
+48V Out). Additional conductors required if using individual lamp monitoring.
CONNECTION OF RTO’s TO TERMINAL BLOCK (TB2) IN MAIN CONTROLLER
+48V OUT Connections:
Port 1
+48Vdc
Voltage to Individual L810 or Tier (up to 4 SL)
Port 2
+48Vdc
Voltage to Individual L810
Port 3
+48Vdc
Voltage to Individual L810
Port 4
+48Vdc
Voltage to Individual L810
NOTE: A single Port connection can power all L810’s.
Return Connections:
Port 1
-48Vdc
Voltage to Individual L810 or Tier (up to 4 SL)
Port 2
-48Vdc
Voltage to Individual L810
Port 3
-48Vdc
Voltage to Individual L810
Pin 4
-48Vdc
Voltage to Individual L810
NOTE: A maximum of 1.2 amps can be monitored through each port connection.
SIDE MARKER
LIGHT CONNECTIONS
RTO Red wire
RTO- Green wire
RTO- Black Wire

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 16 of 34
Photocell Connection:
One photocell is used for all Dialight Medium Intensity Controllers, p/n D2566000PEC.
No other photocell can be used as it will damage the system and void the warranty.
Open supplied photocell enclosure by removing four screws.
NOTE: Screws are not captive to the cover plate.
Insert cable/wires thru bottom port of housing.
Strip back required length of jacket to allow connections.
Remove green connector from circuit board.
With screws shown –connect Red, Green, and Black wires.
Completely reseat connector into circuit board.
NOTE: A zip tie is provided inside the photocell enclosure to secure the cable from
falling out. A UL knot can also be used to prevent the cable from sliding down the
conduit. Weight of cable should not be placed on terminal block alone.
Cable Requirements:
Three conductor, 18AWG minimum with a max. distance of 500 feet from the controller.
Photocell must face north and be placed in a location without obstructions or excess
ambient light (i.e. security light).
The photocell comes supplied with a ¾” NPT conduit hub. Conduit mounting is
recommended method for installing the photocell. If exposed cable is used in a hazardous
location, the cable must have either a shieldor braiding that is properly connected to body
of the photocell and to the controller enclosure. Failure to properly ground or use a cable
without the shield or braid will void all warranties and the product could be subject to
premature failures.
Photocell to Controller
Connections
V+= Red Wire
(Supply from Controller)
SIG IN= Green Wire
(Sense to Controller)
RET= Black Wire (Ground)

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 17 of 34
Flashhead Cable Preparation:
1. Run the cable through the provided strain relief before stripping the outer jacket
in order not to fray the braiding.
2. Remove 10” of the outer jacket. Careful not to damage internal braid. If cut, cable
should be re-stripped to ensure proper bonding.
3. Wrap electrical tape 3-4” from end of outer jacket to prevent fraying.
4. Remove remaining braiding for the wires to be connected at flashhead terminal
block (Red/Black, Red, White/Black, and White) back to electrical tape.
5. Strip conductors back 3/8” for termination into terminal block.
6. Connect the four conductors to terminal block and ground connection as detailed
the next section.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 18 of 34
Flashhead/Controller Cable Connections:
Flashheads and Controller have the same surge/terminal connections so the
information below will be used for connecting inside the Flash Head. Use same
installation method for the controller.
The flashhead cable must be an uncut run from the flashhead to the controller.
Mixing wires will result in severe damage to the controller and/or Flashhead. This will
VOID all warranties.
NOTE: This is the only connection in the Flash Head pedestal that is required.
NOTE: If color code is different than shown, the installer must provide this information to
the site manager upon completion for future reference when required.
J2 pin designators Description
RED Connections (RED)
- Pin 1 (Red/Black wire)
RED LED’s negative (Cathode connection)
+ Pin 2 (Red wire)
RED LED’s positive (Anode connection)
White Connections (WHT)
- Pin 3 (White/Black wire)
WHITE LED’s negative (Cathode connection)
+ Pin 4 (White wire)
WHITE LED’s positive (Anode connection)
Terminal block in Flashhead shown
Using a small tipped Flat head screwdriver, insert and lift handle
upwards to push the internal latch down to insert the wire.
Do a pull test to ensure conductor is properly seated.
Insert braiding in to the clip and use zip tie to secure to clip.
See NOTICE on inside lid of flashhead for more details.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 19 of 34
WARNING: It is vitally important that the braid and foil be properly connected under the
clamping washers for lightning protection. Failure to do will result in premature failures
during lightning strikes.
NOTE: For commissioning the system, pictures must be taken of all the clamping
washers and the cables secured under them.
Terminal block in Controller shown
Using a small tipped Flat head screwdriver, insert and lift handle
upwards to push the internal latch down to insert the wire.
Do a pull test to ensure conductor is properly seated.

Document: 9100-127-3481-99
Revision D
Release Date: 07/18/2022
1501 Route 34 South, Farmingdale, NJ 07727
Tel: [phone] Fax: [phone] www.dialight.com
Page 20 of 34
Spare Parts - Controller/Power Supply:
NOTE: Interior Door with LCD Display and Sidelight Module not shown.
I D
Description
Part Number
W1 / W2
WHITE LED DRIVER BOARD
D1W0084WA
RS485
RS485 CONNECTOR BOARD
8800865420100
ALM
DRY CONTACT ALARM MODULE
D7600RLY
CAP
CAPACITOR BOARD
D1RW0084CP
LPB
LIGHTNING PROTECTION BOARD
D7208SUR
M/F
MICRO/FILTER ASSY
D7300ASY
R
RED LED DRIVER
D1CW0084RA
AC/DC
POWER SUPPLY CONVERTER (AC Units Only)
D1RW9005RA
I/L
INTERLOCK SWITCH
7700865000100
F/S
FILTER/SURGE BOARD (AC Units)
D7202SUR
F/S
FILTER/SURGE BOARD (DC Units)
D7204SUR
LCD
LCD MODULE (door mounted)
D7401LCD
SLM
DC SIDELIGHT MODULE (door mounted)
D7502SLM
(W1)
(W2)
(CAP)
(LPB)
(M/F)
(R)
(F/S)
(I/L)
(AC/DC)
(RS485)
(ALM)
