dosatron D8 RANGE Operator's manual

QUICK START UP
CAUTION
- When connecting a DOSATRON either to the public water
supply or to its own water source, you must respect the
regulations in force concerning protection of the source i.e.
backflow prevention, etc.
- Contact local authorities for requirements of backflow
prevention.
- When installing, operating, and maintaining the DOSATRON
water powered metering pump, keep safety considerations
foremost. Use proper tools, protective clothings, and eye
protection when working on the equipment and install the
equipment with a view toward ensuring safe operation.
- Follow the instructions in the manual and take additional
safety measures appropriate to the liquid being pumped and
the temperature of the water that powers the DOSATRON.
Be extremely careful in the presence of hazardous
substances (e.g. corrosives, toxins, solvents, acids, caustic,
flammables, etc.).
- Before applying any aggressive chemicals, please consult
your distributor to confirm compatibility with the dosing
pump.
Hand tighten. No tools needed.
Congratulations on your new Dosatron.
Please read the following important information.
IMPORTANT NOTES
For complete information on the features and operations,
refer to your manual on www.dosatron.com
or download our DOSATRON app
or
NEED HELP ? Contact your DOSATRON distributor
for service or parts.
D8 RANGE
8 m3/h - 40 US GPM
ET283/Warning-D8-EN-US/11/15
8
m3/h
This document does not form a contractual engagement on the part of Dosatron International and is for
information only. Dosatron International reserves the right to alter product specification or appearance
without prior notice.
© DOSATRON INTERNATIONAL S.A.S 2012
CUSTOMER SERVICE - SERVICE CLIENTÈLE
(NORTH & CENTRAL AMERICA)
DOSATRON INTERNATIONAL INC.
2090 SUNNYDALE BLVD. CLEARWATER - FL 33765 - USA
Tel. [phone] - Fax [phone]
Site web: www.dosatronusa.com
www.dosatron.com
40 US GPM
DOSATRON INTERNATIONAL S.A.S. Certified QEH&S System
Rue Pascal - B.P. 6 - 33370 TRESSES (BORDEAUX) - FRANCE
Tel. [phone]
Fax. [phone]
[email protected] - www.dosatron.com
CUSTOMER SERVICE - SERVICE CLIENTÈLE (WORLDWIDE - EUROPE)
MANUFACTURED BY - FABRIQUÉ PAR :
RECOMMENDATIONS
DO NOT USE THIS UNIT WITHOUT A 60 MICRON
[300 MESH] WATER FILTER*
OR YOUR WARRANTY WILL BE VOID.
*The 60 micron [300 mesh] water lter (sold separately)
protects your unit from debris in the water that causes
scoring to the piston and housing.
KNOW YOUR WATER FLOW!
GRADUALLY TURN ON THE WATER.
COUNT THE NUMBER OF CLICKS IN
15 SECONDS. DO NOT EXCEED 40* CLICKS.
MAXIMUM PRESSURE 8 bar [110 PSI]
CLICK CHART
Clicks/15sec l/h GPM
4 820 3,6
8 1640 7,2
16 3280 14,5
32 6500 29
40 8000 36

8EQ001
(option)
Ø 16 Ø 20
w
a
t
e
r
f
o
w
Max.Torque 30 Nm thus 3 kg (1 N.m = 0,1 DaN.m)
Valve Check
valve
Filter
Filter :
60 microns [300 mesh]
Depending on your
water quality
Maximum: 40 clicks/15 sec.
NO !
When possible,
DO NOT PLACE
the container directly
under
the DOSATRON
BY PASS Option
Air-Bleed
Button
1
2
1 2
34
5
6 7
8 9
INSTALLATION
HINTS
Scan the QR-
code on the
dosing pump.
