Dokki CLK-4 User manual

Quick Reference Guide CLK-4 DOKKi.eu
Legal Notices
This manual and an examples contained herein are provided "as is". JNC makes no warrant of an kind with regard to this manual,
including, but not limited to, the implied warranties of merchantabilit , non-infringement and fitness for a particular purpose. JNC shall
not be liable for an errors or for incidental or consequential damages in connection with the furnishing, performance, or use of this
manual or the examples contained herein.
Reproduction, adaptation or translation of this manual is prohibited without prior written permission of JNC Service B.V.
CAUTION: This Quick Reference Guide ma be revised or withdrawn at an time without prior notice.
This document provides basic usage instructions and information on setting up our DOKKi docking station.
UNPACKING
Do NOT use a knife to open the package or contents as this ma result in damage to the product(s)
Open the outer box on the top-side. Take the CLK-4 from it's box and remove the bubble-foil.
BOX CONTENTS
•CLK-4 docking station
•Power Suppl
•USB cable
Promotional items aren't listed here.
The CLK-4 will fit Opticon scanner models OPH-3000 and CLK-3000 (also known as 'Opticon SMART').
The insertion area is as tight as possible to ensure stabilit for the scanner. This also means that the scanner won't fit
when used in combination with an available sleeve or case (rubber, leather, etc.).
B removing the USB cover from the scanner dust and/or moist can penetrate the connector and opening(s) behind
the USB cover more easil . It is possible that the products' IP rating has been altered too.
Removing an original part from the scanner could void warrant . Doing so is at our own risk!
Before inserting an scanner in the dock be sure to remove the USB cover
(see the above note).
Save the USB cover in case it's needed at a later stage.
DOKKi.eu is a trademark of JNC Service B.V. ('JNC'). Cop right JNC Service B.V. All rights reserved.
CLK-4_QRG-001 / August 2014
DOKKi CLK-4

Quick Reference Guide CLK-4 DOKKi.eu
POSITIONING
The CLK-4 has rubber feet on the bottom and can be used on a flat surface. Please make sure the CLK-4 is positioned on a flat surface
which is level.
POWER AND CONNECTION
Plug the power adapter cable into the wall outlet
and the other end of the connector in the back
power connection of the CLK-4.
The CLK-4 is now read for use.
CLK-4 USAGE SAMPLES
•CHARGE ONLY
You can use the CLK-4 as a 'charge onl dock'.
•COMMUNICATION AND CHARGING (MIXED)
You can also connect our terminal to the PC using the CLK-4. For this connect the CLK-4 with an appropriate USB cable to a
PC. Be aware that the cradle itself doesn't create it's own random Virtual Com Port (VCP)! (*1)
DRIVER INSTALLATION FOR COMMUNICATION WITH PC – depending on usage
The DOKKi.eu CLK-4 docking station itself does not need a separate driver. The onl driver that needs to be installed on our
PC is the appropriate driver for our scanner model and designated t pe of usage. If not alread done so, please follow the
instructions for driver installation in the corresponding manual that belongs to our scanner model.
(*1) When used in Mass Storage Device mode no driver installation is necessar .
DOCKING YOUR SCANNER
Take the scanner in our hand with the displa up and facing towards ourself. Hold it
with the front side at the same angle as the front-plate of the CLK-4. Make sure the
handstrap points to the right so it can slide through the right side opening. Now put the
backside (at batter height) against the back-plate of the CLK-4 and let the scanner slide
down towards the USB connector. Make sure ou feel the USB connectors make proper
contact and then gentl press the scanner down into its place.
Press firml but never use excessive force when pressing down as this
might damage the connectors!
Alwa s check for obstructions on both connectors before tr ing to
dock the scanner.
ACCESSORIES
•none at the moment
Check for available accessories on our website.
DOKKi.eu is a trademark of JNC Service B.V. ('JNC'). Cop right JNC Service B.V. All rights reserved.
CLK-4_QRG-001 / August 2014
CLK-4 back

Quick Reference Guide CLK-4 DOKKi.eu
TROUBLESHOOTING
If ou are experiencing an problem with the CLK-4 the first thing to check is if the scanner operates correctl when connected directl
to the PC with an USB cable. Do so b plugging the USB cable that came with our scanner into our scanner and make sure the other
end of the USB cable goes directl into the PC (b passing an present HUB).
If it does function properl continue at the check-list below, otherwise the problem is with our scanner itself, the USB cable or the PC
(USB port and/or driver(s)).
Checklist
No power *1 -Is the scanner firml pressed into the docking station?
-Are the cables working and properl connected?
-Is the PC switched on?
No communication *1 -Is the scanner full charged?
-Are the necessar scanner drivers properl installed?
-Do the communication settings match between scanner and the PC?
-Are there no other programs polling on the same COM-port?
*1 and if connected to a
powered USB hub
-Is the power-suppl of the USB hub plugged in?
-Is one port on the USB hub failing, or are all ports fault ?
-Is the USB cable securel fitted on both ends?
Please contact our dealer if ou have an questions regarding the use of the DOKKi.eu docking station.
BY OPENING THE PACKAGE OF THIS PRODUCT YOU AGREE TO BECOME BOUND
BY THE LIABILITY AND WARRANTY CONDITIONS.
Limited Warrant , Liabilit and Disclaimers
This Limited Warrant and Disclaimer extends onl to products purchased directl from DOKKi.eu or a DOKKi.eu Authorized Dealer as
stated on our website (http://www.dokki.eu/dealers).
Under no circumstance JNC will be liable for an direct, indirect, incidental, special, consequential, punitive, or exemplar
damages, including but not limited to, damages for loss of profits, revenue, income, goodwill, use, data, or other intangible losses that
arise from use or inabilit to use the CLK-4, even if JNC has been informed about the possibilit of such damages.
The DOKKi.eu CLK-4 is warranted for a period of one ear after purchase, covering defects in material and workmanship. JNC will
repair or, at its opinion, replace products that prove to be defective in material or workmanship under proper use during the warrant
period. The warrant does not appl to defects resulting from (a) improper or inadequate maintenance measures taken; (b) interfacing
parts or supplies not supplied or authorised b JNC; (c) unauthorized modification or misuse; (d) operation outside the applicable
environmental parameter limits specified for the product; or (e) improper site preparation or maintenance for installation.
Outside The Netherlands, return the product to our dealer. Follow the instructions provided b our dealer.
DOKKi.eu is a trademark of JNC Service B.V. ('JNC'). Cop right JNC Service B.V. All rights reserved.
CLK-4_QRG-001 / August 2014
