dibea C200 User manual

D
Corded Vacuum Cleaner
C200
Please read this instruction carefully before using.
Please make sure to keep this instruction properly
so that it can be consulted at any time in the future.
Please use it properly on the basis of full understanding
of this instruction.
Instruction Manual

Introduction
Thank you for buying Dibea brand household cleaning electrical appliances, and wish you
a pleasant use!
Please read this instruction carefully to know how to operate this product safely and correctly,
and obtain the most ideal use effect from it.
This instruction includes the latest information as of the time of printing, and the Dibea
Electrical Co., Ltd. is solely responsible for the revision, interpretation and explanation of
this manual. The Company's strategy is to continuously modify the products, so the Company
reserves the right to change the products without notice after this instruction is printed.
In the process of using, if you have any questions and suggestions about our products, please
call our service hotline: [phone]. We will serve you wholeheartedly!

1
Contents
…………………………………………………………………………………… 1
Safe Operation Guide
…………………………………………………… 2
Electrical appliance description
……………………………… 3
Installation and removal of vacuum cleaner
…………………………………………………………………………… 4
Installation of electric main brush
………………………………………………………………… 4
Installation of extended aluminum tube
……………………………………………………………………… 4
Removal and installation of dust cup
Use of vacuum cleaner
………………………………………………………………………………… 5
Start of vacuum cleaner…………………………………………………………………………………………… 5
…………………………………………………………………………………………………………………… 5
Notes
Product care and maintenance
………………………………………………………………… 6
Cleaning of machine………………………………………………………………………………………………… 6
Replacement or cleaning of filtering HEPA ……………………………………………………………… 7
Disassembly and cleaning of floor brush ………………………………………………………………… 7
Common faults
………………………………………………………………………………………………… 8
Product parameters
……………………………………………………………………………………… 8
Safe operation guide
Please operate the product subject to the basic safety precautions, including
but not limited to the following contents.
Please read all instructions carefully before using the vacuum cleaner:
Power supply
* In the process of using this product, you need to plug in the AC power and press the
machine's power button.
* If any abnormality is found, please do not use this product and contact the after-sales
department of the Company in time for replacement.
* When plugging and unplugging the power cord, please hold the power plug of the charging
base and do not pull or twist the power cord.
Operating precautions
1. Please do not use this product outdoors or in wet places, and do not grasp or grip it with
wet hands.
2. If the machine has been dropped, damaged, placed outdoors or fallen into water, please do
not use and send it to an authorized service center for inspection.
3. Do not put any large objects into the suction port of the vacuum cleaner. Please keep
suction port unblocked; keep the suction port away from ginned cotton, large amount of
hair and anything that may block the suction port.
4. When operating, keep your hair, loose clothes, fingers and all parts of your body away from
suction port and movable parts to avoid being sucked or entangled.
5. Do not deal with burning substances or smoking garbage such as cigarettes, matches or soot.
6. Do not handle flammables or liquids such as gasoline or places where gasoline may be
available, kerosene, paint, alcohol, detergent, etc.
7. Do not operate the vacuum cleaner when the filter device is not installed.
8. Please shut down the machine before connecting or replacing accessories.
9. The vacuum cleaner should be stored indoors and only used in dry rooms.
10. Improper use may harm the motor and the user, please follow the instructions for correct use.
11. Do not use it for any other purposes excluded in the instructions.
12. It is not allowed to be used as a toy. When operating, please pay special attention if there
are children on the side.
13. Please lay special stress on safety when cleaning the stairs.
14. If the vacuum cleaner is damaged, it must be repaired by the manufacturer, its agents
or personnel with equivalent qualifications in order to prevent injury accidents.
15. Please operate the cleaner correctly according to the operating instruction. It is only
applicable to accessories recommended by the manufacturer.
Warnings: In order to reduce possible fire risk, electric shock or injury, please observe the
above rules.

2 3
Electrical appliance description
Handle
Switch button Air outlet
Extension tube lock
Dust cup lock
Dust cup bottom
cover lock
Extension tube
Electric floor brush
Dust cup
Dust cup
HEPA
Cyclone
separator
filter
Installation and removal of vacuum cleaner
1. Installation of electric main floor brush
When you need to connect the electric main ground brush directly to the body for
use (as shown in Figure 1), directly connect the body.
(In disassembly, just press the lock button (as shown in Figure 2) and pull it down)
2. Installation of extended aluminum tube
We can use one end of the extended aluminum tube to connect the machine first
(after hearing the"click" sound during installation, the installation is successful),
and then connect the floor brush or other accessories to theother end of thepipe
(as shown in the Figure), so that it can be used as a vertical vacuum cleaner:
*After connecting the floor brush, it can be used directly to clean the floor or blanket
*After connecting the flat suction, it can be used to clean ceilings, curtains and other
places that are usually difficult to clean, which is very convenient and practical
(In disassembly, just press the lock button of each part in the figure to pull it out)
Hold the lock
（As shown in Figure 1) (As shown in Figure 2）

