Directed DS4+ User manual

TL10
INSTALLATION GUIDE
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.
2017-05-29
© 2017 Directed, Vista CA
DS4+
Designed by Installers for Installers

Contents
Warning! Safety first ....................................................................................................................... 4
Introduction .................................................................................................................................... 5
Pre-installation and application warnings ..................................................................................... 5
Vehicle application guide........................................................................................................... 6
Wiring connections ......................................................................................................................... 7
Main harness (H1), 12-pin black connector .................................................................................. 7
Relay harness (H2), 10-pin white connector.................................................................................. 7
Data harness (H3), 8-pin white connector..................................................................................... 7
Analog input/output harness (H4), 22-pin white connector............................................................. 8
RF Port harness (H5), 2-pin white connector.................................................................................. 8
D2D harness (H6), 4-pin white (1) and black (2) connectors ........................................................... 8
Temperature sensor harness (H7), 2-pin black connector ................................................................ 8
Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)........................................ 9
Type 1 with T-Harness (THTON3) ................................................................................................ 9
Type 1 ................................................................................................................................... 10
Type 2 with T-Harness (THTON4) .............................................................................................. 12
Type 2 ................................................................................................................................... 13
Type 3 with T-Harness (THTON5) .............................................................................................. 15
Type 3 ................................................................................................................................... 16
Type 4 with T-Harness (THTON3) .............................................................................................. 18
Type 4 ................................................................................................................................... 19
Type 5 with T-Harness (THTON4) .............................................................................................. 21
Type 5 ................................................................................................................................... 22
Type 6 with T-Harness (THTON4) .............................................................................................. 24
Type 6 ................................................................................................................................... 25
Type 7 with T-Harness (THTON3) .............................................................................................. 27
Type 7 ................................................................................................................................... 28
Type 8 with T-Harness (THTON3) .............................................................................................. 30
Type 8 ................................................................................................................................... 31
Type 9 with T-Harness (THTON3) .............................................................................................. 33
Type 9 ................................................................................................................................... 34
Type 10 with T-Harness (THTON3) ............................................................................................ 36
Type 10 ................................................................................................................................. 37
Type 11 with T-Harness (THTON4) ............................................................................................ 39
Type 11 ................................................................................................................................. 40
Type 12 with T-Harness (THTON4) ............................................................................................ 42
Type 12 ................................................................................................................................. 43
Type 13 with T-Harness (THTON3) ............................................................................................ 45
Type 13 ................................................................................................................................. 46
Type 14 with T-Harness (THTON3) ............................................................................................ 48
Type 14 ................................................................................................................................. 49
Type 15 with T-Harness THTON4) ............................................................................................. 51
Type 15 ................................................................................................................................. 52
Type 16 with T-Harness (THTON3) ............................................................................................ 54
Type 16 ................................................................................................................................. 55

Configuring the system................................................................................................................... 57
Important! .............................................................................................................................. 57
Vehicles equipped with a manual transmission............................................................................ 57
RF Systems ............................................................................................................................. 57
8504D Combo Sensor............................................................................................................. 57
When used in conjunction with SmartStart.................................................................................. 57
D2D port configuration ............................................................................................................ 58
When used in conjunction with SmartStart.................................................................................. 58
D2D 1.0/2.0 port configuration ............................................................................................... 59
Module programming.............................................................................................................. 59
LED diagnostics and troubleshooting.......................................................................................... 60
Soft reset................................................................................................................................ 62
Hard reset .............................................................................................................................. 62
Learning the Tach (not needed with Virtual Tach) ............................................................................... 63
Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 63
Limited lifetime consumer warranty .................................................................................................. 64
Quick Reference Guide.................................................................................................................. 65

4DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.
• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never
operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:
• Never use a test light or logic probe when installing this unit. Always use a multimeter.
• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must
be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from
children all remote controls to assure that the system does not unintentionally remote start the vehicle.
• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.
ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or
death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with
the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the
neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to fix the problem
immediately.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF
OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE
OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When testing to ensure the
installation is working properly, only remote start the vehicle in neutral gear, on a flat surface and with a functional, fully engaged
parking brake. Do not allow anyone to stand in front of or behind the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such
vehicles may pose certain risk.

5DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Introduction
The TL10 firmware for DS4+ is compatible with specific TOYOTA and LEXUS vehicles. It is a complete solution
for remote start, security (when security features are enabled), bypass, and features built in Bluetooth 4.0
allowing you to configure and control your system. This guide provides information on the installation of the
module as an analog unit, however a digital solution could be available for your vehicle. Please refer to the
DirectLink application or www.directechs.com for more information about which configuration is best for your
application.
Warning! This module is designed to be configured using the DirectLink application for mobile devices, however it can also
be configured using the web tool located at www.directechs.com. To download the DirectLink mobile application, please visit the
Google Play or Apple store.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
THTON3,
THTON4, THTON5
Keys required for
programming 1Keys required for operation 0
This guide is compatible with TL10 v2.12+.
The optional Plug & Play THTON3, THTON4 or THTON5 T-Harnesses are sold separately. Refer to the "Vehicle wiring
reference chart" for vehicle and t-harness compatibility.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
It is important to check that the fuses are positioned correctly in the module. Refer to the "Fuse selection" section following
each installation type for more information.
Refer to the "Vehicle wiring reference chart" following each installation type.
It is important to make sure you DO NOT connect the keysense wire in the installation for each of these vehicles or you will
encounter issues when attempting to start the vehicle.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during Directed DS4 module flashing.
[3] The Green wire is only required for starter disable and antigrind connections.
[4] Autolight Interrupt connection required only if the vehicle is equipped with automatic headlights.
[5] SIL Interrupt connection required ONLY if the vehicle is equipped with TPMS (Tire Pressure Monitoring System).
[6] Trunk release connection required when not available through Data.
Additional parts required (maximum required):
Diode 6A
0 x 1A Diodes 86 85
30
87a
87
0 x Relay
Resistor 100Ω
0 x Resistor
Fuse 7.5A
0 x Fuse

6DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Vehicle application guide
The following table lists the vehicles and features which are compatible with this product. The number assigned to each year
allows you to determine which installation type should be used for your vehicle.
Vehicles
2018 2017 2016 2015 2014 2013
PK-Immobilizer Bypass-Data No Key Req'd AV-Auto Headlamp Shutoff AV-Parking Lights Control DL-Arm Factory Security DL-Disarm Factory Security DL-Door Lock Control DL-Door Unlock DL-Driver Priority Unlock DL-Sliding Door Control Driver DL-Sliding Door Control Passenger DL-Trunk / Hatch Release FOB-Control of aftermarket alarm with OEM remote RS-3x LOCK START (Start control using OEM Remote) RS-SmartStart RS-Tach / RPM Output SS-Entry Monitoring ALL Door Pins SS-Entry Monitoring Hood Pin SS-Entry Monitoring Trunk/Hatch Pin SS-Factory Alarm Trigger Monitoring ST-Brake Status (foot brake) ST-Door Locks Status ST-E-Brake Status ST-Ignition Status
Scion
iM
(
H Ke
y)
1 •••••••• ••••••••••••
To
y
ota
Camr
y
(
H Ke
y)
151515 •••••••• •••••••••••••
Corolla
(
H Ke
y)
8111
•••••••• •••••••••••••
Corolla IM
(
H Ke
y)
8 •••••••• •••••••••••••
CH-R
(
H Ke
y)
14 •••••••• •••••••••••••
Hi
g
hlander
(
H Ke
y)
13444 •••••••• •••••••••••••
Prius c
(
H Ke
y)
966 •••••••• ••••••••••••
RAV4
(
H Ke
y)
77161616•••••••• ••••••••••••
Se
q
uoia
(
H Ke
y)
222 •••••••• •••••••••••••
Sienna
(
H Ke
y)
333 •••••••••••••••••••••••
Tacoma
(
H Ke
y)
10 •••••••• •••••• •••••
Yaris Hatchback
(
H Ke
y)
W/ OEM Alarm 11 5 5
•••••••• ••••••••••••
Yaris Hatchback
(
H Ke
y)
W/O OEM Alarm 12 6 6 • • • • • •
••••••••••••
Le
g
end:
AV: Horn & Lights Controls
DL: OE Door Lock & Alarm Controls
FOB: S
y
nc CAN Interface w/ FOB Remote
PK: Transponder & Immobilizer Override
RS: Remote Start & Engine Controls
SS: Integrated Security & Monitoring
ST: Function/Feature Status
Key Types
Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings. A“H”
means the vehicle is compatible with TL10 firmware. “G” or a dot “.” indicates the vehicle is not compatible with this firmware.
Key Type
Standard Key
G-stamped keys
H-stamped keys
For vehicles with G-stamped key, see the
TL7 firmware. TL11 works only with standard
key.
For vehicles with dot-stamped key, see the TL11
firmware. TL11 works only with standard key.
H
Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings.
A “H” means the vehicle is compatible with TL10 firmware.

7DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Wiring connections
The wiring connections listed below are specific to this firmware.
Main harness (H1), 12-pin black connector
Conn./Pin Color Description
H1/1 Blue/White Relay 1 N.C. – SIL Interrupt (vehicle side) 1
H1/2 Blue/Red Relay 1 N.O. – No Connection 1
H1/3 Blue Relay 1 COM – SIL Interrupt (connector side) 1
H1/4 White/Brown Relay 3 N.C. – No Connection 1
H1/5 White Relay 3 COM – (+) Starter 2 Output 1
H1/6 Red (+) 12 Volt (Battery)
H1/7 Lt. Green/Red Relay 2 N.O. – No Connection 1
H1/8 Lt. Green Relay 2 COM – Autolight Interrupt (vehicle side)1
H1/9 Lt. Green/White Relay 2 N.C. – Autolight Interrupt (connector side) 1
H1/10 Black (-) Ground
H1/11 White Relay 3 COM – (+) Starter 2 Output 1
H1/12 Red (+) 12 Volt (Battery)
Relay harness (H2), 10-pin white connector
Conn./Pin Color Description
H2/1 N/A No Connection
H2/2 Red/Black (+) 12 Volt Input (Accessory/Starter)
H2/3 Pink/Black Relay N.C. – Flex 1
H2/4 Pink/White Relay COM – Flex 1
H2/5 Red (+) 12 Volt Input (Ignition)
H2/6 Green Relay COM – (+) Starter 1
H2/7 Violet Relay N.C. – (+) Starter 1
H2/8 Orange Relay COM – (+) Accessory 1
H2/9 Red/White (+) 12 Volt Input (Flex)
H2/10 Pink Relay COM – (+) Ignition
Data harness (H3), 8-pin white connector
Conn./Pin Color Description
H3/1 Tan HS CAN 1 Low
H3/2 Tan/Black HS CAN 1 High
H3/3 Orange/Brown HS CAN 2 Low
H3/4 Orange/Green HS CAN 2 High
H3/5 Lt. Green No Connection
H3/6 Violet/Brown No Connection
H3/7 Orange/Black RDA
H3/8 Yellow/Black SIL Data
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.

8DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Analog input/output harness (H4), 22-pin white connector
Conn./Pin Color Description
H4/1 Lt. Green/Black (-) Parking Lights Output 1
H4/2 Blue/White (-) Ground When Running (Status) Output 1
H4/3 Dk. Green/Black (-) Lock Output 1
H4/4 Red/White (-) Trunk Release Output 1
H4/5 Brown/Black (-) Horn Output 1
H4/6 Brown/White (-) AUX 1 Output 1
H4/7 White (+) AUX 1 Output 1
H4/8 Violet/Black (+) AUX 4 Output 1
H4/9 Dk. Blue/Black (-) Unlock Output 1
H4/10 Lt. Blue/Black (-) FAD Output 1
H4/11 Brown/Red (+) Siren Output 1
H4/12 Pink (+) Ignition Sense Input
H4/13 Violet (+) Door Sense Input 2
H4/14 Brown (+) Brake Input 2
H4/15 White/Blue (-) Activation Input 2
H4/16 Red/Blue (-) Valet Switch 2
H4/17 Black/White (-) E-Brake Input 2
H4/18 Orange/Black (-) Instant Alarm Trigger Input 2
H4/19 Blue (-) Trunk Sense Input 2
H4/20 Green (-) Door Sense Input 2
H4/21 Gray (-) Hood Pin Input 2
H4/22 Violet/White (AC) Tach Input
RF Port harness (H5), 2-pin white connector
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
D2D harness (H6), 4-pin white (1) and black (2) connectors
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Black (-) Ground
H6/3 Green (Data) RX
H6/4 Red (+) 12 Volt
Temperature sensor harness (H7), 2-pin black connector
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 6 for a
list of compatible features. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they
are low current and a relay may be necessary.

9DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)
Type 1 with T-Harness (THTON3)
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 11 for important information on this installation.
FUSES
BODY ECU
OR
Body ECU
Connector
456
1617
18
131415
10
11
12
1
23
789
19
Autolight: Violet, pin 20
20
Headlight Switch
Autolight Interrupt (veh. side): Lt. Green
Autolight Interrupt (conn. side): Lt. Green/White
Ignition Connector
RDA: Orange/Black
Body ECU Connector
(middle or underside conn. of ECU)
4 56
161718
28 2930
131415
252627
101112
222324
123
789
192021
RDA: Green, pin 16
THTON3
(optional T-Harness)
8-pin White
Connector
12-pin Black
Connector
10-pin White
Connector
Diagnostic Connector OBDII
16
8
9
1
Cut
Refer to the "Vehicle wiring reference
chart" for more specific T-harness
compatibility.
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
15
30
20
20
5
15
SIL Interrupt (veh. side): Blue/White
SIL Interrupt (conn. side): Blue
Cut
Tire Pressure
Warning ECU
(white conn.
on dash fuse box)
SIL:
Blue,
pin 28
111
12
13
14
15
16
26
27
28
29
30
31
17
18
19
20
21
22
32
33
34
35
36
37
23
24
25
38
39
40
2
3
4
5
6
7
8
9
10

10 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 1
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 11 for important information on this installation.
FUSES
BODY ECU
OR
Body ECU
Connector
456
1617
18
131415
10
11
12
1
23
789
19
Autolight: Violet, pin 20
16
8
9
1
Diagnostic
Connector OBDII
HS CAN Low: White, pin 14
HS CAN High:
Red, pin 6
SIL Data: Lt. Green, pin 7
20
Headlight Switch
(+) Ignition Input/Ouput: Pink: 10
(+) 12V Ignition Input: Red: 5
(+) 12V Accessory Output: Orange: 8
(+/-) Flex Input: Red/White: 9
(+) 12V Input: Red/Black: 2
(+/-) Flex Output: Pink/White: 4
(+) 12V Starter Output (starter side): Violet: 7
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Starter Disable (key side): Green: 6
Siren
Hood Pin
Autolight Interrupt (veh. side): Lt. Green: 8
Autolight Interrupt (conn. side): Lt. Green/White: 9
(-) Ground: Black: 10
(+) Starter 2 Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
HS CAN Low 1: Tan: 1
HS CAN High 1: Tan/Black: 2
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
Body ECU Connector
(middle or underside conn.of ECU)
456
161718
282930
131415
252627
101112
222324
123
789
192021
RDA: Green, pin 16
1
Dash Fuse Box
(white conn.)
(+) 12V:
White, pin 1
Cut
Refer to the Vehicle Wiring
Reference Information for wire
and connector details.
Ignition Connector
67
1234
8 5
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
15
30
20
20
5
15
Tire Pressure
Warning ECU
(white conn.
on dash fuse box)
SIL Interrupt (veh. side): Blue/White: 1
SIL Interrupt (conn. side): Blue: 3
Cut
111
12
13
14
15
16
26
27
28
29
30
31
17
18
19
20
21
22
32
33
34
35
36
37
23
24
25
38
39
40
2
3
4
5
6
7
8
9
10
SIL:
Blue,
pin 28

