Dolphin WAVE User manual

I
Table of Contents
SAFETY PRECAUTIONS .....................................................................................................................II
GENERAL NOTES.................................................................................................................................II
INTRODUCTION ....................................................................................................................................1
DOLPHIN WAVE CADDY ASSEMBLY .............................................................................................1
ASSEMBLY INSTRUCTIONS......................................................................................................................1
FIRST POOL CLEANING SESSION ...................................................................................................3
STARTING THE FIRST CLEANING SESSION..............................................................................................3
EVERYDAY OPERATION....................................................................................................................5
MANUAL STOP CONTROL .......................................................................................................................6
CUSTOMIZED SETTINGS....................................................................................................................7
MMI OPERATIONS..................................................................................................................................7
MAIN MENU PARAMETERS.....................................................................................................................9
CONFIGURING ADDITIONAL POOL PROFILES..........................................................................9
MANUAL PROCEDURE FOR CONFIGURING POOL PROFILES..................................................................11
STARTING CLEANING OPERATIONS......................................................................................................13
MANUAL DIRECTION SETUP.................................................................................................................13
OPERATING GUIDELINES................................................................................................................14
MAINTENANCE .....................................................................................................................................14
REMOTE CONTROL UNIT................................................................................................................15
TROUBLESHOOTING.........................................................................................................................17

II
Safety Precautions
Please adhere strictly to the following warnings:
Do not operate the Dolphin Wave Robot Pool Cleaner when
there are people in the swimming pool.
When examining the Dolphin Wave Robot Pool Cleaner,
disconnect the main power supply.
Please ensure that the following precautions are implemented:
Only a trained operator should operate the Dolphin Wave Robot
Pool Cleaner.
Operator should keep hands away from driving belt mechanism
The Dolphin Wave Robot Pool Cleaner should not be operated
out of the pool at distance of more than 3 meters from pool's
edge.
Keep the Dolphin Wave Robot Pool Cleaner out of the reach of
children.
Only an original power cable must be used, at all times. Replaced
by a Dolphin Wave Robot Pool Cleaner certified technician, in
case of need.
When lifting the Dolphin Wave Robot Pool Cleaner, take care
to prevent back injury.
General Notes
•In this user manual, the instruction press "Start" is performed by pressing
both green buttons - - simultaneously on the MMI (Figure 2).
•The MMI is equipped with a screensaver that comes into effect after
5 minutes idle time. Press Pool and Home in that order to unlock the MMI
console.

1
Introduction
This user guide describes how to use your MMI operating console for the
Dolphin Wave robotic pool cleaner. The interactive, state of the art MMI
control console enables full control of the robot and allows you to determine
the cycle time, operation delay, and cleaning scan that the robot performs. It
also enables diagnosis of various technical functions and parameters. The
console houses a remote control unit for manual operation and temporarily
overriding automatic cleaning operations.
The Dolphin Wave is designed to handle four different swimming pool
configurations and when these are set, the pool configurations are stored in the
MMI's memory. The robot is preset in the factory with specific default pool
settings, which can be reset. Please refer to the first Main Menu screen,
Figure 7 and Customized Settings, SDJH.
Dolphin Wave Caddy Assembly
Carefully remove all the items from the shipping box and check them against
the packing list.
You should have:
•Documentation and accessories
•Un-assembled caddy for storing and carrying the Dolphin Wave robot
•MMI console
•Dolphin Wave robot and floating cable
•Filter Bags - 2 disposable bags assembled in the Wave robot, 2 permanent
filter bags, 20 additional disposable bags
•Power supply unit
Assembly instructions
Refer to Figure 1.
1. Attach the caddy handle to the caddy base and fasten with the screws
and nuts provided.
2. Place the Dolphin Wave robot on the caddy in front of the power
supply as shown in Figure 1.
3. Place the coiled Dolphin Wave's power cable on the caddy's cable
support bracket and remove the binding sticker.
4. Connect the MMI communication's cable to the power supply unit.
5. Connect the Dolphin Wave floating cable to the power supply.
Tighten the connecting adaptor firmly to ensure proper electrical
connectivity.

