Digital Projection HIGHlite Laser II 3D Series User manual

Rev B December 2016
HIGHlite Laser II 3D Series
High Brightness Digital Video Projector
4INSTALLATION AND QUICK-START GUIDE
4CONNECTION GUIDE
4OPERATING GUIDE
4REFERENCE GUIDE
118-089B

page i
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
About This Document
Follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the
instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2016 Digital Projection Ltd. All rights reserved.
Notes

page ii
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
Laser Information
Caution-useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespeciedhereinmayresultin
hazardous radiation exposure.
Notes
CAUTION
Possibly hazardous optical radiation emitted
from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
ATTENTION
Ce produit peut émettre des rayonnements
optiques dangereux.
Ne pas fixer la lampe en fonctionnement.
Peut être nocif pour les yeux.
RISK GROUP 2
AC Input / Entrée CA ( 輸入 / 输入 ) : 200-240Vac 9A 50/60Hz
AC Input / Entrée CA ( 輸入 / 输入 ) : 110-130Vac 11.5A 50/60Hz
Model/Modèle (型號 / 型号): HIGHlite Laser II 3D
DLP PROJECTOR / DLP Projecteur
( 數位投影機/数字投影机 )
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
450nm - 460nm < 333.5mW
激光輻射 避免眼睛受到直射 3R类激光產品
波長 : 450nm - 460nm < 333.5 mW
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL À LASER DE CLASSE 3R
450nm - 460nm < 333.5 mW
GB 7247.1-2012 / IEC/EN 60825-1:2007
警告:此為A 級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
KTL ZUXXXXX-XXXXX
MSIP-REM-DVP-XXXXXXXXXX
Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007
상호명/제조자: 델타일렉트로닉스㈜
제조공장/제조국가: 델타 비디오 디스플레이
시스템 (우장) 리미티드
제조시기 : 년 월
116-330
S/N:
M/F Date:
제품명:프로젝터
모델명 : HIGHlite Laser II 3D
A/S전화: [phone]
製造商:Digital Projection Limited
Greenside Way Middleton Manchester, M24 1XX UK 製造地:中國/製造地:中國 / Made in China

page iii
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• Support for most 3D formats.
• HDBaseT® for transmission of uncompressed High Denition Video up to 100 m from the source.
• 3G-SDI with loop-through.
• Edge Blend.
• Blanking control for custom input window sizing.
• Cornerstone, Vertical & Horizontal Keystone, Pincushion & Barrel, and Image Rotation.
• Control via LAN and RS232.
• Motorised lens mount.
A serial number is located on the side of the projector. Record it here:
Notes

page iv
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
CONTENTS
INSTALLATION AND QUICK-START GUIDE ..............................1
WHAT’S IN THE BOX? ................................................................... 3
CONNECTING THE POWER SUPPLY ............................................. 4
Voltage selection ................................................................................... 4
PROJECTOR OVERVIEW ............................................................... 5
Front and rear views ............................................................................. 5
Control panel......................................................................................... 6
REMOTE CONTROL....................................................................... 7
Infrared reception................................................................................ 10
POSITIONING THE SCREEN AND PROJECTOR........................... 11
Roll and pitch ...................................................................................... 12
CHANGING THE LENS................................................................. 13
The lens hood ..................................................................................... 13
Inserting a new lens ............................................................................ 14
Removing the lens .............................................................................. 15
CHANGING THE FILTERS ............................................................ 16
OPERATING THE PROJECTOR.................................................... 17
Switching the projector on................................................................... 17
Switching the projector off................................................................... 17
Selecting an input signal ..................................................................... 18
Selecting a test pattern ....................................................................... 18
Adjusting the lens................................................................................ 19
Adjusting the image............................................................................. 19
CONNECTION GUIDE ............................................................................21
SIGNAL INPUTS .......................................................................... 23
Digital inputs and outputs.................................................................... 23
Analog inputs and outputs................................................................... 24
EDID on the HDMI, DisplayPort and VGA inputs ................................ 25
Using HDMI/DisplayPort switchers with the projector......................... 25
3D connections ................................................................................... 26
3D sources up to 60Hz requiring frame doubling and left/right interleaving.......... 26
Frame sequential 3D sources up to 120Hz ................................................. 26
Dual Pipe 3D ...................................................................................... 26
3D Sync............................................................................................... 27
3D Sync in ......................................................................................... 27
3D Sync out ....................................................................................... 27
CONTROL CONNECTIONS........................................................... 28
LAN connection examples .................................................................. 29
RS232 connection example ................................................................ 30

