Digital Projection HIGHlite 740 Series User manual

Rev I February 2015
HIGHlite 740 Series
High Brightness Digital Video Projector
4INSTALLATION AND QUICK-START GUIDE
4CONNECTION GUIDE
4OPERATING GUIDE
4REFERENCE GUIDE
114-751I

page i
Digital Projection HIGHlite 740 Series
Rev I February 2015
About This Document
Please follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Keep this manual handy for future reference.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2015 Digital Projection Ltd. All rights reserved.
Notes

page ii
Digital Projection HIGHlite 740 Series
Rev I February 2015
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• Full range of digital and legacy analog inputs
• Control of most aspects of the projector’s operation via LAN and RS232
• Support for a number of aspect ratios and screen sizes
• Non-linear warp adjustment by moving points on an interpolated grid
• Ceiling mount and rear-screen installation options
• Simultaneous display of two sources via Picture-In-Picture
• Long lamp life
• Motorised lens mount
A serial number is located on the back of the projector. Please record it here:
Notes