2
Figure 1: The Dolphin Wave
Disposable filter bags should be kept in a dark place - avoid
exposure to direct sun light
MMI communications cable
Cable holder
Floating cable
Floating cable handle
Power supply
Impeller cover
MMI communications cable
Wave Power supply
Floating cable
Connected to Wave Power
supply
Mail Power supply Cable

3
First Pool Cleaning Session
This section explains how to proceed with the first cleaning session. The robot
is preset in the factory with certain configurations that enable you to
commence pool cleaning immediately. The settings made during this setup
session remain in use until changed by the operator.
Figure 2: The MMI Dolphin Wave Console
To start a pool cleaning session directly after you have assembled
your Dolphin Wave, proceed as follows:
1. Lift the MMI's protective cover.
2. Connect the Wave power supply to the main power supply line.
3. Switch on the power supply. The MMI Wave screen opens in the home
window.
4. Position the caddy with robot about 0.5–1.0 meter from the pool edge
with its sloping edge facing the swimming pool ensuring that the
floating cable is facing the direction of the Dolphin Wave power
supply unit.
5. According to the pool's size, release the appropriate length of cable.
Starting the First Cleaning Session
1. On the MMI press POOL. The robot starts moving towards the pool
and enters the swimming pool positioning itself on the pool floor.
2. Wait for the WAVE screen to appear.
3. Press Start. "Please select pool length" displays on the screen.
After 2 seconds the Pool Length Set Up screen appears.
Remote Unit Wave Home Screen Keyboard Buttons

4
Figure 3: Pool Length Set Up
4. Using the arrows,, select the required pool length. Press Set.
5.TheAlign Robot to Pool Width screen displays.
6. Using the floating cable, move the robot so that it is parallel to the
width of the pool with the cable behind it.
7. Press Start. The MMI screen displays "Direction setup please wait".
The robot moves forward slowly for 20 seconds and stops.
The screen displays "Direction setup completed".
8. Press Start. The cleaning session starts. Factory default settings are
used. In order to change parameters refer to Configuring Additional
Pool Profiles on page 9.
The robot starts its cleaning cycle and the MMI displays the
Countdown screen (Figure 4):
Figure 4: Countdown screen for 3 hour session
The countdown screen shows that a 3 hour cycle time was selected and
that the time remaining is 2 hours, 59 minutes and 59 seconds.
At the end of the cleaning session, the robot stops automatically.
To remove the robot from the pool, proceed as explained in Removing
the Robot from the Swimming Pool on page 5.
3hr - cycle
lock stop
hh:mm:ss
Default cleaning
02:59:59
Pool Length Set Up
25 30 35 40 50 60
Set  back

5
Everyday Operation
After you have set up the Dolphin Wave and configured it for the first time,
the device is set for everyday operation. When performing your next cleaning
session, proceed as follows:
1. Position the caddy about 0.5–1.0 meter from the pool edge with its
front sloping edge facing the swimming pool and the floating cable
pointing in the direction of the Dolphin Wave power supply unit.
2. Press Pool on the MMI. The robot starts moving towards the pool and
enters the swimming pool positioning itself on the pool floor.
3. Wait for the Wave screen to display on the MMI.
4. To start the robot, press Start on the MMI. The robot starts its cleaning
cycle and the Countdown screen displays:
Figure 5: Countdown screen
To avoid unauthorized changes to the MMI settings you can lock the
MMi's keyboard:
From the countdown screen, press Lock (Figure 5).
To unlock the keyboard, press POOL and then HOME in that order.
At the end of the cleaning session, the robot stops automatically.
Removing the Robot from the Swimming Pool:
1. Press HOME.
The robot starts moving in the direction of the floating cable.
2. Holding the floating cable, gently pull the robot upwards and towards
the caddy. As it reaches the side of the pool, pull the cable gently until
the floating cable handle emerges. Grasp the handle, tilting the robot
slightly allowing water to drain, place by the pool side, or guide it onto
the caddy. The robot shuts down automatically.
3hr - cycle
lock stop
hh:mm:ss
Default cleaning
02:59:59

Manual Stop
Exit
Completed Time 01:20
Toal Hours
Filter Bag Clean
6
If necessary, you can stop the robot during the cleaning session.
1. From the countdown screen (Figure 4), press Stop. The MMI screen
displays the message: "Stopping robot – please wait".
After 5 seconds the Manual Stop screen is displayed (Figure 6).
Figure 6: Manual Stop screen
2. To stop the cleaning session completely, press Exit. The MMI display
returns to the Wave screen.
Manual Stop Control