page v
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
OPERATING GUIDE ................................................................................31
USING THE MENUS ..................................................................... 33
Opening the OSD................................................................................ 33
Opening a menu.................................................................................. 33
Exiting menus and closing the OSD.................................................... 33
Inside a menu...................................................................................... 34
Accessing sub-menus........................................................................... 34
Executing commands............................................................................ 34
Editing projector settings..................................................................... 35
Using a slider to set a value.................................................................... 35
Editing numeric values .......................................................................... 35
USING THE PROJECTOR............................................................. 36
Main menu .......................................................................................... 36
Lens menu .......................................................................................... 37
Lens Control....................................................................................... 37
Lens Memory...................................................................................... 38
Image menu ........................................................................................ 39
Noise Reduction .................................................................................. 40
Position and Phase .............................................................................. 40
Color menu.......................................................................................... 41
Color Space ....................................................................................... 41
Color Mode ........................................................................................ 42
Geometry menu .................................................................................. 47
Aspect Ratio....................................................................................... 47
Digital Zoom & Shift.............................................................................. 49
Overscan........................................................................................... 50
Blanking ............................................................................................ 51
Keystone ........................................................................................... 52
4 Corners .......................................................................................... 54
Rotation ............................................................................................ 55
Pincushion / Barrel............................................................................... 56
Edge Blend menu................................................................................ 57
Blend Width........................................................................................ 58
Black Level Uplift ................................................................................. 59
3D menu.............................................................................................. 60
3D types............................................................................................ 61
Some 3D settings explained ................................................................... 62
Frame rate multiplication in 3D images ...................................................... 63
Laser menu ......................................................................................... 64
Setup menu......................................................................................... 65
ColorMax Setting ................................................................................. 67
Power On/Off...................................................................................... 68
Clock Adjust ....................................................................................... 69
OSD Settings...................................................................................... 70
Memory............................................................................................. 70
Network menu..................................................................................... 71
PIP menu ............................................................................................ 72
Information menu ................................................................................ 73
Signal Format ..................................................................................... 73
System Status .................................................................................... 74
Thermal Status.................................................................................... 74
Factory Reset ..................................................................................... 75
POSSIBLE COMBINATIONS OF SETTINGS.................................. 76
CONTENTS (continued)

page vi
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
REFERENCE GUIDE................................................................................77
THE DMD™.................................................................................. 80
CHOOSING A LENS ..................................................................... 82
Basic calculation ................................................................................. 83
Basic calculation example................................................................... 84
Full lens calculation............................................................................. 85
Introducing TRC .................................................................................. 85
Calculating TRC .................................................................................. 86
Calculating the throw ratio with TRC ......................................................... 87
Full lens calculation example .............................................................. 88
SCREEN REQUIREMENTS........................................................... 89
Fitting the image to the DMD™........................................................... 89
WUXGA images displayed full width ......................................................... 89
WUXGA images displayed with a height of 1080 pixels.................................. 90
WUXGA images displayed full height ........................................................ 91
Diagonal screen sizes......................................................................... 92
Fitting the image to the screen............................................................ 93
Positioning the screen and projector................................................... 94
POSITIONING THE IMAGE........................................................... 95
Maximum offset range......................................................................... 97
ASPECT RATIOS EXPLAINED...................................................... 98
Aspect ratio examples......................................................................... 99
FRAME RATES AND PULLDOWNS EXPLAINED......................... 101
Interlaced and progressive scan ....................................................... 101
Frame rates of image sources .......................................................... 101
Pulldowns - conversion into destination formats............................... 102
2:3 (normal) pulldown ......................................................................... 102
2:3:3:2 (advanced) pulldown................................................................. 103
APPENDIX A: LENS PART NUMBERS........................................ 104
APPENDIX B: LENS CHARTS .................................................... 105
How to use the lens charts ................................................................... 105
TRC values applied in the charts ........................................................... 106
Fixed lenses - full DMD™ width images................................................... 107
Zoom lenses - full DMD™ width images .................................................. 108
Fixed lenses - 1.25:1 images ................................................................ 109
Zoom lenses - 1.25:1 images ................................................................ 110
Fixed lenses - 1.33:1 images .................................................................111
Zoom lenses - 1.33:1 images ................................................................ 112
APPENDIX C: SUPPORTED SIGNAL INPUT MODES ...................113
2D formats......................................................................................... 113
3D formats......................................................................................... 115
APPENDIX D: MENU MAP...........................................................117
CONTENTS (continued)