11 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
T-Harness compatibility
Vehicle Year T-Harness
Scion IM (H Key) 2016 THTON3
Toyota Corolla (H Key) 2014-2016 THTON3
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Scion iM (H Key) 2016
HS CAN High Red 6 Data OBDII. White 16 A
HS CAN Low White 14 Data OBDII. White 16 A
SIL Lt. Green 7 Data OBDII. White 16 A
RDA Green 16 Data Body ECU, below drivers fuse box. White 30 B
Autolights Violet 20 Cut Headlight switch. White 20 C
Accessory Black 7 (+) Ignition switch. White 8 D
Ignition 1 Green 8 (+) Ignition switch. White 8 D
Ignition 2 Gray 3 (+) Ignition switch. White 8 D
Starter 1 White 2 (+) Ignition switch. White 8 D
12V White 1 (+) Dash fuse box. White 1 E
SIL Interrupt Blue 28 Cut Rear of dash fusebox. White 40 F
Corolla (H Key) 2014-2016
HS CAN High Red 6 Data OBDII. White 16 A
HS CAN Low White 14 Data OBDII. White 16 A
SIL Lt. Green 7 Data OBDII. White 16 A
RDA Green 16 Data Below drivers fuse box. White 30 B
Autolights Violet 20 Cut Headlight switch. White 20 C
Accessory Black 7 (+) Ignition switch. White 8 D
Ignition 1 Gray 3 (+) Ignition switch. White 8 D
Ignition 2 Green 8 (+) Ignition switch. White 8 D
Starter 1 White 2 (+) Ignition switch. White 8 D
12V White 1 (+) Dash fuse box. White 1 E
SIL Interrupt Blue 28 Cut Rear of dash fusebox. White 40 F

12 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 2 with T-Harness (THTON4)
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 14 for important information on this installation.
Body ECU
Connector
10 9 8 7 36 25 14
20
28
14
24
15 11
21
16 12
22
17
25
13
23
18
26
19
27
Body ECU Conn.
(middle Connector left side
of steering column)
RDA: Violet, pin 12 RDA: Orange/Black
SIL Interrupt (veh. side): Blue/White
Autolight Interrupt (veh. side): Lt. Green
Autolight Interrupt (veh. side): Lt. Green/White
SIL Interrupt (conn. side): Blue
456
1617 18 131415
10
1112
123
789
19
Autolight: Green, pin 19
20
SIL: Blue,
pin 10
6 5 4 3 2 1
12 1110 9 8 7
Headlight Switch
Tire Pressure
Warning ECU
(behind glove box)
Ignition Connector
THTON4
(optional T-Harness)
16
8
9
1
Diagnostic Connector OBDII
Cut
Cut
Refer to the "Vehicle
wiring reference chart"
for more specific T-harness
compatibility.
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
8-pin White
Connector
12-pin Black
Connector
10-pin White
Connector
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
5

13 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 2
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 14 for important information on this installation.
Body ECU
Connector
SIL Interrupt (veh. side): Blue/White: 1
Autolight Interrupt (veh. side): Lt. Green: 8
Autolight Interrupt (conn. side): Lt. Green/White: 9
(-) Ground: Black: 10
(+) 12V Input: Red: 6 & 12
(+) Ignition Input/Ouput: Pink: 10
(+) 12V Ignition Input: Red: 5
(+) 12V Accessory Output: Orange: 8
(+/-) Flex Input: Red/White: 9
(+) 12V Input: Red/Black: 2
(+/-) Flex Output: Pink/White: 4
(+) 12V Starter Output (starter side): Violet: 7
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Starter Disable (key side): Green: 6
Siren
Hood Pin
SIL Interrupt (conn. side): Blue: 3
HS CAN 1 Low: Tan: 1
HS CAN 1 High: Tan/Black: 2
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
16
8
9
1Diagnostic
Connector OBDII
HS CAN Low: White, pin 14
HS CAN High: Violet,
pin 6
SIL: Tan, pin 7
456
1617 18 131415
10
1112
123
789
19
Autolight: Green, pin 19
20
SIL: Blue, pin 10
6 5 4 3 2 1
12 11
10 9 8 7
10 9 8 7 36 25 14
20
28
14
24
15 11
21
16 12
22
17
25
13
23
18
26
19
27
Body ECU Connector
(middle conn. left side
of steering column)
Headlight Switch
RDA: Violet, pin 12
Tire Pressure
Warning ECU
(behind glove box)
(+) 12V: Black, pin 1
1
Dash Fuse Box
(white conn.)
Refer to the Vehicle Wiring
Reference Information for wire
and connector details.
Ignition Connector
67
1234
8 5
Cut
Cut
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
5

