Digital Projection INSIGHT 4K Dual LED Series Operating manual

Rev A June 2017
118-533A
INSIGHT Dual Laser 4K Series
Important Information

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 2
Important Information
Digital Projection
Digital Projection Asia
16 New Industrial Road
#02-10 Hudson Technocentre
Singapore 536204
Tel [phone]
Fax [phone]
www.digitalprojectionasia.com
Digital Projection Inc.
55 Chastain Road, Suite 115
Kennesaw, GA 30144, USA
Tel [phone]
Fax [phone]
[email protected]
www.digitalprojection.com
Digital Projection China
中国 北京市 朝阳区 芍药居北里101号
世奥国际中心A座2006室(100029)
Rm A2006
ShaoYaoJu 101 North Lane
Shi Ao International Center
Chaoyang District
Beijing 100029, PR CHINA
Tel [phone]
Fax [phone]
[email protected]
www.dp-china.com.cn
Digital Projection Limited
Greenside Way, Middleton
Manchester M24 1XX, UK
Registered in England No. 2207264
Registered Ofce: as above
Tel [phone]
Fax [phone]
[email protected]
[email protected]
www.digitalprojection.co.uk

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 3
Important Information
Super High Brightness Digital Video Projector
Important Information
Full information about operating, connecting and setting up the projector can be found in the User
Manual, located on the CD.
Updates may be available online - visit the Digital Projection website for all latest documents.
Contents
Symbols used in the User Manual...............................................................................................4
Electrical and physical specications........................................................................................5
Laser precautions.............................................................................................................................5
Product labels....................................................................................................................................6
Label locations ...............................................................................................................................7
Location of laser aperture..............................................................................................................8
Interlock switches ............................................................................................................................8
General precautions ........................................................................................................................9
Installation precautions ................................................................................................................10
Light hazard warning.....................................................................................................................11
Light hazard labels used on the body of the projector ............................................................12
Operation and conguration precautions ...............................................................................13
Compliance with international standards ...............................................................................13
RF Interference.............................................................................................................................13
Noise .............................................................................................................................................13
European Waste Electrical and Electronic Equipment (WEEE) Directive ..............................13
Basic operation instructions.......................................................................................................14
Positioning the screen and projector.........................................................................................14
Connecting the power supply.....................................................................................................15
Switching the projector on..........................................................................................................15
Switching the projector off..........................................................................................................15
Selecting an input signal.............................................................................................................16
Adjusting the lens ........................................................................................................................16
Adjusting the image.....................................................................................................................16
Inserting a new lens.....................................................................................................................17
Replacing the lters.....................................................................................................................18
Remote control reference ............................................................................................................19
Keypad reference...........................................................................................................................20
Keypad indicators ........................................................................................................................22
Laser status lights..........................................................................................................................23

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 4
Important Information
Symbols used in the User Manual
LASER WARNING: this symbol indicates that there is a potential hazard of eye
exposure to laser radiation unless the instructions are closely followed.
LIGHT HAZARD WARNING: this symbol indicates that there is a danger of exposure
to intensive light that may result in personal injury unless the instructions are closely
followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical
shock unless the instructions are closely followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself
and/or damage to the equipment unless the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Specications are subject to change without notice.

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 5
Important Information
Electrical and physical specications
Main Voltage 200-240 VAC 50/60Hz
Operating Temperature 0°C to 35°C (32 F to 95 F)
Storage Temperature -10°C to 50°C (14 F to 122 F)
Operating Humidity 20% to 80% non-condensing
Dimensions: W 72.2 cm (28.4 in), H 47.9 cm (18.9 in), D 100.3 cm (39.5 in)
Weight 100 kg (220 lb) without lens
Power Consumption 4000 W
Thermal Dissipation 13,650 BTU/hr
Laser precautions
CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reected toward other people or
reective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specied herein may result in hazardous radiation exposure.
Laser Parameters:
Wavelength 455nm - 470nm