page vii
Digital Projection HIGHlite Laser II 3D Series
Rev B December 2016
APPENDIX E: WIRING DETAILS................................................. 128
Signal inputs and outputs.................................................................. 128
VGA ............................................................................................... 128
HDMI 1 and 2 ................................................................................... 129
DisplayPort ...................................................................................... 130
3G-SDI In, 3G-SDI Out........................................................................ 131
COMPONENT .................................................................................. 131
Control connections .......................................................................... 132
LAN ............................................................................................... 132
RS232 ............................................................................................ 132
Trigger 1 & Trigger 2 ........................................................................... 133
IR input ........................................................................................... 133
3D Sync IN and 3D Sync OUT .............................................................. 133
APPENDIX F: GLOSSARY OF TERMS........................................ 134
TECHNICAL SPECIFICATIONS .................................................. 145
Models............................................................................................... 145
Inputs and outputs............................................................................. 146
Bandwidth ......................................................................................... 146
Remote control and keypad .............................................................. 146
Automation control ............................................................................ 146
Color temperature ............................................................................. 146
Lenses............................................................................................... 147
Lens mount ....................................................................................... 147
Mechanical mounting ........................................................................ 147
Orientation......................................................................................... 147
Electrical and physical specications................................................ 148
Safety & EMC regulations................................................................. 148
CONTENTS (continued)

Rev B December 2016
HIGHlite Laser II 3D Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE
4

Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
IN THIS GUIDE
Rev B December 2016
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Connecting The Power Supply........................................................................ 4
Voltage selection.........................................................................................................4
Projector Overview............................................................................................. 5
Front and rear views ...................................................................................................5
Control Panel........................................................................................................ 6
Remote Control.................................................................................................... 7
Infrared reception......................................................................................................10
Positioning The Screen And Projector....................................................... 11
Roll and pitch ............................................................................................................12
Changing The Lens........................................................................................... 13
The lens hood............................................................................................................13
Inserting a new lens..................................................................................................14
Removing the lens ....................................................................................................15
Changing The Filters........................................................................................ 16
Operating The Projector ................................................................................. 17
Switching the projector on.......................................................................................17
Switching the projector off.......................................................................................17
Selecting an input signal..........................................................................................18
Selecting a test pattern.............................................................................................18
Adjusting the lens .....................................................................................................19
Adjusting the image..................................................................................................19

page 3
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
WHAT’S IN THE BOX?
Rev B December 2016
What’s In The Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
Only one remote will be supplied
with the projector. For more
information, see Remote Control
further in this guide.
You should save the original box
and packing materials, in case you
ever need to ship your projector.
The projector is shipped without a
lens.
Do not use the short lens hood
with the 4.34 - 6.76 : 1 zoom lens.
For further information about using
the right lens and hood, see The
lens hood further in this guide.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control (116-088) 2x AAA batteries
User Manual on disc
(115-759)
Important Information
(114-914)
Power cable, Europe
(112-001)
Power cable, North America
(112-002)
Projector
Power cable, United Kingdom
(112-000)
HDMI cable
Pic Mute
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT
HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
OPEN CLOSE
Power cable, China
remote control cable
VGA cable

