dibea UV-10 User manual

Instruction Manual
Vacuum Cleaner
Read this user manual carefully before first use. Keep this
manual for further guidance in case.
UV-10
Suzhou Dibea Electrical Technology Co.,Ltd.
Providing one-stop household
cleaning solution
EC REP
Wellkang Ltd(www.CE-marking.eu)
16 Castle St, Dover, CT16 1PW, UK
Address: Buliding 8, 9, 10, No.20 Xingnan Road, Wuzhong Economic Development
Zone, Suzhou, Jiangsu, China
Official website: www.dibea.com Email address: [email protected]

Table of ContentsTable of ContentsTable of ContentsTable of Contents
Special Declaration
Safety Instructions
Product Features
Product Components
Preparation before Using
Product Operation
Product Maintanance
Troubleshooting
Product Specification
Special DeclarationSpecial DeclarationSpecial Declaration
Before using this product, please read the safety instruction and follow all those
regular safety instruction and follow all those regular safety precautions.
Dibea will not responsible for any damage caused by self operation or using the
accessories that are not provided from factory. Thanks for your understanding.
Note
This product is used only indoors, do not use it outdoors.
Do not use this product for cleaning construction waste or heavy metal dust.
Do not use this product in wet or moist environment(bathroom for example).
Safety InstructionsSafety InstructionsSafety InstructionsSafety Instructions
Safety Instructions
Do not make this product close to cigarette,lighter,match or any flammables.
Not allowed to be used as children's toys
Placed this product safety when you do not need to use it for a long time.

Safety InstructionsSafety InstructionsSafety InstructionsSafety Instructions
Read this user manual thoroughly and carefully before using the product.
Any operations that oppose to description in this user manual may cause
damage
to human or product.
Power SupplyPower SupplyPower Supply
Plug this product by hand and do not tug or twist power wire.
Do not touch the plug or plug this product when your hands are wet.
Turn off the machine and pull out the plug during transportation or when you
do not
for a long time for a long time.
This product use 220V AC power, do not use other power levels of the
connection
equipment, do not self dismantling.
Using RangeUsing RangeUsing Range
This product is used only indoors, do not use it outdoors.
Do not use this product cleaning clothes, finger, head, hair on the body directly.
This product is electronical item, do not use it in wet or moist environment
(example bathroom, laundry), avoide to electrical fault.
Do not use it in dangerous environment,for example:gas station, chemical plant.
Do not make this product close to cigarette,lighter,match or any flammables.
Do not use this product for cleaning flammable or highly volatile liquid, for
example:
gasoline, kerosene, detergent, alcohol, perfume
Do not use this product for cleaning toner of laser printer, copier, avoide to fire
or explosion.
UV Lamp
This product with UV lamp, do not see the bottom of product when it is working,
avoide UV damage to human body
Do not use UV lamp for cleaning animal.
Do not use UV focus on one place for continuous use, which will damage
cleaning objects.
UV LampUV Lamp
Other
Children, mentally challenged people or lack related exprience and knowledge
are
not allowed to use this product.
Do not sit on top of this product.
Do not make this product close to oven, fireplace, avoide to machine shell get
deformated.
Production FeatureProduction FeatureProduction FeatureProduction FeatureProduction Feature
This product is handhold vacuum cleaner with UV disinfection, adopt advanced
intelligent technology of automatic control UV lamp On/Off, artful design,
power suction,easy operation, safe and reliable.
Feature
Instruction
Vacuum Cleaner
UV disinfection, Mite killing
One-click On/Off
This is product with UV lamp which can effective
clean the mites or bacteria in the mattress
UV lamp automatic On/Off
The UV lamp of this product adopt intelligent
technology, which can automatic induction to
objects in 5cm, then UV lamp will automatic
start working. When UV lamp is far away
cleaning objects UV lamp will automatic
stop working.
Beating
Beating assy whehter working or not by a
On/Off button control. Beating can help to kill
mites and dust thoroughly.

Product ComponentsProduct ComponentsProduct ComponentsProduct Components Product Components
Prepair before UsingPrepair before UsingPrepair before Using
Suction
Infrared sensor
UV Sterilization
Make sure the dust tank is installed properly.
Make sure the Power button is off.
Make sure it is connected with power supply
Label
Wheel
Handle
Air outlet
Suction
On/Off
Dustbin
UV Indicator Light
Dustbin Cover
Main Body
Handle
Dustbin Lock Button
supply cord

Power switch
On/Off
Installing of Main Body and Dustbin
Make sure cut off the power before assembly
or disassembly
Installing: Press the dustbin lock button and
pick up the dustbin.
Uninstalling: The bottom hooks of dustbin plug
into the main body and push in
Installing of Dustbin and Filter
Installing of Main Body and DustbinInstalling of Main Body and DustbinInstalling of Main Body and Dustbin
Installing of Dustbin and FilterInstalling of Dustbin and Filter
Turn left the dust cup and it separates from the cover
Note: the air inlet should be downwards.Note: the air inlet should be downwards.Note: the air inlet should be downwards
Air inlet
transparent dust cup
button
cyclonic filter hepa filter
when install dust bin.when install dust bin.when install dust bin.
Turn right the dust cup and connect with the cover.
Take out the filters: Move along the vertical direction of the dust cup.
Note: Put in the cyclonic filter before hepa filter when installing.
Installing of Rotating brush and Rotating Brush Holder
Rotating brush and rotating brush holder is
assembled together at the factory.
Use a coin rotate 90 degrees along the mark
and take out the holder.
Installing of Rotating brush and Rotating Brush HolderInstalling of Rotating brush and Rotating Brush Holder
Rotating Brush Holder
Rotating Brush
OperationOperation
Connect the supply cord to the sockect, press
the power switch, the vacuum cleaner motor
and the roller brush will start to work. Press the
switch again to stop the machine. Both the roller
brush and the UV light have the safety protec-
tion sensors. They will stop working once the
vacuum cleaner is lift up over 5cm from the
surface.
Note: The UV light will automatically work,
doesn't need any manual operation
Note: When the UV indicator lights turn on, it means the UV light is working
dustbin Hook
main body groove
dustbin
lock button
left
right
