Dorel Asia DA3350-SF User manual

SOFA Model No.:
DA3350-SF
UPC CODE:
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
___________________
DOREL ASIA
0-65857-16500-5
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

*
*
*
*
*
*
WARNING: Should this product become
damaged, and/or components are broken or
missing, DO NOT USE.
Dorel Asia warrants its product to be free from defects in material and workmanship and
agrees to remedy any such defect. This warranty covers 1 year from the date of original
purchase. This warranty is valid only upon presentation of proof of purchase. This is solely
limited to the repair or replacement of defective furniture components and no assembly labor is
included. This warranty does not apply to any product which has been improperly assembled,
subjected to misuse or abuse or which has been altered or repaired in any way. Any wearing,
tearing, fading or splitting of the leather is not covered under the warranty. This warranty gives
you specific legal rights and you may also have other rights which vary from State to State.
CARE AND CLEANING
Dust leather regularly with a clean, dry cloth to avoid soil build-up. A damp cloth may be used
occasionally to clean surface. Buff dry. Keep leather soft and supple by applying a leather care
product occasionally. Avoid contact with oil, furniture polish and varnish.
MAINTENANCE
Check bolts/screws periodically and tighten them if necessary.
LIMITED WARRANTY
Estimated assembly time: 15 minutes.
Montreal, Quebec
Canada H1G 3L1
E-MAIL: [email protected]
NOTES
Ensure all parts and components are present before beginning assembly.
Assemble on a soft, smooth surface to prevent damage to product finish.
DO NOT use power tools.
CAUTION: Adult assembly required.
Assembly and handling will require two people.
12345 Albert-Hudon Boulevard, Suite 100
You can also order parts by writing to the address listed below. Please include the product
model number, color and a detailed description of the part.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first!
CALL 1-800-295-1980
Customer Service Department No. 413

HARDWARE LIST
1 2 3
4
ALLEN KEY
1 PC
HEX SOCKET HEAD BOLT
FLAT WASHER
SPRING WASHER
8 PCS
8 PCS
8 PCS
SOFA
DA3350-SF
Ø5/16" X 45mm
Ø22 X 1.5mm
Ø12.5 X 1.2mm

PARTS LIST
A B C
D E F
G H
FOOT
SEAT CUSHION
3 PCS
4 PCS
4 PCS
PLASTIC WASHER
RIGHT ARM
1 PC
1 PC
FRONT PANEL
SEAT PANEL
1 PC
1 PC
SOFA BACK
LEFT ARM
1 PC
SOFA
DA3350-SF

STEP 1:
Place sofa back (A) on a clean surface. Lift the fabric lining underneath the sofa back (A).
Attach left arm (B) and right arm (C) to sofa back (A) with hex socket head bolts (1), flat
washers (2) and spring washers (3). Use Allen Key (4) to tighten the bolts.
SOFA
DA3350-SF
1
2
3
A
BC

STEP 2:
SOFA
DA3350-SF
Install hex socket head bolts (1), flat washers (2) and spring washers (3) into sofa arms (B &
C). DO NOT tighten the bolts. Leave them extended about half an inch (see photo below).
1
2
3
B
C
A
Bolts extended 1/2"

STEP 3:
SOFA
DA3350-SF
Hook front panel (D) to left arm (B) & right arm (C) as shown below. Push front panel (D)
with a downward force to lock it into place.
Secure front panel (D) to arms (B&C) by tightening the hex socket head bolts (1) with Allen
key (4).
D

STEP 4:
SOFA
DA3350-SF
Gently lay down the assembled unit on its sofa back (A). Attach feet (F) to the arms (B) & (C)
with plastic washers (H) by rotating clockwise.
F
H
B
C
A

STEP 5:
Turn the assembled unit upright. Place seat panel (E) on the assembled frame.
SOFA
DA3350-SF
E

STEP 6:
Place seat cushions (G) on the seat panel (E).
SOFA
DA3350-SF
G
E

That's it ! You've finished assembling your Sofa.
SOFA
DA3350-SF
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with other
products and/or products heavier than the maximum weights
indicated may result in instability or cause possible injury.
Dust leather regularly with a
clean, dry cloth to avoid
soil build-up. A damp
cloth may be used
occasionally to clean surface.
Buff dry. Keep leather soft
and supple by applying a
leather care
product occasionally.
Avoid contact with oil,
furniture polish and
varnish.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
NEED HELP!
CALL US FOR ASSISTANCE
1-800-295-1980
DO NOT RETURN PRODUCT TO STORE
E-MAIL:[e-mail]

MODEL #: DA3350-SF (Black)
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Customer Service Phone Number 1-800-295-1980
Customer Service Fax Number 514-353-7819
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity (Please be sure to list model number or SKN number):
Customer Service
Customer Service Representative Mailing Address:
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Email: [email protected]
