VW08

INSTALLATION GUIDE

This product is intended for installation by a professional installer only! Attempts to install this

product by a person other than a trained professional may result in severe damage to a vehicle’s

electrical system and components.

2018-12-07

Directed Digital

Solutions

Contents

Warning! Safety first ....................................................................................................................... 3

Introduction .................................................................................................................................... 4

Pre-installation and application warnings ..................................................................................... 4

Vehicle application guide........................................................................................................... 5

Wiring connections ......................................................................................................................... 6

Main power harness (H1), 12-pin thick gauge connector ............................................................... 6

Auxiliary output harness (H2), 16-pin black connector ................................................................... 6

Analog harness (H3), 18-pin white connector ............................................................................... 7

MC501 harness (H4), 8 thick-gauge wires (optional)..................................................................... 7

Installation (wiring diagrams & vehicle wiring reference charts) ............................................................ 8

Type 1 ..................................................................................................................................... 8

Type 2 ................................................................................................................................... 12

Immobilizer interface .................................................................................................................... 14

Method 1: Key wrap for Push-To-Start (PTS)................................................................................. 14

Method 2: Key wrap for Push-To-Start (PTS) - Alternate ................................................................. 14

OEM Immobilizer - Removing the center console in Type 1 vehicles ..................................................... 15

OEM Immobilizer - Removing the center console in Audi Q7 .............................................................. 17

Connecting the module .................................................................................................................. 18

Important! .............................................................................................................................. 18

Manual or automatic transmission selection ................................................................................ 18

Optional sensors ..................................................................................................................... 19

RF Systems ............................................................................................................................. 19

When used in conjunction with SmartStart.................................................................................. 19

Module programming.............................................................................................................. 20

LED diagnostics and troubleshooting.......................................................................................... 21

Soft reset................................................................................................................................ 23

Hard reset .............................................................................................................................. 23

Learning the Tach (not needed with Virtual Tach) ............................................................................... 24

Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 24

Limited lifetime consumer warranty .................................................................................................. 25

Quick Reference Guide.................................................................................................................. 26

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.

• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never

operate the system in an area that does not have adequate ventilation.

The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:

• Never use a test light or logic probe when installing this unit. Always use a multimeter.

• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).

• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must

be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from

children all remote controls to assure that the system does not unintentionally remote start the vehicle.

• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.

ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE

STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.

Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or

death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with

the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the

neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.

This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product

installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to ﬁx the problem

immediately.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF

OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE

OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE

START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.

Remote starters for manual transmission pose signiﬁcant risks if not properly installed and operated. When testing to ensure the

installation is working properly, only remote start the vehicle in neutral gear, on a ﬂat surface and with a functional, fully engaged

parking brake. Do not allow anyone to stand in front of or behind the vehicle.

This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such

vehicles may pose certain risk.

3Directed Digital Solutions VW08

Introduction

The VW08 ﬁrmware for Directed Digital Solutions is compatible with speciﬁc Audi vehicles. It is a complete

solution for remote start, security (if applicable), bypass interface, and convenience. This guide provides

information on the installation of the module using VW08. If you would prefer using this system as a digital

solution, go to www.directechs.com and search for the make, model and year of the vehicle. This will allow

you to ﬁnd the proper ﬁrmware and corresponding installation guide.

Warning! This module can only be programmed via the web tool, which can be found on www.directechs.com or using the

Directechs Mobile application for mobile devices. Features and functions will become accessible when you connect the module

using the XKLoader.

Pre-installation and application warnings

Firmware notes: This section highlights important information for this speciﬁc ﬁrmware and will assist in

pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.

T-Harness

compatible

Keys required for

programming 1Keys required for

operation 1

This ﬁrmware does not support transponder override. One (1) programmed OEM key must be wired into the vehicle to

complete the installation of a remote starter.

A Note Regarding Climate Controls: Audi climate controls are key memory sensitive. This means that the last key used

to operate the vehicle will determine the setting for the climate controls. In order to make changes to environment control

settings, the following procedure is necessary:

1) Remote start the vehicle.

2) Make your climate control adjustments, ensuring NOT to use the AUTO mode on the control panel as this makes the Audi

adjust its HVAC settings based on external factors such as engine temperature.

3) When the adjustments are complete, turn off the vehicle starter, either by remote or footbrake.

This will ensure the climate controls function as the customer desires them too.

To remote start the engine, the hood, the hatch and all doors must be closed.

Unless speciﬁed otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic

connector.

Refer to the "Vehicle wiring reference chart" following each installation type.

