Digi DI-28SS User manual

-INDICATORDI-28SS-
User Guide
DI-28SS
WEIGHING INDICATOR
Teraoka Seiko Co., Ltd.
< Head office >
13-12 Kugahara 5-chome, Ohta-Ku, Tokyo 146-8580 Japan
TEL: [phone],FAX: [phone]
< Ohsaki office >
2-3-13 Ohsaki, Shinagawa-Ku, Tokyo 141-8566 Japan
TEL: [phone],FAX: [phone]
http://www.digisystem.com
email:[email protected]

-INDICATORDI-28SS-
Contents
Overview………………………………………………………………………………3
Features ………………………………………………….…..…… 3
Description of display ……………………………………………..……… 4
Key switch function ………………………………………………………………5
Function setting ……………………..…………………………………………6
Error Messages ……………………………………………… 7
Operation Mode …………………………………………………………………8
Guarantee…………………………………………..…………………………………8

-INDICATORDI-28SS-
Overview
DI-28SS is a microprocessor chip good for all kinds of weighing application for Bench
Scale , Floor Scale and Platform Scale . It is very high accuracy and use re-charge
battery operate up to 120hrs . It is a new design for weighing indicator with build–in
series output RS-232c.
Features :
1. Accuracy class：C-III.
2. A/D conversion speed：20 times/second.
3. Internal resolution 1/ 300,000.
4. Display resolution ：1/1000～1/30,000 division.
5. Non linearity：＜0.016％F.S.
6. Rated Output：0~20mV.
7. Excitation Voltage：＋DC5V，Analog (up to 4 x 350Ωload cell) .
8. Power supply：DC6V/4Ah re-charge battery or AC230V power supply.
9. Display：6 digits LED display and height 25mm LED.
10.LED indicate ：G.W., N.W., tare, zero, ct, oz, lb, kg.
11.Power consumption：1W.
12.Operating temperature：0 ~ 40 .
13.Humidity：≤85％.
14.Dimension：230mm × 145mm × 98mm.
15.Weight：1.5 kg.

-INDICATORDI-28SS-
Front view Diagram
WEIGHT
ct
oz DI-28SS
lb
kg
▽▽▽▽▽▽
BAT STB GROSS NET TARE ZERO
I T 0 M
Diagram 2 DI-28SS Front-Panel diagram
Description of display
LED Name Description
BAT Low Battery
sign
Battery Voltage is low
STB Stable sign Display show weight is stable
GROSS Gross
Weighing
Display the gross weight .
NET Net Weighing Display value show net weight after deduct
the container from the platter.
TARE Tare weighing Tare weight is after deduct container weight
ZERO Zero Display weight is zero
Kg Unit kg Displayed weight is in Kilogram (Kg).
Lb Unit lb Displayed weight is in Pounds (lb).
Oz Unit oz Displayed weight is in Ounce (Oz).
Ct Unit ct Displayed weight is in Carat (Ct).
Negative Negative
Weight
Display weight is ( - ) negative
Charge Charged
Battery
1. When turn to Red LED show battery is
LOW .
2. When turn to Green LED show battery is
full .
HI Over Limit The weight is over the preset value.
OK Pass Limit The weight is between Hi & Lo preset value.
LO Low limit The weight is under the preset value.

-INDICATORDI-28SS-
Switch bottom function :
1. 【I】：Switches Power On / Off.
i. Press【I】once, the display show a self-test and come to Zero on
the screen. Each LED will display 0 to 9 in sequence during the
self-test.
ii. Press and hold【I 】for 3.0 second, the display will shut down
automatically.
2. 【T】：Place the container on the platter .Press 【T 】,the weight
of the container will be subtracted and “ NET “ & “ 0 “ will appear .
3. 【O 】：Re-zero the weight and display show zero.
4. 【M】：Press【M】to choose the unit weight and display will show :
Kg, lb, oz and ct.
5. 【】：Press 【】the display shown number of times weighed
in “ n x x ” and after to print out accumulated total.
i. To clear or reset the accumulated total , press【O】once.
【】：Press 【】to print current weight and the weight will be
added to the accumulated total.
ii. To clear or reset the accumulated totals, press 【O 】.
Print format:
When printing , pressing 【】each time will print out the current sequence of the
current weight. Upon pressing 【】the accumulated total will be print out.
Example : print out format is as follow: -
№weight
1 1.200 kg
2 2.300 kg
3 3.400 kg
4 4.500 kg
5 5.500 kg
Add 16.90 kg

-INDICATORDI-28SS-
Function Setting :
Put the Cal JP "OFF" position ( Short jumper off ) :
1. Press【T 】1.5 seconds, the display show " OFF × × ", mean is auto power off
function : 3 minute - 30 minute and 0 (always ON) . Press【】to choose 3,10,15
and 30, for automatically power off .
2. Press【M 】the display show : " bp On " or " bp OFF " . Press 【】
to choose On or OFF for buzzer sound or not sound.
3. Press 【M 】the display show : " L XX. X " . Press【】【 】, to select
a new value for weight under the limit ( LO ).
4. Press 【M 】the display show " 0 XX. X " . Press【】【 】, to select a
new value for weight between the HI & LO limit ( OK ).
5. Press 【M】the display show "H XX. X " . Press【】【 】, to select
a new value for weight over the limit ( HI ).
6. Press 【M】the display show "08.09.10 ". Mean is year / month / day.
08 = year , 09 = month , 10 = day . Press【】【 】, to select the value.
7. Press 【M】the display show "12.34.56 ". Mean is hour / minute / second.
12 = hours , 34 = minutes , 56 = second. Press【】【 】, to select the value.
8. Press【M 】return to normal display weight.
Error Messages :
Display Possible Cause Solution
Press "POWER" no
display.
The 230V/AC power supply not
working or Re-chargeable
battery no voltage.
Check the power supply or
battery and power switch.
One section of LED
display no light
The LED display is not good in
condition
To replace LED display
The display reading
not stable To check the platform structure To open the platform
structure and clean the
structure
The scale can not do
calibration.
To check the calibration jumper
( put to ‘ON’ position ) To open casing and place the
Cal jumper ON position
The scale is not
accurate
The Load Cell is not good in
condition
To replace the new Load Cell

-INDICATORDI-28SS-
Operation Mode
Open the casing , switch the jumper ( JP1 ) to “ OFF ” position.
The functions will be as follow : -
Guarantee
This weighing instrument is under one year warranty from date of customer
purchase the scale. If the scale have problem and please send the scale to our
company service department .
Press “ T”
and hold for
1.5 seconds CAL
Press MOFF
Press MBP
Press M LO
Press MO.K
Press MHi
Press M Exit
