digicon dTower User manual

1
11
Produ t Manualc
Tower

2

3
2
Revision
Date
Reviser
History
09
July 2,2019
Anderson Silva
Vinícius Duarte
Gustavo Enedir
Leandro Dandolini
Nicholas Reis
Luisandro Braga
New connection system of electrical panel;
DIP table update;
Software update;
Dimensions;
Preventive Maintenance
10
Setember
18, 2019
Nicholas Hahn
General revision:
Addition of explanatory texts, passage by disk
emulation, and passage by pulse;
Exclusion of energy meter drawing;
DIP table update;
Alteration of pulse time.
11
March 10,
2020
Leandro Dandolini
Vinícius Duarte
Jorge Grass
Layout alteration and removal of non-standard icons;
Alteration of figures to facilitate installation and
fixation of doors;
Alteration of position of some chapters to enhance
task scheduling;
Addition of new figures to facilitate interconnection
between R, T, and RT equipment;
Chapter about cleaning polycarbonate doors;
Preventive maintenance update.
Tower

4
3
Copyright– Digicon S.A.
Controle Eletrônico para Mecânica
All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, translated into any language or computer
language in any electronic, magnetic, optical, chemical, manual way, or otherwise,
without express written permission from Digicon S.A.
Code: 069.31.221
Revision: 11 - English
This manual was elaborated by:Digicon S.A. Controle Eletrônico para Mecânica
Setor de documentação - EDS
After the product's service life ends, dispose of it according to the
National Solid Waste Policy.”
Tower

5
4
Contents
1. ........................................................................................Introduction
2. ...............................................................................Safety instructions
2.1 ..................................................................................Symbols
2.2 .........................................................................Installation site
2.3 ................................................General maintenance precautions
3. ..........................................................................................Guidelines
4. .......................................................................................Walkthrough
5. Características do dTower .....................................................................
5.1 Pictogramas do dTower ..............................................................
6. ..................................................................................dTower Features
6.1 .................................................................................Unboxing
6.2 ..........................................................................Pre-installation
6.3 ....................................................................Fixation to the floor
6.4 ......................................................................Fixation of doors
6.4.1 ..........................................................................Labels
6.5 ................................................Accessing dTower after assembly
7. ............................................................................Electrical connection
7.1 .........................................................Equipment interconnection
7.2 ...................................................
Connection between blockages
7.3 .........................................................Connection of control signs
7.4 ......................................................................dTower operation
7.4.1 ............................................................Controller board
7.4.2 .....................................................................Functions
7.4.2.1 ........................
Configurable functions (via input)
7.4.2.2 ..........................Configurable functions (via Ds1)
7.4.2.3 ..........................Configurable functions (via Ds2)
8. .......................................................................Technical characteristics
8.1 ..............................................................................Dimensions
8.2 ......................................................................Other information
9. ..................................................................................
Trouble shooting
10. ......................................................................Preventive Maintenance
11. ...........................................................................................Cleaning
11.1 ..........................Maintenance and preservation of stainless steel
11.2 ..........................Maintenance and preservation of polycarbonate
12. .......................................................Warranty and technical assistance
Notes ....................................................................................................
06
07
07
08
09
10
10
11
12
13
13
13
15
18
19
20
21
21
23
24
28
28
28
31
32
34
36
36
37
38
41
43
43
44
45
46
Tower

6
1. Introduction
Read this manual carefully because it contains important information that will help you
understand the processes of installation, operations, maintenance, and unboxing.
Correct installation and maintenance ensure equipment operation and increase the
useful life of its components.
Correct equipment installation and operation guarantee proper functioning according
to Digicon specifications.
Tower

