DICE iPod AUX Interface User manual

DICE Auxiliary interface for iPod
Installation Guide/User Manual

Copyrights and Trademarks
Copyright 2008 DICE Electronics, LLC.
The DICE Electronics logo is a trademark of DICE Electronics, LLC.
iPod is a trademark of Apple, Inc.
All rights reserved.
Printed in the U.S.A
3

Table of contents
4
Copyrights and trademarks 3
Table of contents 4
Warning and safety 5
Product registration 6
Charging 8
Integration kit contents 9
Gain adjustment 10
Installation 11
Using the AUX integration 14
Troubleshooting 15
Installation notes 16
Disclaimer and Warranty 18
Supported iPod models 7

5
Warning and safety!
Please read these instructions carefully before proceeding. Failure to follow instructions may result in improper operation
or injury. Neither DICE Electronics, LLC. nor Apple Inc., its regional offices, distributors or resellers take any responsibility for
any damage or injury as a result of using the integrationkit.
- Do not open, disassemble or alter the interface in any way.
- Do not insert anything into the casing.
- Do not cut or try to altercables in any way and always use the correct connections.
- Only operate unit when stationary or ask passengers to operate it for you.
- Do not allow the Apple iPod to distract you from driving.
- Exercise good judgement and keep your eyes on the road at all times.
- Do not expose unit to extreme temperatures, humidity or shock.
- Keep the unit and iPod away from fluids.
- Keep away from children! - Interface components may contain small parts, can be broken or disassembled and
components may become loose from vibration and heat. Small components and packaging materials may be a chocking
hazard when handled by children.

Congratulations on your purchase
Thank you for purchasing the DICE integration kit for iPod. Please review our user manual and installation guide before
operating the unit. This interface was designed and manufactured to seamlessly integrate with your vehicle's factory
entertainment system.
6
In order to validate your warranty period and to receive telephone or online support, you MUST register your DICE
product.
To register your DICE product, please complete the following steps:
1. Visit http://www.diceelectronics.com/register
2. Complete the product registration form.
3. Submit the form.
4. Save the registration/support/warranty sheet in a safe place for future reference.
If you are unable to complete the registration via internet, please call DICE Electronics at 1-888-342-3999.
Product registration

7
FW:3.1.1 FW:1.2.1
FW:1.2.1 FW:1.4.1
FW:1.3.1 FW:1.1.3 FW:1.1.1
FW:1.0.3
FW:1.0.3
Supported iPod models and firmware version requirements
For the latest firmware versions and models not listed, please contact your authorized dealer or DICE Electronics, LLC.
iPod
4th generation
20GB 40GB
iPod
4th generation color display
20GB 30GB 40GB 60GB
iPod classic
80GB 160GB
iPod
5th generation (video)
30GB 60GB 80GB
iPod mini
4GB 6GB
iPod nano
3th generation (video)
4GB 8GB
iPod nano
1st generation
1GB 2GB 4GB
iPod nano
2nd generation (aluminum)
2GB 4GB 8GB
iPod touch
8GB 16GB 32GB

The interface automatically charges the battery of the iPod when
connected and the key is in the ACC/ON position. Charging icon will appear
on the upper right corner
of the iPod screen to
indicate charging.
Charging
8
Most vehicles turn off ACC power when the key is in the OFF position
and the iPod will stop playing and charging. However, in some
vehicles the ACC power is always on and the iPod should be
disconnected to prevent draining the vehicles battery.
Battery icon will appear on
the upper right corner of
the iPod screen to indicate
charging has stopped.
Some vehicles will constantly supply ACC power even when ignition is OFF! The
iPod will continue to charge until disconnected! To prevent battery from draining
or possibly being damaged, iPod MUST be disconnected in these vehicles!

Integration kit contents
1 interface unit
1 auxiliary audio/power cable
1 iPod dock cable
1 User manual
DICE interface for iPod
for AUX
Installation Guide/User Manual
iPod dock cable interface unit
auxiliary audio/power
cable
user manual
9
+12V
REM
GND

Gain adjustment
Increase/decrease
The potentiometers located on the interface unit are used to adjust the gain settings for the iPod and AUX jack to properly
match the radio's input level. We recommend setting the AUX module's output level to match the factory CD or AM/FM
station's sound level.
iPod gain
setting
Interface unit
10
NOTE: Use a small phillips head screw driver or a
plastic pot adjuster tool to adjust the
potentiometers.
mini jack gain
setting

Installation instructions
11
Installation should only be performed by a qualified professional. Beware of sharp edges to avoid injury and exercise
caution when removing trims as they may break. The interface unit should be placed at an accessible location, such as in
the glove box, the center consoleor under the front seat.
1Pull vehicle into service bay.
2Make sure that the radio code is available before disconnecting battery. Disconnect both battery terminals.These cables
must be disconnected during installation to ensure proper initialization of the module when it is connected.
3Pull out the radio by removing surrounding trims and screws to access the radio's auxiliary input connectors. Most
trims can be removed by carefully pulling on the piece or using trim removal tools. Trim is usually held in place by snap-in
clips. Consult your dealership if additional information is needed on removing the radio.

