05
1. mportant nstructionsI i
You can see, below, the symbols that will appear in this manual,
signaling important moments. It is essential to pay attention to them.
TIP: Indicates something Digicon considers important.
CAUTION: Indicates a moment of extreme caution when
handling the equipment/product
ATTENTION: Indicates a moment when your observation
skills should be extremely productive.
INFORMATION: Presents interesting facts about the
purchased product.
QR CODE: Presents additional information or links
with more details about the presented text.

2. Orientations
Read the information and instructions of this manual carefully, before using the
product. This ensures the correct use of the equipment and maximum use of its
technical features as well as a prolonged service life.
This product does not present sealing against the rain, that is, it is designed to be
used indoors.
Keep this manual for future consultations.
Digicon reserves its right to alter its products at any moment to adapt them to more
recent technical advancements.
Digicon maintains its right to alter the information contained in this manual without
previous notice.
Digicon does not provide any contractual warranty concerning the information in this
manual, and cannot be held responsible for errors it may contain and problems due
to its use.
The information contained in this manual is exclusive property of Digicon and is
protected by copyright laws.
This manual cannot be reproduced, photocopied or translated, in its entirety or in
part, into any kind of medium, without Digicon's written consent.
3. Introduction
Following a new technological concept focused on solidity and reliability and counting
with innovative design elements, with color variety and widely curved lines, Digicon has
launched the line .CATRAX Automatic Clip
CATRAX Automatic Clip serves most technologies of access control currently
available, becoming the best option in the market for access control.
This manual presents a detailed description of the components and working of
CATRAX Automatic Clip. To see our complete catalogue, visit www.digicon.com.br.
06

4. Features of Catrax Automatic Clip
07
CATRAX Automatic Clip,an access controller in the model mini turnstile (column
type), destined to individuals with special needs, presents one arm with brushed
stainless steel (AISI 304) finishing and two-directional mechanism, with horizontal
movement. The column can present external finishing in brushed stainless steel (AISI
304) or 1020 carbon steel with electrostatic painting in black epoxy powder. It has
reinforced structure, fully rounded corners, and non-exposed screws, offering space
and comfort for any access control solution. It also has room for a collecting box
(optional item). Aiming at facilitating assembly and maintenance, the column
CATRAX presents a U-shaped internal support (mounting rack) withAutomatic Clip
standard holes for the fixation of additional electronic boards. Moreover, the clients,
according to their needs, can add additional holes. Access to the mounting rack is
done through a key with secret, and the removal and insertion are done through the
frontal door.
A plastic cover and a stainless steel sheet compose the upper panel. The cover, made
of injected plastic, can be purchased in stainless steel or black (other colors available
on demand). Optionally, the cover can present a slot for the reading of magnetic
cards/badges and barcodes. The upper cover in stainless steel allows easy
configuration and low-cost customization of the product. The sheet can also present
slots for optional items, such as pictogram, collecting box input, display kit, or a
combination of these items.

TIP: CATRAX AutomaticTo see details about the dimensions of
Clip's items, see item 8. Technical characteristics.
4.1 Catrax Automatic Clip operation
CATRAX Automatic Clip has a two-dimensional rotation system with two 24 V cd
electromagnets for activating the locks.
It includes a microprocessor control board where a signal enabling passage is sent
through one of the inputs, depending on the passage direction. If this signal is
recognized, the equipment will allow the movement of the arm of CATRAX Automatic
Clip. After half of the turning is complete (45 degrees), a 400 milliseconds returning
signal will be sent, informing the passage direction. After the signal, the arm cannot be
returned to the previous position.
Depending on the model and configuration, if the passage isCATRAX Automatic Clip
forced without the enabling signal, an electromagnet will be activated to prevent
passage. In addition, the equipment can emit a signal for a sound alarm and/or the
exhibition of a red sign on the upper panel display (models with pictogram). In this
case, a return signal will be sent, indicating that the turnstile was forced, informing the
direction of turn.
The image below shows how mechanism works:CATRAX Automatic Clip's
08

5. Installation/Assembly
5.1 Unboxing
As the items inside the package can vary (depending on the client's requests), it is
important to perform a cautious visual inspection before installing and assembling the
turnstile. A checklist that works as a guide during inspection accompanies all Digicon
packages.
See below the parts that can compose CATRAX Automatic Clip.
09
Arm
Front cover
Rear cover
Lock for accessing the column's interior
Pictogram
(optional)
Rotary axis
Lock for accessing
the mechanism
Cables passage
Column