7
You may find this symbol in the product manual. It indicates important
instructions concerning operation or maintenance.
You may find this symbol attached to the product. It indicates a powered
terminal where dangerous voltage may be present.
You may find this symbol attached to the product. It indicates a protective
ground wire.
WARNING
To reduce the risk of electric shock, follow the guidelines included in the
installation and operation instructions. Leave all maintenance services to
qualified technical professionals.
WARNING
To reduce the risk of electric shock, before maintenance, turn off the power of
the equipment by moving the circuit breaker key to the position OFF. Leave all
maintenance services to qualified technical professionals.
2. Safety Instructions
2.1 Symbols
Read and keep the instructions: Carefully read the safety and operation
instructions before using this equipment and keep them for future reference.
Carefully follow instructions and warnings: Follow the instructions of operation
and use. Pay attention to warnings and cautions present in the operation instructions as
well as those affixed to the equipment.
Terminology: the terms defined below are used in this document. The
definitions are based on those found in safety regulations
Technical professional – the term technical professional applies to trained or qualified
people who have permission to install or replace technical equipment or to offer technical
support. It is recommended that the technical professional use his experience and
technical abilities to avoid possible injuries regarding himself and others due to the risks in
areas of restricted access.
User and operator – the terms user and operator apply to people who are not technical
professionals.
Risk of electrical shock.
This equipment meets the applicable safety standards.
Tower

8
Electric shock can cause personal injuries or even death. Avoid direct contact with
dangerous voltages at all times. The protective grounding connection, when offered,
is essential for a safe operation and must be checked before connecting the
equipment to the power grid.
Know the following warnings and safety guidelines:
Dangerous voltages
·Only qualified technical professionals can install or replace the equipment.
·Only qualified technical professionals can remove equipment doors and
access any components, except for the card-collecting box and the circuit
breaker.
·Before performing any maintenance, turn off the power of the equipment by
moving the circuit breaker key to the position OFF
Grounding
·Do not violate the protective grounding by using an extension cable, a
feeding cable, or an autotransformer without protective earth conductor.
·Be careful to maintain the protective grounding of this equipment during
maintenance or repair and to reestablish the protective grounding before
putting the equipment in operation again.
2 2. Installation site
When selecting the installation site, meet the following standards:
Protective grounding - The protective grounding of the building's electrical
installation must meet national and local regulations.
Environmental conditions – The installation site must be dry, clean, and ventilated.
Do not use this equipment where it can get in contact with water. Make sure that this
equipment is operational in an environment that meets the requirements established
in the equipment's technical specifications found in this manual.
Installation requirements
Overload of electrical network
Know the effects of overload before connecting this equipment to the electrical network.
An easily accessible shutdown device must be installed on the external of the equipment
or set of equipment.
WARNING
Only allow qualified personnel to install this equipment. The installation
must be in accordance with all local standards and regulations.
CAUTION
Consider the connection of this equipment to the electrical network and
the effect that an overload can have on the overcurrent protection and
the electrical wiring. Check the consumption information in this manual.
Tower

9
2.3 General maintenance precautions
Be aware of the following general precautions and guidelines:
Maintenance – Maintenance is necessary when this equipment is damaged in
any way, such as damaged feeding cable or plug; liquid has been spilled or
objects fell onto this equipment; this equipment was exposed to rain or
humidity; this equipment is not working properly or suffered a fall. Before
maintenance, turn off the power of the equipment by moving the circuit
breaker key to the position OFF. Leave all maintenance services to qualified
technical professionals.
Wristwatch and jewelry – to ensure personal safety and to avoid amages to
this equipment, do not wear electrically conductive objects during
aintenance, such as wristwatches or jewelry.
Atmospheric discharges – Do not work on the equipment neither connect
nor disconnect cables during periods of atmospheric discharges
Labels – Do not remove warning labels. Replace any labels that are damaged or
illegible by new ones.
Doors – Do not open the doors of this equipment to perform maintenance
unless the product manual requires so. Leave all maintenance services to
qualified technical professionals.
Humidity – Do not allow humidity to enter this equipment.
Safety checks – After performing maintenance, assemble the equipment and
perform safety checks to ensure safe use before operation.
Electrostatic discharge
The electrostatic discharge (ESD) results from the accumulation of static electricity in
the human body and other objects. This electric discharge can degrade components
and cause failures.
WARNING
Avoid electric shock! Opening or removing the doors of this equipment
can expose it to dangerous voltages.
WARNING
To reduce the risk of electric shock, before maintenance, turn off the
power of the equipment by moving the circuit breaker key to the position
OFF. Leave all maintenance services to qualified technical professionals.
CAUTION
These maintenance precautions are only guidelines to qualified technical
professionals. To reduce the risk of electric shock, do not perform any
maintenance not specified in the operation instructions, unless you are
qualified to do so. Leave all maintenance services to qualified technical
professionals.
Tower