General notes: This section highlights important information for this speciﬁc ﬁrmware.

[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.

[2] The siren is ONLY required when enabling the security features during module ﬂashing.

[3] For Key Wrap instructions refer to pages 12 to 15.

[4] Direct connection for trunk release in case not available through data.

[5] The correct brake activation wire will test as 0.6V with the ignition on and 12V with the brake pedal depressed with

ignition ON. Failure to identify the correct wire will cause permanent damage to the interface.

Additional parts required (maximum required):

Diode 6A

3 x 1A Diodes 86 85

87a

0 x Relay

Resistor 100Ω

0 x Resistor

Fuse 7.5A

0 x Fuse

4Directed Digital Solutions VW08

Vehicle application guide

The following table lists the vehicles and features which are compatible with this product. The number assigned to each year

allows you to determine which installation type should be used for your vehicle.

Vehicles

2019

2018

2017

AV-Parking Lights Control

DL-Arm Factory Security

DL-Disarm Factory Security

DL-Door Lock Control

DL-Door Unlock

DL-Driver Priority Unlock

DL-Trunk / Hatch Release

FOB-Control of aftermarket alarm with OEM remote

RS-3x LOCK START (Start control using OEM Remote)

RS-3x LOCK STOP (Stop control using OEM Remote)

RS-RAP Shut Down (Retained ACC Power)

RS-SmartStart

RS-Tach / RPM Output

SS-Entry Monitoring ALL Door Pins

SS-Entry Monitoring Hood Pin

SS-Entry Monitoring Trunk/Hatch Pin

ST-Brake Status (foot brake)

ST-Door Locks Status

ST-E-Brake Status

ST-Ignition Status

Audi

A4 (Smart Key) 1 1

••••••••••••••••••••

A4 Allroad (Smart Key) 1 1 ••••••••••••••••••••

A5 (Smart Key) 1••••••••••••••••••••

Q5 (Smart Key) 1••••••••••••••••••••

Q7 (Smart Key) 2 2 2 ••••••••••••••••••••

S4 (Smart Key) 1••••••••••••••••••••

S5 (Smart Key) 1

••••••••••••••••••••

SQ5 (Smart Key) 1••••••••••••••••••••

Legend:

AV: Horn & Light Controls

DL: OE Door Lock & Alarm Controls

FOB: Sync CAN Interface w/ FOB Remote

RS: Remote Start & Engine Controls

SS: Integrated Security & Monitoring

ST: Function/Feature Status

5Directed Digital Solutions VW08

Wiring connections

The wiring connections listed below are speciﬁc to this ﬁrmware.

Main power harness (H1), 12-pin thick gauge connector

Conn./Pin Color Description

H1/1 White Relay 3 COM – No Connection 1

H1/2 White/Brown Relay 3 N.O. – No Connection 1

H1/3 Brown/Red Relay 2 N.O.– Key Wrap

H1/4 Yellow/Red Relay 2 COM – Key Wrap

H1/5 Orange/Red Relay 2 N.C. – Key Wrap

H1/6 Yellow Relay 1 COM – No Connection 1

H1/7 White Relay 3 COM – No Connection 1

H1/8 White/Brown Relay 3 N.O. – No Connection 1

H1/9 Black (-) Ground

H1/10 Red (+) 12V Input

H1/11 Orange/Yellow Relay 1 N.C. – No Connection 1

H1/12 Brown Relay 1 N.O. – No Connection 1

Auxiliary output harness (H2), 16-pin black connector

Conn./Pin Color Description

H2/1 Violet/Brown No Connection

H2/2 Yellow/Black No Connection

H2/3 Orange/Black No Connection

H2/4 Tan HS CAN 1 Low

H2/5 Tan/Black HS CAN 1 High

H2/6 Light Green No Connection

H2/7 Orange/Green HS CAN 2 Low

H2/8 Orange/Brown HS CAN 2 High

H2/9 Violet/Green No Connection

H2/10 Green/Black No Connection 2

H2/11 White/Violet No Connection 2

H2/12 White/Red (+) Brake Activation Output 2

H2/13 Lt. Blue/Black (-) Push-to-Start Output 2

H2/14 Green/Red No Connection 2

H2/15 N/A No Connection

H2/16 Violet/Yellow No Connection

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed.

2. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are low current and a relay

may be necessary.

