Dimplex MIDI FIRE MIDI32B User manual

The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC)
EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2006/108/EC
08/51916/0 (UK) Issue 2
MIDI FIRE (MIDI32B)
Console
Console
UK

1
2
45
3
SW 1 SW 2
862 350
439

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
UK
General
Unpack the heater carefully and retain the packaging for possible future use,
in the event of moving or returning the fire to your supplier.
These models are designed to be free standing and are normally positioned
against a wall. The fire incorporates a flame effect, which can be used with
or without heating, so that the comforting effect may be enjoyed at any time
of the year. Using the flame effect on its own only requires a little electricity.
Achoice of 750W to 1500W heat output is provided by the fan heater, which
is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is the same as
that stated on the heater.
Please note: Used in an environment where background noise is very low, it
may be possible to hear a sound which is related to the operation of the flame
effect. This is normal and should not be a cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on anAC ~ supply only and the voltage marked on
theheater must correspond to thesupplyvoltage. Before switching on, please
read the safety warnings and operating instructions.
Access to the Controls - see Fig. 2
To access the controls switches of the appliance, guide your hand along the
inner Right Hand side panel until a opening in the panel is found. Moving your
hand through the opening of the side panel. The two control switches are
recessed on the back panel of the appliance as shown in Fig.2
Controls - see Fig. 2
The main ON/OFF Switch (SW 1) must first be turned ON to operate any of
the other controls. Switch (SW2) has the following operations.
Setting Operation Indication
Flame Effect Press the ‘I’ button once Bottom Neon
Flame Effect & 750W heat Press the ‘I’ button again Bottom &
middle neon
Flame Effect & 1500W heat Press the ‘I’ button again All 3 neons
To turn off any of the settings Press the’O’button once.
Neon indicators - see Fig. 4
Three Neon’s as shown in Fig. 6 indicate the setting for a couple of seconds
every time you change the setting.
One Neon means ON (flame effect only, no heat), two Neon’s means 750W
heat and all three Neon’s are on to indicate full 1500W heat setting.
Important Safety Advice
When using electrical appliances, basic
precautions should be followed to reduce
the risk of fire, electric shock, and injury to
persons, including the following:
If the appliance is damaged, check
immediately with the supplier before
installation and operation.
Do not use this heater in the immediate
surroundings of a bath, shower or swimming
pool.
Do not use outdoors.
This heater must not be located immediately
above or below a fixed socket outlet or
connection box.
The heater carries the Warning symbol,
indicating that it must not be covered.
Warning: In order to avoid overheating do not
coverthe heater.Ensure thatfurniture, curtains
orother combustiblematerial arepositionedno
closer than 1 metre from the heater.
In the event of a fault unplug the heater.
Unplug the heater when not required for long
periods.
The supply cord must be placed on the right
hand side of the heater away from the heat
outlet underneath the heater.
Although this heater complies with safety
standards, we do not recommend its use
on deep pile carpets or on long hair type of
rugs.
This appliance can be used by children aged
8 years and above and persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by Children without supervision.
Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position and
theyhavebeen givensupervisionor instruction
concerning use of the appliance in a safe
way and understand the hazards involved.
Children aged from 3 years and less than 8
years shall not plug in, regulate and clean
the appliance or perform user maintenance.
The appliance must be positioned
so that the plug is accessible.
Ifthesupplycordisdamageditmustbereplaced
by the manufacturer or service agent or
Midi Fire (Midi32B)
similarlyqualifiedpersoninordertoavoidahazard.
Caution:Inordertoavoidahazardduetoinadvertent
resetting of the thermal cut-out, this appliance
mustnotbe suppliedthroughan externalswitching
device, such as a timer, or connected to a circuit
that is regularly switched on and off by the utility.
This heater is not equipped with a device to
control the room temperature. Do not use this
heater in small rooms when they are occupied by
persons not capable of leaving the room on their
own, unless constant supervision is provided.
The appliance must not to be located beneath a
socket outlet.
Caution: Some parts of this product can become
very hot and cause burns. Particular attention
has to be given where children and vulnerable
people are present.
This Instruction can be found at WWW.DIMPLEX.
CO.UK

Discard leaking batteries
Dispose of batteries in the proper manner according to provincial and
local regulations.
Any battery may leak electrolyte if mixed with a different battery type, if
inserted incorrectly, if all the batteries are not replaced at the same time,
if disposed of in a fire, or if an attempt is made to charge a battery not
intended to be recharged.
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.
Forgeneralcleaninguseasoftcleanduster–neveruseabrasivecleaners.
The high gloss finish has been carefully created by hand. take maximum
care not to scratch this finish . We recommend carefully lifting objects on
andofftheappliance.Theglassviewingscreenshouldbecleaned carefully
with a soft cloth. DO NOT use proprietary glass cleaners.
To remove any accumulation of dust or fluff the soft brush attachment of
a vacuum cleaner should occasionally be used to clean the outlet grille
of the fan heater.
Warning: The maximum loading that can be applied to the glass
shelving must not exceed 10kg’s.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not be disposed
of with household waste. Please recycle where facilities exist. Check
with your Local Authority or retailer for recycling advice in your country.
After Sales Service
Your product is guaranteed for one year from the date of
purchase.
Within this period, we undertake to repair or exchange
this product free of charge (excluding lamps & subject to
availability) provided it has been installed and operated in
accordance with these instructions.
Midi Fire (Midi32B)
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
UK
Dimplex
Millbrook House
GrangeDrive
HedgeEnd
Southampton
Hampshire.SO30 2DF
TEL: [phone]
FAX: [phone]
WEBSITE: www.dimplex.co.uk
Republic of Ireland Tel. [phone]
[c] GDC Group Ltd,
All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Dimplex.
A division of GDC Group Ltd,
Remote control - see Fig. 5
The maximum range of use is ~ 15metres.
The buttons on the remote control have the same function as the swiches
on the heater.
For details on the function please refer to the ‘Controls’ section above.
Warning: It takes time for the receiver to respond to the transmitter.
Do not press the buttons more than once within two seconds for correct
operation.
Battery information - see Fig. 7
1. Slide open the battery cover on the back of the remote control
2. Install AAA batteries into the remote control
3. Replace the battery cover.
Thermal Safety Cut-out
The built-in overheat cut-out switches off the appliance automatically in
the event of a fault. If this occurs switch off the appliance or disconnect
the mains plug from the socket. After a short cooling down phase, the
appliance is ready for use again. If the fault should occurs again, see
your local dealer.
Yourrights under this guaranteeare additional to yourstatutoryrights, which
in turn are not affected by this guarantee.
Should you require after sales information or assistance with this product
please go to www.dimplex.co.uk where you will find our self help guide by
clicking on “After Sales” or ring our helpdesk on 0844 879 3588 (UK) or 01
842 4833 (R.O.I.) .
Spare parts are also available on the website
www.dimplex.co.uk
Please retain your receipt as proof of purchase.
