Elumen8 CYC100 User manual

Order codes: ELUM123
CYC100 RGBW 100W
COB Cyclorama Wash
User Manual

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment has been exposed to drastic
temperature uctuation (e.g. after transportation),
do not connect power or switch it on immediately.
The arising condensation might damage the equipment.
Leave the equipment switched off until it has reached
room temperature.
• Never touch the xture during operation as it may be hot.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Pro Light
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This lighting xture is for professional use only - it is not
designed for or suitable for household use. The product
must be installed by a qualied technician in accordance
with local territory regulations. The safety of the installation
is the responsibility of the installer. The xture presents
risks of severe injury or death due to re hazards, electric
shock and falls.
• Warning! Risk Group 2 LED product according to
EN 62471. Do not view the light output with optical
instruments or any device that may concentrate the beam.
• WARRANTY: Two years from date of purchase.

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 3
Product overview & technical specications
• 100W quad-colour COB LED (RGBW)
• Beam angle: 90° x 105°
• 360 Lux @ 2m (full on)
• 1.2kHz refresh rate
• 16 bit dimming
• DMX channels: 4/7/12 selectable
• Stand alone operation including manual RGBW colour mix,
64 preset colour macros and 9 programs
• 0 - 100% 16 bit dimming and variable strobe
• 4 dimming curves with two dimming response times:
Linear, square law, inverse square law and S-curve
• Bracket allows for multiple rigging
or oor standing applications
• 4 push button menu with OLED display
• PowerCON input/output
• 5-Pin XLR input/output
• Eight leaf barn doors with integral gel frame
• Temperature controlled fan
CYC100 RGBW 100W COB Cyclorama Wash
Specications CYC100 RGBW
Power consumption 105W
Fuse T2A 250V
Power supply 100~240V, 50/60Hz
Dimensions 315 x 270 x 281mm
Weight 4.3kg
Order code ELUM123 0m 1m 2m 3m 4m 5m
90° x 105° - Lux
FULL ON
R
G
B
W
1140
236
309
75.6
464
360
65.9
77.4
18.9
116
160
29.2
34.4
8.4
51.5
90° x 105°
90
16.4
19.3
4.7
29
57.6
10.5
12.3
3
18.5
The CYC100 from eLumen8 is a compact, quad colour cyclorama wash light suitable for theatre, stage or studio.
The wide angle, 90° x 105° beam is designed to deliver rich, even tones across large areas while the COB LED
technology ensures a perfect colour mix without any multi coloured shadows.

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 4
Technical specications
32mm160mm
435mm
373mm
170mm 265mm
281mm192mm
270mm
230mm
315mm
149mm
192mm

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 5
Technical specications
01 - OLED display
02 - Function buttons
03 - 5-Pin DMX input
04 - 5-Pin DMX output
05 - PowerCON input
06 - PowerCON output
07 - Fuse T2A 250V
08 - Safety eye
09 - Hanging bracket
10 - Hanging bracket
adjustment knobs
In the box: 1 x xture,
1 x barn door,
1 x power cable
& 1 x user manual
1010
03 04
01
09
02
07 05 06 08

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 6
Installation
Before installing the xture, the supporting structure (ie. truss) must be able to hold a minimum of 10
times the xtures weight without any deformation (eg. 15kg - 150kg point load). The xture must be
secured with a secondary safety attachment when being installed (ie. an appropriate safety cable).
Never stand directly below the xture when mounting, removing, and/or servicing.
Overhead installation requires experience and qualications to calculate working load limits, the
material being used at the installation area and periodic safety inspections of the xture and installation
material. If you do not have the relevant experience and/or qualications please do not attempt the
installation yourself. The installation should be checked annually by a qualied person.
The eLumen8 CYC100 RGBW 100W COB Cyclorama Wash can be operated in a number of mounting
positions as shown in the diagram above, hanging upside-down from the ceiling or truss, mounting
sideways on truss or stood upright on a at level surface. Always use a safety wire as an extra
safety precaution to prevent damage/injury in the event a clamp fails (see the next page for
clamp installation). Never use the carry handles for secondary attachments.

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 7
Operating instructions
Control Panel Menu:
The OLED control panel situated on the front of the xture allows the user to access the menu system to
adjust the xtures settings.
When the unit has been powered on the display will show “CYC100 RGBW Cyclorama”.
The xture will then return to its home screen.
Pressing the “MENU” button once will take the user to the xtures main menu. Using the “UP” and
“DOWN” buttons you can then navigate between the different options in the main menu. Pressing the
“ENTER” button on one of these options allows you to access the sub menu where you can use the “UP”
and “DOWN” buttons to select option/value required. Once the option/value has been selected press
the “ENTER” button once more to conrm the setting.
To exit out of any of the above options, press and hold the “MENU” button.