7
Customized Settings
The Dolphin Wave robot is controlled from the MMI console. You can
customize the robot's settings to match the specific type of swimming pool that
is to be cleaned. Four different swimming pool configurations can be set and
stored in the MMI's memory for future use.
When you configure the pool profile, you can also set the cleaning-cycle time
and the delay time before the robot starts its cleaning cycle. The procedure for
configuring additional pool profiles is explained in Configuring Additional
Pool Profiles on page 9.
The MMI keyboard procedures are explained in the next section.
MMI Operations
Use the control buttons, , located on the MMI below the screen,
to activate the various commands.
Use the MMI functions that appear in the various screen displays to navigate
between the screens and to configure the software.
MMI Functions:
Command Description
Menu From the opening screen press Menu to
display the Main Menu.
ŸScroll up.
źScroll down.
Start Press both green buttons simultaneously to
Start pool cleaning.
Select Press Select to confirm your selection after
using the scrolling buttons.
Modify Press Modify to change settings after making
a selection.
Back Press to return to the previous screen.
Exit Press to return to the Wave screen.
Defining the robot's parameters:
1. Switch on the power supply. The MMI Wave screen opens in the home
window.
2. Press Menu to enter the Main Menu (Figure 7).

Main Menu
Select cdExit
Pool Profile
Filter Sate Clean
Eror Report
Statistics
Main Menu
Select cdExit
Clock Setup
Date Setup
Technician Mode
LanguDJH English
8
Figure 7: Main Menu
There are two Main Menu screens and you access the second screen by
pressing the scroll down arrow, ź.
After "Statistics", scroll down to the second Main Menu screen (Figure 8).
Fig

ure 8: Second Main Menu screen

9
Main Menu Parameters
The Main Menu and the parameters are explained in the table below:
Parameter Description
Pool Profile Press Select to go to the Pool Profile screen.
Selecting Pool Profile opens the Pool Profile
screen for four different pool types. Pool A is
the default setting.
Filter State Reports on the filter’s condition.
•Clean: Filter bag is ready for use
•Full: Change/clean filter bag
The FILTER BAG warning light on the
console will also indicate that the filter bag
needs cleaning/replacing.
Error Report Displays information for Service Technician.
Statistics Press Select to review data on robot usage.
Second Main Menu screen parameters:
Parameter Description
Clock Setup Press Select to enter Clock Setup screen and
12/24 hour mode.
Date Setup Date setup screen.
Technician Mode Technician screen with restricted access.
Language Language interface mode.
Configuring Additional Pool Profiles
As noted previously, the Dolphin Wave can be configured for four different
pool types. The configured settings are stored in the MMI's memory. This
section describes how to configure additional pool settings.
To add a new pool configuration, proceed as follows:
1. Go to the Wave screen. "Pool A" is displayed as the currently defined
setting as shown in Figure 9.

10
Figure 9: Wave screen showing Pool A as default setting
2. From the Wave screen, press Pool A. The Pool Profile screen opens
(Figure 10).
Figure 10: Pool Profile screen
3. To select a second pool profile, scroll down to Pool B and press Select.
The Wave screen automatically displays showing that Pool B is the
currently defined pool.
4. To configure Pools B, C and D, go to Step 1 of Starting the First
Cleaning Session, page 3.
To go to a previously defined pool setting:
1. From the Wave screen, press the currently displayed pool setting at the
right side of the screen (see Figure 9) to open the Pool Profile screen.
2. Scroll to the required pool and press Select. The Wave screen is
displayed with the chosen pool setting.
Select Pool Profile
select cb
exit
Pool A
Pool D
Pool C
Pool B
Menu Start Pool A

11
Manual Procedure for Configuring Pool Profiles
1. From the Wave logo menu, press Menu.
2. From the Main Menu, with Pool Profile highlighted, press Select and
then modify, to display the current active profile screen.
3. Press Select to enter the Pool Length Setup screen.
Figure 11: Pool Length Setup screen
4. Using the Select and Scrolling buttons Ÿź, set each parameter in turn,
for example:
5. With Pool Length highlighted, press Select.The Pool Length Set Up
screen is displayed:
Figure 12: Pool length setup screen
6. Using the arrows,, select the desired pool length. Press Select and
scroll down to the next parameter, Cycle Time.
Cycle Time determines the duration of each cleaning cycle.
Pool A Profile
select cb
back
Pool Length
Scanning Path
Navigation Mode
Cycle Time
25 m
Defaul
t
Rec. 1
3 h
Pool Length Set Up
25 30 35 40 50 60
set _`back

