dji DF01 User manual

v1.0 2020.10
DJI RONIN
3D Focus System
User Guide
使用说明
使用說明
ユーザーガイド
사용자 가이드
Bedienungsanleitung
Guía del usuario
Guide de l'utilisateur
Guida all’uso
Gebruiksaanwijzing
Manual do utilizador
Guia do usuário
Руководство пользователя

2
A.
B.
1
2
2
1

3
EN
Disclaimer and Warning
Congratulations on purchasing your new DJI OSMOTM product. Please read this
entire document and all safe and lawful practices DJI OSMO provided carefully
before use. Failure to read and follow instructions and warnings may result in serious
injury to yourself or others, damage to your DJI OSMO product, or damage to other
objects in the vicinity. By using this product, you hereby signify that you have read
this document carefully and that you understand and agree to abide by all terms and
conditions of this document and all relevant documents of this product. You agree
to use this product only for purposes that are proper. You agree that you are solely
responsible for your own conduct while using this product, and for any consequences
thereof. DJI OSMO accepts no liability for damage, injury or any legal responsibility
incurred directly or indirectly from the use of this product.
RONIN is a trademark of SZ DJI OSMO TECHNOLOGY CO., LTD. (abbreviated as
“DJI OSMO”) and its affiliated companies. Names of products, brands, etc., appearing
in this document are trademarks or registered trademarks of their respective owner
companies. This product and document are copyrighted by DJI OSMO with all rights
reserved. No part of this product or document shall be reproduced in any form without
the prior written consent or authorization of DJI OSMO.
This document and all other collateral documents are subject to change at the sole
discretion of DJI OSMO. For up to date product information, visit http://www.dji.com
and click on the product page for this product.
This document is available in various languages. In the event of divergence among
different versions, the English version shall prevail.
Introduction
The DJI RONINTM 3D Focus System can be installed onto the camera or camera
cage to assist manual lens focus. The 3D Focus System can only be used to focus
on subjects in the center of the camera view. It is not recommended to set the focal
length of the lens to longer than 85 mm when using the 3D Focus System.


4
Overview
1. Status Indicator
2. AF/MF Switch Button
3. USB-C Port
4. 1/4”-20 Thread to Cold Shoe Adapter
5. Thumb Screw
6. Mounting Base
7. Lock Wheel
8. Infrared Distance Sensor (TOF)
9. USB-C Cable
×1
×1
1
2
3
45
6
7
8
9
3
Installation and Connection
Installing on Camera Cold Shoe (Figure A)
1. Remove the 1/4”-20 thread to cold shoe adapter.
2. Install the 3D Focus System on the cold shoe of the camera and rotate the lock
wheel to fix firmly.
3. Use two USB-C cables to connect the 3D Focus System to the USB-C port and
focus motor of the gimbal.
DO NOT directly insert third-party cables or devices into either USB-C ports
of the 3D Focus System. Otherwise, the 3D Focus System or third-party
devices may be damaged by the power supply.
Installing on Camera Cage (Figure B)
1. Use a 1/4”-20 thread to cold shoe adapter to install the 3D Focus System onto the
camera cage and rotate the thumb screw to fix firmly.
2. Use two USB-C cables to connect the 3D Focus System to the USB-C port and
focus motor of the gimbal.
Using the 3D Focus System
A focus motor is required in order to use the 3D Focus System.

5
Calibration
The 3D Focus System must be calibrated before using for the first time. Follow the
steps below to calibrate. A person or large object must be placed in the center of the
camera view in order to calibrate.
1. Power on the DJI RS 2 gimbal, swipe up on the touchscreen, tap Dial Functions,
and Focus Motor.
2. Return to the home screen, swipe left, tap Create, swipe up, and tap 3D Focus .
3. Tap Lens Calibration. Perform Focus Motor Calibration by following the prompts and
select the focal length.
AF
MF
Lens Config
Lens1
Focal Len
50mm
3D Focus
Lens Calibration
4. Focus the 3D Focus Sytem on a person or large object in the center of the camera view
that is approx. 1 m away. Keep the camera stable and DO NOT move the gimbal
until the progress bar is completely green. Adjust the front dial until the subject is in
focus and tap Confirm.
Keep camera stable
NOW: 1.1m
Lens 1 Calibration
Focus on subject
around 1m away
Lens 1 Calibration
Confirm
Keep camera stable
Focus on subject
around 1m away
NOW: 1.1m
Confirm
5. Repeat the previous step with a person or large object that is approx. 4 m away.
The 3D Focus System must be recalibrated if the lens is replaced.
It is recommended to focus on a person during calibration.

6
Lens Conáguration
Lens configuration can be used to store up to three sets of calibrated lens parameters.
Once stored, users can select parameters directly by tapping Lens Configuration.
Usage
If the camera lens is replaced, the focus motor must be recalibrated the next time the
3D Focus System is powered on. To calibrate the focus motor, either double tap the
AF/MF Switch button or follow the prompts to calibrate the focus motor after selecting
the lens in Lens Configuration.
To switch between AF and MF, press the AF/MF Switch button once or switch between
AF and MF on the touchscreen. Once in AF, the 3D Focus System will be active and
the status indicator turns solid green.
DO NOT hot plug and unplug the 3D Focus System. Otherwise, the
parameters will be lost and the focus motor will need to be calibrated again.
Only manual focus lenses with a mechanical limit are supported.
DO NOT use corrosive organic solvents such as alcohol to wipe the lens of
the 3D Focus System.
Make sure the infrared distance sensor (TOF) is not blocked by the hood
or filter of the camera. Otherwise, the auto focus of the 3D Focus will be
inaccurate.
Status Indicator Description
Status Indicator Description
Solid green The 3D Focus System is working in AF
Solid yellow The 3D Focus System is calibrated and working in MF
Solid red The 3D Focus System needs calibrating
Specications
Model DF01
Weight 54.8 g