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 6
Important Information
Product labels
1Manufacturer’s ID label
Includes model name, serial number, manufacturer’s name and address.
Also contains the Certication Statement label and Explanatory label, as well as the Risk
Group 3 label.
2 Certication Statement label and Explanatory label
States that the product is Class 3R and shows laser parameters.
Also shows a Laser Hazard Warning symbol.
3Risk Group 3 label
States that the product is Risk Group 3 according to IEC 62471-5:2015.
Also shows a Light Hazard Warning symbol.
4Hazard Warning Symbol and Aperture label
Caution : Air inlet - Do not block
注意：通风口——请勿堵塞
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED LIGHT
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED LIGHT
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED LIGHT
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED LIGHT
5Protective Housing label
118-790A
IDL
Made in UKGreenside Way, Manchester, UK, M24 1XX
Digital Projection Limited Name of Product : Projector
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) This device may not cause harmful interference. (2) This device must
accept any interference recieved, including interference that may cause undesired operation.
To reduce the risk of re or electric shock, do not expose this equipment to rain or moisture.
Complies with 21 CFR 1040.10
and 1040.11 except for
deviations pursuant to
Laser notice No.50,
Dated June 24, 2007
Laser Radiation
Avoid direct eye exposure
Class 3R Laser product
Wave length : 455-470nm
Max output : 330mW
IEC/EN 60825-1:2007
Rayonnement Laser
Èvitez d’exposer directement les yeux
Produit Laser de classe 3R
Longueur d’onde : 455-470nm
Sortie maximale : 330mW
IEC/EN 60825-1:2007
Risk Group 3
Warning!
Do not look into the beam.
No direct eye exposure to the beam is permitted.
RG3 IEC EN 62471-5:2015
Hazard Distance : Refer to Manual
Groupe de Risque 3
Attention!
Ne pas regarder dans le faisceau.
Pas d'exposition directe des yeux au faisceau est autorisée.
RG3 IEC EN 62471-5:2015
Distance de danger : Se reporter au manuel
WARNING
200-240VAC 50/60Hz 20A
MODEL
Part No.
Serial No.
Power
110-130VAC 50/60Hz 16A
For Oce Use
Isolate mains before removing cover.
1
2
3

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 7
Important Information
Label locations
1Location of Manufacturer’s ID label, including the Certication Statement label and
Explanatory label and the Risk Group 3 label on the projector
2Location of Hazard Warning Symbol and Aperture Label on the body of the projector
3Location of Protective Housing label (under the side cover, only visible once the
cover is removed)
Caution: Airinlet - Do not block
注意：
通风口——请勿堵塞
2
注意：通风口——请勿堵塞
Airexit - Do not block
Caution: Airinlet - Do not block
注意：通风口——请勿堵塞
118-790A
IDL
Madein UKGreensideWay,Manchester, UK, M24 1XX
DigitalProjection Limited Nameof Product : Projector
Thisdevice complies with Part 15 of the FCC Rules. Operationis subject to the following
twoconditions : (1) This device may not cause harmful interference. (2)This device must
acceptany interference recieved, including interference that may cause undesired operation.
Toreduce the risk of re or electric shock, do not expose this equipment to rain or moisture.
Complieswith 21 CFR 1040.10
and1040.11 except for
deviationspursuant to
Lasernotice No.50,
DatedJune 24, 2007
LaserRadiation
Avoiddirect eye exposure
Class3R Laser product
Wavelength : 455-470nm
Maxoutput : 330mW
IEC/EN60825-1:2007
RayonnementLaser
Èvitezd’exposerdirectement les yeux
ProduitLaser de classe 3R
Longueurd’onde: 455-470nm
Sortiemaximale : 330mW
IEC/EN60825-1:2007
RiskGroup 3
Warning!
Donot look into the beam.
Nodirect eye exposure to the beam is permitted.
RG3IEC EN 62471-5:2015
HazardDistance : Refer to Manual
Groupede Risque 3
Attention!
Nepas regarder dans le faisceau.
Pasd'exposition directe des yeux au faisceauest autorisée.
RG3IEC EN 62471-5:2015
Distancede danger : Se reporter au manuel
WARNING
200-240VAC 50/60Hz ??A
MODEL
PartNo.
SerialNo.
Power
110-130VAC 50/60Hz ??A
ForOce Use
Isolatemains before removing cover.
1
Caution: Airinlet - Do not block
注意：通风口——请勿堵塞
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURETO
DIRECT OR SCATTERED LIGHT
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURETO
DIRECT OR SCATTERED LIGHT
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURETO
DIRECT OR SCATTERED LIGHT
M2-S1-00003-170309-39
CAUTION- CLASS 4 LASER LIGHT WHEN OPEN
AVOID EYE OR SKIN EXPOSURETO
DIRECT OR SCATTERED LIGHT
3

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 8
Important Information
Location of laser aperture
The laser aperture is located as indicated below.
1Laser aperture
Interlock switches
Six interlock switches installed at the main frame, inside the cover, will power-off the system
individually when activated.
1Will be activated when the back cover is removed.
2Will be activated when the top cover is removed.
3Will be activated when the right side cover is removed.
4Will be activated when the projection lens is removed.
5Will be activated when the front cover is removed.
6Will be activated when the left side cover is removed.
1
3
4
5
1
2
6