12
7. Set each parameter and then scroll down to the next line.
8. Set Navigation Mode and choose either Rectangular 1 (Default),
Rectangular 2, or Shaped.
Rectangular 1- Recommended for pools with parallel walls, and 90º 'L'
shape.
Rectangular 2- as above, in case magnetic interference that cause
curved motion.
Shaped- Recommended for free formed pools.
9. Set Scanning Path and choose either Default,Lines to Right, or Lines
to Left.
Default- Recommended.
Lines to Right / Left- To be used in cases when the pool scan needs to
be limited to one direction or split into two sections.
In order to use this mode, consult your dealer.
10. After setting the Scanning Path, from the Pool Profile screen, scroll
down to the next screen to "Direction Setup" (Figure 13).
Figure 13: Second pool profile screen
11. Press Select to enter Direction Setup.
12. To change the Direction Setup, proceed as explained in Manual
Direction Setup, below.
13. Press Select to enter Delay Time.
Setting a Delay Time allows you to delay the start of cleaning
operations by a time factor selected from the MMI screen.
To override the Delay Time instruction, from the Wave screen press
Start.
Pool A Profile
select cb
back
Direction Setup
Reset Pool A profile
Line Spacing
Delay Time
180.0
Medium
0h

13
14. Line Spacing- used only when Lines to Right / Left scanning path is
used, in order to optimize scanning. Choose Fine / Medium / Coarse to
set the distance between lines.
15. Reset Pool Profile- Allows to delete all current pool profile parameters.
(Pool Length, Cycle Time, Navigation Mode, Delay time…)
During parameter setting operations:
•Press Back to return to the previous screen
•Press HOME on the console, to return to the Wave screen
Starting Cleaning Operations
Once all the customized settings have been configured, you can proceed to a
cleaning session:
1. Prepare the Dolphin Wave for operation and immersion into the pool.
2. Proceed as in Everyday Operation, page 5.
If a Delay Time has been set (see Configuring the Dolphin Wave, above), the
countdown commences and the time remaining before automatic cleaning
starts is displayed on the screen.
If no delay time is specified, the robot commences cleaning immediately.
Once cleaning operations have started, the MMI screen displays the
countdown time as in Figure 5, above.
To override the delay time and commence cleaning immediately, press
Start. The robot starts working immediately.
Manual Direction Setup
After the cleaning cycle has started, you might find it necessary to set the
robot's direction more precisely.
This can be performed in 2 ways:
a) Using Direction Setup – from pool profile. Press start and go through
similar procedure as described in Starting the First Cleaning Session, line No.
5, page 4.
b) Using the Direction Setup procedure while the robot is in the pool, as
described below.
Direction Setup:
1. From the Countdown screen press Stop. (If the robot is during cleaning
cycle)
If the screensaver is displayed, press POOL and then HOME to unlock
the MMI.
2. Navigate to the Pool Profile screen and select Direction Setup and
then Fine Tuning.
3. Press Start. The robot starts moving along the width of the pool.

14
4. From the MMI, press "+" or "-" to correct the robot's direction until it
moves exactly along the width of the pool.
"+" = clockwise direction
"-" = counter clockwise direction
5. Once the desired width direction is achieved, press Next.
6. The Robot will turn 90 degrees to the left and move along the length of
the pool.
7. Next, fine tune along the pool's length using "+" or "-", as in step 2
until the robot moves along the pool's length.
8. Once the desired direction is reached, press Next to confirm the end of
the fine tuning procedure.
9. Press HOME to return to the Wave screen and then press Start to
continue the cleaning session.
Operating Guidelines
•A large-sized swimming pool of approximately 300 square meters requires
approximately 2–3 hours cleaning time. This is the default setting.
•An Olympic size pool of 1,250 square meters requires approximately 5
hours cleaning time. This is the default setting.
Maintenance
1. Clean and replace filter as needed. When the MMI displays "Filter Bag
Full", you should clean/replace the bag before the next operating cycle.
It is not necessary to stop the Wave in the middle of the cycle when
"Filter Full" indication appears. Clean the filter before the next
cycle.
Non-disposable filter bags can be cleaned in a washing machine.
Under normal working conditions, disposable bags may be used for
about 3 cleaning cycles.
2. Before each operating cycle, clean the robot body, brushes, and driving
belt area and remove foreign objects, rubber bands, hair etc.
3. Once a week clean impeller area:
•Remove the impeller cover securing screw using a No. 2 Philips screw
driver.
•Twist counter-clockwise and open the cylinder cover.
•Remove foreign objects from the impeller.
•Close the impeller cover and replace the securing screw.
4. Keep the electrical cable orderly enabling it to be rolled up easily and
placed on the caddy's handle.
Important: Every two or three cleaning sessions, disconnect the main