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 8
Main Menu Sub Menu Options/Values (Default Settings in BOLD) Description
DMX Functions
DMX Address 001-512 DMX Address Setting
Mode
4 Channel
DMX Channel Setting7 Channel
12 Channel
DMX Fail
M/S (Master/Slave)
DMX Fail SettingHold
Blackout
View DMX Value
1. Red
View DMX Value
2. Green
3. Blue
4. White
...
Manual Settings
Mode Auto Auto (Show)/
Manual Mode Setting
Manu Dened
Show Chase Show 0 Co: 1-64 Static Colour Mode
Show 1 - Show 9 Sp: 0-99 Auto (Show) Modes
Fixture Settings
Dimmer Curve
Linear
Dimming Curve Setting
Square Law
Inv SQ Law
S Curve
Dimmer Speed LED Dimming Speed Setting
Halogen
White Balance
Red
White Balance SettingGreen
Blue
Display Settings
Display Inverse No Display Inverse Setting
Yes
Backlight Auto Off No Backlight Setting
Yes
Display Contrast 0-30 (15) Display Brightness Setting
Fixture Test
Auto Test Auto Test
Manual Dened
1. Red 000-255
Manual Mode
2. Green 000-255
3. Blue 000-255
4. White 000-255
5. Dimmer 000-255
6. Strobe 000-255
Fixture Information Fixture Hour xxx Fixture Run Time
Firmware Version CPU-A V x.x B x.x Fixture Firmware Version
Special Functions Factory Settings No Default Factory Settings
Yes
Operating instructions

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 9
Operating instructions
Channel Value Function
4 Channel 7 Channel 12 Channel
1 1 1 000-255 Red dimmer (0-100%)
2 2 2 000-255 Green dimmer (0-100%)
3 3 3 000-255 Blue dimmer (0-100%)
4 4 4 000-255 White dimmer (0-100%)
– – 5
000 Not function
001-004 Colour Macro 1
005-008 Colour Macro 2
009-012 Colour Macro 3
013-016 Colour Macro 4
017-020 Colour Macro 5
021-024 Colour Macro 6
025-028 Colour Macro 7
029-032 Colour Macro 8
033-036 Colour Macro 9
037-040 Colour Macro 10
041-044 Colour Macro 11
045-048 Colour Macro 12
049-052 Colour Macro 13
053-056 Colour Macro 14
057-060 Colour Macro 15
061-064 Colour Macro 16
065-068 Colour Macro 17
069-072 Colour Macro 18
073-076 Colour Macro 19
077-080 Colour Macro 20
081-084 Colour Macro 21
085-088 Colour Macro 22
089-092 Colour Macro 23
093-096 Colour Macro 24
097-100 Colour Macro 25
101-104 Colour Macro 26
105-108 Colour Macro 27
109-112 Colour Macro 28
113-116 Colour Macro 29
117-120 Colour Macro 30
121-124 Colour Macro 31
125-128 Colour Macro 32
129-132 Colour Macro 33
133-136 Colour Macro 34
DMX channel modes:

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 10
Operating instructions
Channel Value Function
4 Channel 7 Channel 12 Channel
– – 5 (cont.)
137-140 Colour Macro 35
141-144 Colour Macro 36
145-148 Colour Macro 37
149-152 Colour Macro 38
153-156 Colour Macro 39
157-160 Colour Macro 40
161-164 Colour Macro 41
165-168 Colour Macro 42
169-172 Colour Macro 43
173-176 Colour Macro 44
177-180 Colour Macro 45
181-184 Colour Macro 46
185-188 Colour Macro 47
189-192 Colour Macro 48
193-196 Colour Macro 49
197-200 Colour Macro 50
201-204 Colour Macro 51
205-208 Colour Macro 52
209-212 Colour Macro 53
213-216 Colour Macro 54
217-220 Colour Macro 55
221-224 Colour Macro 56
225-228 Colour Macro 57
229-232 Colour Macro 58
233-236 Colour Macro 59
237-240 Colour Macro 60
241-244 Colour Macro 61
245-248 Colour Macro 62
249-252 Colour Macro 63
253-255 Colour Macro 64
– 5 6 000-255 Colour Temperature (2800K-7200K)
– 6 7 000-255 Master dimmer (0-100%)
– – 8 000-255 Dimmer ne (0-100%)
DMX channel modes:

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 11
Operating instructions
Channel Value Function
4 Channel 7 Channel 12 Channel
– – 9
000-049 Dimming Curve selected via the xture
050-099 Linear
100-149 Square Law
150-199 Inv SQ Law
200-255 S Curve
– 7 10
000-049 LED off
050-099 LED on
100-149 Strobe (slow-fast)
150-199 LED on
200-249 Random Strobe (slow-fast)
250-255 LED on
– – 11
000-002 No function
003-030 Show 1
031-058 Show 2
059-086 Show 3
087-114 Show 4
115-142 Show 5
143-170 Show 6
171-198 Show 7
199-226 Show 8
227-255 Show 9
– – 12 000-255 Show speed (slow-fast)
DMX channel modes:
Please note: the Show modes will not function without the dimmer channel being greater than 0.
When using Master/Slave mode via the show modes the slave should be set to Show 0.

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 12
Setting the DMX address:
The DMX mode enables the use of a universal DMX controller. Each xture requires a “start address”
from 1- 512. A xture requiring one or more channels for control begins to read the data on the channel
indicated by the start address. For example, a xture that occupies or uses 7 channels of DMX and was
addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104,
105 and 106. Choose a start address so that the channels used do not overlap. E.g. the next unit in
the chain starts at 107.
DMX 512:
DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent
xtures and controllers. A DMX controller sends DMX data instructions form the controller to the xture.
DMX data is sent as serial data that travels from xture to xture via the DATA “IN” and DATA “OUT”
XLR terminals located on all DMX xtures (most controllers only have a data “out” terminal).
DMX linking:
DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the shortest
cable path possible. The order in which xtures are connected in a DMX line does not inuence the
DMX addressing. For example; a xture assigned to a DMX address of 1 may be placed anywhere in
a DMX line, at the beginning, at the end, or anywhere in the middle. When a xture is assigned a
DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit,
no matter where it is located in the DMX chain.
DATA cable (DMX cable) requirements (for DMX operation):
This xture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit.
Your unit requires either a standard 3-pin or 5-pin XLR connector for data input/output,
see images below.
Also remember that DMX cable must be daisy chained and cannot be split.
DMX setup
Further DMX cables can be purchased from all good sound and lighting suppliers or Prolight Concepts dealers.
Please quote: CABL10 – 2m CABL11 – 5m CABL12 – 10m3-Pin:
CABL185 – 2m CABL187 – 5m CABL188 – 10m5-Pin:

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 13
Notice:
Be sure to follow the diagrams below when making your own cables.
Do not connect the cables shield conductor to the ground lug or
allow the shield conductor to come in contact with the XLRs
outer casing. Grounding the shield could cause a short circuit
and erratic behaviour.
Line termination:
When longer runs of cable are used,
you may need to use a terminator on
the last unit to avoid erratic behaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL90,
5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin XLR connectors in to a
3-pin line a cable adaptor must be used. The diagram below details the correct cable conversion.
5-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup
Termination reduces signal
transmission problems and
interference. It is always
advisable to connect a DMX
terminal, (resistance 120
Ohm 1/4W) between pin 2
(DMX-) and pin 3 (DMX+) of
the last xture.
5-Pin
1
2 4
5
3
3-Pin
1 2
3
Pin Conguration
3-Pin 5-Pin
Pin 1 - Ground
Pin 2 - Negative
Pin 3 - Positive
– Pin 4 - N/C
– Pin 5 - N/C
1
2
3
1
2
3
DMX 512
3-Pin XLR output
DMX 512
3-Pin XLR input
GROUND
DMX +
DMX –
DMX 512
5-Pin XLR output
DMX 512
5-Pin XLR input
1
2
45
3
12
4
5
3
GROUND
N/C
DMX –
N/C DMX +
1 ground
3 hot
2 cold
3-Pin XLR male 3-Pin XLR female
2 cold
3 hot
1 ground
2 cold
1 ground 5 N/C
3 hot 4 N/C
5-Pin XLR male 5-Pin XLR female
4 N/C
5 N/C 1 ground
3 hot 2 cold

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 14
Multiple xture power linking
Power linking:
This xture provides power linking via the power output on the rear allowing multiple units to be
connected together. The maximum number of xtures that can be connected is 16 xtures @ 240V
or 8 xtures @ 120V (including the rst xture). After the maximum number of xtures are
connected a new power run will need to be started.
Please note: Caution should be used when power linking other xtures to the CYC100 RGBW 100W COB
Cyclorama Wash as the power consumption of other xtures will vary. Fixtures tted with lamps often
require 2/3 times more current on startup, these may require their own power source.

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 15

www.prolight.co.uk CYC100 RGBW 100W COB Cyclorama Wash
User Manual 16
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government ofce, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
