dosatron HSPKD45 User manual

Part #: HSPKD45
MOUNTING INSTRUCTIONS
(Portable Fertilizer System ts 20 GPM Dosatron model.
Dosatron, Quick Hook-Up Kit and Cart sold separately.)
D45 Quick Hook-Up Kit

CHAT AT WWW.DOSATRONUSA.COM
Velcro Strap
6
NOTE: Do not over tighten parts onto the blue inlet and outlet of the unit.
Thread
Seal
Tape
5
INLETINLET
OUTLET
Swivel Adapter
3/4” FNPT to
3/4” Garden Hose
5
6
1” Elbow, FNPT to FNPT
Check Valve
3
3/4”
Reinforced
Hose
3
Clamp
6
1” to 3/4”
Barb MNPT
6
Clamp
6
Clamp
6
200 Mesh/80
Micron Filter
6
3/4” Street
Elbow FNPT
to MNPT
6
3/4” Barb
MNPT
6
Clamp
6
Barb 3/4”
MNPT
6
1” to 3/4”
Barb MNPT
6
3/4” FNPT
to 3/4”
Garden
Hose
5
Contents Shown Assembled (Dosatron unit sold separately)
4 - Stainless Steel Clamp 1 - 1” Street Elbow FNPT to MNPT
2 - 3/4” Reinforced Hose 2 - Barb Fittings 3/4” MNPT
1 - 1” Elbow FNPT to FNPT 3 - 3/4” Street Elbow FNPT to MNPT
2 - Barb Fittings 1” to 3/4” 1 - 3/4” FNPT to 3/4” Garden Hose
1 - 3/4” Close Nipple 1 - Swivel Adapter 3/4” FNPT to 3/4” Garden Hose
1 - 200 Mesh/80 Micron Filter 1 - Thread Seal Tape
1 - Check Valve 1 - Velcro Strap
Set of Bolts/Nuts
Bolts/
Nuts
5
3/4” Street
Elbow MNPT
to 3/4” FNPT
6
3/4” Close
Nipple
6

CHAT AT WWW.DOSATRONUSA.COM
Remove the 10 screws from the
back plate, to remove from the
back of the DosaCart.
1
Attach the 20 GPM Dosatron unit
bracket on the eyebolts, with the
two screws and two nylon locking
nuts provided in the hardware bag.
2
Attach the 200 mesh/80 micron lter
to the bottom left of the back of the plate.
3
Contents Shown Assembled (Dosatron unit sold separately)

CALL 1-800-523-8499 FOR SUPPORT CHAT AT WWW.DOSATRONUSA.COM
Using the instructions included,
assemble the Quick Hook-up kit with
the 20 GPM unit.
NOTE: Be cautious not to use excessive
force when attaching the ttings onto blue
housing of the unit
5
Attach the Dosatron unit and Quick
Hook-Up Kit assembly onto the
unit bracket.
6
Re-attach the black plate back onto
the DosaCart by installing eight
screws around the plate except for
the top two screws (these will be used
for the crash bar, see step 9).
4

CALL 1-800-523-8499 FOR SUPPORT CHAT AT WWW.DOSATRONUSA.COM
Secure the outgoing hose with a zip
tie to the eye hook.
Attach the crash bar into place using
the remaining two screws.
8
9
Insert the hose onto the lter barb
and secure with the clamp.
7
