Diphano Alexa User manual

Alexa
barstool 77h & 62h
INSTRUCTION MANUAL

2
CONTENT
how to assemble the barstool
2x bolt (M6x28mm) 2x bolt (M6x15mm)
1x alu intermediate piece
A B
1x hex key (5x)
DC
Start by unpacking everything carefully. Make sure to cover the floor to prevent any
damage or scratching (you can use the cardboard box for this).
Diphano cannot be held responsible if the assembly instructions are not followed properly.

3
POSITION INTERMEDIATE PIECE
Place the intermediate piece (D) with the long side to the front and the
short side at the back as shown in the picture.

4
CONNECT THE FRONT
Use the hex key (C) to fixate the intermediate piece at the front
by screwing the 15mm bolts (B).
B

5
CONNECT THE BACK
Use the hex key (C) to fixate the intermediate piece at the back
by screwing the 28mm bolts (A).
A

6
RESULT

7
maintenance & care
Simply brush away loose dirt, rinse, and clean with a mild, lukewarm
soapy solution. Rinse thoroughly and pat dry with a cloth.
Easy to clean with water or a specific Batyline cleaner. Avoid the use of abrasive
products and high pressure cleaning.
POWDERCOATED ALUMINIUM
BATYLINE®

PIDE230120
www.diphano.com
Textielstraat 4 - 8790 Waregem - Belgium
Tel. [phone] - [e-mail]
