Dorel Asia TG3878 User manual

WINGBACK HEADBOARD WITH NAILHEADS Model No:
UPC CODE:
Lot number:
(TAKEN FROM CARTON)
_____________________________________
DOREL ASIA
TG3878
0-65857-15970-7
DPCI#:
242-19-1185
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]

*
*
* Read all instructions before use.
*
*
*
*
* The bed frame is not included and must be purchased separately.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service
representative first! CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the product model
number, color and a detailed description of the part.
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada H1G 3L1
E-MAIL: [email protected]
NOTES
Ensure all parts and components are present before beginning assembly.
Assemble on a soft, smooth surface to prevent damage to product finish.
DO NOT use power tools.
CAUTION: Adult assembly required.
Assembly and handling will require two people.
Estimated assembly time: 10 minutes.
LIMITED WARRANTY
Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to
remedy any such defect. This warranty covers 1 year from the date of original purchase. This
warranty is valid only upon presentation of proof of purchase. This is solely limited to the repair or
replacement of defective furniture components and no assembly labor is included. This warranty
does not apply to any product which has been improperly assembled, subjected to misuse or abuse or
which has been altered or repaired in any way. Any wearing, tearing or fading of the fabric is not
covered under the warranty. This warranty gives you specific legal rights and you may also have
other rights which vary from State to State.
WARNING: Should this product become
damaged, and/or components are broken or
missing, DO NOT USE.
CARE AND CLEANING
Dust regularly with a soft, dry cloth to prevent soil build up. Wipe away spills immediately to prevent
staining. Use a cloth dampened with water or a professional product to clean the fabric. Always test
an inconspicuous area first. Allow upholstery to dry and brush lightly. Keep away from heat to avoid
glazing, melting or scorching.
MAINTENANCE
Check bolts/screws periodically and tighten them if necessary.

HARDWARE LIST
H1 H2 H3
H4 H5 H6
H7 H8 H9
H10 H11
WINGBACK HEADBOARD WITH NAILHEADS
TG3878
Ø5/16" X 50mm Ø19mm Ø12.5mm
HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER
6 PCS 10 PCS 10 PCS
Ø5/16" X 70mm Ø16mm Ø4mm
HEX SOCKET HEAD BOLT FLAT WASHER SCREW
4 PCS 4 PCS 4 PCS
Ø5/16" X 125mm Ø8mm Ø22mm
HEX SOCKET HEAD BOLT NUT FLAT WASHER
4 PCS 4 PCS 8 PCS
1 PC 1 PC
Ø5mm
ALLEN KEY WRENCH
- 1 -

PARTS LIST
AB
C
WINGBACK HEADBOARD WITH NAILHEADS
TG3878
HEADBOARD BODY HEADBOARD WING
1 PC 2 PCS
FOOT
4 PCS
- 2 -

STEP 1:
Place all parts on a clean, smooth surface.
Pull back the fabric lining underneath headboard body (A).
WINGBACK HEADBOARD WITH NAILHEADS
TG3878
Attach the headboard wings (B) to the headboard body (A) with flat washers (H2), spring
washers (H3) and hex socket head bolts (H1). Use Allen Key (H10) to tighten the bolts.
A
BB
H10 H1 H3
H2
- 3 -

STEP 2:
Attach the feet (C) to the headboard body (A) with flat washers (H2) and hex socket head
bolts (H4). Use Allen Key (H10) to tighten the bolts.
screwdriver (not included) to tighten the screws.
WINGBACK HEADBOARD WITH NAILHEADS
TG3878
Attach the feet (C) to the headboard wings (B) with flat washers (H5) and screws (H6). Use a
A
B
B
C
C
H10 H4 H2
H6 H5
- 4 -

For a Queen Size Bed,
attach the bed frame to the
outer holes.
For a Full Size Bed,
attach the bed frame to the
inner holes.
wrench (H11) to tighten the nuts.
NOTE: THE BED FRAME IS NOT INCLUDED AND MUST BE
PURCHASED SEPARATELY. THE FOLLOWING
ILLUSTRATIONS ARE FOR REFERENCE ONLY.
WINGBACK HEADBOARD WITH NAILHEADS
TG3878
Attach the bed frame (purchased separately) to bed posts using bolts (H7), spring washers (H3),
flat washers (H9) and nuts (H8). Use Allen Key (H10) to tighten bolts and use the open end
H11
H8 H9
H8
H7
H10
H9
- 5 -

That's it ! You've finished assembling your headboard.
WINGBACK HEADBOARD WITH NAILHEADS
TG3878
CAUTION: This unit is intended for use only with the
products and/or maximum weights indicated. Use with other
products and/or products heavier than the maximum weights
indicated may result in instability or cause possible injury.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: [phone]
E-Mail: [email protected]
Fax #: [phone]
Dust regularly with a
clean, dry cloth to avoid
soil build-up. A damp
cloth may be used
occasionally to clean
surface. Buff dry. Keep
leather soft and supple by
applying a leather care
product occasionally.
Avoid contact with oil,
furniture polish and
varnish.
- 6 -

MODEL #: TG3878
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING
NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S).
Customer Service Phone Number 1-800-295-1980
Customer Service Fax Number 514-353-7819
Request Date:
Name:
Shipping Address:
Street & Number:
City & State:
Zip Code:
Day Time Phone Number:
(including area code)
Date & Place of Purchase:
Part(s) description and quantity (Please be sure to list model number or SKN number):
Customer Service
Customer Service Representative Mailing Address:
Customer Service Department No. 413, 12345 Albert-Hudon Boulevard, Suite 100, Montreal, QC, Canada, H1G 3L1
Email: [email protected]