12
4. You can access the factory AUX port located on the back of the radio. Connect the red and white colored AUX audio
connectors into the red and white colored receptacle on the radio. If the factory AUX port already has something
connected, it must be disconnected. Connect the +12 volt, ground and remote wire leads to their proper sources.
+12V
REM
GND
Red wire - "REM" - connect to switched power
Black wire - "GND" - connect to ground
Yellow wire - "+12V" - connect to +12V
connect to interface unit
AUX audio
RCA connectors:
-Red: Right channel
-White: Left channel
Note: some radios will not have RCA inputs and
will require custom installation.

5Connect the AUX audio cable and the iPod docking cable to the interface unit. If an additional audio device will also
be used (mp3, DVD player, etc.) connect its audio cable to the 1/8” mini-jack. Apply cable ties to secure the cables.
power/antenna cable
iPod docking cable
receptacle receptacle
6
T
Verify that all connections have been properly made.
7Reconnect the car's battery. est the unit before seating the cables and reinstalling the panels/trim.
13
iPod
dock input
power
adapter
input
1/8”
mini-jack

14
Using the AUX integration
disc
COMPACT
DIGITALAUDIO
AM
FM
CD
AUX
VOL
PUSHPWR
REW
1
PLAY/PROG
2
FF
3
NR
4
DISC-
5
DISC+
6
H M R
CLOCK TUNE
PUSHMODE
SCAN
RPT
A.SEL
RDM
DISC
SEEK
SKIP
AUX IN
Connect the iPod to the dock cable and select the auxiliary source on the radio. The charging indicator should appear on
the iPod and a selected song will start to play. If an additional audio device is connected through the 1/8”mini-jack, it will
become active when the iPod is disconnected.
MENU
Song Title
Artist Name
Album Name
1 of 12
2:42 -1:16
AUX source selector
NOTE: Some vehicles require the ignition to be in the on position to provide ACC power.
Inthiscasetheinterfaceunitwill not function untilignition is turnedon.
mp3 01

15
Troubleshooting
Problem Solution
No audio from iPod source Reset the iPod.Verify proper connection to iPod/interface.
Cannot select the interfaceusing the radio. Check all connections. With the ignition OFF disconnect
vehicle harness from module for a few seconds and
reconnect.Turn ignition to ACC/ON. Verify that the correct
button is used to accessthe AUX input.
iPod does not charge Check all connections. Reset iPod and make sure iPod
charges while connected to computeror wall charger.
Music is distorted or sound level is too low The output gain for iPod and AUX should be adjusted
using the potentiometers. See pg. 10.
No audio from auxiliary device (1/8”mini jack) Refer to the documentation of the device for the correct
audio ouput settings. Verify proper connection to
device/interface.

16
Installation notes:
Installed by:
Install date:
Other notes:
Illustration:

17
Notes:

18
Disclaimer and warranty
Importantdisclaimer, please read!
A DICE product specialist must determine that defect is present in the product and issue an RMA. Be sure that all wiring is
connected as described in the user manual and all related equipment is functioning properly.
, or visit our support site at
http://www.diceelectronics.com/support.
Unauthorized reproduction or reverse engineering is strictly prohibited! Intellectual property included is distributed under specific license
agreement with respective owners and is licensed only, not sold. No warranty, explicit or implied, is stated. Neither DICE Electronics, LLC., nor
any of its agents, distributors, dealers or vendors shall be liable for damages.
IN NO EVENT SHALL DICE ELECTRONICS' LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE OR ITS
DOCUMENTATION.
Warranty and Support
Products carry a 90 day limited warranty that protects you from defects in material and workmanship of products sold byDICE Electronics, or
its authorized agents, distributors and dealers. a s
e warranty period either DICE Electronics
DICE Electronics
If experience any problems or need help, please contact your local dealer or call 888-342-3999
The warranty period begins the day product is purchased by the end user. Product found to
be defective during th will be repaired or replaced by at no charge unless warranty is void.
Unauthorized attempt of repair or alteration of the product in any way immediately voids this warranty. Warranty does not extend to
cosmetics or finish.
disclaims any liability for
other incurred damages resulting from product defects. Any expenses in the removal and reinstallation of products are not covered by this
warranty.

AUX-iPod
www.diceelectronics.com
AUX-iPod 2008-03