10
3.Guidelines
Read the information carefully before using the product. This ensures the correct
use of the equipment and maximum use of its technical features as well as
prolonged service life.
This product does not present sealing against rain, that is, it is designed to be used
indoors.
Keep this manual for future consultations.
This product has moving parts that expose the user to injuries if safety and
operation instructions are not observed.
For safety reasons, children near the unit, and during passage through the
equipment, should always be under adult supervision.
Digicon recommends using the maximum-security level whenever children use the
equipment.
Digicon reserves its right to alter its products at any moment to adapt them to more
recent technological advancements.
Digicon maintains its right to alter the information contained in this manual without
previous notice.
Digicon does not provide any contractual warranty concerning the information in
this manual and cannot be held responsible for errors it may contain and problems
due to its use.
The information contained in this manual is exclusive property of Digicon and is
protected by copyright laws.
This manual cannot be reproduced, photocopied or translated, in its entirety or in
part, into any kind of medium, without Digicon's written consent.
The equipment described here is customizable, that is, this manual describes all
possible models and they may not reflect, necessarily, the model purchased by the
customer.
4. Walkthrough
Blockage line especially developed for access control solutions that operate in small
spaces. Using the comfort and safety of swing gate doors, the line offersdTower
maximum flexibility with minimum use of space.
Tower
Take the following precautions against electrostatic discharge:
Maintain the components in their antistatic packages until installation.
Avoid touching the electronic components when installing a module or board.

11
5.dTower features
_Innovative design, alongside the dGate and dFlow lines;
_Robust solution, with motorized system and control with proprietary technology;
_Reinforced structure for fixing it to the ground;
_Available in stainless steel and carbon steel painted in powdered epoxy;
_Available with doors in 12mm polymer;
_Customizable door movement speed;
_Offers operational pictogram (top) –clear/blocked access;
_Offers orientation pictograms (front) for both directions;
_Offers sound signal (beep) for customizable access control;
_Doors with bidirectional movement;
_Inputs for activation sensors that open or close the doors;
_Optional card collecting box;
_Allows installation of proximity reader on the edges;
_Available with optional 2D barcode reader;
_Easy integration with access controllers available in the market;
_Easy integration between blockages “R”and “T”;
_Customizable modes for controlling passage time;
_Customizable safety mode.
Orientation
pictograma:
and
Operational
pictogram
Swing Gate
Upper
cover
Upper cover lock
dTower R
Identification
tab (per color)
Access door
dTower T
Tower

12
5.1 dTower pictograms
O has two pictograms: direction and operation.dTower
A) Operational pictogram (top):
The operational pictogram is installed on the upper part of the equipment and is
represented by a sequence of LED lights in two colors, depending on the direction of the
operational flow and validation group, if it exists.
LED lights flashing red or flowing only in the opposite direction represent passage not
cleared.
LED lights flashing green indicating the direction of passage represent passage
cleared.
B) Orientation pictogram (front):
The orientation pictogram is installed on the edges of the equipment and is represented
by a green arrow or red .< x
The red pictogram informs the user that is not operating in the indicateddTower
direction or that passage is not allowed, or even that it is busy.
The green pictogram informs the user that is free or controlled for passage indTower
the indicated direction.
and
Tower

13
6.Installing and assembling
6.1 Unboxing
As is customizable, it is important to perform a cautious visual inspectiondTower
before the installing and assembling processes. In case of missing pieces, immediately
contact the Digicon representative responsible for the sale.

Two people are necessary to remove the equipment from the box;
The top flaps of the box can be folded in the middle, facilitating access to the
equipment;
Be careful when removing the equipment from its box not to damage it
6.2 Pre-installation
Before starting installation of , the floor where the equipment will be installeddTower
must be ready. The built-in boxes must be installed before affixing the . There isdTower
an opening underneath the equipment and the built-in boxes must be centered on it.
The floor must be steady and levelled to ensure good performance of the equipment.
NOTE -Measurements are illustrated in millimeters and (inches).
Tower
WARNING
Allow only qualified personnel to install this equipment. The
installation must meet all the local standards and regulations.
Built-in box
51(2,007")
173 (6,811")
36
(1,417")
88
(3,464")