page 4
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
CONNECTING THE POWER SUPPLY
Rev B December 2016
Connecting The Power Supply
Lift the cable lock up, push the mains connector in rmly and
push the lock down to secure the cable.
1AC mains inlet with cable lock
Voltage selection
The VOLTAGE SELECT switch must be set to match the power supply you are using:
Voltage of power supply used Position of VOLTAGE SELECT switch
AC100V outlet
AC200V (single phase) outlet
Notes
Use only the power cable
provided.
Ensure that the power outlet
includes a ground connection as
this equipment MUST be earthed.
Handle the power cable carefully
and avoid sharp bends. Do not
use a damaged power cable.
1

page 5
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev B December 2016
Projector Overview
Front and rear views
1Control panel
2Connection panel
3Air outlet
4Lens hood
5Front infrared window
6Power switch and power connection
7Air outlet
8Rear infrared window
9Air inlet
10 Adjustable feet
Notes
Do not use the short lens hood
with the 4.34 - 6.76 : 1 zoom lens.
For further information about using
the right lens and hood, see The
lens hood further in this guide.
Front view
4 5
3
12
6
Rear view
7 8
10
9

page 6
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
CONTROL PANEL
Rev B December 2016
Control Panel
1ON indicator (blue)
Behavior Meaning
Off The projector is switched off.
On The projector is switched ON.
Flashing The projector is warming up or cooling down.
2ERROR indicator (red)
Behavior Meaning
Flash once, then pause Laser failure.
Flash twice, then pause Cover open.
Flash three times, then pause Fan failure.
Flash four times, then pause Over temperature.
On System error.
3STANDBY indicator (green)
Behavior Meaning
On The projector is in STANDBY mode.
Flashing The projector is in STANDBY mode.
It can be switched on with a network command.
4MENU button
Access the projector OSD (on-screen display).
5Navigation (arrow buttons and ENTER)
Navigate the OSD and edit settings with the arrows, conrm choice with ENTER.
6INPUT button
Select input source.
7Focus IN / OUT
Adjust focus.
8Zoom IN / OUT
Adjust zoom.
9Shutter CLOSE / OPEN
Open and close the shutter.
10 POWER button
Switch the projector on and off (in STANDBY mode)
11 EXIT button
Close the OSD.
12 SHIFT button
Press and hold this button, then press the arrow buttons to move the lens.
ERROR STANDBY
INPUT
CLOSE
FOCUS
ZOOM
SHUTTER
OPEN
OUT IN
OUT IN
SHIFT
MENU EXIT
4
5
6
3
8
1
2
9
7
10
12
11
Notes

page 7
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B December 2016
Remote Control
1Power ON / OFF
Turns power on and off.
2Pic Mute OPEN / CLOSE
Shows and hides the projected image.
When CLOSE is pressed, the light source switches off completely and the screen
becomes black.
2OSD ON / OFF
Enable and disable screen timeout messages and control whether to show the OSD
during projection.
4MENU
Access the OSD. If the OSD is open, press this button to go back to the previous menu.
5Navigation (arrows and OK)
Navigate through the menus with the arrows, conrm your choice with OK.
In lens adjustment modes, the arrows are used to move, zoom or focus the lens. See 11
below.
In lens adjustment modes, or when the OSD is not showing, the OK button switches
between modes: Shift Adjustment and Zoom / Focus Adjustment.
6EXIT
Go up one level in the OSD. When the top level is reached, press to close the OSD.
7FREEZE
Freeze the current frame.
8DEFAULT
When editing a parameter, press this button to restore the default value.
9INFO
Access information about the projector.
10 RE-SYNC
Re-synchronise with the current input signal.
continues on next page...
Pic Mute
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
OPEN CLOSE
1
2
5
6
8
4
9
7
3
10
Notes