5.2 Floor drilling and column fixation
Before installing , check:CATRAX Automatic Clip
1. The place chosen for the installation.
2. If there is a power source or electric socket nearby (ducts for connection).
3. If the place chosen is adequate for the installation of the access controller (indoors).
4. If there will be enough space (minimum 5 cm) between the rear of the CATRAX C
Automatic Clip lip column and the wall. This space is important in order to provide
access to the upper panel and plug's locks for the cables passage.
5. If there will be enough space for the arms after CATRAX Automatic Clip is assembled.
6. If the floor is in conditions to receive anchor bolts (minimum of 4 cm of FCK15 M.P.A.
concrete or equivalent).
ATTENTION: To see details on the dimensions of CATRAX Automatic Clip,
see item 8 (technical characteristics).
10
To fix the column to the floor, observe the following steps and the indicated images:
1. rill the floor with 3/8” drills (then use a 12mm or the ½” drill). Make four externalD
holes, according to the measures indicated in the image below:
2. Clean the holes, removing any debris from drilling.
3. Place the external part of the bolts in the holes. Leave about 25mm of the bolt out of
the hole.
4. Position the column and fasten it to the floor with the four screws that accompany
the bolts. Use a flex-head socket wrench with ¾'' or an articulated socket wrench.
12,5 (4x)
210
170
60
45
Saída de cabos
92,5
32
20
Fixing drilling
30
90
TIP: We recommend the bolts by the brand Tecnart, model AF38110, 3/8x4''.

5.3 Assembling the arms
INFORMATION: The cover to access the screws is open/closed by
pressure (fitting). To assemble the CATRAX Automatic Clip's arms, use
an Allen n.5 wrench.
11
After drilling the floor and assembling the column, it is possible to assemble the arms
and plastic covers.
The sequence below shows the instructions to help assembling CATRAX Clip's arms.
Digicon suggests that two people assemble the arms.
1. With already unboxed and installed, set the arms close toCATRAX Automatic Clip
the tube's frontal holes (central axis). First, fit the arm's lower rod and press the upper
rod so it reaches the respective hole.
2. Once the arm has both rods duly fitted, turn the arm to one side up to about 180
degrees or until it reaches the end of its track. You will notice there are two holes on the
back of the tube.
3. Use an Allen n.5 wrench to fasten the arms to the holes using the bolts and washers
provided with the product.
1º) 2º) 3º) 4º)

5.4 Accessing Catrax Automatic Clip after assembly
After is installed and assembled, access to the interior of theCATRAX Automatic Clip
equipment can be done with the key that accompanies the equipment, in two ways:
- Rear cover and frontal cover: open the lock with the key at the rear of CATRAX
Automatic Clip CATRAX Automatic Clip.; unscrew the screws at the front of
- Column door: Open the lock with the key and pull the door.
As shown below:
12

5.5 Connection to power network
The Turnstile is powered by a 24 V c supply (located inside the turnstile). The powerd
supply can be of 100 to 240 V . Digicon recommends the regulation NBR 5410 asac
reference to the equipment's electrical connections. In one of its columns, the turnstile
has circuit breakers in its columns where the power cables (electrical supply) and the
ground wire must be connected.
CAUTION: Electric connections must be performed by qualified
professionals.
13
Aterramento
Rede elétrica
TIP: We recommend that you use a good quality AC cable and ground
wire and with compatible dimensions to the distance until the
switchboard. The data cable must be type CAT5E. Recommended
manufactures: FURUKAWA and AMP.
Entrada para
cabo de dados

6. Installing/assembling optional items
CATRAX Automatic Clip is compatible with most access control technologies in the
market today; however, Digicon offers a range of optional items that allow enhancing
and matching the equipment's performance to the client's needs. See the description
of each of these items:
The collecting box kit has a device for collecting, retaining, and gathering cards or
badges. It is ideal for places with eventual visitors or users. The kit is composed of a
socket, a retention device activated by a solenoid, and a storage box. The image below
shows the items that accompany the collecting box kit and may work as a guide for its
assembling:
14
6.1 Collecting box kit

6.1.1 Connecting collector kit to control board
12 11 10 98765432112 11 10 987654321
BOX SENSOR ELECTROMAGNETS TURNSTILE SENSORS
DIGICON CONTROL BOARD
INPUTS CN8 OUTPUTS CN9
- SOLENOID
+ SOLENOID
SOLENOID
Seu leitor de cartão
(não faz parte do kit)
Para placa
controle de acesso
Sensor utilizado para
recolher o cartão após
1,5 segundos
TIP: To obtain information about the collecting box kit's configuration,
consult item 6.5 Control board.
15
Sensor used for collecting
the card after 1.5 seconds
To the access control board
Your card reader
(not included in the kit)
INFORMATION:
- The box for cards is part of the kit and is positioned under the
collecting kit.
- The badge reader is not part of the kit.