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 9
Important Information
General precautions
The unit is never to be operated if the unit is defective or the cover or seal is damaged.
No maintenance allowed by end user.
Do not open the cabinet. There are no user serviceable parts inside.
No service is allowed except by authorized personnel.
Use only the power cable provided.
Ensure that the power outlet includes a Ground connection, as this equipment MUST be
earthed.
Take care to prevent small objects such as paper or wire from falling into the projector.
If this does happen, switch off immediately, and have the objects removed by
authorised service personnel.
Do not expose the projector to rain or moisture, and do not place any liquids on top of
the projector.
Unplug before cleaning, and use a damp, not wet, cloth.
Do not touch the power plug with wet hands.
Do not touch the power plug during a thunder storm.
Handle the power cable carefully and avoid sharp bends. Do not use a damaged power
cable.
Do not touch the ventilation outlets, as they will become hot in use.
Do not cover or obstruct the ventilation outlets or inlets.
Do not cover the lens whilst the projector is switched on. This could cause a re
Always allow the projector to cool for 5 minutes before disconnecting the power or
moving the projector.
Never use strong detergents or solvents such as alcohol or thinners to clean the
projector and lens.

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 10
Important Information
Installation precautions
Connect the LAN cable only to a computer LAN connection. Other similar connectors
may have a dangerously high voltage source.
The projector must be installed only by suitably qualied personnel, in accordance with
local building codes.
The projector should be installed as close to the power outlet as possible.
The power connection should be easily accessible, so that it can be disconnected in an
emergency.
Ensure that there is at least 50cm (19.7in) of space between the ventilation outlets and
any wall, and 30cm (11.8in) on all other sides.
Do not install the projector close to anything that might be affected by its operational
heat, for instance, polystyrene ceiling tiles, curtains etc.
Place the projector in a dry area away from sources of dust, moisture, steam, smoke,
sunlight or heat.
The projector is heavy. Use safe handling techniques when lifting the projector.
Do not drop or knock the projector.
Before installation, make sure that the surface, ceiling or rigging that is to support the
projector is capable of supporting the combined weight of the projector and lens.
When stacking projectors, the stack MUST be vertical, to ensure that the stresses are
distributed to all four chassis corners.
Do not stack more than 3 projectors.
Do not place heavy objects on top of the projector chassis. Only the chassis stacking
points and the optional grab rail are capable of withstanding the weight of another
projector.
Backup safety chains or wires should always be used with ceiling mount installations.
The projector can be operated in any position. It is recommended to position the
projector in portrait mode with inputs facing upward, as shown in the diagram:
1Recommended positions: inputs side up
2Also possible
Pitch
360° 2
30°
330° 2
1
Roll

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 11
Important Information
Light hazard warning
Failure to comply with the following may result in serious injury:
• No direct exposure to the beam is permitted, RG3 IEC 62471-5:2015.
• Operators control access to the beam within the hazard distance or install the
projector at sufcient height to prevent exposures of spectators’ eyes within the
hazard distance.
The hazard distance (Fig. 1) is the distance measured from the projection lens at which the intensity
or energy per unit of surface is lower than the applicable exposure limit on the cornea or skin. If the
person is within the hazard distance, the beam is considered unsafe for exposure.
The hazard distance for this projector is 12 m.
Fig. 1: hazard distance