14
The distance between doors depends on their sizes. Doors must be adjusted so to have
a small space between them of about 30mm. Such space is important to ensure that,
even closed, the door will not injure the user.
Built-in Boxes
4"x4"
Conduits with
50 mm diameter
Transmitter
Receiver
Standard direction
for entry
Communication duct
Feeding duct
Tower

15
6.3 Fixation to the floor
The image below indicates the points for fixing the product to the floor.
The surface must be steady and leveled to ensure good performance for the passage-
controlling sensor and to maintain the doors aligned.
Fixing can be done through mechanical bolts, also known as parabolts, or through
chemical anchorage.
For mechanical bolts, minimum floors thickness should be 100mm.
In case of floors with less than 100mm thickness or special floors, use chemical
anchorage.
NOTE – To facilitate tightening the screws, use a long extensor.
NOTE -Measurements are illustrated in millimeters and (inches).
It is very important to check, upon installation, the alignment of the doors in the closed
position. The distance, from top to bottom, must be the same.
- Fixing points
170
(6,692")
93
(3,661")
Ø15 (0,590")
Tower

16
Tower
NOTE -Digicon meets the norm ABNT NBR 9050: Accessibility to buildings,
furniture, space, and urban equipment.
Step-by-step:
1. Use the 12mm (0,47'') drill to drill the hole with depth of 90mm (Threaded bar M10);
2. Clean the hole with an air blower or a vacuum to remove any debris.
3. Place the threaded bar inside the hole and measure the depth. The bar has a mark
that must be leveled with the ground;
4. Place the HVU capsule inside the hole;
5. Attach the threaded bar to the drill and screw it until it reaches the bottom of the hole
or until the mark of the threaded bar is leveled with the ground;
6. Apply the drill until the chemical material rises to the surface;
7. Do not touch the threaded bar until the chemical reaction is over (10min);
8. Curing time according to the table:
Free span for passage:
90°
70
(2,755")
90°
285
(11,220")
Long door Short door
Data according to ETA 05/0255/0256/0257, edition 2010-03-01 / 2006-01-20
Base material temperature
Curing time necessary for the fixing to
receive total load tcure
20°C to 40°C
20min
10°C to 19°C
30min
0°C to 9°C
1h
-5°C to -1°C
5h

17
Tower
NOTE -We recommend using chemical anchorage; however, if you prefer
parabolts, make sure the floor is adequate.

18
Tower
6.4 Fixation of doors
dTower is packaged with the doors unassembled, that is, they accompany the
equipment separately in order to avoid damage.
To install/fixate the doors, follow the step-by-step below:
1º Place the screw (1) only in the upper part, in the fastener hole (2);
2º With the screw inside the fastener hole (2), place it in the door hole (4);
3º With the three parts fitted, fix them to the equipment engine (5);
4º With the upper part fixed, place the screw (3) on the lower part, going through the
fastener (2), the door (6) and the engine (7);
5º With the door suspended, before tightening the screws all the way, align the door;
6º With a torque meter, the recommended torque is 20Nm when tightening the screws
in place.
Door(4)
Screw(6)
Fastener(2)
Screw(3)
Screw(1)
Engine (5)
Engine (7)

19
6.4.1 Labels
Alongside the equipment, there are identification labels for passage, which are blue and
yellow circles:
Blue: Identify passage for people with special needs (PNE), with a passage space of
920mm.
Yellow: Identify passage for people with special needs, with a passage space of 520mm.
NOTE –Using the identification labels for passage is optional.
Identification labels for
pasagem
Tower

20
6.5 Accessing dTower after assembly
After is installed and assembled, access to the interior of the equipment can bedTower
done with the key that accompanies the equipment, in 2 ways:
1º Via upper cover: access to readers, pictograms and engine board;
2º Via access door: access to controller board, connection terminals, AC terminals, circuit
breaker, and power supply.
Lock for opening upper cover
Lock for opening access door
Tower
WARNING
Avoid electric shock! Opening or removing the doors of this
equipment can expose it to dangerous voltages.
WARNING
To reduce the risk of electric shock, before maintenance, turn off
the power of the equipment by moving the circuit breaker key to
the position OFF. Leave all maintenance services to qualified
technical professionals.