6Directed Digital Solutions VW08

Analog harness (H3), 18-pin white connector

Conn./Pin Color Description

H3/1 Lt. Blue/Red No Connection

H3/2 Black/White (-) Parking Brake Input (manual transmission) 2

H3/3 Gray (-) Hood Input 2

H3/4 N/A No Connection

H3/5 Gray/Black (+) Glow Plug Input 2

H3/6 Violet/White (AC) Tach Input 2

H3/7 Dark Blue No Connection 1

H3/8 Brown/Black (-) Horn 1

H3/9 Red/White (-) Trunk Release Output 1

H3/10 White/Green (-) Door Input 2

H3/11 Yellow/Green (+) Door Input 2

H3/12 Blue/Red No Connection

H3/13 Light Blue (-) Trunk Trigger Input 2

H3/14 Pink/Yellow (-) Activation (start) Input

H3/15 Dark Green No Connection 1

H3/16 Brown/White (+) Brake Input 2

H3/17 Brown (+) Siren Output 1

H3/18 Blue/White (-) Ground When Running (status) Output 1

MC501 harness (H4), 8 thick-gauge wires (optional)

Conn./Pin Color Description

H4/1 Pink/White (+) Ignition 2/Flex Relay Output 3

H4/2 Red/White (+) Fused (30A) Ignition 2/Flex Relay Input

H4/3 Pink (+) Ignition Output (also input to Yellow in ribbon cable)

H4/4 Red (+) 12 Volt (battery) Input

H4/5 Orange (+) Accessory Output

H4/6 Red (+) 12 Volt (battery) Input

H4/7 Green Starter Input (from key switch) 4

H4/8 Violet (+) Starter Output (to starter)

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are low current and a relay

may be necessary.

2. These connections are only required if the corresponding statuses are not supported by the ﬁrmware. See "Vehicle application guide" on page 5 for a

list of compatible features.

7Directed Digital Solutions VW08

Installation (wiring diagrams & vehicle wiring reference charts)

Type 1

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).

9: Black: (-) Ground

10: Red: (+) 12V Input

HS CAN 1 Low: Tan: 4

HS CAN 1 High: Tan/Black: 5

HS CAN 2 High: Orange/Green: 7

HS CAN 2 Low: Orange/Brown: 8

(-) Hood Input: Gray: 3

(+) Siren Output: Brown: 17

(+) Brake Activation Output: White/Red: 12

(-) PTS Output: Lt. Blue/Black: 13

5: Orange/Red: Key Wrap

4: Yellow/Red: Key Wrap

3: Brown/Red: Key Wrap

HS CAN 2 High:

Orange/Green

or Green, pin 40

HS CAN 2 Low:

Orange/Brown, pin 41

(+) 12V:

Red/Gray,

pin 1

1OBDII

Diagnostic

Connector

HS CAN 1 Low:

Orange/Brown,

pin 14

HS CAN 1 High:

Orange/Red or Red,

pin 6

The Remote Start

Safety Override

Switch MUST be in

the ON position.

Remote Start Safety

Override Switch

VESCM Right Connector

(black & white 73-pin conn.)

(-) PTS 1:

Brown/

Red, pin 3

(-) PTS 2:

Yellow/Green,

pin 6

(-) PTS 3

White/Red,

pin 5

Diode 1A

Diode

Push-to-Start Button

(black 6-pin connector

in center console)

See Vehicle Wiring

Reference Chart for

more information.

(+) Brake

VESCM (in upper driver kick panel)

Drivers door

Firewall

Siren

Hood Pin

8Directed Digital Solutions VW08

Vehicle wiring reference chart

This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to

www.directechs.com for additional information.

Wire Information Connector Information

Function Color Pin Polarity Location Color Pins Ref.

Audi A4 (Smart Key) 2017-2018

PTS 1 Brown/Red 3 (-) Push-to-Start button located in center console. Black 6 A

PTS 2 Yellow/Green 6 (-) Push-to-Start button located in center console. Black 6 A

PTS 3 White/Red 5 (-) Push-to-Start button located in center console. Black 6 A

HS CAN 1 High Orange/Red or Red 6 Data OBDII connector. White 16 B

HS CAN 1 Low Orange/Brown 14 Data OBDII connector. White 16 B

HS CAN 2 High Orange/Green or Green 40 Data VESCM right connector in upper driver kick panel. Black & White 73 C

HS CAN 2 Low Orange/Brown 41 Data VESCM right connector in upper driver kick panel. Black & White 73 C

12V Red/Gray 1 (+) VESCM right connector in upper driver kick panel. Black & White 73 C

Brake Black N/A (+) Main harness located on ﬁrewall (image below). N/A N/A D

Audi A4 Allroad (Smart Key) 2017-2018
