DKN technology SPEEDBIKE PRO X User manual

1
SPEEDBIKE PRO X
OWNER’S MANUAL
WEBSITE MANUAL
OWNER’S MANUAL

2
1
S
SP PI IN NN NI IN NG G B BI IK KE E
IMPORTANT !
Please read all instructions carefully before using this product.
Retain this manual for future reference.
The specifications of this product may vary slightly from the illustrations and are subject to change
without notice.

3
2
Before You Start
Thank you for purchasing our SPINNING Bike! For your safety and benefit, read this manual carefully
before using the machine.
Prior to assembly, remove components from the box and verify that all the listed parts were included.
Assembly instructions are described in the following steps and illustrations.
IMPORTANT SAFETY NOTICE
PRECAUTIONS
BE SURE TO READ THE ENTIRE MANUAL BEFORE YOU ASSEMBLE OR OPERATE
YOUR MACHINE. IN PARTICULAR, NOTE THE FOLLOWING SAFETY
PRECAUTIONS:
1、Check all the screws, nuts and other connections before using the machine for the first time and ensure
that the trainer is in the safe condition.
2、Set up the machine in a dry level place and leave it away from moisture and water.
3、Place a suitable base (e.g. rubber mat, wooden board etc.) beneath the machine in the area of assembly
to avoid dirt and etc..
4、Before beginning training, remove all objects within a radius of 2 meters from the machine.
5、DO NOT use aggressive cleaning articles to clean the machine, Only use the supplied tools or suitable
tools of your own to assemble the machine or repair any parts of machine. Remove drops of sweat from
the machine immediately after finishing training.
6、Your health can be affected by incorrect or excessive training. Consult a doctor before beginning a
training program. He can define the maximum setting (Pulse. Watts. Duration of training etc) to which
you may train yourself and can get precise information during training. This machine is not suitable for
therapeutic purpose.
7、Only do training on the machine when it is in correct working way. Use only original spare parts for
any necessary repairs.
8、This machine can be used for only one person’s training at a time.
9、Wear training clothes and shoes which are suitable for fitness training with the machine. Your training
shoes should be appropriate for the trainer.
10、If you have a feeling of dizziness, sickness or other abnormal symptoms, please stop training and
consult a doctor asap.
11、People such as children and handicapped persons should only use the machine in the presence of
another person who can give aid and advice.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT.
SAVE THESE INSTRUCTIONS / Maximum user’s weight: 150 KG

4
3
WARNING! Consult your physician before starting with any exercise program. He can advise on the
kind of training and which impact is suitable.
WARNING! This machine is not suitable for therapeutic or medical purpose.
WARNING! Over exercising may result in serious injury or death. If you experience dizziness,
nausea, chest pain, or any other abnormal symptoms STOP EXERCISING IMMEDIATELY AND
CONSULT A PHYSICIAN WITHOUT DELAY.
WARNING! Inappropriate use of this machine such as while under the influence of drugs or alco-
hol, not in line with instructions or excessive usage, may result serious injury or death.
WARNING! Incorrect/excessive training may cause health injuries.
►The owner’s manual is only for customers’ reference.
►The supplier cannot guarantee for mistakes occurring due to translation or change in
technical specification of the product.
►DKN-Technology ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR
PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT

5
4
EXPLODED DIAGRAM

6
5
PARTS LIST
No.
Item Name
Qty
No.
Item Name
Qty
1
Main Frame
1
29
Rear Foot Rest
2
2
Handlebar Post
1
30
Adjusting Foot Pad
4
3
Steel Ring
1
31
Rear Post Bushing
1
4
Front Stabilizer
1
32
Roller
2
5
Rear Stabilizer
1
33
Lower glide cap
4
6
Saddle Post
1
34
Upper glide cap 1
2
7
Handlebar Joint
1
35
Upper glide cap B
2
8
Saddle upper glide
1
36
Locking Handlebar Joint
2
9
Handlebar upper glide
1
37
Screw Cap
2
10
Foot Rest
1
38
Handlebar Fixing Holder
1
11
Cross tapping screw
ST4.2x16xΦ8
20
39
Saddle
1
12
Cross pan head screw
M4×10
16
40L/R
L/R Pedals
1 each
13
Locking Screw
2
41
Fixing Holder
1
14
T-shape Nut
2
42
Square neck bolt
2
15
Quick Clamp Handle
2
43
Pressure Spring
2
16
Brake Handle
1
44
End Cap
1
17
Inner Hex Bolt M6×10
2
45
Inner Hex Bolt M8×15
2
18
Inner Hex Bolt M56×15
2
46
Packing tube
2
19
Inner pan head screw
M10x25
8
47
Extension wire 1
1
20
Inner sank head screw
M8x15
3
48
Extension wire 2
1
21
Spring Washer D10
8
49
Flat washer D8
3
22
Flat Washer D10xΦ20x2
8
50
Connecting tube
1
23
Hex Nut M10x H7 x S17
4
51
Computer bracket
1
24
Hex Bolt M10X50
2
52
Display screen
1
25
Nylon Nut M10
2
53
Cross pan head screw M5 x
10
4
26
Arch Washer D10xΦ
25x2
16
54
Nylon nut M8
3
27 L/R
L/R crank
1 each
55
Alloy sleeve
2
28 L/R
Front L/R Foot Rest
1 each
56
Hex pan head screw M8 x 90
x L20
1
NOTE:
Most of the listed assembly hardware has been packaged separately, but some hardware items have been
preinstalled in the identified assembly parts. In these instances, simply remove and reinstall the hardware as
assembly is required.
Please reference the individual assembly steps and make note of all preinstalled hardware.
PREPARATION: Before assembling, make sure that you will have enough space around the item; Use the
present tooling for assembling; before assembling please check whether all needed parts are available.
It is strongly recommended this machine to be assembled by two or more people to avoid possible injury.