14 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
T-Harness compatibility
Vehicle Year T-Harness
Toyota Sequoia (H Key) 2015-2017 THTON4
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Sequoia (H Key) 2015-2017
HS CAN High Violet 6 Data OBDII. White 16 A
HS CAN Low White 14 Data OBDII. White 16 A
SIL Tan 7 Data OBDII. White 16 A
SIL Interrupt Blue 10 Data TPMS warning ECU behind glove box. White 12 B
RDA Violet 12 Data Main body ECU left of steering column. White 28 C
Autolights Green 19 Cut Headlight switch. White 20 D
Accessory Gray 2 (+) Ignition switch. White 8 E
Ignition 1 Black 6 (+) Ignition switch. White 8 E
Ignition 2 Lt. Green 1 (+) Ignition switch. White 8 E
Starter Green 7 (+) Ignition switch. White 8 E
12V Black 1 (+) Dash fuse box. White 1 F

15 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 3 with T-Harness (THTON5)
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 17 for important information on this installation.
Body ECU
Connector
SIL Interrupt (veh. side): Blue/White
Autolight Interrupt (veh. side): Lt. Green
Autolight Interrupt (conn. side): Lt. Green/White
SIL Interrupt (conn. side): Blue
456
1617 18 131415
10
1112
123
789
19
Autolight: Violet, pin 19
20
SIL: White,
pin 10
6 5 4 3 2 1
12 1110 9 8 7
Headlight Switch
Tire Pressure Warning ECU
(left of steering column)
Ignition Connector
RDA: Orange/Black
THTON5
(optional T-Harness)
16
8
9
1
Diagnostic Connector OBDII
Cut
Cut
RDA: Pink, pin 26
Body ECU Connector
(middle or underside conn. of ECU)
456
16 1718
28 2930
131415
25 26 27
101112
222324
123
789
192021
Refer to the "Vehicle
wiring reference chart"
for more specific T-harness
compatibility.
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
8-pin White
Connector
12-pin Black
Connector
10-pin White
Connector
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
5

16 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 3
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 17 for important information on this installation.
Body ECU
Connector
SIL Interrupt (veh. side): Blue/White: 1
Autolight Interrupt (veh. side): Lt. Green: 8
Autolight Interrupt (conn. side): Lt. Green/White: 9
(-) Ground: Black: 10
(+) 12V Input: Red: 6 & 12
(+) Ignition Input/Ouput: Pink: 10
(+) 12V Ignition Input: Red: 5
(+) 12V Accessory Output: Orange: 8
(+/-) Flex Input: Red/White: 9
(+) 12V Input: Red/Black: 2
(+/-) Flex Output: Pink/White: 4
(+) 12V Starter Output (starter side): Violet: 7
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Starter Disable (key side): Green: 6
Siren
Hood Pin
SIL Interrupt (conn. side): Blue: 3
HS CAN 1 Low: Tan: 1
HS CAN 1 High: Tan/Black: 2
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
16
8
9
1Diagnostic
Connector OBDII
HS CAN Low: White, pin 14
HS CAN High: Red,
pin 6
SIL: White,
pin 7
456
1617 18 131415
10
1112
123
789
19
Autolight: Violet, pin 19
20
SIL: White,
pin 10
6 5 4 3 2 1
12 1110 9 8 7
Headlight Switch
Tire Pressure
Warning ECU
(left of
steering column)
Refer to the Vehicle Wiring
Reference Information for wire
and connector details.
Ignition Connector
67
1234
8 5
RDA: Pink, pin 26
Body ECU Connector
(middle or underside conn. of ECU)
456
16 1718
28 2930
131415
25 26 27
101112
222324
123
789
192021
Cut
Cut
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
5

17 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
T-Harness compatibility
Vehicle Year T-Harness
Toyota Sienna (H Key) 2015-2017 THTON5
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Sienna (H Key) 2015-2017
HS CAN High Red 6 Data OBDII. White 16 A
HS CAN Low White 14 Data OBDII. White 16 A
SIL White 7 Data OBDII. White 16 A
SIL Interrupt White 10 Data ECU left side of the dash fuse box. White 12 B
RDA Pink 26 Data Middle Plug main body ECU left of steering column. White 30 C
Autolights Violet 19 Cut Headlight switch. White 20 D
Accessory Blue 3 (+) Ignition switch. White 8 E
Ignition 1 Black 6 (+) Ignition switch. White 8 E
Ignition 2 Yellow 4 (+) Ignition switch. White 8 E
Starter Red 8 (+) Ignition switch. White 8 E
12V Red 7 (+) Ignition switch. White 8 E