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 12
Important Information
Light hazard labels used on the body of the projector
Light hazard labelling is part of the product label.
1Product label
2Risk Group 3 label
3Not For Home Use logo
4Hazard Warning symbol
118-790A
IDL
Made in UKGreenside Way, Manchester, UK, M24 1XX
Digital Projection Limited Name of Product : Projector
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) This device may not cause harmful interference. (2) This device must
accept any interference recieved, including interference that may cause undesired operation.
To reduce the risk of re or electric shock, do not expose this equipment to rain or moisture.
Complies with 21 CFR 1040.10
and 1040.11 except for
deviations pursuant to
Laser notice No.50,
Dated June 24, 2007
Laser Radiation
Avoid direct eye exposure
Class 3R Laser product
Wave length : 455-470nm
Max output : 330mW
IEC/EN 60825-1:2007
Rayonnement Laser
Èvitez d’exposer directement les yeux
Produit Laser de classe 3R
Longueur d’onde : 455-470nm
Sortie maximale : 330mW
IEC/EN 60825-1:2007
Risk Group 3
Warning!
Do not look into the beam.
No direct eye exposure to the beam is permitted.
RG3 IEC EN 62471-5:2015
Hazard Distance : Refer to Manual
Groupe de Risque 3
Attention!
Ne pas regarder dans le faisceau.
Pas d'exposition directe des yeux au faisceau est autorisée.
RG3 IEC EN 62471-5:2015
Distance de danger : Se reporter au manuel
WARNING
200-240VAC 50/60Hz 20A
MODEL
Part No.
Serial No.
Power
110-130VAC 50/60Hz 16A
For Oce Use
Isolate mains before removing cover.
118-790A
IDL
Made in UKGreenside Way, Manchester, UK, M24 1XX
Digital Projection Limited Name of Product : Projector
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) This device may not cause harmful interference. (2) This device must
accept any interference recieved, including interference that may cause undesired operation.
To reduce the risk of re or electric shock, do not expose this equipment to rain or moisture.
Complies with 21 CFR 1040.10
and 1040.11 except for
deviations pursuant to
Laser notice No.50,
Dated June 24, 2007
Laser Radiation
Avoid direct eye exposure
Class 3R Laser product
Wave length : 455-470nm
Max output : 330mW
IEC/EN 60825-1:2007
Rayonnement Laser
Èvitez d’exposer directement les yeux
Produit Laser de classe 3R
Longueur d’onde : 455-470nm
Sortie maximale : 330mW
IEC/EN 60825-1:2007
Risk Group 3
Warning!
Do not look into the beam.
No direct eye exposure to the beam is permitted.
RG3 IEC EN 62471-5:2015
Hazard Distance : Refer to Manual
Groupe de Risque 3
Attention!
Ne pas regarder dans le faisceau.
Pas d'exposition directe des yeux au faisceau est autorisée.
RG3 IEC EN 62471-5:2015
Distance de danger : Se reporter au manuel
WARNING
200-240VAC 50/60Hz 20A
MODEL
Part No.
Serial No.
Power
110-130VAC 50/60Hz 16A
For Oce Use
Isolate mains before removing cover.
1 3
4
2

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 13
Important Information
Operation and conguration precautions
Do not make changes to the networking conguration unless you understand what you
are doing, or have taken advice from your Network Manager. If you make a mistake,
it is possible that you will lose contact with the projector. Always double-check your
settings before pressing the APPLY button. Always keep a written note of the original
settings, and any changes you have made.
Software update should NOT be carried out except by, or with the supervision of, Digital
Projection Service personnel.
Compliance with international standards
RF Interference
FCC
The Federal Communications Commission does not allow any modications or changes to the unit
EXCEPT those specied by Digital Projection in this manual. Failure to comply with this government
regulation could void your right to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference, in which case the
user will be responsible for correcting any interference.
Noise
GSGV Acoustic Noise Information Ordinance
The sound pressure level is less than 45 dB (A) according to ISO 3744 or ISO 7779.
European Waste Electrical and Electronic Equipment (WEEE) Directive
Digital Projection Ltd is fully committed to minimising Waste Electrical and Electronic
Equipment. Our products are designed with reuse, recycling and recovery of all components
in mind. To this end, at end of life, your projector may be returned to Digital Projection Ltd or
its agent so that the environmental impact can be minimised.

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 14
Important Information
Basic operation instructions
Positioning the screen and projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll
the screen. Set the adjustable feet so that the projector is level, and perpendicular to the screen.
The drawings below shows the feet for table mounting, and the xing holes for ceiling mounting.
Also shown is one of four rings each located in the top corners. These can be used for lifting a single
projector.
Never use the rings for lifting more than one projector.
1Four stacking points
2Four adjustable feet
3Four M10 holes for ceiling mount
The screws should not penetrate more than 18 mm into the body of the projector.
4Stacking point at the top of the projector
5Lifting ring (for handling a single projector)
The rings can be removed to reveal M10 x 18 deep holes for ceiling mounting.
Bottom view of the projector Top corner (detail)
1
2
1
1
1
2
2
2
3
3
3
3
4
5

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 15
Important Information
Connecting the power supply
Firmly push the mains connector into the socket 1, then
press the ON/OFF switch 2.
Use only the power cable provided.
Ensure that the power outlet includes a
ground connection as this equipment MUST be
earthed.
Handle the power cable carefully and avoid
sharp bends. Do not use a damaged power
cable.
Switching the projector on
1. Connect the power cable between the mains supply and the projector. Switch on at the switch
next to the power connector. (See Connecting the power supply above.)
2. Wait until the self-test has completed and the standby indicator on the projector keypad shows
amber. The light source will be off and the projector will be in STANDBY mode.
3. Press ON on the remote control or the control panel and hold for three seconds, to switch the
projector ON. The power indicator on the control panel will show green, the light source will light
and the shutter will open.
Switching the projector off
1. Press OFF on the remote control or the keypad, and hold for three seconds. The power indicator
on the keypad will show amber, the light source will go out and the cooling fans will run for a short
time until the projector enters STANDBY mode.
2. If you need to switch the projector off completely, switch off at the mains power switch next to the
power connector and then disconnect the power cable from the projector.
1
2

