Dimplex CKHA Series Configuration guide

14 | RESIDENTIAL HEATERS TO ORDER PLEASE CALL 1-877-362-1101 OR FAX [phone] www.dimplexheating.com
CKHA Series
Kick Space Heater
Voltage 120, 240/208V
Wattage Five outputs ranging from 450W to 1800W
Colour Black or White
Airflow 80 CFM
Finish Specially formulated polyester powder coating process is applied to the
front panel which resists fading and abrasion.
Construction The enclosure is constructed of 20 gauge steel. Horizontal mount only.
Heating Element The Kick Space heater has four totally enclosed nickel chromium
resistance elements with steel sheaths. The elements are complete
with spiral steel fins that are brazed to the steel sheath to provide
excellent heat transfer.
Controls & Wiring The Kick Space heater is factory wired for 240/208V @ 900/675W and is
field convertible for 240/208V @ 1800/1350W, 120V @ 450, 900, 1350,
or 1800W configuration. The unit is controllable from a line voltage wall
thermostat or field installed built-in tamperproof single or double pole
thermostat kit.
Warranty One year warranty on complete unit.
CSA certified and UL approved.
Dimensions
562mm[22 1/8"]
WIRING
JUNCTION BOX
241mm
[9 1/2"]
45mm
[1 3/4"]
25mm[1"]
22mm[7/8"] DIA. K.O.
2 PLACES
114mm
[4 1/2"]
613mm
[24 1/8"]
45mm
[1 3/4"]
51mm
[2"]
89mm[3 1/2"]
S
S
LEFT SIDE BACK VIEW
TOP VIEW
LEFT SIDE FRONT VIEW
Ordering Guide
Cat. No. Watts BTU Volts
Weight
(kg/lbs.)
CKHA20D31 450 1535 120 6.4/14
900 3071 120
1350 4606 120
1800 6142 120
900/675 3071/2303 240/208
1800/1350 6142/4606 240/208
Note: Standard colour is Black – To order White add “W”
at end of Cat. No. Factory wired at 240/208V for
900/675W
Specifications
Low-profile fan-forced heater that provides comfort in places where space is limited (i.e. under-counter, stair riser etc.).
Features
•Single model offers flexible
wattage output with voltage
selection
•Makes an economical floor
warmer
•Superior finned tubular
element design
•Automatic primary and
secondary reset thermal
cutout for safety
•Pilot light will activate if unit
trips on high limit
Applications
•Kitchen or bathroom
under-cabinet, stair riser
Control Options (field installed)
Tamperproof Thermostat Kits
Cat. No. Description
CKHATD13 Single pole thermostat
CKHATD23 Double pole thermostat
Note: Thermostats are adjustable by slotted screw
adjustment through front grille only