18 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 4 with T-Harness (THTON3)
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 20 for important information on this installation.
Body ECU
Connector
456
161718
282930
131415
252627
101112
222324
123
789
192021
RDA: Lt. Green, pin 4
456
1617 18 131415
10
1112
123
789
19
20
Autolight: Black, pin 20
Body ECU Connector
(middle conn. left side of steering column)
Headlight Switch
Autolight Interrupt (veh. side): Lt. Green
Autolight Interrupt (conn. side): Lt. Green/White
RDA: Orange/Black
Cut
Ignition Connector
THTON3
(optional T-Harness)
16
8
9
1
Diagnostic Connector OBDII
Refer to the "Vehicle
wiring reference chart"
for more specific T-harness
compatibility.
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
8-pin White
Connector
12-pin Black
Connector
10-pin White
Connector
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
15
30
20
20
5
15
SIL Interrupt (veh. side): Blue/White
SIL Interrupt (conn. side): Blue
Cut
Tire Pressure Warning ECU
(white conn. on Body ECU)
SIL:
Yellow,
pin 32
36
35
34
33
31
30
29
28
27
26
25
24
23
22
21
20
19 7
6
5
4
3
2
1
18
17
16
15
14
13
8
9
10
11
12
32

19 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Type 4
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 20 for important information on this installation.
(+) Ignition Input/Ouput: Pink: 10
(+) 12V Ignition Input: Red: 5
(+) 12V Accessory Output: Orange: 8
(+/-) Flex Input: Red/White: 9
(+) 12V Input: Red/Black: 2
(+/-) Flex Output: Pink/White: 4
(+) 12V Starter Output (starter side): Violet: 7
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Starter Disable (key side): Green: 6
Siren
Hood Pin
Autolight Interrupt (veh. side): Lt. Green: 8
Autolight Interrupt (conn. side): Lt. Green/White: 9
(-) Ground: Black: 10
(+) Starter 2 Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
HS CAN Low 1: Tan: 1
HS CAN High 1: Tan/Black: 2
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
16
8
9
1Diagnostic
Connector OBDII
HS CAN Low: White, pin 14
HS CAN High:
Violet, pin 6
SIL Data: Lt. Blue, pin 7
456
161718
282930
131415
252627
101112
222324
123
789
192021
RDA: Lt. Green, pin 4
456
1617 18 131415
10
1112
123
789
19
20
Refer to the Vehicle Wiring
Reference Information for wire
and connector details.
Ignition Connector Autolight: Black, pin 20
Body ECU Conn.
(middle Connector
left side of steering column)
Headlight Switch
67
1234
8 5
Cut
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
15
30
20
20
5
15
Cut
Tire Pressure Warning ECU
(white conn. on Body ECU)
SIL:
Yellow,
pin 32
36
35
34
33
31
30
29
28
27
26
25
24
23
22
21
20
19 7
6
5
4
3
2
1
18
17
16
15
14
13
8
9
10
11
12
32
SIL Interrupt (veh. side): Blue/White: 1
SIL Interrupt (conn. side): Blue: 3

20 DS4+ TL10
© 2017-05-29 Directed. All rights reserved.
Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
T-Harness compatibility
Vehicle Year T-Harness
Toyota Highlander (H Key) 2014-2016 THTON3
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Highlander (H Key) 2014-2016
HS CAN High Violet 6 Data OBDII. White 16 A
HS CAN Low White 14 Data OBDII. White 16 A
SIL Lt.Blue 7 Data OBDII. White 16 A
RDA Lt.Green 4 Data Middle Plug main body ECU left of steering column. White 30 B
Autolights Black 20 Cut Headlight switch. White 20 C
Accessory Gray 7 (+) Ignition switch. White 8 D
Ignition 1 Black 3 (+) Ignition switch. White 8 D
Ignition 2 Green 8 (+) Ignition switch. White 8 D
Starter 1 Blue 2 (+) Ignition switch. White 8 D
Starter 2 Gray 6 (+) Ignition switch. White 8 D
12V Black 4 (+) Ignition switch. White 8 D
SIL Interrupt Yellow 32 Cut Body ECU left of steering column. White 36 E