4 5
3. Removal and installation of dust cup
a. Remove dust cup from the machine body: Press the body locks on both sides of the
dust cup at the same time, and then take it out (as shown in Figure A).
b. Installation of dust cup: Make sure that the bottom of the dust cup is buckled with
the body (please note the direction and position) and then push the dust cup toward
the body. When you hear a "click" sound, it indicates that the dust cup is locked.
Installation and removal of vacuum cleaner
Use of vacuum cleaner
Start of vacuum cleaner
Notes
After everything is properly installed, plug the power cord into the socket, turn on
the start switch at the handle, and the power indicator light is on to start work.
Press the start switch again and the machine stops working. (Button in Figure A)
Please keep away from heaters, such as radiators and cigarette butts.
Figure (A)
Figure (A)
Figure (B）
Press the locks on both
sides of the body at the
same time
Insert the upper end first
Switch button
Click
Use of vacuum cleaner
1. In the use of vacuum cleaner
Please remove large and sharp objects to prevent the machine from being damaged
after collision. Do not suck up flammable materials or liquids, such as gasoline,
cigarettes, alcohol, etc.
If clogging occurs, the floor brush and the telescopic tube have been locked, and the
vacuum cleaner should be turned off immediately. Before turning on the vacuum
cleaner again, please first dispose of the locked dust material.
2. Before the use of vacuum cleaner

6 7
Product care and maintenance
Daily storage
When not using the machine for a long time, please place the machine in a cool and
dry place, and avoid direct sunlight or humid environment.
Cleaning of machine
A. How to pour dust and clean dust cup
1. Please separate the dust cup from the body as shown in (Figure A).
2. Press the lock at the bottom of the dust cup, and the dust will fall out automatically
Under normal circumstances, you only need to operate as shown in (Figure B).
Figure (A)
Figure (A)
Figure (B)
Product care and maintenance
B. Replacement or cleaning of HEPA
1. Take out the filter assembly on the top of dust cup.Use multifunctional cleaning tools
to clean the HEPA after remove it, clean the dust cup and cyclone separator filter in
warm water directly. Before using it again, please make sure that all the filter assemblies
are dry (Replace HEPA with a new one when you find the suction is weakened) (Figure A).
C. Disassembly and cleaning of floor brush
Long-term use, the floor brush and roller brush will be contaminated with hair dust and
need to be cleaned in time.
Pull out the roller brush buckle (the button shown in the figure) at the floor brush, one
end of the roller brush can be taken out, and then the roller brush can be taken out, as
shown in the figure.
Note: Before using the vacuum cleaner, make sure that all filters are installed in the
proper position.

8
Common faults
Product parameters:
Common faults of the machine and solutions:
Serial
No. Phenomenon Cause Solutions
1
The suction power of
the machine becomes
weak or leaks
1. The suction port of the floor
brush is stuck with foreign matters
2. The dust cup is full of too
much dust
3. HEPA filter paper has too much
ash storage and has not been
cleaned or replaced for a long time
4. The roller brush is entangled
with hair-like foreign matters
1. Check the floor brush
and remove foreign matters
2. Clean up the dust cup
3. Clean up or replace with
new HEPA
4. Clean the roller brush
2
No suction after being
connected the power
brush
The vacuum vibrates
violently or the fan is
noisy
The vacuum stops
when working, and be
normal after a while
Motor self-protection because
of overheating Normal
Something stuck in the fan
or the motor is defect Contact us by Email
1. Abnormal floor brush 1. Contact us by Email
2. Metal tube blocked 2. Clean the metal tube
3
4
5
Doesn't work 1.Out of power
2.The fuse blows
1.The power plug is not
in good contact, reconnect
the power plug
2.The main board is broken,
contact us by Email
Item
Rated power
Noise
Boundary dimension
Dust cup capacity
Parameter
500W
80dB
1120*230*230mm
350ml

Address: Buildings 8, 9 and 10, No. 20 Xingnan Road, Wuzhong Economic
Development Zone, Suzhou City
Official website: www.dibea.com
Email address: [email protected]
Suzhou Dibea Electrical Technology Co., Ltd.
