Page 9
Feature & Option List
It is recommended to configure all the features and options listed below using the configuration tool found on the module
flashing page on www.directechs.com. The web offers more options such as EIPS and RSR; however, manual
configuration of the features is possible using the information on this page.
* Default option
Feat. Operation Flashes / Option Description
1. Disabled* Module is connected to a remote starter using a standard installation.
2. RFTD Output Module is connected to an XL202 using an RSR or RXT installation (when available).
3. SmartStart Module is connected to SmartStart using an RSR or RXT installation (when available).
1. Driver Priority* Unlocks only the driver door on first press and unlocks all doors on a second press within 5 seconds.
2. All Unlocks all doors on first press.
1. Disabled* No operation.
2. Enabled When the feature is enabled, it will activate the Heated Seats and heated steering wheel.
1. Disabled* No operation.
2. Enabled When the feature is enabled, it will activate the rear defroster and heated mirrors.
1. 32° Farenheit (0°
Celsius)*
When Heated Seats or Defroster feature is enabled, it will activate the feature upon remote start when
temperature is below 32 °F (0 °C).
2. 23° Farenheit (-5°
Celsius)
When Heated Seats or Defroster feature is enabled, it will activate the feature upon remote start when
temperature is below 23 °F (-5 °C).
3. 41° Farenheit (5°
Celsius)
When Heated Seats or Defroster feature is enabled, it will activate the feature upon remote start when
temperature is below 41 °F (5 °C).
4. Always ON When Heated Seats or Defroster feature is enabled, it will activate the feature at any temperature.
1. High* When Heated Seats are activated, they will be set to HIGH.
2. Low When Heated Seats are activated, they will be set to LOW.
1. Disabled The OEM alarm will not be controlled by DBALL upon remote start. No disarm or arm command will be
executed at the beginning or end of the sequence; it must be controlled by the Remote Starter.
2. Normal / Safelock Smart OEM Alarm Control will behave like a standard Safelock feature on a remote starter. It will unlock at
the beginning of the sequence, and relock after start and shutdown.
3. Enabled*
Smart OEM Alarm Control will synchronize with the OEM alarm so that it will disarm and rearm the vehicle in
the remote start sequence, only when required. The reason for this is, factory alarm control must often be
done by lock or unlock operation. This could create unnecessary actions on door lock modules, such as the
horn to honk. When possible, Smart OEM Alarm Control will monitor the alarm and door lock status to detect
if the disarm or rearm is required. If the vehicle is unlocked or is not equipped with factory alarm, the
disarm/rearm will not be executed. Smart OEM Alarm Control will also monitor the remote starter actions so
that the factory alarm control is not done twice. A remote starter, for which the Safelock feature is active, will
work perfectly with this option and will make it invisible to the user.
6
Heated Seats
Temperature
Level
7Smart OEM
Alarm Control
Unlock Driver
Priority
2
1 RF Output Type
3 Heated Seats
5
Heated
Seats/Defroster
Temperature
Control
4 Defroster
Rev.: 20151126
Platform: DBALL2
Firmware: CHRYSLER8 Remote Start Ready (RSR) Installation