15
power supply, unroll the entire cable and re-arrange it on the caddy
handle as required.
5. Preventive Maintenance (PM): should be performed on the Wave robot
pool cleaner, in order to keep it in good and long lasting working
condition. MAYTRONICS provides the parts required – as a dedicated PM
kit. The work and the service will be provided through the dealer. PM
service should be performed every 1,500 working hours or 1 year (the
earlier of the two).
6. A warning message to perform PM will appear on the MMI screen, when
applicable. It is obligatory that PM service will be performed. Please
contact your dealer. Failure to perform the PM service will void the
warranty.
Remote Control Unit
The remote control unit (RCU) is located on the MMI console and held in
position by a magnet. Pull it upwards gently to remove it from its base. When
the robot is in automatic operation, use the remote control to override the
robot’s programmed direction settings.
When the robot is moving in a forward direction, the floating cable
follows the robot from its tail end.
The remote unit has a control range of 50 meters from the Caddy.
Figure 14: Remote Control Unit
Using the Remote Unit:
1. To activate the remote unit, press the touch pad as indicated in the
diagram. Four activation lights are illuminated.
Forward
On-the
spot
turning
Reverse
Touch
pad
On/Off
switch

16
2. Press the forward arrow briefly. The robot commences moving in a
forward direction.
To stop the forward movement, briefly press and release the forward
arrow.
3. Press the backward arrow briefly. The robot commences moving in a
backward direction.
To stop the reverse movement, briefly press and release the backward
arrow.
On-the-spot turns:
On-the-spot turns can be carried out while the robot is in motion or
executed when the robot stationary.
4. To turn the robot clockwise, press and hold down the right arrow. The
robot turns on-the spot.
Release the button to stop the robot from turning.
5. To turn the robot counter-clockwise, press and hold down the left
arrow.
Release the button to stop the robot from turning.
6. To deactivate the remote unit, press and hold down the touch pad. The
activation lights switch off.
The robot reverts to its programmed direction mode of cleaning after
the manual correction.
The remote unit deactivates automatically after approximately 3 minutes
and the indicator lights switch off.
Maintaining the remote unit:
The remote control unit is powered by two AAA batteries. It is splash-proof
and should not be immersed in water.
To replace the batteries, remove the four back-cover securing screws and
replace all the batteries with new battery cells.

17
Troubleshooting
Error Message Check Action to Take
Imp over load Is there dirt or other
foreign matter in the
impeller?
Unscrew the bolt that secures the protective
cover of the impeller. Turn it counter-
clockwise slightly, until it is released.
Remove any dirt around the impeller.
Replace the protective cover.
Imp over load Does the problem re-
occur on every
operation?
Contact the Maytronics dealer/distributor.
Imp under load Does the problem re-
occur on every
operation?
Contact the Maytronics dealer/distributor.
Drive over load Is there any interfering
dirt in the driving
belts, brushes, or drive
axles?
Remove any dirt or foreign bodies that might
have become entangled with the driving
belts, brushes, or drive axles.
Drive over load Does the problem re-
occur on every
operation?
Contact the Maytronics dealer/distributor.
Drive under load Does the problem re-
occur on every
operation?
Contact the Maytronics dealer/distributor.
DC input 1. Is there an
electrical short,
partial or complete
disconnection?
2. Is there a visible
rupture in the
floating cable?
Contact the Maytronics dealer/distributor.
Robot got stuck on
pool wall
1. Has the robot
stopped in a
vertical position of
more than 70º?
2. Has the robot stuck
on an obstacle?
Move the robot from its position and remove
the obstacle. Reactivate.
If this recurs, contact the Maytronics
dealer/distributor.
Out of water Was the robot operated
out of the water for an
extended time?
1. Check that the impeller is in order and
that its blades are not broken.
2. Reactivate. If this recurs, contact the
Maytronics dealer/distributor.