7
6
ASSEMBLY INSTRUCTION
STEP 1
1. Take off Packing Tube (46) from Main Frame (1), keep well the Packing Tube (46) in case of
packing next time.
2. Lock Front Stabilizer (4) and Rear Stabilizer (5) to Main Frame (1) by using Inner pan head screw
M10x25 (19), Spring Washer D10, Flat Washer D10xΦ20x2 (22) and Arch Washer D10xΦ25x2 (26)
STEP 2
1. Lock L/R Pedals (40L/R) to L/R Cranks (27L/R), lock Left Pedal (40L) counter clock
wisely, Right Pedal (40R) clock wisely., make sure the L/R Pedals (40L/R) are
locked tightly during exercise.

8
7
STEP 3
1. Use open end wrench to lock Saddle (39) to Saddle Post (6); loosing Quick Clamp Handle (15) to adjust
Saddle Post (6), make sure Saddle Post (6) and Saddle (39) are locked tightly before exercise.

9
8
STEP 4
1. Lock Handlebar upper glide (9) to Handlebar Joint (7) by Inner Hex Bolt M8×15 (45).
2. Insert Locking Screw (13) to Handlebar Joint (7); insert Pressure Spring (43) and T-shape Nut (14) to the bottom
of Handlebar upper glide (9) to lock with Locking Screw (13);
3. Unlock Lower glide cap (33) from Handlebar Post (2) by using multifunctional cross wrench, and then lock
Handlebar Joint (7) to Handlebar Post (2), shown as Pic A.
STEP 5
1. Lock Locking Handlebar Joint (36) to Handlebar Joint (7) with Inner Hex Bolt M6×10 (17), then put on Screw
Cap (37) (NOTE: make sure Handlebar Joint (7) is locked tightly before exercise).
2. Lock Lower glide cap (33) tightly to lower slider of Handlebar Post (2) with Cross pan head screw M4×10 (12).

10
9
STEP 6
Connect well Extension wire 1 (47) with Extension wire 2 (48), and then lock Connecting tube (50) tightly to
Handlebar joint (7) with Square neck bolt (42), Flat washer (49) and Nylon nut (54).
Draw out Extension wire 2 (48) from Computer bracket (51), and them lock Computer bracket (51) to Connecting
tube (50).

11
10
Step 7
Connect extension wire 2 (48) with Display screen (52),, and then lock Display
screen (52) to Computer bracket (51) with Screw (53).

12
2023/8/7P1/20
DISPLAY
1. POWER ON ( Home page):
2. Function Spec Description:
A. MY TRAINING：Displays total motion data
B. GET STARTED：
QUICK START / INTERVAL / MAP YOUR ROUTE /Constant Power/Program/Heart rate Control
Total six modes of exercise for choose
C. System Setting ：This page can operate login account/home page/historical data/new linked
account/Settings and other functions
D. Volume control:
E. Brightness adjustment function:
F. Time zone selection :
G.WIFI setting function :
H. Bluetooth heartbeat matching function:
I. Fan adjustment function：OFF/High/medium /low grade(依照製單是否要刪除)
J. Multimedia mode :
NETLIX、YOUTUBE、SPOTIFY、KINOMAP、CHROME、FACEBOOK、TWITTER、INSTAGRAM、
AMAZON PRIME VIDEO、AMAZON SHOPPING PS.Multimedia APP will be optimized for replacement
according to availability.

13
2023/8/7P2/20
Data&time setting
WIFI setting
BT PULSE

14
2023/8/7P3/20
3. Display Range ：
：
ITEM Description
DISTANCE ‧Display the movement distance
‧Display value range 0.0 ~ 99.9 in Cycle
SPEED ‧Display the movement speed
‧Display Value range 0.0 ~ 99.9
RPM ‧Display RPM
‧Value range 0 ~ 999
TIME ‧Display the movement time
‧Display value range 0:00 ~ 99:59 in Cycle
Heart Rate ‧Display the movement heart rate.
‧Value range 0 ~ 230
HR Zone ‧Display the movement HR Zone.
‧Value range 0% ~ 100%
BAI ‧Display the consumption BAI value during the exercise.
‧Value range 0 ~ 999
WATT ‧Display the movement power consumption
‧Display range 0~999
4. Button Function :
START/PAUSE：
：
When in starting status press this key ,it will stop training, and when in stopping mode press
this key it will start to work .
STOP：Press this key stop training.
UP：
：
Press this key to increase the load level
DOWN：
：
Press this key to decrease the load level
FAN：
：
control the FAN force: OFF , high speed , mediate speed , low speed . (依照製單是否刪除)

15
2023/8/7P4/20
5. SYSTEM SETTING OPERATION :
A. LOGO IN: ( photo) Personal information login and create, login account
(Email application, FB , We Chat , GOOGLE login)
B . HOME: Back to home page
C.TRAINING HISTORY: Exercise information enquiry (login required)
D. SETTING: Setting mode
A. Click Logo in (photo) to login the account , select face book /GOOGLE/ We Chat / / enter the email
password to log IN.

16
2023/8/7P5/20
GOOGLE /FACEBOOK/WECHAT
CREATE ACCOUNT

17
2023/8/7P6/20
B. TRAINING HISTORY
C
C
.
.
S
S
E
E
T
T
T
T
I
I
N
N
G
G
:
:

18
2023/8/7P7/20
Click SYSTEM SETTINGS to enter into system setting (wifi brightness ,volume ,BT, Language ,KM/ML)
a.Brightness
b.Volume

19
2023/8/7P8/20
c.WIFI
d. bluetooth device

20
2023/8/7P9/20
e. language
f.Distance Unit
