ZKTeco MB20-VL User manual

Attach the mounting template sticker to
the wall, and drill holes according to the
mounting paper.
Fix the back plate on the wall using wall
mounting screws.
After passing the wires through the wiring hole and
connecting them to the device, and then attach the
device to the back plate from top to bottom.
Fasten the device to the back plate with
a security screw.
Copyright © 2021 ZKTECO CO., LTD. All rights reserved.
ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China.
Phone: +86 769 - 82109991 Fax: +86 755 - 89602394
ZKTECO CO.,LTD. www.zkteco.com
MB20-VL Installation Guide
1.1m
Baseline
How to install the device?
1 2
34
Version: 1.0

WiringDiagram
1. RecommendedAC adapter: 5V, 2A
2. To share the powerwith other devices, use an AC adapter
withhigher current ratings.
Power Connection
Ethernet Connection
Door Sensor & Exit Button Connection
Lock Relay Connection
Door Sensor
Exit button
GND
+5V
DC12V
DC5V
NC Lock
FR107
Not sharing power with the lock
COM1
NO1
BUT
GND
SEN
NC1
Sensor
Button
Lock
Terminals
Scan the QR Code
and Download
the User Manual,
Installation Guide
and Quick Start Guide
Connect the device and computer software over an Ethernet cable.
Note: In LAN, IP addresses of the server (PC) and the device must be in
the same network segment when connecting to ZKBioAccess IVS software.
Click on [Comm.] > [Ethernet] > [IP Address], input the IP address and
click on [OK].
Default IP address: 192.168.1.201
Subnet mask: 255.255.255.0
IP address: 192.168.1.130
Subnet mask: 255.255.255.0
