INSTRUCTION PAPER
SELECTA | Extendable table 225-345x108
CONTENT
16x bolt (M6x35mm)
1x alu table top
28x washer (M6)
2x alu legs
1x hex key (5)
12x bolt (M6x15mm)
8x silicone cap
A
E
B
F
C
G
D
STEP 1: PLACE SILICONE CAPS STEP 2: SLIDE LEGS ON TABLE TOP
STEP 3: FIXATE LEGS
E
A
C
DBC D
C
A
D
123
Place 4 silicone caps (E) onto the right side of the table top (F) as
shown in the picture. Repeat this for the left side.
Slide the legs (G) equally into the table top (F).
Fixate the legs (G) with the table top (F) by following the 3 steps. Make sure you follow the correct order as indicated by the letters in the
picture. Repeat this for the other 3 corners.
Start by unpacking everything carefully. Make sure to cover the floor to prevent any damage or scratching (you can use the cardboard box for this).

INSTRUCTION PAPER
SELECTA | Extendable table 225-345x108
2/2
PIDE210120 Diphano cannot be held responsible if the assembly instructions are not followed properly.
www.diphano.com
DINING
ARMCHAIR LOUNGE CHAIR FOOTREST BEACH CHAIR DECK CHAIR
DINING TABLES HIGH DINING TABLES EXTENDABLE TABLE
LOUNGERS
BISTRO TABLES
108 | 92 | 74h
Slide the 2 table tops outwards (1), tilt the middle table top in the
direction indicated by the arrows (2). Slide the 2 outer table tops
back inwards (3).
Turn the table carefully to its normal position with at least 6 persons.
STEP 6: PLACE REMAINIG BOLTS
STEP 4: TURN TABLE STEP 5: OPEN TABLE
STEP 7: ADJUST FEET
B
D
C
1
2
3
Fixate 4 bolts (B) with the washers (C) in the remaining center holes
at the left side and repeat this for the remaining center holes at the
right side. Make sure you follow the correct order as indicated by the
letters in the picture.
Check with a spirit level if the table is placed level. If not, (un)screw
the adjustable feet till your table is completely level.