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 16
Important Information
Selecting an input signal
The last selected input remains active until a new input is selected. To select a new input:
1. Connect one or more image sources to the projector.
2. Select the input you want to display in one of the following ways:
• Press one of the input buttons on the remote control (1, 2, 3or 4).
• Alternatively, open the On-screen display (OSD) by pressing MENU. Highlight Input from the
main menu, press ENTER/OK and then select an input signal using the UP and DOWN arrow
buttons. Press ENTER/OK to conrm your choice.
• On the keypad, press INPUT + or INPUT - to switch to the next or previous input in the list.
Adjusting the lens
The lens can be adjusted using the lens buttons on the keypad or remote control.
On either device, press FOCUS, ZOOM or SHIFT, then use the arrow keys to adjust the lens.
Adjusting the image
Orientation
• This can be set from the OSD menu.
Choose from Upper Left, Upper Middle, Upper Right, Mid Left, Mid Middle,Mid Right,
Lower Left,Lower Middle and Lower Right.
• Settings such as Gamma, Brightness and Contrast can be set from the Image menu.

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 17
Important Information
Inserting a new lens
Before changing the lens, always make sure the projector is switched off and fully
disconnected from its power supply.
When changing the lens, avoid using excessive force as this may damage the
equipment.
The lens is shipped separately.
Take care to preserve the original lens packaging and protective caps for future use.
The projector will not power on without the lens tted.
Before turning on the projector, please ensure the protective caps are removed from the front
and rear of the lens.
1. Insert the lens into the mount.
Engage the three locating studs 1into
the corresponding slots 2on the mount.
2. Rotate the lens clockwise 3until the
studs slide all the way into the slots.
3. Tighten the two fixing screws 4on the
lens collar.
To remove the lens, reverse the above
procedure.
43
21

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 18
Important Information
Replacing the lters
1. Loosen the six captive screws, then remove the front/side panel 1.
2. Replace the filters 2.
3. Reattach the panel and tighten the screws.
1 2

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 19
Important Information
Remote control reference
The remote control is shipped with no battery tted. Remove the back cover and insert the supplied
cells while observing the correct cell polarity.
1Transmit indicator
Flashes when the remote sends a signal to the
projector. Lights solidly when the projector is in
FOCUS, ZOOM or SHIFT ADJUSTMENT mode.
2Power ON / OFF
3FOCUS
Press for FOCUS ADJUSTMENT mode, use the
arrows to make the adjustment.
4Shutter OPEN / CLOSE
5Input selection
Select input source. Press:
1 for HDMI A, 2 for HDMI B, 3 for DisplayPort A
and 4for DisplayPort B
6Remote control backlight ON / OFF
Make the remote control keys glow in the dark,
or switch this feature off.
7CAL
Press and hold this key, then press FOCUS or
ZOOM to calibrate focus or zoom respectively.
8ZOOM
Press to enter ZOOM ADJUSTMENT mode,
then use the arrow keys to make the adjustment.
9SHIFT
Press to enter SHIFT ADJUSTMENT mode,
then use the arrow keys to make the adjustment.
10 Arrow keys
Use these keys for focus, zoom and shift.
11 EXIT
Exit lens adjustment modes.
Not all keys are used on this projector. The
unused keys are grayed out.
You can use the remote control wirelessly or
with a standard TRS cable.
When a new lens is tted, a calibration
procedure must be carried out.
When adjusting focus or zoom, UP and LEFT
will focus/zoom in, DOWN and RIGHT will zoom
out. When adjusting shift, each arrow key moves
the image in the corresponding direction.
When you enter FOCUS, ZOOM or SHIFT
ADJUSTMENT mode, all other remote control
functions become unavailable. To cancel an
adjustment mode, either press EXIT or wait ten
seconds.
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
1
2
5
4
7
9
8
3
10
11
6

Digital Projection INSIGHT Dual Laser 4K Series
Rev A June 2017
Page 20
Important Information
Keypad reference
CTRL FOCUS
AUTO INFO SHIFT ZOOM
MENU INPUT
OK
EXIT INPUT
OFF
ON
OSD
ON
OFF
POWER
OPEN
CLOSE
SHUTTER
+
–
RPY
1
5
10
3
4
2
9
7
8
6