page 8
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B December 2016
11 LENS adjustment
FOCUS IN / OUT: adjust focus.
SHIFT: press and hold this button, then use the Navigation arrow
buttons to move the lens.
ZOOM IN / OUT: adjust zoom.
12 USER PRESET A, B, C, D
Load user presets.
13 ALT
Press and hold this button to access alternative functions for all
buttons with a green label.
14 DVI / GAMMA / numeric input 3
Select the DVI input.
Use with ALT to switch to the next Gamma value:
...1.0, 1.8, 2.0, 2.2, 2.35, 2.5...
15 HDMI 2 / CON / numeric input 2
Select the HDMI 2 input.
Use with ALT to bring up the Contrast control, then adjust the value
with the LEFT and RIGHT arrow buttons.
16 HDMI 1 / BRI / numeric input 1
Select the HDMI 1 input.
Use with ALT to bring up the Brightness control, then adjust the
value with the LEFT and RIGHT arrow buttons.
17 TEST / SWAP / numeric input 0
Show a test pattern. Press again to show the next test pattern:
...Off, White, Black, Red, Green, Blue, CheckerBoard,
CrossHatch, V Burst, H Burst, ColorBar...
When PIP mode is on, use this button with ALT to swap the main and
sub images.
continues on next page...
Notes
For further information about
user presets, see Memory in the
Operating Guide.
Remote control
Pic Mute
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
OPEN CLOSE
13
11
12
14
15
16
17

page 9
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B December 2016
17 DISPLAYPORT / R / numeric input 4
Select DisplayPort input.
18 HD-T / G / numeric input 5
Select the HDBaseT input.
19 3GSDI / B / numeric input 6
Select the 3G-SDI input.
20 VGA / 3D / numeric input 7
Select the VGA input.
Use with ALT to toggle the 3D Format setting between Off and Auto.
21 COMP1 / EYE / numeric input 8
Select the Component 1 input.
Use with ALT to switch between left and right eye 3D dominance.
22 COMP2 / PIP / numeric input 9
Select the Component 2 input.
Use with ALT to switch on Picture In Picture (PIP) mode.
23 ADDR / ALL (with red indicator at the top)
Assign and unassign an IR remote address.
To assign an address:
1. Press and hold this button until the indicator starts ashing.
2. Release this button and while the indicator is still ashing, enter
a two-digit address using the numeric input buttons. The indicator
will ash three times quickly to conrm the change.
To unassign an address and return to the default address 00,
• Press and hold ALT and this button simultaneously until the
indicator ashes to conrm the change.
Notes
Remote control bottom
Pic Mute
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
OPEN CLOSE
23
18
19
17
20
21
22
Pic Mute
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
OPEN CLOSE
Remote control top

page 10
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B December 2016
Infrared reception
The projector has infrared sensors at the front and back.
The angle of acceptance is 40°. Make sure that the remote control is within the angle of
acceptance when trying to control the projector.
40°
40°
Infrared reception
Notes

page 11
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev B December 2016
Positioning The Screen And Projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll the screen. Set the adjustable feet so that
the projector is level, and perpendicular to the screen.
The drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling mounting.
1Four adjustable feet
2Six M6 holes for ceiling mount
The screws should not penetrate more than 15 mm into
the body of the projector.
Notes
Always allow the projector
to cool for 5 minutes before
disconnecting the power or
moving the projector.
Ensure that there is at least 50
cm (20 in) of space between the
ventilation outlets and any wall,
and 30 cm (12 in) on all other
sides.
Do not stack more than 3
projectors.
1
2
1
1
1
2
2
2
2
2

page 12
Digital Projection HIGHlite Laser II 3D Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev B December 2016
Roll and pitch
The projector can be operated in numerous positions.
It is not recommended to position the projector in portrait mode with inputs facing upward, as shown in the diagram.
1Positions to avoid: inputs side up
2Recommended positions
Notes
360° 2
Pitch
30°
330° 2
1
Roll