16
6.2 Operational pictogram kit
The operational pictogram kit visually signals if the passage is cleared or not (through
green and red pictograms) on CATRAX Automatic Clip's front.
Passage
cleared
(green)
Passage
blocked
(red)
TIP: To obtain information on the configuration of the pictogram, see item
6.5 Control board.

17
6.3 Power supply
Among the main advantages of this optional item, is its adaptation capability to the
voltage variations often found in installation sites – the input voltage can vary between
100 and 240 V .ac
The supply's specific technical features, protections and dimensions were carefully
tested and approved in hostile temperature and environmental conditions, which
ensures the adequate power supply to the equipment's performance. Besides the
input and output voltages indicated in the image below, the supply has a short-circuit
and overheating protection.
PHASE
NEUTRAL
GROUND WIRE
GND
24V / 3Adc
INPUT:
100 a 240 Vac
OUTPUT
6.4 Electromechanical counter kit
The counter kit presents six digits, from no return to zero, and is located on the bowl's
upper part of the turnstile.
The counter presents pulse input, making it possible to detect turnstile rotations in a
given direction. The device is also capable of counting single pulses (as other counters
available on the market).
Technical characteristics:
Power supply: 24 V cd
Number of digits: 06 (no return to zero)
Digits size: 5 x 2 mm (height x width)

6.5 Control Board
CATRAX Automatic Clip's control board was designed to meet most technologies of
access control terminals in the market. The controller have mechanical features and
layout perfectly suited for the CATRAX Automatic Clip's needs and it is one of the best
options for the equipment's operation.
The following images show the control board with its straps, connectors, and dipswitch,
as well as the location of the power supply and the control board in CATRAX Automatic
Clip.
CONNECTOR
CN8
CONNECTOR
CN9
Ds1
Ds2
The table below describes the functions of the control board's connectors:
18

19
Signal Nome/Description
CN1 BOX SENSOR
1 LED anode
2 Box Signal
3 GND
4 GND
CN2 JTAG – Inner use
CN3 SERIAL RS - 232
2 TX
3 RX
5 GND
CN4 ENGINE
1 DATE +
2 DATE -
3 GND_485
4 (+) 24V_EXT
5 GND
CN5 POWER – POWER SUPPLY
1 (+) 24V cd
2 GND
3 (+) 24V cd
CN6 TURNSTILE SENSORS
1 sensor 1 signal
2 LED 1 anode
3 sensor 2 signal
4 GND
5 LED 2 anode
CN7 AUDIO
1 SIGNAL
2 GND
CN8 ENTRADAS
1 (+) vext1 (enables turn through voltage)
2 HAB1 (enables turn through dry contact – from right to left)
3 GND
4 Vext2 (enables turn through voltage)
5 HAB2 (enables turn through dry contact – from left to right)
6 GND
7 +24V c (available to auxiliary – maximum 500 mA)d
8 Vext3 (enables turn through voltage)
9 BQC (activates anti-panic system)
10 GND
11 Output for yellow pictogram
12 NC
13 NO or NC contact (bob return)
14 C Contact (bob return)
15 NO or NC contact (BOC return)
16 contact C (BOC return)

ca
Vca
20
The following sections concern important aspects of CATRAX Automatic Clip control
board configuration and connections of CATRAX Automatic Clip.
6.5.1 Inputs
The input signals or passage clearance (HAB1 and HAB2) or anti-panic (BQC) can be
originated by a relay contact, pushbutton contact, tension from 5 to 24 Vca/cc, from
110 to 220 Vca/cc. To enable passage through relay contact or pushbutton, make the
connection as shown below:
INFORMATION: - The engine (CN4) and electromagnets (CN18) cables
are provided alongside CATRAX Automatic Clip.
CN9 OUTPUTS
1 NO or NC Contact (HAB1 return)
2 Contact C (HAB1 return)
3 NO or NC Contact (HAB2 return)
4 Contact C (HAB2 return)
5 Output for indicative X (open collector NPN – maximum 500 mA)
orange wire
6 Output for arrow > (open collector NPN – maximum 500 mA) blue
wire
7 Output for arrow < (open collector NPN – maximum 500 mA) green
wire
8 +24V c (indicative arrows' power) red wired
9 GND (indicative arrows' power) black wire
10 + solenoid of badge collector box
11 - solenoid of badge collector box
12 Sound signal (open collector – NPN)
CN10 SOL BQC
1 (+) 24V cd
2 SIGNAL
CN14 BQC SENSOR
1 (+) 2 4V cd
2 SIGNAL
CN18 ELECTROMAGNETS
1 (+) electromagnet 1
2 (-) electromagnet 1
3 (+) electromagnet 2
4 (-) electromagnet 2
